Fuse Connector Module ZL-CM16TF2
Cables and PLC I/O Modules
PLC I/O Module TypeCable TypePLC Type
D3-16TD1-2
ZL-3CBL3FRD16 DL305
D4-16TAZL-4CBL2DL405
D4-16TD1
ZL-4CBL2DL405
Connector Module Type
ZL-CM16TF2
ZL-CM16TF2
ZL-CM16TF2
ZL-CM16TF2
WARNING : WIRE ONLY ACCORDING TO WIRING DIAGRAMS SHOWN BELOW TO
AVOID CAUSING DAMAGE TO THE PLC OR CONNECTOR MODULE. MATCH THE
CORRECT COMBINATION OF CABLE, PLC I/O MODULE, AND CONNECTOR MODULE AS SHOWN.
D4-16TD2ZL-4CBL2DL405 ZL-CM16TF2
- - -
Load 0
-
Load 1 Load 2
Load 15
Wiring Diagram Output
REMOVAL INSTALLATION
Fuse Installation And Removal
REV 1.1PAG. 1

Wiring Diagram power supply and cable
Wiring Diagram power supply and cable
ZL-CM16TF2
PLC DL 305 Type D3-16TD1-2
DC Output I/O Module
Cable ZL-2CBL2
Cable ZL-3CBL3FRD16
ZL-CM16TF2
+
-
Power supply
24V dc
+
-
I/O Module Output Octal Address 0 corresponds to FUSE 0
I/O Module Output Octal Address 1 corresponds to FUSE 1
I/O Module Output Octal Address 2 corresponds to FUSE 2
I/O Module Output Octal Address 3 corresponds to FUSE 3
I/O Module Output Octal Address 4 corresponds to FUSE 4
I/O Module Output Octal Address 5 corresponds to FUSE 5
I/O Module Output Octal Address 6 corresponds to FUSE 6
I/O Module Output Octal Address 7 corresponds to FUSE 7
I/O Module Output Octal Address 10 corresponds to FUSE 8
I/O Module Output Octal Address 11 corresponds to FUSE 9
I/O Module Output Octal Address 12 corresponds to FUSE 10
I/O Module Output Octal Address 13 corresponds to FUSE 11
I/O Module Output Octal Address 14 corresponds to FUSE 12
I/O Module Output Octal Address 15 corresponds to FUSE 13
I/O Module Output Octal Address 16 corresponds to FUSE 14
I/O Module Output Octal Address 17 corresponds to FUSE 15
I/O Module Common corresponds to FUSE FC
External power supply for
PLC I/O Module and load devices
External power supply for
PLC I/O Module and load devices
PLC DL 405 Type D4-16TA
AC Output I/O Module
Cable ZL-2CBL2
Cable ZL-4CBL2
ZL-CM16TF2
Auto power supply
to module PLC internal module
Auto power supply
to module PLC internal module
Vac
I/O Module Output Octal Adress 0 corresponds to FUSE 0
I/O Module Output Octal Adress 1 corresponds to FUSE 1
I/O Module Output Octal Adress 2 corresponds to FUSE 2
I/O Module Output Octal Adress 3 corresponds to FUSE 3
I/O Module Output Octal Adress 4 corresponds to FUSE 4
I/O Module Output Octal Adress 5 corresponds to FUSE 5
I/O Module Output Octal Adress 6 corresponds to FUSE 6
I/O Module Output Octal Adress 7 corresponds to FUSE 7
I/O Module Output Octal Adress 10 corresponds to FUSE 8
I/O Module Output Octal Adress 11 corresponds to FUSE 9
I/O Module Output Octal Adress 12 corresponds to FUSE 10
I/O Module Output Octal Adress 13 corresponds to FUSE 11
I/O Module Output Octal Adress 14 corresponds to FUSE 12
I/O Module Output Octal Adress 15 corresponds to FUSE 13
I/O Module Output Octal Adress 16 corresponds to FUSE 14
I/O Module Output Octal Adress 17 corresponds to FUSE 15
REV 1.1PAG. 2
I/O Module Common corresponds to FUSE FC

Wiring Diagram power supply and cable
Wiring Diagram power supply and cable
ZL-CM16TF2
PLC DL 405 Type D4-16TD1
DC Output I/O Module
Cable ZL-2CBL2
Cable ZL-4CBL2
ZL-CM16TF2
+
-
Power supply
24V dc
+
-
Auto power supply
to module PLC internal module
Auto power supply
to module PLC internal module
I/O Module Output Octal Adress 0 corresponds to FUSE 0
I/O Module Output Octal Adress 1 corresponds to FUSE 1
I/O Module Output Octal Adress 2 corresponds to FUSE 2
I/O Module Output Octal Adress 3 corresponds to FUSE 3
I/O Module Output Octal Adress 4 corresponds to FUSE 4
I/O Module Output Octal Adress 5 corresponds to FUSE 5
I/O Module Output Octal Adress 6 corresponds to FUSE 6
I/O Module Output Octal Adress 7 corresponds to FUSE 7
I/O Module Output Octal Adress 10 corresponds to FUSE 8
I/O Module Output Octal Adress 11 corresponds to FUSE 9
I/O Module Output Octal Adress 12 corresponds to FUSE 10
I/O Module Output Octal Adress 13 corresponds to FUSE 11
I/O Module Output Octal Adress 14 corresponds to FUSE 12
I/O Module Output Octal Adress 15 corresponds to FUSE 13
I/O Module Output Octal Adress 16 corresponds to FUSE 14
I/O Module Output Octal Adress 17 corresponds to FUSE 15
PLC DL 405 Type D4-16TD2
DC Output I/O Module
Cable ZL-2CBL2
Cable ZL-4CBL2
ZL-CM16TF2
+
-
Power supply
24V dc
-
+
Auto power supply
to module PLC internal module
Auto power supply
to module PLC internal module
INSERT
JUMPER
I/O Module Output Octal Adress 0 corresponds to FUSE 0
I/O Module Output Octal Adress 1 corresponds to FUSE 1
I/O Module Output Octal Adress 2 corresponds to FUSE 2
I/O Module Output Octal Adress 3 corresponds to FUSE 3
I/O Module Output Octal Adress 4 corresponds to FUSE 4
I/O Module Output Octal Adress 5 corresponds to FUSE 5
I/O Module Output Octal Adress 6 corresponds to FUSE 6
I/O Module Output Octal Adress 7 corresponds to FUSE 7
I/O Module Output Octal Adress 10 corresponds to FUSE 8
I/O Module Output Octal Adress 11 corresponds to FUSE 9
I/O Module Output Octal Adress 12 corresponds to FUSE 10
I/O Module Output Octal Adress 13 corresponds to FUSE 11
I/O Module Output Octal Adress 14 corresponds to FUSE 12
I/O Module Output Octal Adress 15 corresponds to FUSE 13
I/O Module Output Octal Adress 16 corresponds to FUSE 14
I/O Module Output Octal Adress 17 corresponds to FUSE 15
REV 1.1PAG. 3
I/O Module Common corresponds to FUSE FC
I/O Module Common corresponds to FUSE FC
