Automotive Data Solutions RSA-SUB2 User manual

INSTALL GUIDE
2017 SUBARU CROSSTREK PTS AUTOMATIC
DOCUMENT NUMBER
REVISION DATE
FIRMWARE
HARDWARE
ACCESSORIES
ATTENTION: TO COMPLETE THIS INSTALLATION SOME ACCESSORIES MAY BE
REQUIRED. VISIT OUR WEBSITE TO SEE ALL THE REQUIRED ACCESSORIES FOR
YOUR VEHICLE.
TERMS OF USE
Automotive Data Solutions Inc. (“ADS”) products are strictly intended for installation by Certified Technicians who are employed
by a registered business specialized in the installation of automotive aftermarket electronics products. Prior to beginning
installation of an ADS product in a vehicle, it is the Certified Technician’s responsibility to review the most current Product Guide,
Install Guide and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever, including but
not limited to any consequential damages, incidental damages, damages for loss of time, loss of earnings, loss of profit,
commercial loss, loss of economic opportunity and the like that may or may not have resulted from the use, misuse, improper
installation or operation of its products. ADS reserves itself the right to suspend any Weblink® account without notice and
decline to offer technical support to non-Certified Technicians, noncompliant Certified Technicians or end users.
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
A5E91E3
20220818_163900
RSA-SUB2
CMHCXA0

REMOTE START Supported
Data Immobilizer Bypass (no key required) ✓
Key Required for Immobilizer Bypass
Takeover Available ✓
No Takeover Available (shutdown on unlock or door open)
3x Lock Start from OEM Remotes ✓
Data / MUX Parking Light Control - Constant ✓
Data / MUX / Hazard Parking Light Control - Flashing
Tach Monitoring ✓
Hood Status
Brake Status ✓
E-Brake Status ✓
Glow Plug Status
RAP Shutdown ✓
KEYLESS ENTRY Supported
OEM Remotes Functional during RS ✓
OEM RFID Entry Sensors Functional during RS ✓
Door Lock ✓
Door Unlock ✓
Driver Door Priority Unlock
Trunk/Hatch Release
Power Liftgate
Power Sliding Door (L)
Power Sliding Door (R)
SECURITY SYSTEM Supported
Arm OEM Alarm ✓
Disarm OEM Alarm ✓
Aftermarket Alarm Control from OEM Remotes ✓
Aftermarket Alarm Control from OEM RFID Entry Sensors ✓
Door Status ✓
Trunk/Hatch Status ✓
COMFORT Supported
Rear Defrost Activation
Heated Mirror Activation
Heated Seat Activation
Cooled Seat Activation
Heated Steering Wheel Activation
FEATURE LIST - 1 OF 1 PAGE 2 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

3x RED LED flashes during module programming
If the module blinks 3 times red during learning (after KLON) an OEM remote starter is detected on the vehicle's CAN bus and must be disconnected before
the ADS bypass can be programmed to the vehicle.
Here is a link to help you disconnect the OEM Remote Starter.
http://12voltdata.com/ads/OEMRS/index.html
Scan for more information:
PLEASE READ THE INFORMATION BELOW PRIOR TO INSTALLATION
NOTES - 1 OF 1 PAGE 3 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

T003_W
HARDWIRE / COMPONENT LOCATOR - 1 OF 1
A
B
C
PAGE 4 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

!
16
4
789
19
123
2021
101112
222324
13
1415
252627
1718
28
5
6
2930
10111213141516171819
2021222324
252627
2829303132333435
1234567
89
12
75 4
6
17
18
38
1516 11121314
910
12
67
3
8
4
9 5
1
1
T003_W
CUT LOOP FOR AUTOMATIC TRANSMISSION ONLYCUT LOOP FOR AUTOMATIC TRANSMISSION ONLY
HARDWIRE / WIRING DIAGRAM - 1 OF 1
M5
M4
M2
M3
12V (+) RED - 06
STARTER (+) PINK - 07
PTS (-) BLACK - 30
IMMO. (DATA) RED/YELLOW
OR YELLOW - 25
HORN (-)
HOOD SWITCH
INSTALL THE SUPPLIED HOOD SWITCH IF
THE VEHICLE IS NOT EQUIPPED WITH ONE.
IGNITION 2 (+) LTBLUE - 09
ACCESSORY (+) BLUE - 04
IGNITION (+) PURPLE - 06
CANH (DATA) WHITE - 14
CANL (DATA) BLUE - 15
09 YELLOW09 YELLOW
14 ORANGE/WHITE - PTS (-) OUTPUT14 ORANGE/WHITE - PTS (-) OUTPUT
01 GRAY/BLACK•BLUE DOT - IGNITION (+) INPUT01 GRAY/BLACK•BLUE DOT - IGNITION (+) INPUT
05 GRAY•BLUE DOT - IGNITION (+) OUTPUT
05 GRAY•BLUE DOT - IGNITION (+) OUTPUT
04 GREEN/WHITE•BLACK DOT04 GREEN/WHITE•BLACK DOT
03 BROWN/RED - CANH 103 BROWN/RED - CANH 1
04 BROWN/YELLOW - CANL 104 BROWN/YELLOW - CANL 1
06 BLUE/WHITE•BLACK DOT06 BLUE/WHITE•BLACK DOT
08 WHITE/PURPLE•BLACK DOT
01 GREEN•BLACK DOT01 GREEN•BLACK DOT
02 BLUE•BLACK DOT02 BLUE•BLACK DOT
05 GREEN/BLACK•BLACK DOT05 GREEN/BLACK•BLACK DOT
07 EMPTY07 EMPTY
11 BROWN/BLACK•BLACK DOT11 BROWN/BLACK•BLACK DOT
12 WHITE•BLACK DOT12 WHITE•BLACK DOT
01 BROWN•SILVER DOT01 BROWN•SILVER DOT
02 BLACK/WHITE•SILVER DOT02 BLACK/WHITE•SILVER DOT
03 PURPLE•SILVER DOT03 PURPLE•SILVER DOT
04 GREEN•SILVER DOT04 GREEN•SILVER DOT
05 PURPLE/WHITE•SILVER DOT05 PURPLE/WHITE•SILVER DOT
06 WHITE/BLUE•SILVER DOT06 WHITE/BLUE•SILVER DOT
08 BLUE•SILVER DOT08 BLUE•SILVER DOT
09 GRAY/BLACK•SILVER DOT09 GRAY/BLACK•SILVER DOT
10 EMPTY10 EMPTY
01 EMPTY01 EMPTY
02 EMPTY02 EMPTY
05 BLUE/RED05 BLUE/RED
06 BLUE/YELLOW06 BLUE/YELLOW
07 EMPTY07 EMPTY
08 ORANGE08 ORANGE
10 EMPTY10 EMPTY
12 GRAY/YELLOW12 GRAY/YELLOW
16 ORANGE/BLACK - IMMO. (DATA) CONNECTOR SIDE16 ORANGE/BLACK - IMMO. (DATA) CONNECTOR SIDE
02 WHITE/BLACK•BLUE DOT - IMMO. (DATA) VEHICLE SIDE
02 WHITE/BLACK•BLUE DOT - IMMO. (DATA) VEHICLE SIDE
03 GRAY/RED•BLUE DOT03 GRAY/RED•BLUE DOT
04 WHITE/RED•BLUE DOT - IMMO. (DATA) CONNECTOR SIDE04 WHITE/RED•BLUE DOT - IMMO. (DATA) CONNECTOR SIDE
06 WHITE•BLUE DOT06 WHITE•BLUE DOT
09 PURPLE/BLACK•BLACK DOT09 PURPLE/BLACK•BLACK DOT
07 GRAY•SILVER DOT - HOOD (-) INPUT07 GRAY•SILVER DOT - HOOD (-) INPUT
10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT
11 GRAY/RED11 GRAY/RED
13 GREEN/RED13 GREEN/RED
ECU, BEHIND GLOVE BOX (B)
CERTIFICATION ECU, BEHIND DASH FUSE BOX (A)
1
2
1
1
2
1: WHITE
1: BROWN
BACKSIDE OF DASH FUSEBOX (C)
03 RED/WHITE•BLACK DOT03 RED/WHITE•BLACK DOT
15 BROWN - ACCESSORY (+)15 BROWN - ACCESSORY (+)
17 PINK - IGNITION (+) IN/OUT17 PINK - IGNITION (+) IN/OUT
18 PURPLE - STARTER (+) OUTPUT18 PURPLE - STARTER (+) OUTPUT
19 RED - 12V (+) INPUT19 RED - 12V (+) INPUT
20 BLACK - GROUND (-)20 BLACK - GROUND (-)
M1
01 ORANGE01 ORANGE
08 BLACK08 BLACK
06 WHITE06 WHITE
04 PINK/WHITE
02 RED02 RED
03 PURPLE03 PURPLE
05 PINK05 PINK
07 RED07 RED
!
M3
M1
M2 M5
M4
PAGE 5 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

01
02
ENGINE
START
STOP
STOP ACC ON START
ON
03
04
ENGINE
START
STOP
STOP ACC ON START
START
05
06
ENGINE
START
STOP
STOP ACC ON START
STOP
07
08
09
10
ENGINE
START
STOP
STOP ACC ON START
ON
11
12
ENGINE
START
STOP
STOP ACC ON START
START
13
14
ENGINE
START
STOP
STOP ACC ON START
STOP
15
ENGINE
START
STOP
STOP ACC ON START
START
16
17
18
MODULE PROGRAMMING PROCEDURE - 1 OF 2
When programming, only one keyfob will be
used. Place the other one at least 10 feet away
from the vehicle.
Set ignition to ON position.
Wait, LED 1 will turn solid RED.
Set ignition to START position. (Engine
running.)
Wait, LED 1 will flash GREEN rapidly.
Set ignition to OFF position.
WARNING: Disconnect power last. Disconnect
module from vehicle.
Connect module to computer and proceed
with extended programming.
Connect power first. Connect module to
vehicle.
Set ignition to ON position.
Wait, LED 1 will turn solid RED.
Set ignition to START position. (Engine
running.)
Wait, LED 1 will turn solid GREEN for 2
seconds.
Set ignition to OFF position.
START vehicle for 15 seconds.
Press and hold the brake pedal.
Press and release the module’s programming
button.
Release the brake pedal.
PAGE 6 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

19
20
MODULE PROGRAMMING PROCEDURE - 2 OF 2
Wait, LED 2 will flash GREEN.
Module Programming Procedure completed.
PAGE 7 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

>>
01
02
03
04
05
06
>>
TAKEOVER PROCEDURE - 1 OF 1
All vehicle doors must be closed and locked
prior to remote start sequence.
Time restriction. Complete steps 2 to 5 within
45 seconds.
Unlock driver door.
Open driver door and enter vehicle.
Close driver door.
Press and release BRAKE pedal.
Take over procedure completed.
Failure to follow procedure will result in
vehicle engine shutdown.
PAGE 8 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

MODULE CONNECTORS CONNECTOR PINOUT
7
9
3
10
8
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
4
5
3
2
1
6
4
2
8
1
3
5
7
6
M5
M4
M3
M2
M1
M5
M4
M3
M2
M1
MODULE LAYOUT - 1 OF 1
AUTOMATIC
TRANSMISSION
CUT LOOP
NC - 4 PIN RED
SMARTSTART - 4 PIN RED
TELEMATIC 1 - 4 PIN BLUE
3 PIN BLACK - TEMP. SENSOR
PROGRAMMING BUTTON
USB
LED 1 (BYPASS)
LED 2 (RS)
RF PORT/WEBLINK PORT - 4 PIN BLACK
FIRST GENERATION HCx [HCX-192]
M3 - 10 PIN WHITE
M2 - 12 PIN BLACK M5 - 6 PIN BLUE
M4 - 20 PIN BLACK
M1 - 8 PIN BLACK
TELEMATIC 1 - 4 PIN BLUE
PROGRAMMING BUTTON
USB
LED 1 (BYPASS)
LED 2 (RS)
RF PORT/WEBLINK PORT - 4 PIN BLACK
SECOND GENERATION HCx [HCA-320]
M3 - 10 PIN WHITE
M2 - 12 PIN BLACK M5 - 6 PIN BLUE
M4 - 20 PIN BLACK
M1 - 8 PIN BLACK
01 ORANGE - ACCESSORY (+)
01 ORANGE - ACCESSORY (+)
02 RED - POWER (30A)
02 RED - POWER (30A)
03 PURPLE - STARTER (+)03 PURPLE - STARTER (+)
04 PINK/WHITE - PROG. RELAY #4 - IGNITION 2 (+) (DEFAULT)04 PINK/WHITE - PROG. RELAY #4 - IGNITION 2 (+) (DEFAULT)
05 PINK - IGNITION (+)
05 PINK - IGNITION (+)
07 RED - POWER (30A)
07 RED - POWER (30A)
08 BLACK - GROUND08 BLACK - GROUND
01 GREEN•BLACK DOT - LOCK (-) OUTPUT
01 GREEN•BLACK DOT - LOCK (-) OUTPUT
02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT
03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT
03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT
04 GREEN/WHITE•BLACK DOT - ARM (-) OUTPUT04 GREEN/WHITE•BLACK DOT - ARM (-) OUTPUT
05 GREEN/BLACK•BLACK DOT - DISARM (-) OUTPUT05 GREEN/BLACK•BLACK DOT - DISARM (-) OUTPUT
06 BLUE/WHITE•BLACK DOT - GWR (-) OUTPUT
06 BLUE/WHITE•BLACK DOT - GWR (-) OUTPUT
07 EMPTY07 EMPTY
08 WHITE/PURPLE•BLACK DOT - POC 1 - 2ND UNLOCK OTHER DOORS (-) OUTPUT
08 WHITE/PURPLE•BLACK DOT - POC 1 - 2ND UNLOCK OTHER DOORS (-) OUTPUT
09 PURPLE/BLACK•BLACK DOT - POC 2 - RAP SHUTDOWN (-) OUTPUT09 PURPLE/BLACK•BLACK DOT - POC 2 - RAP SHUTDOWN (-) OUTPUT
10 WHITE/BLACK•BLACK DOT - POC 3 - HORN (-) OUTPUT10 WHITE/BLACK•BLACK DOT - POC 3 - HORN (-) OUTPUT
11 BROWN/BLACK•BLACK DOT - POC 4 - STARTER KILL (-) OUTPUT
11 BROWN/BLACK•BLACK DOT - POC 4 - STARTER KILL (-) OUTPUT
12 WHITE•BLACK DOT - PARKING LIGHTS (-) OUTPUT
01 BROWN•SILVER DOT - BRAKE (+) INPUT
02 BLACK/WHITE•SILVER DOT - E-BRAKE (-) INPUT
03 PURPLE•SILVER DOT - DOOR (+) INPUT
04 GREEN•SILVER DOT - DOOR (-) INPUT
05 PURPLE/WHITE•SILVER DOT - TACH (-) INPUT
06 WHITE/BLUE•SILVER DOT - X-TRIGGER (-) INPUT
07 GRAY•SILVER DOT - HOOD (-) INPUT
08 BLUE•SILVER DOT - TRUNK (-) INPUT
09 GRAY/BLACK•SILVER DOT - GLOW PLUG (+) INPUT
10 EMPTY
FUNCTIONS DEFINED BY FIRMWARE
FUNCTIONS DEFINED BY FIRMWARE
06 WHITE - PROG. RELAY #5 (10A) - PARKING LIGHTS (+) (DEFAULT)
06 WHITE - PROG. RELAY #5 (10A) - PARKING LIGHTS (+) (DEFAULT)
PAGE 9 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

01 [4x]
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
05
06
07
08
ENGINE
START
STOP
OFF ACC ON STARTOFF
09
_________________________________
>>
F
_________________________________
>>
_________________________________
REMOTE PROGRAMMING PROCEDURE - 1 OF 1
WARNING: Complete the module
programming procedure and tach
programming procedure before programming
the remotes. A maximum of four [4x] remotes
per system.
Set ignition to ON position.
Press and release the antenna button, then
press and hold the antenna button. The
antenna’s leds will turn solid BLUE.
Parking Light will flash once [1x].
Press once [1x] on the LOCK button of each
remote.
The antenna’s leds will flash BLUE once [1x]
for each successful pairing.
Release the antenna button. The antenna’s
leds will turn OFF.
Set ignition to OFF position.
Remote Programming Procedure completed.
To program an additional remote as second
vehicle mode: Follow steps 1 to 4. Press twice
[2x] on the “F” button then press once [1x] on
the LOCK button of the remote. Follow steps
6 to 9.
Please visit www.idataguides.com to see all of
our remote user manuals
PAGE 10 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

REMOTE STARTER ERROR CODES - 1 OF 1
REMOTE STARTER ERROR CODES: NOTES PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking lights are
connected and supported by the system.
3 + 1 Tach is not programmed OR engine is already running.
3 + 2 Key is in ignition ON position.
3 + 3 Door is open.
II After a remote starter failure, the parking lights will flash three [3x]
times followed by the error code. See table.
3 + 4 Trunk is open.
3 + 5 Foot brake is ON.
3 + 6 Hood is open.
3 + 7 Loop is not cut.
3 + 8 No tach detected.
3 + 9 Vehicle movement detected (VSS).
3 + 10 System is in Valet Mode.
3 + 11 CAN communication failure
3 + 12 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
3 + 13 Bypass problem.
3 + 14 Idle mode or takeover is not available on this vehicle.
3 + 15 Overheat protection.
REMOTE STARTER SHUTDOWN ERROR CODES: NOTES PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking lights are
connected and supported by the system.
4 + 1 Engine tach signal was lost.
4 + 2 Emergency brake signal was lost.
4 + 3 Foot brake ON detected.
II If the engine shuts down after a remote starter sequence
use the query command from a compatible aftermarket
remote to display the shutdown error code. The parking lights will
flash four [4x] times followed by the error code. See table.
4 + 4 Hood open detected.
4 + 5 Tach over rev detected.
4 + 6 Glow plug timeout error.
4 + 7 Vehicle movement detected (VSS).
4 + 8 Check engine light ON.
4 + 9 Low fuel level.
4 + 10 Open door detected.
4 + 11 CAN communication failure during RS sequence.
4 + 12 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
4 + 13 Bypass problem.
4 + 14 Idle mode or takeover is not available on this vehicle.
4 + 15 Overheat protection.
PAGE 11 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

MODULE DIAGNOSTICS - 1 OF 2
MODULE STATUS DURING: LED 2* LED 1** LED STATUS DIAGNOSTIC
MODULE PROGRAMMING
•Flashing RED Missing/wrong information from firmware or vehicle.
See firmware specific diagnostics, or contact technical support.
•Solid RED Module waiting for more vehicle information. Programming incomplete.
•Flashing GREEN Additional steps required to complete programming. Refer to install guide.
•Solid GREEN then OFF Module programming completed successfully.
oOFF No activity or module already programmed.
•1 RED flash No firmware on module. Connect to Weblink and flash device.
•2 ORANGE flashes Contact technical support.
•3 ORANGE flashes Module programming not completed.
•4 ORANGE flashes Contact technical support.
•7 ORANGE flashes Contact technical support.
•8 ORANGE flashes Loop not cut. Ensure loop is cut for automatic transmission. Reset and re-learn.
•9 ORANGE flashes Loop not cut. Ensure loop is cut for automatic transmission. Reset and re-learn.
•10 ORANGE flashes Boot loader update failed. Contact technical support.
•11 ORANGE flashes T-harness detection does not match install type selection in Weblink.
TACH PROGRAMMING
•Solid RED Tach learn in progress.
•1 GREEN flash Tach signal programmed in analog.
•2 GREEN flashes Tach signal programmed in data.
•3 RED flashes No tach signal detected
•4 RED flashes System is in valet mode. Turn off valet mode to program tach.
•6 RED flashes Engine sensing set for ‘assumed start’. No tach programming required.
•7 ORANGE flashes Engine sensing not configured properly. Contact technical support.
* LED 2 (RS) displays generic diagnostic codes specific to the remote start module. Orange LED flashes may appear red.
** LED 1 (Bypass) displays diagnostic codes specific to the firmware loaded on the module.
Visit the programming diagnostics page for more information.
PAGE 12 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900

MODULE DIAGNOSTICS - 2 OF 2
MODULE STATUS DURING: LED 2* LED 1** LED STATUS DIAGNOSTIC
REMOTE START SEQUENCE
•Flashing rapid RED Remote start shutdown sequence.
•Flashing slow RED Remote start shutdown error code. Contact technical support.
•Solid RED Remote start crank delay.
•Flashing rapid GREEN Remote start cycle in progress. Working correctly.
•1 GREEN flash Remote start initiated successfully.
•3 GREEN flashes Idle mode cycle in progress.
•4 GREEN flashes Turbo mode cycle in progress.
•Flashing GREEN Remote start cycle in progress. Displays vehicle platform during runtime.
•Rapid GREEN flashing Secure takeover initiated. Waiting to complete takeover after brake press.
TRANSMITTER PROGRAMMING
•Solid RED Remote programming in progress, waiting for remote pairing.
•1 GREEN flash Remote programmed.
•4 RED flashes Shutdown remote starter before attempting remote programming.
•5 RED flashes Engine must be off before attempting remote programming.
•6 RED flashes System must be unlocked/disarmed before attempting remote programming.
•7 RED flashes Module must be learned to the vehicle before attempting remote programming.
* LED 2 (RS) displays generic diagnostic codes specific to the remote start module. Orange LED flashes may appear red.
** LED 1 (Bypass) displays diagnostic codes specific to the firmware loaded on the module.
Visit the programming diagnostics page for more information.
PAGE 13 OF 13
U.S. Patent No. 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022 www.idatalink.com
RSA-SUB2-[CMHCXA0]-EN
2017 Subaru Crosstrek PTS Automatic
Doc No.: A5E91E3 - 20220818_163900
