Avalue Technology ECM-CFS User manual

Part No. E2047394204R
ECM-CFS
3.5" Coffee Lake-S Micro Module
User’s Manual
5th Ed –14 November 2019
Copyright Notice
Copyright 2019 Avalue Technology Inc., ALL RIGHTS RESERVED.

ECM-CFS User’s Manual
2 ECM-CFS User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

User’s Manual
ECM-CFS User’s Manual
3
Content
1. Getting Started............................................................................................................6
1.1 Safety Precautions ................................................................................................6
1.2 Packing List...........................................................................................................6
1.3 Document Amendment History..............................................................................7
1.4 Manual Objectives.................................................................................................8
1.5 System Specifications ...........................................................................................9
1.6 Architecture Overview—Block Diagram...............................................................11
2. Hardware Configuration...........................................................................................12
2.1 Product Overviews ..............................................................................................13
2.2 Jumper & Connector list ......................................................................................15
2.3 Setting Jumpers & Connectors............................................................................17
2.3.1 Clear CMOS (JBAT1) ................................................................................................................ 17
2.3.2 Serial port 1 pin9 signal select (JRI1)........................................................................................ 17
2.3.3 AT/ATX Input power select (JAT1) ............................................................................................ 18
2.3.4 LCD backlight brightness adjustment (JBKL_SEL1) ................................................................. 18
2.3.5 LCD Inverter connector (JBKL1)................................................................................................ 19
2.3.6 CPU fan connector (CPU_FAN1) .............................................................................................. 19
2.3.7 Serial port 2 connector (JCOM1)............................................................................................... 20
2.3.8 General purpose I/O connector (JDIO1).................................................................................... 20
2.3.9 SATA power connector 1 (SATA_PWR1).................................................................................. 21
2.3.10 SATA power connector 2 (SATA_PWR2) ............................................................................. 21
2.3.11 Power connector (PWR1)...................................................................................................... 22
2.3.12 On-board header for USB2.0 (JUSB1).................................................................................. 22
2.3.13 LPC connector (JLPC1)......................................................................................................... 23
2.3.14 LVDS connector (JLVDS1).................................................................................................... 23
2.3.15 Front Panel connector (JFP1) ............................................................................................... 24
2.3.16 SPI connector (JSPI1)........................................................................................................... 24
2.3.17 Battery connector (BAT1)...................................................................................................... 25
2.3.18 Audio connector (JAUDIO1).................................................................................................. 25
2.3.18.1 Signal Description –Audio connector (JAUDIO1)............................................................................25
2.3.19 EC Debug connector (JEC_ROM1)....................................................................................... 26
2.3.20 PC Buzzer header (JBZ1) ..................................................................................................... 26
2.4 Audio/USB Daughter Board User’s Guide ...........................................................27
2.4.1 Jumper and Connector Layout....................................................................................................... 27
2.4.2 Jumper and Connector List............................................................................................................ 27

ECM-CFS User’s Manual
4 ECM-CFS User’s Manual
2.4.3 Setting Jumper and Connector...................................................................................................... 28
3.BIOS Setup....................................................................................................................29
3.1 Introduction..........................................................................................................30
3.2 Starting Setup......................................................................................................30
3.3 Using Setup.........................................................................................................31
3.4 Getting Help.........................................................................................................32
3.5 In Case of Problems............................................................................................32
3.6 BIOS setup..........................................................................................................33
3.6.1 Main Menu ................................................................................................................................. 33
3.6.1.1 System Language............................................................................................................................34
3.6.1.2 System Date....................................................................................................................................34
3.6.1.3 System Time....................................................................................................................................34
3.6.2 Advanced Menu......................................................................................................................... 34
3.6.2.1 CPU Configuration...........................................................................................................................35
3.6.2.1.1 CPU –Power Management Control.................................................................................................36
3.6.2.2 PCH-FW Configuration....................................................................................................................37
3.6.2.2.1 OEM Flags Settings.........................................................................................................................38
3.6.2.2.2 Firmware Update Configuration.......................................................................................................38
3.6.2.3 Trusted Computing ..........................................................................................................................39
3.6.2.4 APCI Settings ..................................................................................................................................39
3.6.2.5 IT8528 Super IO Configuration........................................................................................................40
3.6.2.5.1 Serial Port 1 Configuration...............................................................................................................41
3.6.2.5.2 Serial Port 2 Configuration...............................................................................................................41
3.6.2.6 EC 8528 HW Monitor.......................................................................................................................42
3.6.2.7 S5 RTC Wake Settings....................................................................................................................42
3.6.2.8 Serial Port Console Redirection.......................................................................................................43
3.6.2.8.1 Legacy Console Redirection Settings..............................................................................................44
3.6.2.9 USB Configuration...........................................................................................................................45
3.6.2.10 Network Stack Configuration ...........................................................................................................46
3.6.2.11 NVMe Configuration.........................................................................................................................46
3.6.3 Chipset..................................................................................................................................... 47
3.6.3.1 System Agent (SA) Configuration....................................................................................................47
3.6.3.1.1 Memory Configuration......................................................................................................................48
3.6.3.1.2 Graphics Configuration....................................................................................................................49
3.6.3.1.3 DMI/OPI Configuration.....................................................................................................................50
3.6.3.2 PCH-IO Configuration......................................................................................................................50
3.6.3.2.1 PCI Express Configuration...............................................................................................................51
3.6.3.2.1.1 Intel I211 LAN Chip (PCI-E Port 6)..........................................................................................51
3.6.3.2.1.2 mPCIe/mSATA Slot (PEI-E Port 15)........................................................................................52
3.6.3.2.2 SATA And RST Configuration..........................................................................................................53

User’s Manual
ECM-CFS User’s Manual
5
3.6.3.2.3 HD Audio Configuration...................................................................................................................54
3.6.3.3 Board & Panel Configuration ...........................................................................................................54
3.6.4 Security .................................................................................................................................... 56
3.6.4.1 Secure Boot.....................................................................................................................................56
3.6.4.1.1 Key Management.................................................................................................................................57
3.6.5 Boot.......................................................................................................................................... 61
3.6.6 Save and exit ........................................................................................................................... 62
3.6.6.1 Save Changes and Reset................................................................................................................62
3.6.6.2 Discard Changes and Reset............................................................................................................62
3.6.6.3 Restore Defaults..............................................................................................................................62
3.6.6.4 Launch EFI Shell from filesystem device.........................................................................................62
4. Drivers Installation.......................................................................................................63
4.1 Install Chipset Driver ...........................................................................................64
4.2 Install Display Driver............................................................................................65
4.3 Install LAN Driver.................................................................................................66
4.4 Install ME Driver...................................................................................................68
4.5 Install Serial IO Driver..........................................................................................69
4.6 Install Audio Driver (For Realtek ALC892)...........................................................70
4.7 Install IRST Driver................................................................................................71
5. Mechanical Drawing ....................................................................................................73

ECM-CFS User’s Manual
6 ECM-CFS User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x ECM-CFS 3.5”Micro Module
1 x AUX-032 daughter board
1 x Cable set contains the followings:
—1 x Audio cable (12P/2.0mm-12P/ 2.0mm)
—1 x USB 2.0 cable (10P/2.0mm-10P/2.0mm)
—1 x Serial ATA cable (7P/1.27mm, standard)
—1 x Wire SATA power cable (15P/1.27mm-2P/2.0mm)
—1 x Flat Cable 9P(M)-PHD (10P/2.0mm)
3M foam (VHB-4622 10mm*20mm*1.1mm)

User’s Manual
ECM-CFS User’s Manual
7
1.3 Document Amendment History
Revision
Date
By
Comment
1st
August 2018
Avalue
Initial Release
2nd
July 2019
Avalue
Update 2.3 Setting Jumpers & Connectors
3rd
August 2019
Avalue
Update 1.5 System Specifications
4th
October 2019
Avalue
Remove CEC1 connector
4th
November 2019
Avalue
Update 1.5 System Specifications

ECM-CFS User’s Manual
8 ECM-CFS User’s Manual
1.4 Manual Objectives
This manual describes in details Avalue Technology ECM-CFS Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to set up
ECM-CFS or change the standard configurations. Whilst all the necessary information is
available in this manual we would recommend that unless you are confident, you contact
your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors regarding this manual and want to inform us
of these, please contact our Customer Service department with the relevant details.

User’s Manual
ECM-CFS User’s Manual
9
1.5 System Specifications
System
CPU
8th/9th generation Intel® Coffee lake-S (LGA 1151) 6+2,4+2 Processor (35W)
BIOS
AMI uEFO BIOS,256 Mbit SPI Flash ROM
iAMT supported
System Chipset
Intel® CNL PCH-H Q370/H310 Corp
I/O Chip
EC(IT8528E)
System Memory
1 x 260-Pin DDR4 2400/2666MTs SO-DIMM up to 32GB
SSD
mSATA from MiniPCIe
Watchdog Timer
H/W Reset, 1sec.–65535sec./min.
1sec. or 1min. step
H/W Status Monitor
Monitoring System Temperature, Voltage and FAN Status with Auto Throttling
Control
Expansion
1 x Full-Size Mini PCI Express Mini Card with mSATA supported
I/O
MIO
2 x SATA III (with 2 x (1 x 2 )pin wafer w/2.0mm pitch for SATA Power)
1 x RS232 (COM1)
1x RS232 for COM2
LPC,SPI
1 x mPCIe support PCIe / mSATA (H310 only support mSATA, Q370 support
mPCIe/mSATA)
USB
4 x USB3.1 Gen2(dual deck USB connector for 2 USB3.1 port 10Gbps) (H310
support USB3.1 Gen1,Q370 support USB3.1 Gen2), 2 x USB 2.0( by 2 x 5 pin
header)
GPIO
8-bit GPIO
Others
LPC
Display
Chipset
Intel® Coffee Lake Processor integrated Graphics
Resolution
LVDS: 1920 x 1200@60Hz
2 x HDMI: 4096 x 2304@30Hz (cost reduce)
Multiple Display
Q370 support Triple Display
H310 only support Dual Display:LVDS+HDMI1(default LVDS enable)or
HDMI1+HDMI2(LVDS disabled)
HDMI
HDMI 1.4
LCD Interface
Dual channel 18/24-bit LVDS (via 7511B)
Audio
AC97 Codec
Realtek ALC892 HD codec Supports 5.1-CH Audio

ECM-CFS User’s Manual
10 ECM-CFS User’s Manual
Audio Interface
Line in ,Line-Out, Mic in
Ethernet
LAN Chip
1 x Intel I211AT GbE controller
1 x Intel I219LM Gigabit Ethernet PHY
Ethernet Interface
10/100/1000 Base-Tx compatible
Internal I/O Connectors
Fan
CPU_FAN1 4pin 2.5mm wafer header (smart FAN)
Buzzer
With Pin header
CMOS Battery
CR2032
Power ON
AX / ATX selectable by jumper
Audio
6 x 2 pin header w/2.0mm pitch
COM
1 x JCOM2 (RS232)
SATA power
2 x (1 x 2)pin wafer for SATA power
Rear I/O Connectors
USB
4 x USB3.1 (10Gbps) type-A
LAN
2 x Ethernet
HDMI
2 x HDMI
COM
1 x DB-9 male connector for COM1(RS-232)(support RI,5V,12V)
LED
Stack LED for PWR and HDD LED
Mechanical & Environmental
Power Requirement
+12V
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 5.0 Compliant
Power Type
AT/ATX
Operating Temp.
0°C ~60°C( 32°F ~ 140°F )
Storage Temp.
-40°C ~75°C ( -40°F ~ 167°F )
Operating Humidity
0% ~ 90% relative humidity, non-condensing
Size (L x W)
5.7" x 4" (146mm x 101mm)
Weight
0.44 lbs (0.2 Kg)
OS Support
Win 10 / Linux
Note: Specifications are subject to change without notice.

User’s Manual
ECM-CFS User’s Manual
11
1.6 Architecture Overview—Block Diagram
The following block diagram shows the architecture and main components of ECM-CFS.

ECM-CFS User’s Manual
12 ECM-CFS User’s Manual
2.Hardware
Configuration
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

User’s Manual
ECM-CFS User’s Manual
13
2.1 Product Overviews

ECM-CFS User’s Manual
14 ECM-CFS User’s Manual

User’s Manual
ECM-CFS User’s Manual
15
2.2 Jumper & Connector list
Jumpers
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.00 mm
JRI1
Serial port 1 pin9 signal select
3 x 2 header, pitch 2.00 mm
JAT1
AT/ATX Input power select
3 x 1 header, pitch 2.00 mm
JBKL_SEL1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.00 mm
Connectors
Label
Function
Note
BAT1
Battery connector
2 x 1 wafer, pitch 1.25 mm
CPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54 mm
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00 mm
JBKL1
LCD inverter connector
5 x 1 wafer, pitch 2.00 mm
Matching Connector: JST PHR-5
COM1
Serial port 1 connector
D-sub 9-pin, male
JCOM1
Serial port 2 connector
5 x 2 header, pitch 2.00 mm
JDIO1
General purpose I/O connector
6 x 2 header, pitch 2.00 mm
JFP1
Front Panel connector
5 x 2 header, pitch 2.00 mm
JLPC1
LPC connector
5 x 2 header, pitch 2.00 mm
JLVDS1
LVDS connector
20 x 2 header, pitch 1.25 mm
Matching Connector: Hirose
DF13-40DS-1.25C
JSPI1
SPI connector
4 x 2 header, pitch 2.00 mm
USB1/2
H310 support USB3.1 Gen1
Q370 support USB3.1 Gen2
JUSB1
On-board header for USB2.0
5 x 2 header, pitch 2.00 mm
HDMI1
DUAL HDMI connector
LAN1
RJ-45 Ethernet x 2
LED1
HDD/Power LED indicator
PWR1
Power connector
2 x 2 wafer, pitch 4.20 mm
SATA_PWR1
SATA power connector 1
2 x 1 wafer, pitch 2.00 mm
SATA_PWR2
SATA power connector 2
2 x 1 wafer, pitch 2.00 mm
SATA1/2
Serial ATA connector 1/2

ECM-CFS User’s Manual
16 ECM-CFS User’s Manual
JBZ1
PC Buzzer header
2 x 1 wafer, pitch 2.00 mm
JEC_ROM1
EC Debug connector
3 x 1 header, pitch 2.00 mm
MINI_PCIE1
Full size Mini-PCI-e connector
SO_DIMM1
DDR4 SODIMM socket

User’s Manual
ECM-CFS User’s Manual
17
2.3 Setting Jumpers & Connectors
2.3.1 Clear CMOS (JBAT1)
* Default
Protect*
Clear CMOS
2.3.2 Serial port 1 pin9 signal select (JRI1)
* Default
Ring*
+5V
+12V

ECM-CFS User’s Manual
18 ECM-CFS User’s Manual
2.3.3 AT/ATX Input power select (JAT1)
AT*
ATX
2.3.4 LCD backlight brightness adjustment (JBKL_SEL1)
* Default
PWM Mode*
DC Mode

User’s Manual
ECM-CFS User’s Manual
19
2.3.5 LCD Inverter connector (JBKL1)
Signal
PIN
+12V
1
GND
2
BKLEN
3
VBRIGHT
4
+5V
5
2.3.6 CPU fan connector (CPU_FAN1)
Signal
PIN
GND
1
+12V
2
CFAN_IN
3
CFAN_OUT
4

ECM-CFS User’s Manual
20 ECM-CFS User’s Manual
2.3.7 Serial port 2 connector (JCOM1)
Signal
PIN
PIN
Signal
NC
10
9
COM_RI#_2
COM_CTS#_2
8
7
COM_RTS#_2
COM_DSR#_2
6
5
GND
COM_DTR#_2
4
3
COM_TXD_2
COM_RXD_2
2
1
COM_DCD#_2
2.3.8 General purpose I/O connector (JDIO1)
Signal
PIN
PIN
Signal
DIO_GP20
1
2
DIO_GP10
DIO_GP21
3
4
DIO_GP11
DIO_GP22
5
6
DIO_GP12
DIO_GP23
7
8
DIO_GP13
SMB_SCL_S0
9
10
SMB_SDA_S0
GND
11
12
+5V
