Avalue Technology ACP-PNVDV-A1-DCR User manual

Part No. E2017PNVD00R
ACP-PNVDV-A1-DCR
Intel ATOM Mini ITX Motherboard
Quick Installation Guide
1st Ed –29 October 2012

ACP-PNVDV-A1-DCR Quick Installation Guide
2 ACP-PNVDV-A1-DCR Quick Installation Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Headquarters and Branch
Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei,
Taiwan
Tel:[phone]
Fax: [phone]
Information:[e-mail]
Service: [e-mail]
Avalue Technology Inc.
9 Timber Lane, Marlboro, NJ 07746-1443
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Service: [e-mail]
BCM Advanced Research
Avalue Europe
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: sales.e[email protected]
Service: service.europ[email protected]
Avalue China
Avalue Japan
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: sales.chi[email protected]n
Service: [e-mail]
Avalue Technology Inc.
3F Ishiyama-Bldg, 1-6-1 Taito,
Taito-ku, Tokyo 110-0016 Japan
Tel: [phone]
Fax: [phone]
Information: sales.japa[email protected]
Service: [e-mail]

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 3
Content
1. Getting Started............................................................................................................4
1.1 Safety Precautions .........................................................................................4
1.2 Packing List....................................................................................................4
2. Hardware Configuration.............................................................................................5
2.1 Product Overview...........................................................................................6
2.2 Jumper and Connector List ............................................................................7
2.3 Setting Jumpers & Connectors.......................................................................9
2.3.1 AT/ATX power mode select (JAT/ATX1)..................................................9
2.3.2 Serial port 1 pin9 signal selector (JRI1)....................................................9
2.3.3 Serial port 2 pin9 signal selector (JRI2)..................................................10
2.3.4 CF/IDE Master/SLAVE Selector (JCFMS1)............................................10
2.3.5 SATA Dom power jumper 1 (JSTDP1)...................................................11
2.3.6 SATA Dom power jumper 2 (JSTDP2)...................................................11
2.3.7 Clear CMOS (JRTC1) ............................................................................12
2.3.8 Serial port 2 in RS-422/485 mode (J422_485).......................................12
2.3.9 Serial port connector 2 (JCOM2)............................................................13
2.3.10 General purpose I/O connector (DIO1) ................................................13
2.3.11 Keyboard/Mouse connector (KBMS2)..................................................14
2.3.12 Miscellaneous settings connector (JFTP1)...........................................14
2.3.13 Low Pin Count connector (JLPC1).......................................................15
2.3.14 USB connector 1 (JUSB1)....................................................................15
2.3.15 USB connector 2 (JUSB2)....................................................................16
2.3.16 SPI connector (SPI1)............................................................................16
2.3.17 DC-IN power connector (PWR2)..........................................................17
2.3.18 System Fan connector (SYS_FAN1)....................................................17
2.3.19 Serial ATA power connector 1~2 (SATAP1/2)......................................18
2.3.20 CPU fan connector 1 (CPU_FAN1)......................................................18
2.3.21 Audio connector (JAUD1).....................................................................19
2.3.21.1 Signal Description –Audio connector (JAUD1)................................................. 19
2.3.22 Primary IDE connector (IDE1)..............................................................20

ACP-PNVDV-A1-DCR Quick Installation Guide
4 ACP-PNVDV-A1-DCR Quick Installation Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x ACP-PNVDV-A1-DCR Intel ATOM Mini ITX Motherboard
1 x Quick Installation Guide for ACP-PNVDV-A1-DCR
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
1 x Cable set contains the followings:
—1 x Wire SATA Power (15P/1.27-4P/5.08)
—1 x Serial ATA Cable (7P/1.27mm-7P/1.2)
1 x I/O Shield

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 5
2.Hardware
Configuration

ACP-PNVDV-A1-DCR Quick Installation Guide
6 ACP-PNVDV-A1-DCR Quick Installation Guide
2.1 Product Overview

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 7
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JRI1
Serial port 1 pin9 signal selector
3 x 2 header, pitch 2.00 mm
JRI2
Serial port 2 pin9 signal selector
3 x 2 header, pitch 2.00 mm
JAT/ATX1
AT/ ATX power mode select
3 x 1 header, pitch 2.00mm
JCFMS1
CF/IDE Master/SLAVE Selector
3 x 1 header, pitch 2.00 mm
JSTDP1~2
SATA Dom power jumper 1~2
3 x 1 header, pitch 2.00 mm
JRTC1
Clear CMOS
3 x 1 header, pitch 2.00 mm
Connectors
Label
Function
Note
BAT1
Battery holder

ACP-PNVDV-A1-DCR Quick Installation Guide
8 ACP-PNVDV-A1-DCR Quick Installation Guide
J422_485
Serial port 2 in RS-422/485 mode
3 x 2 header, pitch 2.54 mm
JCOM2
Serial port connector 2
5 x 2 header, pitch 2.54 mm
DIMM1
204-pin SODIMM DDR3 connector
DIO1
General purpose I/O connector
10 x 2 header, pitch 2.54 mm
IDE1
Primary IDE connector
KBMS2
Keyboard/Mouse connector
4 x 2 header, pitch 2.54mm
JFTP1
Miscellaneous settings connector
5 x 2 header, pitch 2.54mm
JLPC1
Low Pin Count connector
5 x 2 header, pitch 2.00mm
JUSB1
USB connector 1
5 x 2 header, pitch 2.54mm
JUSB2
USB connector 2
5 x 2 header, pitch 2.54mm
SATA1~2
Serial ATA connector 1~2
SPI1
SPI connector
4 x 2 header, pitch 2.54mm
PWR2
DC-IN power connector
2 x 2 wafer, pitch 4.20mm
SYS_FAN1
System Fan connector 1
3 x 1 wafer, pitch 2.54mm
PCIE1
PCI Express connector 1
AUDIO1
Audio connector
JAUD1
Audio connector
5 x 2 header, pitch 2.54mm
ESATA1
ESATA connector 1
LAN_USB1~2
LAN_USB connectors 1~2
VGA_COM1
VGA_COM connector 1
SATAP1~2
Serial ATA power connector 1~2
4 x 1 wafer, pitch 2.54mm
CPU_FAN1
CPU fan connector 1
3 x 1 wafer, pitch 2.54mm
MPCIE1
Mini-PCI connector 1

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 9
2.3 Setting Jumpers & Connectors
2.3.1 AT/ATX power mode select (JAT/ATX1)
* Default
ATX*
AT
2.3.2 Serial port 1 pin9 signal selector (JRI1)
* Default
Ring*
+5V
+12V
Signal
PIN
PIN
Signal
PNRI#_A
6
5
+12V
PNRI#_A
4
3
+5V
PNRI#_A
2
1
NRI#_A

ACP-PNVDV-A1-DCR Quick Installation Guide
10 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.3 Serial port 2 pin9 signal selector (JRI2)
* Default
Ring*
+5V
+12V
Signal
PIN
PIN
Signal
NRI#_B
1
2
PNRI#_B
+5V
3
4
PNRI#_B
+12V
5
6
PNRI#_B
2.3.4 CF/IDE Master/SLAVE Selector (JCFMS1)
* Default
CF-MASTER, IDE-SLAVE*
CF-SLAVE, IDE-MASTER
Signal
PIN
IDE_SEL#
3
GND
2
CF_SEL#
1

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 11
2.3.5 SATA Dom power jumper 1 (JSTDP1)
* Default
SATA CABLE*
SATA DOM
Signal
PIN
GND
3
SATADIMP1
2
+V5_SATA1
1
2.3.6 SATA Dom power jumper 2 (JSTDP2)
* Default
SATA CABLE*
SATA DOM
Signal
PIN
GND
3
SATADIMP2
2
+V5_SATA2
1

ACP-PNVDV-A1-DCR Quick Installation Guide
12 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.7 Clear CMOS (JRTC1)
* Default
Normal Operation *
Clear CMOS
Signal
PIN
NC
1
RTC_RST#
2
GND
3
2.3.8 Serial port 2 in RS-422/485 mode (J422_485)
Signal
PIN
PIN
Signal
485TXB-
1
2
485RXB-
485TXB+
3
4
485RXB+
+V5_COM2
5
6
GND

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 13
2.3.9 Serial port connector 2 (JCOM2)
Signal
PIN
PIN
Signal
NDCD#_B
1
2
NRXD_B
NTXD_B
3
4
NDTR#_B
GND
5
6
NDSR#_B
NRTS#_B
7
8
NCTS#_B
PNRI#_B
9
10
NC
2.3.10 General purpose I/O connector (DIO1)
Signal
PIN
PIN
Signal
DI0
1
2
DO0
DI1
3
4
DO1
DI2
5
6
DO2
DI3
7
8
DO3
DI4
9
10
DO4
DI5
11
12
DO5
DI6
13
14
DO6
DI7
15
16
DO7
SMB_CLK_V5
17
18
SMB_DAT_V5
GND
19
20
+5V

ACP-PNVDV-A1-DCR Quick Installation Guide
14 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.11 Keyboard/Mouse connector (KBMS2)
Signal
PIN
PIN
Signal
KB_DT
1
2
KB_CK
GND
3
4
+V5_KBMS
MS_DT
5
6
MS_CK
NC
7
2.3.12 Miscellaneous settings connector (JFTP1)
Signal
PIN
PIN
Signal
+3.3V
1
2
PWR_LED+
HDD_LED
3
4
GND
GND
5
6
POWER Button
SYS_RESET#
7
8
GND
NC
9

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 15
2.3.13 Low Pin Count connector (JLPC1)
Signal
PIN
PIN
Signal
GND
10
9
PCI_SERIRQ
CLK_LPC
8
7
LPC_AD3
LPC_FRAME#
6
5
LPC_AD2
PLT_RST#
4
3
LPC_AD1
+3.3V
2
1
LPC_AD0
2.3.14 USB connector 1 (JUSB1)
Signal
PIN
PIN
Signal
NC
10
GND
8
7
GND
USB_D+
6
5
USB_D+
USB_D-
4
3
USB_D-
+5V
2
1
+5V

ACP-PNVDV-A1-DCR Quick Installation Guide
16 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.15 USB connector 2 (JUSB2)
Signal
PIN
PIN
Signal
NC
10
GND
8
7
GND
USB_D+
6
5
USB_D+
USB_D-
4
3
USB_D-
+5V
2
1
+5V
2.3.16 SPI connector (SPI1)
Signal
PIN
PIN
Signal
+3.3V
1
2
GND
SPI_CS0#
3
4
SPI_CLK
SPI_SO
5
6
SPI_SI
SPI_HOLD#
7

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 17
2.3.17 DC-IN power connector (PWR2)
Signal
PIN
PIN
Signal
+VDC_INP
3
1
GND
+VDC_INP
4
2
GND
2.3.18 System Fan connector (SYS_FAN1)
Signal
PIN
GND
1
SYSFAN_PWR
2
SYSFANIN
3

ACP-PNVDV-A1-DCR Quick Installation Guide
18 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.19 Serial ATA power connector 1~2 (SATAP1/2)
Signal
PIN
+5V
1
GND
2
GND
3
+12V
4
2.3.20 CPU fan connector 1 (CPU_FAN1)
Signal
PIN
GND
1
CPUFAN_PWR
2
CPUFANIN
3
SATAP2
SATAP1

ACP-PNVDV-A1-DCR Quick Installation Guide
ACP-PNVDV-A1-DCR Quick Installation Guide 19
2.3.21 Audio connector (JAUD1)
Signal
PIN
PIN
Signal
MIC2-L-IN
1
2
GND
MIC2-R-IN
3
4
ACZ_DET#
LINE2-R-OUT
5
6
MIC2_SJD
FRONT-IO-SENSE
7
LINE2-L-OUT
9
10
LINE2_SJD
2.3.21.1 Signal Description –Audio connector (JAUD1)
Signal
Signal Description
LINE2_SJD
AUDIO Out (ROUT/LOUT) sense pin
MIC2_JD
MIC IN (MIC_RIN/LIN) sense pin
ACZ_DET#
Detect if there is Front Audio board contected
FRONT-IO-SENSE
Detect whether MIC2 or LINE2 is contected or not

ACP-PNVDV-A1-DCR Quick Installation Guide
20 ACP-PNVDV-A1-DCR Quick Installation Guide
2.3.22 Primary IDE connector (IDE1)
Signal
PIN
PIN
Signal
IDE_RST#
1
2
GND
IDE_PDD7
3
4
IDE_ PDD8
IDE_ PDD6
5
6
IDE_ PDD9
IDE_ PDD5
7
8
IDE_ PDD10
IDE_ PDD4
9
10
IDE_ PDD11
IDE_ PDD3
11
12
IDE_ PDD12
IDE_ PDD2
13
14
IDE_ PDD13
IDE_ PDD1
15
16
IDE_ PDD14
IDE_ PDD0
17
18
IDE_PDD15
GND
19
20
NC
IDE_PDDREQ
21
22
GND
IDE_PDIOW#
23
24
GND
IDE_PDIOR#
25
26
GND
IDE_PIORDY
27
28
IDE_SEL#
IDE_PDDACK#
29
30
GND
IDE_PINTRQ
31
32
NC
IDE_PDA1
33
34
IDE_PDIAG
IDE_PDA0
35
36
IDE_PDA2
IDE_PDCS1#
37
38
IDE_PDCS3#
IDE_ACT#
39
40
GND
+5V
41
42
+5V
GND
43
44
NC
