Ava Charging Station
(Model AVA-CS)
Installation Instructions
Document # 5200003, revision B
© 2023-2018 Ava Robotics Inc. All Rights Reserved.
Ava® is a registered trademark of Ava Robotics Inc.
Ava Charging Station Installation Instructions
Regulatory and Safety Info
This product is certified to comply with IEC/UL/CSA 62368-1.
This product has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules.
This Class A digital apparatus complies with Canadian ICES-003.
This product was tested and complies with all the requirements for the CE Mark.
Disposal of this product should be handled according to local and national laws and
regulations.
Manufactured by Ava Robotics Inc., www.avarobotics.com.
Please read these safety instructions carefully before installing the Ava charging station:
●For indoor use only.
●Installation should comply with local and national building codes.
●Do not use the product if damaged.
●Follow all operating and use instructions.
DO NOT EXPOSE THE ELECTRONICS OF THIS CHARGING STATION. THERE ARE NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. PLEASE ENSURE VOLTAGE RATING FOR CHARGING STATION MATCHES
STANDARD OUTLET VOLTAGE.
This equipment is not suitable to be used in locations where
children are likely to be present.
Page 2 © 2023-2018 Ava Robotics
Ava Charging Station Installation Instructions
Electrical/Technical Ratings
Input Voltage: 100-240V ∿3.3-7A 50/60Hz
Output Voltage: 36V ⎓13A
Operating Temperature: 5 to 30°C
Operating Humidity: 20 to 85%
Space Considerations
The charging station should be installed in a location with the following characteristics:
●Level ground floor
●Power outlet within 1.8m/6ft.
●A flat wall with total 0.5m/1.5ft clearance on both sides, and no more than 1.8m/6ft
from a power outlet.
●The wall should not have protruding features up to 2m/6.5ft, and there should be
1.8m/6 ft of open space in front so that the robot can move off dock.
Page 3 © 2023-2018 Ava Robotics
Ava Charging Station Installation Instructions
Installation
The charging station ships pre-assembled inside of the robot's transport box.
Once you have removed the charging station from the transport box, proceed as follows:
1. Connect the power
cord to the charging
station at the
location shown.
2. Place the
charging
station at the
desired
location.
3. Plug the power
cord to the wall
outlet.
4. Route the power
cord along the
platform wall.
5. Excess cord can be
wrapped around
the spindle.
6. Push charging
station towards
wall, and verify
that the charging
station light is on.
