Avalue Technology ECM-US15WP User manual

Part No. 2017381800R
ECM-US15WP
3.5" Intel® Atom™ processor Z510P / Z530P Micro Module
Quick Installation Guide
1st Ed – 11 September 2009

ECM-US15WP Quick Installation Guide
2 ECM-US15WP Quick Installation Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright ©2009 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
A Message to the customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.

Quick Installation Guide
ECM-US15WP Quick Installation Guide
3
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/
Headquarters and Branch
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei, Taiwan
Tel: [phone] Fax: [phone]
Information: [email protected] Service:[email protected]
Avalue USA Avalue Europe
Avalue Technology Inc.
200 Tornillo Way, Suite 210, Tinton Falls,
NJ 07712
Tel: [phone]
Fax: [phone]
Information: [email protected]
Service: [email protected]
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: [email protected]
Service: [email protected]
BCM Advanced Research Avalue China
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: [e-mail]
Service: [email protected]

ECM-US15WP Quick Installation Guide
4 ECM-US15WP Quick Installation Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Always note that improper disassembling action could cause damage to the
motherboard. We suggest not removing the heatsink without correct
instructions in any circumstance. If you really have to do this, please contact
us for further support.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z1 x Intel® US15WP Micro Module
z1 x Quick Installation Guide for ECM-US15WP
z1 x SDVO to VGA daughter board
z1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
— Ethernet driver and utilities
— VGA drivers and utilities
— Audio drivers and utilities
z1 x Cable set contains the followings:
— 1 x VGA cable (DB 15P(F) – 10P/2.0mm)
— 1 x IDE cable (44-pin, pitch 2.0mm)
— 1 x Serial ATA cables (7-pin, standard)
— 1 x PS/2 Keyboard & mouse Y cable (7-pin, Mini-DIN)

Quick Installation Guide
ECM-US15WP Quick Installation Guide
5
2. Hardware
Configuration

ECM-US15WP Quick Installation Guide
6 ECM-US15WP Quick Installation Guide
2.1 Product Overview

Quick Installation Guide
ECM-US15WP Quick Installation Guide
7
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label Function Note
JBAT1 Clear CMOS 3 x 1 header, pitch 2.0mm
JCF1 CF card mode select 3 x 1 header, pitch 2.0mm
JTOUCH1 Touch panel mode select 3 x 1 header, pitch 2.0mm
PWR_SEL1 AT/ATX power mode select 3 x 1 header, pitch 2.0mm
RI1 Serial port 1 – Ring, +5V, +12V power
select 3 x 1 header, pitch 2.0mm
RI2 Serial port 2 – Ring, +5V, +12V power
select 3 x 1 header, pitch 2.0mm

ECM-US15WP Quick Installation Guide
8 ECM-US15WP Quick Installation Guide
Connectors
Label Function Note
ATXPW1 ATX power connector 3 x 1 wafer, pitch 2.54mm
BBAT1 Battery connector 2 x 1 wafer, pitch 1.25mm
COM1 Serial port1 connector D-sub 9-pin, male
COM2 Serial port 2 connector 5 x 2 header, pitch 2.0mm
DIO1 Digital Input/ Output connector 10 x 2 header, pitch 2.0mm
IDE1 Primary IDE connector 22 x 2 header, pitch 2.0mm
IR1 IrDA connector 5 x 1 header, pitch 2.54mm
J1 LCD inventer power connector 2 x 1 wafer, pitch 2.54mm
J422/485 Serial port 2 in RS-422/485 mode
connector 3 x 2 header, pitch 2.0mm
JAUDIO1 Audio connector 3 x 2 header, pitch 2.0mm
JBKL1 LCD inverter connector 5 x 1 wafer, pitch 2.0mm
JCD1 CD-ROM audio input connector 4 x 1 header, pitch 2.54mm
JKB/MS1 PS/2 Keyboard & Mouse connector 4 x 2 header, pitch 2.0mm
JLPC1 (Reserved for BIOS programming) 3 x 2 header, pitch 2.0mm
JLVDS1 LVDS connector HIROSE DF13-200P-1.25C
JSDVO1 SDVD port connector 12 x 2 header, pitch 2.0mm
CON1 (Reserved for BIOS programming) 5 x 2 header, pitch 2.0mm
JUSB1 USB 5&6 connector 5 x 2 header, pitch 2.0mm
JVR1 LCD backlight brightness adjustment 3 x 1 header, pitch 2.0mm
LAN1 RJ-45 Ethernet connector
LED4 Power & HDD indicator
LINEOUT1 Audio out connector
MICPHONE1 MIC connector
PWRBTN1 Power button connector 2 x 1 header, pitch 2.0mm
PWRCON1 Power connector 2 x 2 wafer, pitch 4.2mm
RSTBTN1 Reset button
SATA1 SATA 1 connector
SATA2 SATA 2 connector
SDIO_J1 SDIO connector 5 x 1 header, pitch 2.54mm
SDIO_J2 SDIO connector 6 x 1 header, pitch 2.54mm
USB1 USB 2&3 connector Double deck
USB2 USB 0&1 connector Double deck

Quick Installation Guide
ECM-US15WP Quick Installation Guide
9
2.3 Setting Jumpers & Connectors
2.3.1 Clear CMOS (JABT1)
* Default
Protect*
Clear CMOS
2.3.2 CF Card mode select (JCF1)
* Default
Master *
Slave

ECM-US15WP Quick Installation Guide
10 ECM-US15WP Quick Installation Guide
2.3.3 Touch Panel mode select (JTOUCH1)
* Default
4/8-Wire*
5-Wire
2.3.4 AT/ATX power mode select (PWR_SEL1)
* Default
AT *
ATX

Quick Installation Guide
ECM-US15WP Quick Installation Guide
11
2.3.5 Serial port 1 – Ring, +5V, +12V power select (RI1)
* Default
Ring*
+5V
+12V
2.3.6 Serial port 2 – Ring, +5V, +12V power select (RI2)
* Default
Ring*
+5V
+12V

ECM-US15WP Quick Installation Guide
12 ECM-US15WP Quick Installation Guide
2.3.7 ATX power connector (ATXPW1)
Signal PIN
PSON- 1
GND 2
PS5VSB 3
2.3.8 Battery connector (BBAT1)
Signal PIN
BAT 1
GND 2

Quick Installation Guide
ECM-US15WP Quick Installation Guide
13
2.3.9 Serial Port 1 connector (COM1)
Signal PIN PIN Signal
DCD 12 RxD
TxD 3 4 DTR
GND 56 DSR
RTS 7 8 CTS
RI 9
2.3.10 Serial Port 2 connector (COM2)
Signal PIN PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10 NC

ECM-US15WP Quick Installation Guide
14 ECM-US15WP Quick Installation Guide
2.3.11 Digital Input/ Output connector (DIO1)
Signal PIN PIN Signal
GPI0 12 GPO0
GPI1 3 4 GPO1
GPI2 56 GPO2
GPI3 7 8 GPO3
GPI4 910 GPO4
GPI5 11 12 GPO5
GPI6 13 14 GPO6
GPI 15 16 GPO7
SMB_CLK 17 18 SMB_DATA
GND 19 20 +5V

Quick Installation Guide
ECM-US15WP Quick Installation Guide
15
2.3.12 Primary IDE connector (IDE1)
Signal PIN PIN Signal
RESET# 12 GND
PDD7 3 4 PDD8
PDD6 56 PDD9
PDD5 7 8 PDD10
PDD4 910 PDD11
PDD3 11 12 PDD12
PDD2 13 14 PDD13
PDD1 15 16 PDD14
PDD0 17 18 PDD15
GND 19 20 NC
PDREQ 21 22 GND
PDIOW# 23 24 GND
PDIOR# 25 26 GND
PIORDY 27 28 GND
PDACK# 29 30 GND
IRQ15 31 32 NC
PDA1 33 34 LID
PDA0 35 36 PDA2
PDCS1# 37 38 PDCS3#
HD_LED1 39 40 GND
+5V 41 42 +5V
GND 43 44 NC

ECM-US15WP Quick Installation Guide
16 ECM-US15WP Quick Installation Guide
2.3.13 IrDA connector (IR1)
Signal PIN
+5V 1
NC 2
IRRX 3
GND 4
IRTX 5
2.3.14 Audio connector (JAUDIO1)
Signal PIN PIN Signal
LINEIN_L 12 LINEIN_R
GND 3 4 LINE1-JD
SPDIFO 56 SPDIFI

Quick Installation Guide
ECM-US15WP Quick Installation Guide
17
2.3.15 LCD inverter power connector (J1)
Signal PIN
+12V 1
GND 2
2.3.16 Serial port 2 in RS-422/485 mode (J422/485)
Signal PIN PIN Signal
485TX- 12 485RX-
485TX+ 3 4 485RX+
+5V 56 GND

ECM-US15WP Quick Installation Guide
18 ECM-US15WP Quick Installation Guide
2.3.17 LCD Inverter Connector (JBKL1)
Signal PIN
+12V 1
GND 2
BLK_ON 3
BRIGHT 4
+5V 5
Note:
For inverters with adjustable Backlight function, it is possible to control the LCD
brightness through the VR signal controlled by JVR1. Please see the JVR1 section
for detailed circuitry information.
2.3.17.1 Signal Description – LCD Inverter Connector (JBKL1)
Signal Signal Description
VR Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W)
BLK_ON LCD backlight ON/OFF control signal

Quick Installation Guide
ECM-US15WP Quick Installation Guide
19
2.3.18 CD-ROM audio input Connector (JCD1)
Signal PIN
CD_R 1
GND 2
GND 3
CD_L 4
2.3.19 Keyboard & mouse connector (JKB/MS)
Signal PIN PIN Signal
7 NC
MSCK 6 5 MSDT
+5V 4 3 GND
KBCK 2 1 KBDT

ECM-US15WP Quick Installation Guide
20 ECM-US15WP Quick Installation Guide
2.3.20 LVDS connector (JLVDS1)
Signal PIN PIN Signal
GND 21 GND
LCDS_0- 4 3 LCDS_0+
LCDS_1- 65 LCDS_1+
LCDS_2- 8 7 LCDS_2+
LCDS_3- 10 9 LCDS_3+
LCDS_CLK- 12 11 LCDS_CLK+
GND 14 13 GND
I_SCL 16 15 I_SDA
+5V 18 17 +3.3V
+5V 20 19 +3.3V
Note:
Mating Connector: HIROSE DF13-20DS-1.25C
2.3.21 USB 5&6 connector (JUSB1)
Signal PIN PIN Signal
+5V 12 GND
DN6 3 4 GND
DP6 56 DP5
GND 7 8 DN5
GND 910 +5V
