Avalue Technology EMX-BYT3 User manual

Part No. E2047MXT301R
EMX-BYT3
Intel ® Atom™ Celeron® J1900 D1 Processor Mini ITX
Motherboard
User’s Manual
2nd Ed –17 April 2019

EMX-BYT3 User’s Manual
2 EMX-BYT3 User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2019 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

User’s Manual
EMX-BYT3 User’s Manual
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

EMX-BYT3 User’s Manual
4 EMX-BYT3 User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU type and speed, Avalue’s products model name, hardware & BIOS
revision number, other hardware and software used, etc.) Note anything
abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material
authorization) number from your dealer. This allows us to process your good
return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the
purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.

User’s Manual
EMX-BYT3 User’s Manual
5
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions....................................................................................................8
1.2 Packing List...............................................................................................................8
1.3 Document Amendment History .................................................................................9
1.4 Manual Objectives...................................................................................................10
1.5 System Specifications.............................................................................................11
1.6 Architecture Overview—Block Diagram..................................................................14
2. Hardware Configuration...........................................................................................15
2.1 Product Overview....................................................................................................16
2.2 Jumper and Connector List.....................................................................................17
2.3 Setting Jumpers & Connectors ...............................................................................19
2.3.1 Serial port 1/2 pin9 signal select (JRI1/JRI2)................................................................................. 19
2.3.2 SATA2/MSATA1 mPCIe slot selector (JMSW1)............................................................................ 19
2.3.3 LVDS Back Light power selection (JSBKL1).................................................................................. 20
2.3.4 AT/ATX Power Mode Select (JSATX1).......................................................................................... 20
2.3.5 Clear CMOS (CMOS1)................................................................................................................... 21
2.3.6 LCD Inverter connector (JBKL1).................................................................................................... 21
2.3.7 Serial port 1~4 connector (COM14)............................................................................................... 22
2.3.8 Serial port 5~8 connector (COM58)............................................................................................... 23
2.3.9 Serial Port 1 RS485/422 Mode connector (JRS485) ..................................................................... 24
2.3.10 Serial Port 2 RS485/422 Mode connector (J2RS485)................................................................... 24
2.3.11 General purpose I/O connector (DIO1) ......................................................................................... 25
2.3.12 SATA Power connector 1/2 (SPWR1/2)........................................................................................ 25
2.3.13 Power connector 1 (PWR1)........................................................................................................... 26
2.3.14 Power connector 2 (PWR2)........................................................................................................... 26
2.3.15 LVDS connector (LVDS1).............................................................................................................. 27
2.3.16 Front Audio connector (FAUD1).................................................................................................... 28
2.3.16.1 Signal Description –Front Audio connector (FAUD1)............................................................ 28
2.3.17 LPC connector (JLPC1)................................................................................................................. 28
2.3.18 EC_Program (EC1)........................................................................................................................ 29
2.3.19 PS/2 keyboard & mouse connector (KBMS1) ............................................................................... 29
2.3.20 BIOS connector (BIOS1) ............................................................................................................... 30
2.3.21 Sony/Philips Digital Interface (SPDIF1)......................................................................................... 30
2.3.22 Speaker connector (SPK1)............................................................................................................ 31
2.3.23 Miscellaneous setting connector 1 (FPT1).................................................................................... 31

EMX-BYT3 User’s Manual
6 EMX-BYT3 User’s Manual
2.3.24 Miscellaneous setting connector 2 (FPT2).................................................................................... 32
2.3.25 LED indicator connector 1 (LED1)................................................................................................. 32
2.3.26 LED indicator connector 2 (LED2)................................................................................................. 33
2.3.27 CPU fan connector (FAN1)............................................................................................................ 33
2.3.28 Battery connector (BT1) ................................................................................................................ 34
2.3.29 USB connector 3 (USB3)............................................................................................................... 34
3.BIOS Setup....................................................................................................................35
3.1 Introduction .............................................................................................................36
3.2 Starting Setup .........................................................................................................36
3.3 Using Setup ............................................................................................................37
3.4 Getting Help............................................................................................................38
3.5 In Case of Problems................................................................................................38
3.6 BIOS setup..............................................................................................................39
3.6.1 Main Menu...................................................................................................................................... 39
3.6.1.1 System Language.................................................................................................................. 40
3.6.1.2 System Date.......................................................................................................................... 40
3.6.1.3 System Time.......................................................................................................................... 40
3.6.2 Advanced Menu ............................................................................................................................. 40
3.6.2.1 Trusted Computing................................................................................................................ 41
3.6.2.2 APCI Settings ........................................................................................................................ 41
3.6.2.3 IT8528 Super IO Configuration.............................................................................................. 42
3.6.2.3.1 Serial Port 1 Configuration .................................................................................................... 43
3.6.2.3.2 Serial Port 2 Configuration .................................................................................................... 44
3.6.2.3.3 Serial Port 3 Configuration .................................................................................................... 45
3.6.2.3.4 Serial Port 4 Configuration .................................................................................................... 45
3.6.2.3.5 Serial Port 5 Configuration .................................................................................................... 46
3.6.2.3.6 Serial Port 6 Configuration .................................................................................................... 46
3.6.2.3.7 Serial Port 7 Configuration .................................................................................................... 47
3.6.2.3.8 Serial Port 8 Configuration .................................................................................................... 47
3.6.2.4 H/W Monitor........................................................................................................................... 48
3.6.2.5 S5 RTC Wake Settings.......................................................................................................... 48
3.6.2.6 Serial Port Console Redirection ............................................................................................ 49
3.6.2.7 CPU Configuration................................................................................................................. 49
3.6.2.7.1 Socket 0 CPU Information..................................................................................................... 51
3.6.2.8 PPM Configuration................................................................................................................. 51
3.6.2.9 IDE Configuration .................................................................................................................. 52
3.6.2.10 Network Stack Configuration................................................................................................. 53
3.6.2.11 CSM Configuration ................................................................................................................ 53
3.6.2.12 USB Configuration................................................................................................................. 54
3.6.2.13 Security Configuration ........................................................................................................... 55

User’s Manual
EMX-BYT3 User’s Manual
7
3.6.2.14 Driver Health.......................................................................................................................... 56
3.6.3 Chipset.......................................................................................................................................... 56
3.6.3.1 North Bridge......................................................................................................................... 57
3.6.3.1.1 Intel IGD Configuration.......................................................................................................... 57
3.6.3.1.2 IGD - LCD Control ................................................................................................................. 58
3.6.3.2 South Bridge........................................................................................................................ 60
3.6.3.2.1 Azalia HD Audio..................................................................................................................... 60
3.6.3.2.2 USB Configuration................................................................................................................. 61
3.6.3.2.3 PCI Express Configuration .................................................................................................... 62
3.6.4 Security......................................................................................................................................... 62
3.6.4.1 Secure Boot menu............................................................................................................... 63
3.6.4.1.1 Key Management................................................................................................................... 64
3.6.5 Boot .............................................................................................................................................. 64
3.6.6 Save and exit................................................................................................................................ 65
4. Drivers Installation.......................................................................................................67
4.1 Install Chipset Driver...............................................................................................68
4.2 Install TXE Driver....................................................................................................69
4.3 Install VGA Driver....................................................................................................70
4.4 Install Audio Driver..................................................................................................71
4.5 Install Ethernet Driver..............................................................................................72
4.6 Install USB 3.0 Driver..............................................................................................73
4.7 Install MBI Driver.....................................................................................................74
5. Mechanical Drawing ....................................................................................................75

EMX-BYT3 User’s Manual
8 EMX-BYT3 User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x EMX-BYT3 motherboard
2 x SATA cables
1 x I/O Shield
1 x SATA Power Cable

User’s Manual
EMX-BYT3 User’s Manual
9
1.3 Document Amendment History
Revision
Date
By
Comment
1st
December 2017
Avalue
Initial Release
2nd
April 2019
Avalue
Update EMX-BYT3 Description

EMX-BYT3 User’s Manual
10 EMX-BYT3 User’s Manual
1.4 Manual Objectives
This manual describes in details Avalue Technology EMX-BYT3 Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to set up
EMX-BYT3 or change the standard configurations. Whilst all the necessary information is
available in this manual we would recommend that unless you are confident, you contact
your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors regarding this manual and want to inform us
of these, please contact our Customer Service department with the relevant details.

User’s Manual
EMX-BYT3 User’s Manual
11
1.5 System Specifications
System
CPU
Onboard Intel® Celeron® Processor J1000 Series for Desktop
Onboard Intel® Celeron® Processor N2000 Series for Mobile
BIOS
AMI uEFI BIOS, 64/128 Mbit SPI Flash ROM
I/O Chip
EC IT8528E
System Memory
2 x 204-pin DDR3L 1333MHz SODIMMs, up to 8GB
Watchdog Timer
H/W Reset, 1sec. –65535sec./min.1sec. or 1min. step
H/W Status
Monitor
CPU temperature monitoring
Voltages monitoring
CPU fan speed control
Expansion
1 x full size Mini PCI-e support mSATA only (SATA II and mSATA Switchable
Through jumper)
1 x full size Mini PCI-e support WiFi or communication module or 1 x PCI-e x1 slot
Switchable Through by switch IC & BIOS (either one)
1 x SIM card slot
S3/S4
Yes (S0/S3/S4/S5)
I/O
USB
4 x USB 3.0, 2 x USB 2.0
GPIO
16-bits GPIO
Display
Resolution
HDMI: 1920x1200 @60Hz
VGA: 2560 x 1600 @ 60 Hz
2CH 18/24bits LVDS 1920 x 1080
Chrontel. CH7511B eDP to LVDS Converter
HDMI +LVDS, HDMI+VGA, VGA+LVDS
Multiple Display
Dual Display
HDMI
1 x HDMI
LCD Interface
2CH 18/24bits LVDS 1920 x 1080
Audio
AC97 Codec
Realtek ALC662 HD Audio Decoding Controller
Audio Amp
Realtek ALC105 3W x 2
Audio Codec
Realtek ALC662 HD Audio Decoding Controller with 3W Amplifier
Ethernet
LAN Chip
2 x Intel I211AT PCI-Express Gigabit Ethernet
Ethernet
Interface
10/100/1000 Gigabit Ethernet

EMX-BYT3 User’s Manual
12 EMX-BYT3 User’s Manual
Internal I/O
Connectors
Fan
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
Buzzer
Yes
CMOS Battery
1 x horizontal type battery connector (Battery cable 170mm length)
Power ON
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 1
1 x 2 x 6 pin, pitch 2.54mm connector for front panel 2
Audio
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
Internal I/O
Connector
Optional Onboard Infineon SLB9665 support TPM 2.0(co-lay TPM 1.2)
COM 1 & 2: Support 422/485 selected by BIOS selection
- 2 x 2 x 3 pin, pitch 2.00mm connector, support RS422/485 connector, Pin 5 with
+5V
COM 1~4
- 1 x 2 x 20 pin, pitch 2.00mm connector for COM 1~4 support RS-232 connector
COM 5~8
- 1 x 2 x 20 pin, pitch 2.00mm connector for COM 5~8: support RS-232 connector
Storage:
- 1 x full size Mini PCI-e support mSATA only (SATA II and mSATA Switchable
Through jumper)
- 2 x SATA power connectors
1 x full size Mini PCI-e support WiFi or communication module or 1 x PCI-e x1 slot
Switchable Through by switch IC & BIOS (either one)
1 x SIM card Slot
1 x 2 x 5 pin, pitch 2.54mm connector for 2 USB 2.0
1 x 2 x 10 pin, pitch 2.00mm connector for GPIO: 16 bits & +3.3S Level SMBus
1 x 2 x 4 pin, pitch 2.00mm connector for BIOS SPI
1 x 2 x 4 pin, pitch 2.00mm connector for EC SPI
1 x 2 x 5 pin, pitch 2.0mm connector for LPC
1 x horizontal type battery connector (Battery cable 170mm length)
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 1
1 x 2 x 6 pin, pitch 2.54mm connector for front panel 2
1 x 2 x 20 pin, pitch 1.25mm connector for LVDS (must be using DF13-2S-1.25C
connector)
1 x 1 x 5 pin, pitch 2.00mm Wafer connector for LCD inverter backlight connector
(5V/12V)
1 x 3 pin, pitch 2.54mm connector LCD backlight brightness adjustment (PWM/DC)
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
1 x 3 pin, pitch 2.54mm connector for S/PDIF
1 x 4 pin, pitch wafer 2.00mm connector for 3W x 2 Speaker
1 x 2 x 5 pin, pitch 2.00mm connector for Keyboard & Mouse

User’s Manual
EMX-BYT3 User’s Manual
13
1 x 3 pin ,pitch 2.00mm connector for CMOS clear
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
2 x 1 x 4 pin, pitch 2.00mm connector for LAN Activity Indicator LED
1 x 2 x 2 pin, pitch 4.20mm connector for power input connector
1 x 1 x 3 pin, pitch 2.54mm connector for AT/ATX mode Fanless Operating
Mechanical &
Environmental
Power
Requirement
DC in +12 ~ 24V
ACPI
Single power ATX Support S0, S3, S4, S5
Power Type
AT/ATX mode
Operating Temp.
0 ~ 60°C (32 ~ 140°F)
Storage Temp.
-40 ~ 75°C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Size (L x W)
6.7" x 6.7" (170mm x 170mm)
Weight
0.4 kg
OS Support
BIOS Support:
1. Win7 64bit CSM mode
2. Win 10 UEFI mode
Note: Specifications are subject to change without notice.

EMX-BYT3 User’s Manual
14 EMX-BYT3 User’s Manual
1.6 Architecture Overview—Block Diagram
The following block diagram shows the architecture and main components of EMX-BYT3.

User’s Manual
EMX-BYT3 User’s Manual
15
2. Hardware
Configuration

EMX-BYT3 User’s Manual
16 EMX-BYT3 User’s Manual
2.1 Product Overview

User’s Manual
EMX-BYT3 User’s Manual
17
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JRI1/2
Serial port 1/2 pin9 signal select
3 x 2 header, pitch 2.00mm
JMSW1
SATA2/MSATA1 mPCIe slot selector
6 x 2 header, pitch 2.00mm
JSBKL1
LVDS Back Light power selection
3 x 1 header, pitch 2.54mm
JSATX1
AT/ATX Power Mode Select
3 x 1 header, pitch 2.54mm
CMOS1
Clear CMOS
3 x 1 header, pitch 2.00mm
Connectors
Label
Function
Note
FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54mm
FPT1
Miscellaneous setting connector 1
5 x 2 header, pitch 2.54 mm
FPT2
Miscellaneous setting connector 2
5 x 2 header, pitch 2.54 mm
DIMM1/2
204-pin DDR3L DIMM socket

EMX-BYT3 User’s Manual
18 EMX-BYT3 User’s Manual
FAUD1
Front Audio connector
5 x 2 header, pitch 2.54 mm
JBKL1
LCD Inverter connector
5 x 1 wafer, pitch 2.00mm
BIOS1
BIOS connector
4 x 2 header, pitch 2.00 mm
COM14
Serial Port 1~4 connector
20 x 2 header, pitch 2.00mm
COM58
Serial Port 5~8 connector
20 x 2 header, pitch 2.00mm
DIO1
General purpose I/O connector
10 x 2 header, pitch 2.00mm
SPK1
Speaker connector
1 x 4 wafer, pitch 2.00 mm
LVDS1
LVDS Connector
DIN 40-pin wafer, pitch 1.25mm
USB1/2
USB connector 1/2
USB3
USB connector 3
5 x 2 header, pitch 2.54mm
SPDIF1
Sony/Philips Digital Interface
3 x 1 header, pitch 2.54 mm
LAN1/2
RJ-45 Ethernet 1/2
PCIE1
PCIe connector
LED1
LED indicator connector 1
4 x 1 header, pitch 2.00mm
LED2
LED indicator connector 2
4 x 1 header, pitch 2.00mm
KBMS1
PS/2 keyboard & mouse connector
5 x 2 header, pitch 2.00 mm
BT1
Battery connector
2 x 1 wafer, pitch 1.25mm
MSATA1
Full size mPCIe Slot
JRS485
Serial Port 1 RS485/422 Mode
connector
3 x 2 header, pitch 2.00 mm
J2RS485
Serial Port 2 RS485/422 Mode
connector
3 x 2 header, pitch 2.00 mm
JLPC1
LPC connector
5 x 2 header, pitch 2.00mm
DC1
DC Power-in connector
PWR1
Power connector 1
2 x 2 wafer, pitch 4.20mm
PWR2
Power connector 2
2 x 1 terminal, pitch 3.81mm
SATA1/2
Serial ATA connector 1/2
SPWR1/2
SATA Power connector 1/2
4 x 1 wafer, pitch 2.54mm
EC1
EC_Program
5 x 2 header, pitch 2.00 mm
HDMI1
HDMI connector
LOUT1
Line-out audio jack
MIC1
Mic-in audio jack
VGA1
VGA connector

User’s Manual
EMX-BYT3 User’s Manual
19
2.3 Setting Jumpers & Connectors
2.3.1 Serial port 1/2 pin9 signal select (JRI1/JRI2)
* Default
Ring*
+5V
+12V
2.3.2 SATA2/MSATA1 mPCIe slot selector (JMSW1)
* Default
Note:
SATA2/MSATA1 shared SATA signal, can not be used
simultaneously.
SATA2 Connector*
(SATA2 Connector enabled, MSATA1 slot Disabled)
MSATA1 mPCIe slot
(MSATA1 slot enabled, SATA2 Connector Disabled)
JRI1
JRI2

EMX-BYT3 User’s Manual
20 EMX-BYT3 User’s Manual
2.3.3 LVDS Back Light power selection (JSBKL1)
* Default
PWM Mode*(Max current: 2A)
DC Mode(Max current: 2A)
2.3.4 AT/ATX Power Mode Select (JSATX1)
* Default
ATX*
AT
