Avalue Technology IPM-21 User manual

Part No. E2017IP21A1R
IPM-21
21.5" Fanless IP Monitor
Quick Reference Guide
2nd Ed –24 October, 2018
Copyright Notice
Copyright © 2018 Avalue Technology Inc., ALL RIGHTS RESERVED.

IPM-21
2 IPM-21 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2018 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide
IPM-21 Quick Reference Guide
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

IPM-21
4 IPM-21 Quick Reference Guide
Content
1. Getting Started............................................................................................................5
1.1 Safety Precautions ................................................................................................5
1.2 Packing List...........................................................................................................5
1.3 System Specifications ...........................................................................................6
1.4 System Overview...................................................................................................9
1.4.1 Rear View....................................................................................................................9
1.4.2 Membrane ...................................................................................................................9
1.5 System Dimensions.............................................................................................10

Quick Reference Guide
IPM-21 Quick Reference Guide
5
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x IPM-21 Fanless IP Monitor
1 x packing set includes the followings
—1 x adapter
—1 x Power cord

IPM-21
6 IPM-21 Quick Reference Guide
1.3 System Specifications
Component
Mother Board
Mother Board and I/O Board of IPM-1003
HDMI in
HDMI input connector (HDMI monitor)
Memory
on board 1GB DDR2 memory
Audio
Yes (source from Box PC)
Power Supply
DC in
Adapter
60W 12V/5A
System Fan
Fanless
Speaker
2 x 2W Speakers
Panel
LCD Panel
21.5” with PACP (w/ Touch Controller)
B/L
Inverter/Converter
LED Driver Board UNITED LINK
Others
Membrane for power/ volume/ brightness
External I/O
USB Port
3 x USB2.0 Ports for external peripherals in lower connector recess (Through
PCI to USB2.0 Chip)
Video Port
1 x HDMI out on RX module when Tx’s HDMI signal not direct input the scale IC
(Optional) Chassis Knock-out hole
1 x HDMI input on Rx Module
Audio Port
1 x 3.5mm stereo jack
Others
1 x RJ45 port for DoE only
Mechanical
Power Typer
+12 ~ 26V DC in
Power Connector
Type
DC Jack
Dimension
303.3 mm x 505 mm x 41.7mm
Weight
5 kg
Color
Metal housing black
Fanless
Yes
Reliability
EMI Test
CE/FCC Class A
Safety
UL/CB design compatible
Dust and Rain
Test
IP-65(Front Panel) design compatible
Vibration Test
Sine Vibration test (Non-operation)

Quick Reference Guide
IPM-21 Quick Reference Guide
7
Test Fc : Vibration sinusoidal
1. Test Acceleration : 2G
2. Test frequency : 5 ~ 500 Hz
3. Sweep：1 Oct/ per one minute. (logarithmic)
4. Test Axis : X,Y and Z axis
5. Test time :10 min. each axis
6. System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package Vibration Test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
6. IEC 60068-2-64 Test:Fh
Random Vibration Operation
1. PSD: 0.0505G²/Hz, 1.5 Grms
2. operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
7. Storage : N/A
Mechanical Shock
Test
Bump Test
1. Wave form：Half Sine wave
2. Acceleration Rate：10g for operation mode
3. Duration Time：11ms
4. No. of Shock：Z axis 300 times
5. Test Axis: Z axis
6. Operation mode
7. Reference IEC 60068-2-29 Testing procedures Test Eb : Bump Test
Drop Test
Packing Drop
1. One corner , three edges, six faces
2. ISTA 2A, IEC-60068-2-32 Test:Ed
Operating
Temperature
0°C ~ 50°C (32°F ~ 122°F), ambient w/ air flow
Operating
Humidity
5 ~ 90% Relative Humidity, Non-condensing

IPM-21
8 IPM-21 Quick Reference Guide
Storage
Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Note: Specifications are subject to change without notice.
Remark:
When HDMI monitor is connected to HDMI-out connector, the content from Display Over Ethernet (DoE) is
switched to HDMI monitor and the content from HDMI-In remains on IP monitor screen.

Quick Reference Guide
IPM-21 Quick Reference Guide
9
1.4 System Overview
1.4.1 Rear View
1.4.2 Membrane
Connectors
Label
Function
Note
HDMI-IN
HDMI-IN connector
HDMI-OUT
HDMI-OUT connector
DC IN
DC Power-in connector
LAN
RJ45 Gigabit Ethernet(with Powered LAN)
connector
Audio
Audio connector
USB
3 x USB 2.0 connector
Reset
Reset button

IPM-21
10 IPM-21 Quick Reference Guide
1.5 System Dimensions
(Unit: mm)
