Ava CONDUIT BACK BOX Installation instructions manual

CONDUIT BACK BOX
Mounting guide

Ava Bullet - Conduit Back Box • Mounting guide | 2/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
Box contents
Required:
• T20 screwdriver
• Suitable fasteners for your wall
Conduit back box
Washer
Cover
L-key
(HEX 1.5mm)

Ava Bullet - Conduit Back Box • Mounting guide | 3/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
Installing the conduit back box
12 3

Ava Bullet - Conduit Back Box • Mounting guide | 4/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
Determine whether your camera features bracket type A or B4
Type A (Two lock screws) Type B (One lock screw)

Ava Bullet - Conduit Back Box • Mounting guide | 5/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
Bracket type A
A.5 A.6
A.7
Remove standard wall bracket Please refer to the bullet camera mounting guide for
cable management.
Lock the camera to the back box by tightening the 2x screws

Ava Bullet - Conduit Back Box • Mounting guide | 6/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
Bracket type B
B.5 Loosen small set screw using
the supplied L-key
Loosen the M6 set screw (T20) Loosen the M6 set screw on the
opposite side (T20)
B.6 Remove original bracket parts B.7 Insert the included washer and
assemble the new cover.

Ava Bullet - Conduit Back Box • Mounting guide | 7/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
B.8 Tighten the M6 set screw (T20) Tighten the M6 set screw (T20)
on the opposite side
The smallest set screw should sit right
below lush (not tightened properly)

Ava Bullet - Conduit Back Box • Mounting guide | 8/8
Copyright © 2022, Ava Video Security. All rights reserved.AVA-CON-BCK-MG-01
B.9 Please refer to the bullet camera mounting
guide for cable management.
Lock the camera to the back box by
tightening the 2x screws
B.10
