Autopot 48Pot System Instruction Manual

[email protected] I www.autopot.co.uk I [phone] [email protected] I www.autopot.co.uk I [phone]
Your 48Pot system
set-up guidelines
Ensuring that the AQUAvalve floods
and drains correctly
Care and maintenance
Making sure your AQUAvalve floods and
drains correctly is simply achieved and
only takes a few seconds.
Hold the AQUAvalve at eye level so that
you can see the silicon fitted to the top float
resting on the hole below it.
The silicon must create a tight seal when
touching the hole.
If it looks like it is not sitting parallel on the
hole below, simply lift the top float and
apply pressure to one side of the silicon,
drop the float and hold at eye level again.
Repeat the procedure if necessary.
At the end of your growing season, clean
the AQUAvalve using warm soapy water.
Using an old tooth brush will help.
The AQUAvalve is easily disassembled.
The top float will slide all the way across
and the bottom float is unclipped from its
pivoting position. The circular discs fitted to
the top float can also be removed by using
pliers to grip the raised point.
At this point is it advisable to remove the
silicones to avoid them being lost.
It is also handy to have a paper clip or
pipe cleaner to hand so that you can push
it through the AQUAvalve nozzle, this will
remove any lime scale build up that may
have occurred during the growing season.
Blowing through the AQUAvalve nozzle will
also help to remove any build up. Do not
under any circumstances use a drill & drill
bit to clear the AQUAvalve nozzle.
This will potentially damage the
AQUAvalve beyond repair.
Simple care
guidelines
11
2
2
3
4
Ensure the silicon is sitting parallel on
the hole below it. Hold at eye level
to check the position is correct
plants
Allow your
to
establish
before turning your
system
on
.
48

1Pot setup
instructions
Using your front instruction sheet, repeat the module set up instructions for the number of trays.
If you require any guidance email - [email protected]
Advice
1
8
2
Put black marix
disc in pot
Allow your plants to establish for 7-10 days before turning system on
[email protected] I www.autopot.co.uk I [phone]
65
Position tray
so it is level
Insert root control
disc Gold face up
3Remove collar
Push 6mm pipe through
collar and attach to
AQUAvalve nozzle
Rescrew collar - DON’T
overturn... when you
feel it grip STOP
Cut 6mm/16mm pipe
to appropriate length
Connect AQUAvalve
so ‘half moon’ is on
T section in the tray
4
Plan views
and options
48Pot system contents 1Pot dimensions
Advice
Fill pot with medium
and pot up plants.
Water through pot
and allow to drain
outside the tray.
Place pot in the
tray, make sure it is
CLEAN!
Place lid over valve
onto tray
• Pot up your plants, water through, then allow your plants to establish in the pots for a period of 7 to 10
days before turning your system on. This will encourage a stronger and healthier root system.
• Always raise your tank to a minimum of 150mm above the highest AQUAvalve and re-fill the tank when
there is approximately a 1/3 of the solution left - NEVER ALLOW THE TANK TO RUN EMPTY.
• For best results, we recommend mineral fertilisers. Do not use organic fertilisers, as they have a tendency
to block small pipe work.
• Clean all substrate from the bottom and sides of the pots before placing in each tray.
This will ensure your system is clean from the start.
• Always use free draining substrates, for example: soil/perlite, coco/perlite, soil/clay pebbles,
coco/clay pebbles, rockwool/clay pebbles.
Suggested layout
400 ltr
FlexiTank
6mm pipe
16mm pipe
AQUAvalve
16mm click-fit tank adaptor & filter
16mm in-line tap
16mm cross connector
16mm – 6mm cross connector
7
According to the size of your system connect your
6mm/16mm pipe to relevant fitting or tank...
System requires minimum
400 litre FlexiTank (supplied)
400 ltr
FlexiTank
680mm
1110mm
• 1x 400 litre FlexiTank
• 48x 1Pot tray and lid
• 48x 15 litre pot
• 48x AQUAvalve
• 1x 16mm click-fit tank adapter and filter
• 3x 16mm inline tap
• 1x 16mm cross connector
• 24x 16 - 6mm cross connector
• 20 metres of 16mm pipe
• 24 metres of 6mm pipe
• 48x marix disc
• 48x root control disc
400 ltr
FlexiTank
Elevate tank
150mm from
floor to maintain
gravity pressure
