AUX Link User manual

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
USER MANUAL
English

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
CONTENTS
1. Compatibility.................................................................................................................. 4
2. Product Introduction ...................................................................................................... 4
3. Accessories kit................................................................................................................ 4
4. Installation procedure: ................................................................................................... 5
5. Functions and usage: ...................................................................................................... 7
5.1 Applicable storage device: ....................................................................................... 7
5.2 Supported Music Files:............................................................................................. 7
5.3 Supported Folder & Track Quantity:......................................................................... 7
5.4 Music File Saving & Playing Mode: ........................................................................... 8
5.5 AUX IN:.................................................................................................................... 8
5.6 Last Position Memory: ............................................................................................. 8
5.7 Playback function controls: ...................................................................................... 9
6. Other operation instruction ............................................................................................ 9
7. Adapter specifications .................................................................................................. 11
8. Additional AUX Link Bluetooth Module......................................................................... 11
9. Warranty...................................................................................................................... 12

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
1. COMPATIBILITY
Compatibility with car radios
AUX Link car adapter for USB flash and SD cards is compatible with OEM car radios of
Acura, Alfa Romeo, Audi, BMW, Buick, Chevrolet, Citroen, Daihatsu, Fiat, Ford, Honda,
Hyundai, Infiniti, KIA, Lancia, Lexus, Mazda, Mercedes, Mini, Nissan, Opel, Peugeot,
Porsche, Renault, Rover, Range Rover, Scion, Seat, Skoda, Smart, Ssang Yong,
Suzuki, Toyota, Volkswagen, Volvo, etc. It is also compatible with aftermarket car
stereos, such as Alpine, Becker, Blaupunkt, Clarion, Pioneer, Sanyo, Sony and JVC.
The list of compatible car radios can be updated, please contact the supplier for more
information on updating details.
2. PRODUCT INTRODUCTION
AUX Link car adapter for USB flash and SD cards is the best replacement for a CD
Changer. It is both easy to install and to use. It delivers high quality sound directly into
your car stereo system via a CD Changer Port, and you will not experience any loss of
sound quality that often occurs with existing FM transmitter and cassette solutions.
With AUX Link car adapter for USB flash and SD cards you can control music from the
car radio panel or using the buttons of a steering wheel, that remain fully operational.
AUX Link has built-in USB and SD Card slots, which means that users can enjoy music
in MP3/WMA formats, saved on SD/SDHC/MMC card or USB stick with the best
possible sound quality. Having AUX IN slot as well, the adapter provides car owners
access to even a bigger variety of audio sources.
All in all, AUX Link is the best choice of upgrading your current car stereo system, as it
gives you the possibility to enjoy the abundance of CD-quality music without carrying
piles of CDs.
3. ACCESSORIES KIT
Ordering car adapter AUX Link for USB and SD cards you receive:

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
AUX Link Module Unit
User Manual
Wire harness
3.5 mm AUX cable
4. INSTALLATION PROCEDURE:
Important:
The adapter is only suitable for vehicles that have 12 Volt DC and
negative ground system. It is forbidden to use it on any other voltage
system.
The adapter only operates on vehicles that have factory fitted head unit
or aftermarket car radio, equipped with a CD changer port.
The installation can differ slightly depending on the model of the car and
the model of the car stereo.
Carefully read the User Manual before the installation. To guarantee the
correct installation and functioning of the adapter it is highly
recommended to have it installed by professional staff.
Some vehicles may require special tools to remove the car stereo. It is
advisable to consult your vehicle’s dealership or car audio professional if
necessary.
NOTE: MP3/CDC Switch Cable is optional and available for some vehicles only.
1. Turn off the car engine and remove the key from ignition.
2. Make sure your car radio doesn´t have a Security Code, otherwise be certain to
have it before unplugging the radio.
3. Extract the radio from the dash to get access to its rear side.
4. Find a CD Changer port at the back of the radio.

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
5. Plug the wire harness connector into the CD changer port at the back of the
radio. Make sure it has a firm connection.
6. Once the AUX Link car adapter is connected to the radio, you have to test its
performance before re-assembling the dash. Insert USB pen drive or SD card
and switch on the Head Unit. Press the CD (or Disc/Mode/CDC/SOURCE/AUX)
button on the radio once or twice to switch to playback mode of the car adapter,
with the symbol of LED light being on. Depending on the car stereo type CDC,
EX, or CD01 will be displayed on the radio screen. Now the audio adapter will
run normally.
7. Test the performance of the device by playing some of your music files.
8. If the test is successful, insert the car radio back into the dash and put the wire
harness and the adapter unit in a proper place.
9. Put the AUX cable in a convenient place (it can be displayed in the ashtray, glove
box, etc.).
10.The installation is completed. Connect your mobile device or insert USB/SD card
and enjoy your favourite songs with high quality sound.
Important:
If the harness has a BLACK ground wire, please attach it to any metal part of the
head unit body; If the harness has a YELLOW power wire, please attach it to the
power of the car, which connects to the battery; If the harness has a RED ACC
wire, please attach it to the ACC signal of the car. It’s extremely important to attach
these cables to the right place otherwise the AUX Link car adapter will not work!
If the car already has a CD-changer plugged into the jack, the AUX Link adapter
can be connected in parallel through the splitter (Parallel Harness or MP3/CDC
Switch Cable will be provided).
For Fiat, Renault models, there are two black wires with metal ends (male+female)
that come along with CDC connector. If you experience any noise problems when
using the adapter, please make sure to hook up the two grounding wires with each
other.
For Audi factory radio of mini ISO 8 pin, its CDC connector is 20-pin block
connector. In order to install AUX Link, it requires cutting the 8-pin part or
connecting it with our special Audi 20-pin adapter cable.
For Clarion protocol radios (some BUICK and SUZUKI radios), it is important to
totally unplug the wire harness before installation, so that to power off the electric

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
supply. If not, AUX Link may not work or it can cause radio screen flickering.
It is required to unplug the car radio from the power before installation on CAN-Bus
radios of Renault, Peugeot/Citroen, Mazda (new) and Ford (new). Otherwise, AUX
Link car adapter may work improperly or the car radio may be damaged. As for
Peugeot/Citroen without pre-installed CD Changer, to enable AUX Link to work, the
CD Changer function must be activated by professional tools. Please find out with
the Peugeot/Citroen dealer the information on how to activate the CD Changer
function.
The CD Changer must be completely disconnected before installation on BMW
radios with CD Changer (the 3-pin and the 6-pin connector, that are located in the
trunk, must be disconnected). Otherwise, AUX Link will not be recognized. Besides,
specific AUX Link and extra DSP kit should be used if the BMW radios are with
DSP.
5. FUNCTIONS AND USAGE:
5.1 APPLICABLE STORAGE DEVICE:
AUX Link car adapter supports SD/SDHC/MMC cards, while USB slot
supports USB2.0 powered devices, such as USB card reader, USB Drive disk,
mobile Hard Drive, etc. AUX Link can support USB flash sticks and SD cards up to
16GB.
5.2 SUPPORTED MUSIC FILES:
AUX Link supports MP3 and WMA formats of music. So that to enjoy the best
sound quality, we highly suggest you playing music files of high compression ratio.
5.3 SUPPORTED FOLDER & TRACK QUANTITY:
AUX Link supports up to 99 folders with 99 files in each of them. (It’s possible
to save up to 1000 music files, but if your car radio can only display a maximum of

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
two digits for track number, track number 100 will be displayed as 01, track 101 as
02, track 102 as 03, etc.). Still most OEM radios can only identify 6-10 folders.
5.4 MUSIC FILE SAVING & PLAYING MODE:
AUX Link supports multi-folder playback. To be able to access the music, it is
crucial that the music files have been organized/saved into folders, named CD01,
CD02, CD03...CD99, which will be correspondingly displayed on the radio panel
screen. If there is no folder with the name "CD0X", all folders and songs will be
recognized as only one virtual CD disk. Any other folders or music files, not named
according to the above-mentioned rule, will not be recognized or played.
The naming of the tracks is unrestricted, and the playing order will be in line
with the time that music files were saved on the USB stick or SD card. Make sure
not to save music files in the sub directory folders, otherwise, music files will not be
identified or recognized.
5.5 AUX IN:
AUX IN port can be used to connect auxiliary audio equipment, such as
smartphones, MP3 players, tablets, PSPs, laptops via a 3.5mm audio mini jack.
Make sure to remove USB stick or SD card from the adapter before you use the
AUX IN. Otherwise, the playback will not automatically stop. When in AUX playback
status, the volume can be controlled via the head unit.
5.6 LAST POSITION MEMORY:
Car adapter AUX Link supports memory playback. So once you select
another type of playbacks from CD or AM/FM, or you power off the engine, the
adapter will memorize the disc and track number to MCU. When you return to the
playback status of the car adapter, the music playback will continue from the MCU
memorized point.
NOTE: The playback of music tracks via AUX IN does not support Last
Position Memory.

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
5.7 PLAYBACK FUNCTION CONTROLS:
The playback can be controlled with several functions:
SCAN
In order to play each track in the playlist for 10 seconds, press the “Scan”
button on the car stereo.
Random (Shuffle)
In order to play tracks from the current playlist in random order, press the
"RDM" random button (in some models this button is called "P scan").
Repeat
In order to repeat the playback of a current track, press the "Repeat" button.
Track Up/Down
In order to switch to the next song in the playlist, press the "NEXT" button.
To go to the beginning of the track that is currently played, press the "PREV" button.
To go to the previous song in the playlist, press twice the “Track down” button. In
case your OEM car stereo supports the maximum of two digits for numbers of
tracks, the track number 100 will be shown as 01, the track number 101 as 02, etc.
Fast Forward and Rewind
In order to seek within a single song, press the “Fast Forward”or “Fast
Reverse” button. Your new position within the song will be seen on the screen timer.
6. OTHER OPERATION INSTRUCTION
Please make sure to format SD card or USB stick with FAT or FAT32 format
before you save any files in SD/USB. You should remember to name the folders
according to the above-mentioned naming rules.

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
When you use AUX Link for the first time, you have to press CD (or
DISC/Mode/CDC/SRC/AUX) button once or twice to switch to the CD changer
mode, then AUX Link starts running.
When AUX Link starts working, the LED indicating light is on. It usually takes 3-
10 seconds to load music files before the playback starts. If the car radio is turned
on but it doesn’t work and the LED indicating light is not on, the car radio would
probably not be powered on, or AUX Link car adapter is not connected properly.
Once the Head Unit is OFF or you switch to FM, the LED indicating light would go off
and AUX Link would stop working.
The first track in next folder will start playing automatically, when playback of all
tracks in the current folder is finished.
The operation of AUX Link car adapter is nearly equal to that of the factory fitted
head unit, but some button functions of some factory radios might be altered.
However, this alteration would not affect the functions of the factory head unit or
existing CD changer.
For most vehicles, please press CD button once or twice to switch between
original CD radio and AUX Link car adapter.
The displayed track numbers may change unevenly, if the track up or track down
button is pressed quickly in repetition.
MP3/CDC Switch Cable is provided for existing CD Changer on vehicles except
for VAG cars. Power off your head unit or vehicle and switch between MP3 (AUX
Link) and CDC (Original CD changer). For some vehicles, you may have to restart
the radio for once after operation on MP3/CDC Switch.
Parallel Harness (without MP3/CDC switch) is provided for VAG vehicles. When
you are using AUX Link and want to switch to existing CD Changer, press FM/AM or
other audio playback mode button and then press CD button to switch to existing CD
Changer. And vice versa.

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
7. ADAPTER SPECIFICATIONS
Voltage Input: 11V~14.6V DC
Operating Temperatures: -35℃~+85℃
Total Harmonic Distortion: 0.05%
SN Ratio: 90dB
Operational Current: 200mA
Standby Current: 3mA
Frequency Response: 20HZ-20KHZ
DAC Resolution: 20bit
8. ADDITIONAL AUX LINK BLUETOOTH MODULE
AUX Link Bluetooth (Hands Free) module can be ordered together with AUX Link
car adapter. It provides music playback functions and call features through the
wireless connection.
The delivery kit includes:
AUX Link Bluetooth Module Unit;
Small external microphone;
Optional remote control button (plugged into the 3.5 mm jack of the module unit
remote control slot).
Installation:
Connect AUX Link Bluetooth module to the AUX Link car adapter Bluetooth slot.
Then connect the microphone to the microphone slot of the Bluetooth module. Place
the microphone near the driver’s cab to have better vocal effects. When the
installation is done, turn on the car audio and switch to AUX Link adapter playback
mode. When the AUX Link Bluetooth module will be successfully connected to the

AUX Link car adapter for USB flash and SD cards USER MANUAL
AUX Car Kits http://auxcarkits.com/
Copying or reprinting of this material without reference to the original source and reciprocal links are strictly prohibited
device with enabled Bluetooth, the LED indicator will start lighting. If the device with
enabled Bluetooth can’t find the AUX Link Bluetooth module, the Pairing Status will
be automatically enabled for the period of 3 minutes (the LED indicator will start fast
flashing). In 3 minutes the non-Pairing Status will be enabled, in which AUX Link
Bluetooth module is not recognized or searched (the LED indicator will start slow
flashing).
NOTE: Your device is supposed to have Bluetooth function enabled.
For more information read AUX Link Bluetooth Module user manual.
9. WARRANTY
All the items of the AUX Link car kit are guaranteed against manufacturing defects
for a period of twelve months from the date of purchase.
Important:
The software and hardware along with the function setting are subject to
change without prior notice.
For more information about our products, usage, updates and FAQs, please
visit our website at http://auxcarkits.com/
The trade mark and brand are protected by the law.
