Avalue Technology ECM-QM77 User manual

Part No. E2017391204R
ECM-QM77
Intel® Ivy Bridge Processors 3.5” Micro Module
with Intel® QM77 Chipset
Quick Installation Guide
5th Ed –03 September 2013

ECM-QM77 Quick Installation Guide
2 ECM-QM77 Quick Installation Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x 3.5” ECM-QM77 Micro Module
1 x Quick Installation Guide for ECM-QM77
1 x AUX-056 daughter board
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
1 x Cable set contains the followings:
—1 x Audio cable (12pin,2.0 pitch)
—1 x USB 2.0 cable (10P/2.0mm-10P/2.0mm)
—1 x USB 3.0 cable ((20P/2.0mm-20P/2.0mm)
—1 x Serial ATA cable (7-pin, standard)
—1 x Wire SATA power cable (15-pin,4P/2.5mm)
—1 x Flat cable 9P(M)-PHD 10P/2.0mm)
3M foam (VHB-4622 10mm*20mm*1.1mm)

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 3
2.Hardware
Configuration

ECM-QM77 Quick Installation Guide
4 ECM-QM77 Quick Installation Guide
2.1 Product Overview

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 5

ECM-QM77 Quick Installation Guide
6 ECM-QM77 Quick Installation Guide
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.54 mm
JRI1
COM 1 pin 9 signal select
3 x 2 header, pitch 2.00 mm
JAT1
AT/ ATX Input power select
3 x 1 header, pitch 2.00 mm
Connectors
Label
Function
Note
BAT1
Battery connector
2 x 1 wafer, pitch 1.25 mm
COM1
Serial port 1 connector
D-sub 9-pin, male
CPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54 mm
HDMI1
HDMI connector

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 7
J422/1
COM 1 RS-422-485 mode
3 x 2 header, pitch 2.00 mm
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00 mm
JBKL1
LCD inverter connector
5 x 1 wafer, pitch 2.00 mm
JCOM2
Serial port 2 connector
5 x 2 header, pitch 2.00 mm
JDIO1
General purpose I/O connector
6 x 2 header, pitch 2.00 mm
JFP1
Miscellaneous setting connector
5 x 2 header, pitch 2.00 mm
JLPC1
Low pin count interface
7 x 2 header, pitch 2.00 mm
JLVDS1
LVDS connector
20 x 2 header, pitch 1.25 mm
JSPI1
SPI connector
4 x 2 header, pitch 2.00 mm
JUSB1
On-board box header for USB2.0
5 x 2 header, pitch 2.00 mm
JUSB3/1
On-board box header for USB3.0
10 x 2 wafer, pitch 2.00 mm
JVR1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.54 mm
LAN1/S_LAN1
RJ-45 Ethernet connector
LED3
LED connector
PWR_SB1
5VSB connector in ATX
3 x 1 wafer, pitch 2.54 mm
PWR1
Power connector
2 x 2 wafer, pitch 4.2 mm
JKB/MS1
PS/2 keyboard & mouse connector
2 x 3 wafer, pitch 2.00 mm
HD_PWR1
HD power connector
1 x 4 wafer, pitch 2.50 mm
SATA1
Serial ATA connector 1
SATA2
Serial ATA connector 2
SYS_FAN1
System fan connector
4 x 1 wafer, pitch 2.54 mm
USB1_1
On-board connector for USB3.0
VGA1
VGA connector
D-sub 15-pin, female
MPCIE1
Mini-PCI connector
CN4
DDR3 SODIMM connector

ECM-QM77 Quick Installation Guide
8 ECM-QM77 Quick Installation Guide
2.3 Setting Jumpers & Connectors
2.3.1 Clear CMOS (JBAT1)
* Default
Protect*
Clear CMOS
2.3.2 COM 1 pin 9 signal select (JRI1)
* Default
Ring*
+5V
+12V

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 9
2.3.3 AT/ ATX Input power select (JAT1)
* Default
AT*
ATX
2.3.4 5VSB connector in ATX (PWR_SB1)
Signal
PIN
SIO_PSON#
1
GND
2
+ATX5VSB
3

ECM-QM77 Quick Installation Guide
10 ECM-QM77 Quick Installation Guide
2.3.5 Battery connector (BAT1)
Signal
PIN
+3.3V
1
GND
2
2.3.6 CPU fan connector (CPU_FAN1)
Signal
PIN
GND
1
+12V
2
CPUFANIN0
3
CPUFANOUT0
4

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 11
2.3.7 System fan connector (SYS_FAN1)
Signal
PIN
GND
1
+12V
2
SYSFANIN
3
SYSFANOUT
4
2.3.8 COM 1 RS-422-485 mode (J422/1)
Signal
PIN
PIN
Signal
485_422TX-
2
1
422RX-
485_422TX+
4
3
422RX+
+5V
6
5
GND
Note:
J422/485 is available after modify the mode of COM1
in BIOS setting

ECM-QM77 Quick Installation Guide
12 ECM-QM77 Quick Installation Guide
2.3.9 Audio connector (JAUDIO1)
Signal
PIN
PIN
Signal
GND
11
12
MIC1-JD
LINE1-JD
9
10
FRONT-JD
MIC1-L-IN
7
8
MIC1-R-IN
LINE1-L-IN
5
6
LINE1-R-IN
GND
3
4
GND
FRONT-L-OUT
1
2
FRONT-R-OUT
2.3.9.1 Signal Description –Audio connector (JAUDIO1)
Signal
Signal Description
LINE1_JD
AUDIO IN (LINE_RIN/LIN)sense pin
FRONT_JD
AUDIO Out(ROUT/LOUT) sense pin
MIC1_JD
MIC IN (MIC_RIN/LIN) sense pin

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 13
2.3.10 LCD inverter connector (JBKL1)
Signal
PIN
+12V
1
GND
2
BKLEN
3
BRIADJ
4
+5V
5
2.3.11 LCD backlight brightness adjustment (JVR1)
Signal
PIN
+5V
1
BRIGHT
2
GND
3
Variation Resistor
(Recommended: 4.7KΩ, >1/16W)

ECM-QM77 Quick Installation Guide
14 ECM-QM77 Quick Installation Guide
2.3.12 Low pin count connector (JLPC1)
Signal
PIN
PIN
Signal
LPC_AD0
1
2
+3.3V
LPC_AD1
3
4
LPC_RST#
LPC_AD2
5
6
LPC_FRAME#
LPC_AD3
7
8
CLK_PCI_LPC
INT_SERIRQ
9
10
GND
+V5S
11
12
GND
+V5A
13
14
PCH_DRQ#1
2.3.13 Serial port 2 connector (JCOM2)
Signal
PIN
PIN
Signal
DCD2
1
2
RxDD2
TxDD2
3
4
DTR2
GND
5
6
DSR2
RTS2
7
8
CTS2
RI2
9
10
NC

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 15
2.3.14 General purpose I/O connector (JDIO1)
Signal
PIN
PIN
Signal
GND
11
12
GND
SMB_DATA_9555
9
10
SMB_CLK_9555
DIO_GP13
7
8
DIO_GP23
DIO_GP12
5
6
DIO_GP22
DIO_GP11
3
4
DIO_GP21
DIO_GP10
1
2
DIO_GP20
2.3.15 Miscellaneous setting connector (JFP1)
Signal
PIN
PWBT
1
2
RST#
3
4
PWR-LED
5
6
HDD-LED
7
8
COPEN#
9
10

ECM-QM77 Quick Installation Guide
16 ECM-QM77 Quick Installation Guide
2.3.16 SPI connector (JSPI1)
Signal
PIN
PIN
Signal
7
HOLD#
SPI_SI
6
5
SPI_SO
SPI_CLK
4
3
SPI_CS0#
GND
2
1
+3.3V
2.3.17 Power connector (PWR1)
Signal
PIN
PIN
Signal
GND
1
2
GND
+12V
3
4
+12V

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 17
2.3.18 LVDS connector (JLVDS1)
Signal
PIN
PIN
Signal
+12V
39
40
+12V
GND
37
38
GND
LVDS_CLK2_N
35
36
LVDS_CLK1_N
LVDS_CLK2_P
33
34
LVDS_CLK1_P
GND
31
32
GND
LVDS_DATA7_N
29
30
LVDS_DATA6_N
LVDS_DATA7_P
27
28
LVDS_DATA6_P
GND
25
26
GND
LVDS_DATA5_N
23
24
LVDS_DATA4_N
LVDS_DATA5_P
21
22
LVDS_DATA4_P
GND
19
20
GND
LVDS_DATA3_N
17
18
LVDS_DATA2_N
LVDS_DATA3_P
15
16
LVDS_DATA2_P
GND
13
14
GND
LVDS_DATA1_N
11
12
LVDS_DATA0_N
LVDS_DATA1_P
9
10
LVDS_DATA0_P
GND
7
8
GND
NC
5
6
NC
+3.3V
3
4
+5V
+3.3V
1
2
+5V

ECM-QM77 Quick Installation Guide
18 ECM-QM77 Quick Installation Guide
2.3.19 On-board box header for USB3.0 (JUSB3/1)
Signal
PIN
PIN
Signal
+5V
1
USB3_RXN3_L
2
19
+5V
USB3_RXP3_L
3
18
USB3_RXN4_L
GND
4
17
USB3_RXP4_L
USB3_TXN3_L
5
16
GND
USB3_TXP3_L
6
15
USB3_TXN4_L
GND
7
14
USB3_TXP4_L
USB_PN_Z_2
8
13
GND
USB_PP_Z_2
9
12
USB_PN_Z_3
NC
10
11
USB_PP_Z_3
2.3.20 On-board box header for USB2.0 (JUSB1)
Signal
PIN
PIN
Signal
+5V
1
2
+5V
USB_PN_Z_5
3
4
USB_PN_Z_4
USB_PP_Z_5
5
6
USB_PP_Z_4
GND
7
8
GND
GND
9
10
GND

ECM-QM77 Quick Installation Guide
ECM-QM77 Quick Installation Guide 19
2.3.21 PS/2 keyboard & mouse connector (JKB/ MS1)
Signal
PIN
PIN
Signal
KBCK
1
2
KBDT
KBVCC
3
4
GND
MSCK
5
6
MSDT
2.3.22 HD power connector (HD_PWR1)
Signal
PIN
GND
1
GND
2
+5V
3
+5V
4

ECM-QM77 Quick Installation Guide
20 ECM-QM77 Quick Installation Guide
2.4 Audio / USB Daughter Board User’s Guide
2.4.1 Jumper and Connector Layout
2.4.2 Jumper and Connector List
Connectors
Label
Function
Note
AUSB2
USB connector 2.0
AUSB3
USB connector 3.0
MIC1
Mic in connector
Phone Jack
LINEOUT1
Line out connector
Phone Jack
LINEIN1
Line in connector
Phone Jack
AJAUDIO1
Audio connector
6 x 2 header, pitch 2.00mm
AJUSB2
2.00mm USB connector
5 x 2 header, pitch 2.00mm
AJUSB3
2.00mm USB connector
10 x 2 header, pitch 2.00mm
