Tyco TY1136 User manual

Model TY-FRFS, TY-FS Special, and TY-FS
57, 80, and 115 K-factor Upright and Pendent
Flat Spray Sprinklers
Page 1 of 8 MARCH 2020 TFP635
IMPORTANT
Refer to Technical Data Sheet
TFP2300 for warnings pertaining to
regulatory and health information.
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and com-
ponents. Improper handling and
installation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.
Worldwide
Contacts
www.tyco-fire.com
CEA 4001 Sprinkler Systems Plan-
ning and Installation and EN12845
Automatic Sprinkler Systems –
Design, Installation and Maintenance
permits flat spray sprinklers to be used
in concealed spaces, suspended open
ceilings, and in racks.
NOTICE
Model TY-FRFS, TY-FS Special, and
TY-FS Sprinklers, as well as guard/
shield accessories, described herein
must be installed and maintained in
compliance with this document,as
well as with the applicable standards
recognized by the approval agency, in
addition to the standards of any other
authorities having jurisdiction. Failure
to do so may impair the performance
of these devices.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating con-
dition. Contact the installing contrac-
tor or product manufacturer with any
questions.
Sprinkler
Identification
Numbers (SINs)
Model TY-FRFS (3 mm Bulb)
TY1136 – Upright K57
TY1236 – Pendant K57
TY3136 – Upright K80
TY3236 – Pendent K80
TY4136 – Upright K115
TY4236 – Pendent K115
Model TY-FS Special (4 mm Bulb)
TY1146 – Upright K57
TY1246 – Pendent K57
TY3146 – Upright K80
TY3246 – Pendent K80
TY4146 – Upright K115
TY4246 – Pendent K115
Model TY-FS (5 mm Bulb)
TY1156 – Upright K57
TY1256 – Pendent K57
TY3156 – Upright K80
TY3256 – Pendent K80
TY4156 – Upright K115
TY4256 – Pendent K115
General
Description
The Model TY-FRFS, TY-FS Special,
and TY-FS, Upright and Pendent, Flat
Spray Sprinklers are intended for instal-
lation in accordance with CEA 4001
Sprinkler Systems Planning and Instal-
lation or EN12845 Automatic Sprin-
kler Systems – Design, Installation
and Maintenance, as applicable. They
produce a flatter spray pattern than
standard spray sprinklers, enabling
them to be used with lower clearance
above the suspended open ceilings
and in racks.
As necessary the K80 and K115, Flat
Spray Sprinklers may be outfitted
with guards, shields, or guards with
shields. The guards may be used in
areas that make the sprinklers suscep-
tible to mechanical or physical damage,
whereas the shields may be used to
help prevent the sprinklers from being
wetted (cold soldered) from water
spray of higher elevation sprinklers.
Table A provides a detailed matrix of
the allowable combinations.
The Model TY-FRFS with its 3 mm
diameter heat sensitive bulb element is
rated quick response, the Model TYFS
Special with its 4 mm diameter heat-
sensitive bulb element is rated special
response, and the Model TY-FS with
its 5 mm diameter heat sensitive bulb
element is rated standard response
“A.”
Operation
The glass bulb contains a fluid which
expands when exposed to heat. When
the rated temperature is reached, the
fluid expands sufficiently to shatter the
glass bulb, allowing the sprinkler to
activate and water to flow.
Model TY-FS
Model TY-FRFS
Model TY-FS Special

TFP635
Page 2 of 8
Technical
Data
Approvals
VdS Approved for installation per
CEA 4001 Sprinkler Systems Planning
and Installation or
EN12845 Automatic Sprinkler Systems –
Design, Installation, and Maintenance
LPCB Approved
(See Table A)
The Guards, Shields, and Guards with
Shields are VdS Approved with the
combinations of product shown in Table A
For details contact:
Johnson Controls
Enschede, Netherlands
Tel. [phone]
Fax [phone]
Maximum Working Pressure
12,1 ba r
Discharge Coefficient
K=57 Lpm/bar½
K=80 Lpm/bar½
K=115 Lpm/bar½
Temperature Ratings (°C)
57, 68, 79, 93, and 141
Finishes
Sprinklers: Natural Brass
Guards: Red Painted / Zinc Chromate
Shields: Zinc Chromate
Physical Characteristics
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Button .....................Bronze/Copper
Sealing Assembly ..Beryllium Nickel w/TEFLON
Bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Glass
Compression Screw . . . . . . . . . . . . . . . . .Bronze
Deflector . . . . . . . . . . . . . . . . . . . . . . . . . Copper
Guard ................Welded Carbon Steel
Shield . . . . . . . . . . . . . . . . . . . . . . .Carbon Steel
Shield Spring. . . . . . . . . . . . . . . . . .Carbon Steel
Design
Criteria
The Model TY-FRFS, TY-FS Special,
and TY-FS Flat Spray Sprinklers are
only intended for installation per CEA
4001 Sprinkler Systems Planning and
Installation or EN12845 Automatic
Sprinkler Systems – Design, Installa-
tion and Maintenance where flat spray
sprinklers are permitted.
Note: In all cases, CEA 4001 Sprinkler
Systems Planning and Installation or
EN12845 Automatic Sprinkler Systems
– Design, Installation and Maintenance
must be referenced and followed to ensure
an effective installation. The Flat-Spray
Sprinklers have significantly different water
distribution characteristics from that of
conventional and spray pattern sprinklers
that has enabled the Flat-Spray Sprinklers
to be used in conformance with CEA 4001
Sprinkler Systems Planningand Installation
or EN12845 Automatic Sprinkler Systems
– Design, Installation and Maintenance.
Series Bulb Size Orifice Position SIN Approvals Guard Shield Guard/Shield
TY-FRFS 3 mm
K57, 10 mm
Upright
T Y113 6 LPCB, VdS N/A N/A N/A
TY-FS Special 4 mm T Y1146 VdS N/A N/A N/A
TY-FS 5 mm T Y115 6 LPCB, VdS N/A N/A N/A
TY-FRFS 3 mm
Pendent
TY1236 LPCB, VdS N/A N/A N/A
TY-FS Special 4 mm TY1246 VdS N/A N/A N/A
TY-FS 5 mm TY1256 LPCB, VdS N/A N/A N/A
TY-FRFS 3 mm
K80, 15 mm
Upright
TY3136 LPCB, VdS G1 N/A N/A
TY-FS Special 4 mm TY3146 VdS G1 N/A N/A
TY-FS 5 mm TY3156 LPCB, VdS G1 N/A N/A
TY-FRFS 3 mm
Pendent
TY3236 LPCB, VdS G1 H1 or H2 G1/H1 or G1/H2
TY-FS Special 4 mm TY3246 VdS G1 H1 or H2 G1/H1 or G1/H2
TY-FS 5 mm TY3256 VdS G1 H1 or H2 G1/H1 or G1/H2
TY-FRFS 3 mm
K115, 20 mm
Upright
T Y413 6 LPCB, VdS G1 N/A N/A
TY-FS Special 4 mm T Y4146 VdS G1 N/A N/A
TY-FS 5 mm T Y415 6 VdS G1 N/A N/A
TY-FRFS 3 mm
Pendent
TY4236 VdS G1 H1 or H2 G1/H1 or G1/H2
TY-FS Special 4 mm T Y424 6 VdS G1 H1 or H2 G1/H1 or G1/H2
TY-FS 5 mm T Y425 6 VdS G1 H1 or H2 G1/H1 or G1/H2
TABLE A
ALLOWABLE COMBINATIONS OF GUARDS, SHIELDS, AND GUARDS WITH SHIELDS

TFP635
Page 3 of 8
Components:
55 mm
10 mm
NOMINAL
MAKE-IN WRENCH
FLATS 40 mm
55 mm
10 mm
NOMINAL
MAKE-IN
2
6
4
5
3
1
Frame
Button
Bulb (See table above)
Compression Screw
Deector
Sealing Assembly
-
-
-
-
-
-
2
1
3
5
4
6
Temperature rating is indicated on
Deector or adjacent to orice seat
on frame.
DEFLECTOR
DEFLECTOR
BULB
SIZE
MODEL SIN
UPRIGHT
TY11363 mm
TY-FRFS
TY-FS SPECIAL 4 mm TY1146
TY-FS 5 mm TY1156
PENDENT
TY1236
TY1256
TY1246
ISO
7-R 3/8
ISO
7-R 3/8
*
*
*
*
*
UPRIGHT PENDENTCROSS SECTION
Components:
57 mm
11 mm
NOMINAL
MAKE-IN WRENCH
FLATS
UPRIGHT PENDENT
40 mm
57 mm
11 mm
NOMINAL
MAKE-IN
CROSS SECTION
2
6
4
5
3
1
Frame
Button
Bulb (See table above)
Compression Screw
Deector
Sealing Assembly
-
-
-
-
-
-
2
1
3
5
4
6
THREAD
RELIEF
Temperature rating is indicated on
Deector or adjacent to orice seat
on frame.
Pipe thread connections per ISO 7-1
can be provided on special request.
DEFLECTOR
SHIELD AND
ESCUTCHEON
PLATE SEATING
SURFACE
1/2" NPT
DEFLECTOR1/2" NPT
BULB
SIZE
MODEL SIN
UPRIGHT
TY31363 mm
TY-FRFS
TY-FS SPECIAL 4 mm TY3146
TY-FS 5 mm TY3156
PENDENT
TY3256
TY3246
TY3236
*
*
*
* **
*
**
**
Components:
60 mm
13 mm
NOMINAL
MAKE-IN WRENCH
FLATS 46 mm
60 mm
13 mm
NOMINAL
MAKE-IN
BULB
SIZE
MODEL SIN
UPRIGHT
TY41363 mm
TY-FRFS
TY-FS SPECIAL 4 mm TY4146
TY-FS 5 mm TY4156
PENDENT
TY4256
TY4246
TY4236
2
6
4
5
3
1
Frame
Button
Bulb (See table above)
Compression Screw
Deector
Sealing Assembly
-
-
-
-
-
-
2
1
3
5
4
6
THREAD
RELIEF
Temperature rating is indicated on
Deector or adjacent to orice seat
on frame.
Pipe thread connections per ISO 7-1
can be provided on special request.
DEFLECTOR
SHIELD AND
ESCUTCHEON
PLATE SEATING
SURFACE
3/4" NPT
DEFLECTOR3/4" NPT *
*
*
* **
*
**
**
UPRIGHT PENDENTCROSS SECTION
FIGURE 1
57 K-FACTOR, 10 MM ORIFICE, ISO 7-R 3/8 THREAD
UPRIGHT AND PENDENT FLAT SPRAY SPRINKLERS
FIGURE 2
80 K-FACTOR, 15 MM ORIFICE, 1/2 INCH NPT THREAD
UPRIGHT AND PENDENT FLAT SPRAY SPRINKLERS
FIGURE 3
115 K-FACTOR, 20 MM ORIFICE, 3/4 INCH NPT THREAD
UPRIGHT AND PENDENT FLAT SPRAY SPRINKLERS

TFP635
Page 4 of 8
MODEL G1
GUARD
MODEL H1
SHIELD
SHIELD
SEATING
SURFACE
8 mm
100 mm DIA.
15 mm
PENDENT
FLAT SPRAY
SPRINKLER
MODEL H1
SHIELD
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
15 mm
PENDENT
FLAT SPRAY
SPRINKLER
MODEL G1
GUARD
MODEL H2
SHIELD
SHIELD
SEATING
SURFACE
15 mm
PENDENT
FLAT SPRAY
SPRINKLER
15 mm
PENDENT
FLAT SPRAY
SPRINKLER
MODEL H2
SHIELD
160 mm DIA.
32 mm
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
73 mm DIA.
60 mm
BAR
GUARD CLIP
(ENGAGED)
SPRINKLER
THREAD RELIEF
ENGAGED BY
BASE PLATE
MODEL G1
GUARD
BASE
PLATE
15 or 20 mm
UPRIGHT or
PENDENT
FLAT SPRAY
SPRINKLER
UPRIGHT PENDENT
FIGURE 4
MODEL G1 GUARD
ON 15 OR 20MM UPRIGHT OR PENDENT FLAT SPRAY SPRINKLER – TYPICAL INSTALLATION
(Refer to Table A for allowable sprinkler and guard combinations)
FIGURE 5
MODEL H1 SHIELD OR MODEL H1 SHIELD WITH MODEL G1 GUARD
ON 15MM PENDENT FLAT SPRAY SPRINKLER – TYPICAL INSTALLATION
(Refer to Table A for allowable sprinkler, shield and guard combinations)
FIGURE 6
MODEL H2 SHIELD OR MODEL H2 SHIELD WITH MODEL G1 GUARD
ON 15MM PENDENT FLAT SPRAY SPRINKLER – TYPICAL INSTALLATION
(Refer to Table A for allowable sprinkler, shield and guard combinations)

TFP635
Page 5 of 8
Installation
Installation instructions are provided in
the following subsections:
• Sprinkler Only Installation
• Sprinkler with Guard Installation
• Sprinkler with Shield Installation
• Sprinklers with Guard and Shield
Installation
See the Sprinkler Only Installation sub-
section for general instructions.
Sprinkler Only Installation
The Model TY-FRFS, TY-FS Special,
and TY-FS Sprinklers must be installed
in accordance with this section.
General Instructions
Do not install any bulb type sprinkler
if the bulb is cracked or there is a loss
of liquid from the bulb. With the sprin-
kler held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1,6 mm for
57°C to 2,4 mm for the 141°C tempera-
ture ratings.
A leak-tight ISO 7-R 3/8 sprinkler joint
should be obtained by applying a
minimum-to-maximum torque of 8 to
16 N∙m.
A leak tight 1/2 in. NPT sprinkler joint
should be obtained by applying a min-
imum-to-maximum torque of 9,5 to
19,0 N∙m.
A leak tight 3/4 in. NPT sprinkler joint
should be obtained by applying a min-
imum-to-maximum torque of 13,4 to
26,8 N∙m. Higher levels of torque may
distort the sprinkler inlet and cause
leakage or impairment of the sprinkler.
Do not attempt to make-up for insuf-
ficient adjustment in the escutcheon
plate by under- or over-tightening the
sprinkler. Readjust the position of the
sprinkler fitting to suit.
Note: Pendentsprinklersare to beinstalled
in the pendent position; upright sprinklers
are to be installed in the upright position.
Step 1. With pipe thread sealant
applied to the pipe threads, hand-
tighten the sprinkler into the sprinkler
fitting.
Step 2. Tighten the sprinkler into the
sprinkler fitting using only the W-Type
6 Sprinkler Wrench (See Figure 10).
With reference to Figures 1, 2, and 3
the W-Type 6 Sprinkler Wrench is to be
applied to the wrench flats.
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
8 mm
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
MODEL G1
GUARD
MODEL H1
SHIELD
20 mm
PENDENT
FLAT SPRAY
SPRINKLER
MODEL H1
SHIELD
20 mm
PENDENT
FLAT SPRAY
SPRINKLER
100 mm DIA.
160 mm DIA.
32 mm
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
MODEL G1
GUARD
MODEL H2
SHIELD
SHIELD
SEATING
SURFACE
ATTACHMENT
SPRING
20 mm
PENDENT
FLAT SPRAY
SPRINKLER
20 mm
PENDENT
FLAT SPRAY
SPRINKLER
MODEL H2
SHIELD
FIGURE 7
MODEL H1 SHIELD OR MODEL H1 SHIELD WITH MODEL G1 GUARD
ON 20MM PENDENT FLAT SPRAY SPRINKLER – TYPICAL INSTALLATION
(Refer to Table A for allowable sprinkler, shield and guard combinations)
FIGURE 8
MODEL H2 SHIELD OR MODEL H2 SHIELD WITH MODEL G1 GUARD
ON 20MM PENDENT FLAT SPRAY SPRINKLER – TYPICAL INSTALLATION
(Refer to Table A for allowable sprinkler, shield and guard combinations)

TFP635
Page 6 of 8
Sprinkler with Guard
Installation
With reference to Figures 4 and 9,
15 mm or 20 mm Upright or Pendent
Sprinklers with Model G1 Guard must
be installed in accordance with this
section:
Step 1. The G1 Guard is to be mounted
on the sprinkler after the sprinkler has
been installed in accordance with the
Sprinklers Only Installation subsection.
Step 2. With the Clips loose, first
spread the two halves of the Sprin-
kler Guard just enough to pass by the
sprinkler deflector from the side. Then,
once again spread the two halves of the
Sprinkler Guard just enough to pass
over the Thread Relief portion of the
sprinkler. (See Figures 2 and 3)
Step 3. With the Sprinkler Guard posi-
tioned on the Thread Relief portion of
the sprinkler, as applicable, engage the
Clips and then slide the Clips until they
seat against the Base Plate to complete
the installation as shown in Figure 4.
To help assist with the sliding of the
Clips, the Guard Installation Tool
maybe used as shown in Figure 9. In
addition, pliers can be used to facilitate
the final seating of the Clips.
Note: The Clips must seat against the Base
Plate in order to be considered fully seated
and in order to complete the installation.
The G1 Guard may be located in any
position relative to the sprinkler frame
arms.
Sprinkler with Shield
Installation
With reference to Figures 5, 6, 7, or 8,
15 mm or 20 mm Pendent Sprinklers
with Model H1 or Model H2 Shield
must be installed in accordance with
this section:
Note: Pendentsprinklersare to beinstalled
in the pendent position.
Step 1. With pipe thread sealant
applied to the pipe threads, install the
Shield over the sprinkler threads.
Step 2. Place the Attachment Spring
over the sprinkler threads, seating it
against the Shield.
Step 3. Hand-tighten the sprinkler into
the sprinkler fitting.
Step 4. Tighten the sprinkler into
the sprinkler fitting using only the
W-Type 7 Recessed Sprinkler Wrench
(See Figure 11). The wrench is to be
applied to the sprinkler wrenching area
shown in Figures 2 or 3, as applicable.
Note: When installed correctly, the
Attachment Spring will be slightly
compressed and the Shield will be held
firmly in place.
Sprinkler with Guard and
Shield Installation
With reference to Figures 5, 6, 7, or 8,
15 or 20 mm Pendent Sprinklers with
Model H1 or Model H2 Shield and
Model G1 Guard must be installed in
accordance with this section:
Note: Pendentsprinklersare to beinstalled
in the pendent position.
Step 1. With pipe thread sealant
applied to the pipe threads, install the
Shield over the sprinkler threads.
Step 2. When installing K115 Sprin-
klers, place the Attachment Spring over
the sprinkler threads, seating it against
the Shield.
Note: An Attachment Spring is not utilized
for K80 Sprinklers with Guard and Shield.
Step 3. Hand tighten the sprinkler into
the sprinkler fitting.
Step 4. Tighten the sprinkler into the
sprinkler fitting using only the W-Type
7 Sprinkler Wrench (See Figure 11). The
wrench is to be applied to the sprinkler
wrenching area shown in Figures 2 or
3, as applicable.
Step 5. After the sprinkler with shield
is installed into the sprinkler pipe
fitting, install the guard as described
in the Sprinkler with Guard Installation
subsection.
WRENCH
RECESS
PUSH WRENCH
IN TO ENSURE
ENGAGEMENT
WITH SPRINKLER
WRENCHING AREA
WRENCH RECESS
(END "A" USED FOR
ISO 7-R 3/8 AND
1/2" NPT MODELS)
WRENCH RECESS
(END "B" USED FOR
3/4" NPT MODELS)
WITH INSTALLATION TOOL APPLIED OVER
ADJACENT BARS, PRESS SECOND CLIP
TOWARD BASE PLATES UNTIL FULLY ENGAGED
SWIVEL CLIPS OVER
ADJACENT BARS AND SLIDE
TOWARD BASE PLATES
UNTIL SNUG
BASE
PLATES
FIRST
CLIP FULLY
ENGAGED
INSTALLATION
TOOL (SHIPPED WITH
GUARDS)
BAR
SLOT
SECOND
CLIP FULLY
ENGAGED
A PLIER
MAY BE
USED
INSTALLATION
TOOL
CLIP
INSTALLATION
TOOL
CLIP
WITH SPRINKLER PROPERLY
INSTALLED, CAREFULLY
SPREAD BASE PLATES APART
AND FIT ONTO SPRINKLER
THREAD RELIEF
MODEL G1
GUARD
FLAT SPRAY
SPRINKLER
FIGURE 10
W-TYPE 6
SPRINKLER WRENCH
FIGURE 11
W-TYPE 7 RECESSED
SPRINKLER WRENCH
FIGURE 9
MODEL G1 GUARD INSTALLATION PROCEDURE

TFP635
Page 7 of 8
Care and
Maintenance
The Model TY-FRFS, TY-FS Special,
and TY-FS Sprinklers must be main-
tained and serviced in accordance with
this section:
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
it controls, permission to shut down the
affected fire protection system must be
obtained from the proper authorities
and all personnel who may be affected
by this action must be notified.
Sprinklers that are found to be leaking
or exhibiting visible signs of corrosion
must be replaced.
Automatic sprinklers must never be
painted, plated, coated or other-
wise altered after leaving the factory.
Modified sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
Care must be exercised to avoid
damage to the sprinklers before,
during, and after installation. Sprin-
klers damaged by dropping, striking,
wrench twist/slippage, or the like, must
be replaced. Also, replace any sprinkler
that has a cracked bulb or that has lost
liquid from its bulb. Refer to the Instal-
lation section fr additional information.
The owner is responsible for the inspec-
tion, testing, and maintenance of their
fire protection system and devices in
compliance with this document, as well
as with the applicable standards of the
authorities having jurisdiction. Contact
the installing contractor or product
manufacturer with any questions.
It is recommended that automatic
sprinkler systems be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and part number
(P/N).
Note: Sprinklers, wrenches, guards,
shields,attachmentsprings,andadditional
clip installation tool are all sold separately.
Sprinkler Assemblies
Specify: Model (TY-FRFS, TY-FS
Special, or TY-FS), (specify SIN),
(specify Standard , Special, or Quick)
Response, (specify 57, 80, or 115)
K-factor, (specify temperature rating),
(specify Pendent or Upright) Sprinklers,
P/N (specify from Table B)
Sprinkler Wrenches
Specify: W-Type (specify) Sprinkler
Wrench, P/N (specify):
W-6........................ 56-000-6-387
W-7 ........................ 56-850-4-001
Guards
Specify: Model G1 Guard with (specify)
finish, P/N (specify):
Red Painted ................. 56-000-6-387
Zinc Chromate ............... 56-850-4-001
Shields
Specify: Model (specify), (specify NPT
size) Shield, P/N (specify):
H1, 1/2 in. NPT . . . . . . . . . . . . . . . . . . . . . . 22521
H1, 3/4 in. NPT. . . . . . . . . . . . . . . . . . . . . . 22522
H2, 1/2 in. NPT. . . . . . . . . . . . . . . . . . . . . . 22529
H2, 3/4 in. NPT. . . . . . . . . . . . . . . . . . . . . . 22524
Attachment Springs
Specify: (specify NPT size) Shield
Spring, P/N (specify):
1/2 in. NPT . . . . . . . . . . . . . . . . . . . . . . . . . 22526
3/4 in. NPT . . . . . . . . . . . . . . . . . . . . . . . . . 22527
Additional* Clip Installation Tool
Specify: Clip Installation Tool for G1
Guard, P/N 56-000-8-597
* The Clip Installation Tool is included with guard orders
in original cartons.
P/N 51 – XXX – 1 – XXX
SPRINKLER
FINISH
1NATURAL BRASS
TEMPERATURE
RATING
135 135°F (57°C)
155 155°F (68°C)
175 175°F (79°C)
200 200°F (93°C)
286 286°F (141°C)
MODEL TY-FRFS
SIN DESCRIPTION
380 T Y113 6 K57 UPRIGHT, ISO 7-R 3/8
382 TY1236 K57 PENDENT, ISO 7-R 3/8
370 TY3136 K80 UPRIGHT, 1/2 in. NPT
371 TY3236 K80 PENDENT, 1/2 in. NPT
390 T Y413 6 K115 UPRIGHT, 3/4 in. NPT
391 TY4236 K115 PENDENT, 3/4 in. NPT
MODEL TY-FS SPECIAL
SIN DESCRIPTION
480 T Y1146 K57 UPRIGHT, ISO 7-R 3/8
482 TY1246 K57 PENDENT, ISO 7-R 3/8
470 T Y3146 K80 UPRIGHT, 1/2 in. NPT
471 TY3246 K80 PENDENT, 1/2 in. NPT
490 T Y414 6 K115 UPRIGHT, 3/4 in.NPT
491 T Y4 24 6 K115 PENDENT, 3/4 in. NPT
MODEL TY-FS
SIN DESCRIPTION
580 T Y115 6 K57 UPRIGHT, ISO 7-R 3/8
582 TY1256 K57 PENDENT, ISO 7-R 3/8
570 TY3156 K80 UPRIGHT, 1/2 in. NPT
571 TY3256 K80 PENDENT, 1/2 in. NPT
590 T Y4156 K115 UPRIGHT, 3/4 in. NPT
591 T Y4 256 K115 PENDENT, 3/4 in. NPT
TABLE B
FLAT SPRAY SPRINKLERS
PART NUMBER SELECTION

TFP635
Page 8 of 8
TEFLON is a registered trademark of DuPont
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone [phone]
© 2020 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
