Autopot Auto8 Instruction Manual

[email protected] I www.autopot.co.uk I [phone] [email protected] I www.autopot.co.uk I [phone]
Your Auto8
Set-up Guidelines
Ensuring that the AQUAvalve floods
and drains correctly
Care and maintenance
Making sure your AQUAvalve floods and
drains correctly is simply achieved and
only takes a few seconds.
Hold the AQUAvalve at eye level so that
you can see the silicon fitted to the top float
resting on the hole below it.
The silicon must create a tight seal when
touching the hole.
If it looks like it is not sitting parallel on the
hole below, simply lift the top float and
apply pressure to one side of the silicon,
drop the float and hold at eye level again.
Repeat the procedure if necessary.
At the end of your growing season, clean
the AQUAvalve using warm soapy water.
Using an old tooth brush will help.
The AQUAvalve is easily disassembled.
The top float will slide all the way across
and the bottom float is unclipped from its
pivoting position. The circular discs fitted to
the top float can also be removed by using
pliers to grip the raised point.
At this point is it advisable to remove the
silicones to avoid them being lost.
It is also handy to have a paper clip or
pipe cleaner to hand so that you can push
it through the AQUAvalve nozzle, this will
remove any lime scale build up that may
have occurred during the growing season.
Blowing through the AQUAvalve nozzle will
also help to remove any build up. Do not
under any circumstances use a drill & drill
bit to clear the AQUAvalve nozzle.
This will potentially damage the
AQUAvalve beyond repair.
Simple care
guidelines
11
2
2
3
4
Ensure the silicon is sitting parallel on
the hole below it. Hold at eye level
to check the position is correct
plants
Allow your
to
establish
before turning your
system
on
.

If you require any guidance email - [email protected]
Advice
Allow your plants to establish for 7-10 days before turning system on
[email protected] I www.autopot.co.uk I [phone]
• 1x Auto8 tray
• 1x Auto8 lid
• 1x Round blue access cover
• 1x AQUAvalve
• 1x AQUAvalve cover
• 1x 6mm top hat grommet
• 1x metre 6mm piping
• 8x Marix disc (square)
• 8x PotSock Square
• 8x 8.5 ltr pot if (AUTO8/8.5)
• 8x 15 ltr pot if (AUTO8/15)
Auto8 contents Auto8 Setup
Advice
• Pot up your plants, water through, then allow your plants to establish in the pots for a period of 7 to 10 days before
turning your system on. This will encourage a stronger and healthier root system.
• Always raise your reservoir to a minimum of 150mm above the highest AQUAvalve and re-fill the reservoir when
there is approximately a 1/3 of the solution left - NEVER ALLOW THE RESERVOIR TO RUN EMPTY.
• For best results, we recommend mineral fertilisers. Do not use liquid organic fertilisers, as they have a tendency to
block small pipe work.
• Clean all substrate from the bottom and sides of the pots before placing in each tray. This will ensure your system
is clean from the start.
• Always use free draining substrates, for example: soil/perlite, coco/perlite, soil/clay pebbles, coco/clay pebbles,
rockwool/clay pebbles.
10
Remove any slack
from 6mm pipe by
drawing excess pipe
out of the tray.
Ensure that the circular
spirit level indicates
the tray is level,
adjust if required.
Cut 6mm pipe to
appropriate length.
Connect via 6mm
/ 16mm fittings to a
filter (not included).
Connect filter to
reservoir. Leave tap off.
Make sure the
system is clean and
free of debris.
Place the lid on top
of the tray. Insert the
pots. Place the round
blue access cover
over the valve.
8
Pot and Tray Dimensions
575mm
275mm
195mm
245mm
200mm
8.5 ltr
pot
Place AQUAvalve cover
over the AQUAvalve.
The AQUAvalve and
cover should be placed
directly onto the tray.
1190mm
535mm
Required Reservoir Capacity
FlexiTank and FlexiTank Pro are the only collapsible reservoirs
that AutoPot recommend for use with Auto8 Tray Systems.
A minimum 100ltr reservoir is required per unit.
Push 6mm top hat
grommet into the hole
in the Auto8 tray wall.
Thread 6mm pipe into the
tray through the grommet.
Remove AQUAvalve
collar.
Push 6mm pipe through
collar and attach to
AQUAvalve nozzle.
Rescrew collar - DON’T
overturn... when you
feel it grip STOP.
5 6
Fill pots with medium
and pot up plants.
Water through pots
and allow to drain
outside the tray.
1
Put the black marix
discs into the pots
Auto8
System Size 1x Auto8 2x Auto8 4x Auto8 8x Auto8 10x Auto8
FlexiTank or
FlexiTank Pro
Capacity
FlexiTank
/ Pro 100ltr
FlexiTank
/ Pro 225ltr
FlexiTank
/ Pro 400ltr
FlexiTank
750ltr
FlexiTank
1000ltr
350mm
245mm
15 ltr
pot
260mm
195mm
300mm
260mm
195mm
300mm
9
2
Included with
(AUTO8/8.5)
Included with
(AUTO8/15)
Once pots have drained
fit a PotSock Square over
the base of each pot.
Make sure the pots are
clean and free of debris.
4
3
7
