Avalue Technology EMX-H61 User manual

Part No. E2017XH6101R
EMX-H61
Mini ITX Motherboard with Intel® H61 Express Chipset
Quick Installation Guide
2nd Ed –29 October 2012
Copyright Notice
Copyright 2012-2013 Avalue Technology Inc., ALL RIGHTS RESERVED.
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
2 EMX-H61 Quick Installation Guide
Content
1. Getting Started............................................................................................................3
1.1 Safety Precautions..................................................................................................3
1.2 Packing List ............................................................................................................3
1.3 Specifications.................................................................................................4
2Hardware Configuration.............................................................................................6
2.1 Product Overview...........................................................................................7
2.1.1 Main board layout....................................................................................7
2.1.2 Connecting Rear Panel I/O Devices........................................................7
2.2 Setting Jumpers & Connectors.......................................................................9
2.2.1 Additional USB Port Headers (FUSB1/FUSB2).......................................9
2.2.2 JME.........................................................................................................9
2.2.3 CMOS Memory Clearing Header (JBAT) ..............................................10
2.2.4 CPU/System Fan Power Connectors Header (CFAN/SFAN1/SFAN2) .10
2.2.5 ATX Power Input Connectors (PWR12V/ATXPWR) .............................11
2.2.6 Front Panel Switches (FPANEL)...........................................................11
2.2.7 Speaker Headers (SPEAK)...................................................................12
2.2.8 Front Panel Audio Connection Header (F_AUDIO)...............................12
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
EMX-H61 Quick Installation Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Always note that improper disassembling action could cause damage to the
motherboard. We suggest not removing the heatsink without correct
instructions in any circumstance. If you really have to do this, please contact
us for further support.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
Rear I/O bracket X 1
Quick Installation Guide X 1
Driver/Utility CD X 1
Serial ATA Signal Cable X 2
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
4 EMX-H61 Quick Installation Guide
1.3 Specifications
Title
EMX-H61
Intel® Core™ i7, Core™ i5, Core™ i3, Pentium® /Celeron® Mini ITX
Montherboard with Intel® H61 Express Chipset
Features
Intel® LGA1155 socket Supports Core™ i7, Core™ i5, Core™ i3,
Pentium® and Celeron® processors
Intel® H61 Express Chipset
Two 240-pin DIMM sockets up to 8GB Dual Channel unbuffered DDR3
1066/1333MHz SDRAM
VGA , DVI -D, HDMI
Realtek® ALC892 7.1-Channel High-Definition Audio codec
Dual Broadcom® 57788 PCI-Express Gigabit Ethernet
1 x PCIex16 , 1 x Mini PCIe
4 SATA II 3.0Gb/s , 2 x USB 3.0 Ports , 8 x USB 2.0 Ports
8 Channel Audio I/O jacks with S/PDIF Out connector
Specifications
System
CPU
Intel® LGA1155 socket Supports Core™ i7, Core™ i5, Core™ i3,
Pentium® and Celeron® processors
BIOS
AMI UEFI 1 x 32Mbit Flash ROM BIOS
System Chipset
Intel® H61 Express Chipset
I/O Chip
Nuvoton NCT5577D
System Memory
Two 240-pin DIMM sockets up to 8GB Dual Channel unbuffered DDR3
1066/1333MHz SDRAM
Watchdog Timer
NA
H/W Status
Monitor
Monitoring temperature, Voltage, and Fan status.with Auto throttling
control
Expansion
1 x PCIex16 , 1 x Mini PCIe
I/O
MIO
4 SATA II 3.0Gb/s
1 x S/PDIF Out header
2 x 4-pin fan connectors, 1 x 3-pin fan connectors
1 x Front panel high definition audio header
1 x Front System Panel connector
1 x Speaker header
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
EMX-H61 Quick Installation Guide 5
USB
2 x USB 3.0 Ports , rear I/O connectors
4 x USB 2.0 Ports ,rear I/O connectors
4 x USB 2.0 Ports , internal pin-header
Parallel Port
NA
PS2 KB/MS
NA
DIO
NA
Display
Chipset
Intel® HD Graphics Media Accelerator 2000/3000 (Based on CPU type)
Support for DX10.1 and OpenGL3.0
Resolution
VGA 2048X1536 @ 75 Hz
HDMI 1920 x 1200 @ 60 Hz
DVI –D 1920 x 1200 @ 60 Hz
(The DVI-D port does not support D-Sub connection by adapter)
Dual Display
CRT+DVI, CRT+HDMI, DVI+HDMI
Audio
Audio Codec
Realtek® ALC892 7.1-Channel High-Definition Audio codec
Audio Interface
Mic-in , Line-in,Line out , Center/Subwoofer, Rear R/L ,S/PDIF out
Ethernet
LAN Chip
Dual Broadcom® 57788 PCI-Express Gigabit Ethernet
Ethernet
Interface
10/100/1000 Base-Tx Gigabit Ethernet
Mechanical &
Environmental
Power
Requirement
+12V/+5V/+5Vsb/+3.3V/-12V
Power Type
ATX
Operating Temp.
0 ~ 50°C (32 ~ 121°F)
Storage Temp
-40 ~ 75°C (-40 ~ 75°F)
Operating
Humidity
0 ~ 90% Relative Humidity, Non-condensing
Size (L x W)
6.69” x 6.6” (170mm x 170mm)
Weight
0.88lbs (0.4kg)
Others
Ordering Information: EMX—H61-A1R
Intel® Core™ i7, Core™ i5, Core™ i3, Pentium® /Celeron® Mini ITX
Montherboard with Intel® H61 Express Chipset and
VGA ,DVI-D ,HDMI, Audio ,2GbE , 1 PCIex16 , 1 Mini PCIe,4 SATA II, 2
x USB 3.0 , 8 x USB 2.0 , W/SATA Cable , Bracket / CD driver
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
6 EMX-H61 Quick Installation Guide
2Hardware
Configuration
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
EMX-H61 Quick Installation Guide 7
2.1 Product Overview
2.1.1 Main board layout
2.1.2 Connecting Rear Panel I/O Devices
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
8 EMX-H61 Quick Installation Guide
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
EMX-H61 Quick Installation Guide 9
2.2 Setting Jumpers & Connectors
2.2.1 Additional USB Port Headers (FUSB1/FUSB2)
2.2.2 JME
Can’t refresh the ME
Refresh the ME
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
10 EMX-H61 Quick Installation Guide
2.2.3 CMOS Memory Clearing Header (JBAT)
* Default
Normal*
Clear CMOS
2.2.4 CPU/System Fan Power Connectors Header (CFAN/SFAN1/SFAN2)
CFAN1
SFAN1
SFAN2
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
EMX-H61 Quick Installation Guide 11
2.2.5 ATX Power Input Connectors (PWR12V/ATXPWR)
ATXPWR (ATX Power) connector
PWR12V (+12V Power) connector
2.2.6 Front Panel Switches (FPANEL)
HD_LED (Red): Hard Drive LED connector
RST (Blue): Reset Switch
PWR_ON (Black): Power Switch
PWR_LED (Green): Power/Standby LED
All manuals and user guides at all-guides.com

EMX-H61 Quick Installation Guide
12 EMX-H61 Quick Installation Guide
2.2.7 Speaker Headers (SPEAK)
2.2.8 Front Panel Audio Connection Header (F_AUDIO)
