Avalue Technology EMX-H61B series User manual

Part No. E2047H61B01R
EMX-H61B
Intel® Core™/ Pentium®/ Celeron® Mini ITX
Motherboard with Intel® H61 Express Chipset
User’s Manual
2nd Ed –14 August 2015

EMX-H61B User’s Manual
2 EMX-H61B User’s Manual
Content
1. Getting Started....................................................................................................4
1.1 Safety Precautions ...................................................................................4
1.2 Packing List .............................................................................................4
1.3 Document Amendment History..................................................................5
1.4 Manual Objectives....................................................................................6
1.5 Specifications ..........................................................................................7
1.6 Architecture Overview—Block Diagram .....................................................9
2. Hardware Configuration .................................................................................... 10
2.1 Product Overview................................................................................... 11
2.2 Installation Procedure............................................................................. 13
2.3 Jumper and Connector List.....................................................................14
2.4 Setting Jumpers & Connectors................................................................ 16
2.4.1 Clear CMOS (JBAT)........................................................................16
2.4.2 ME update (JME) ............................................................................16
2.4.3 DDR3/DDR3L using (JDIMM)........................................................... 17
2.4.4 LVDS connector for 18/24 bit switches (JLVDS) ................................17
2.4.5 LVDS Power connector (JLVDS_P)..................................................18
2.4.6 LVDS connector (LVDS1) ................................................................18
2.4.7 General Purpose I/O (JGPIO1)......................................................... 19
2.4.8 Serial port 1/2 connector (JCOM1/2).................................................19
2.4.9 System Fan connector (SFAN1).......................................................20
2.4.10CPU Fan connector (CFAN1)..........................................................20
2.4.11USB Connector 1/2 - USB2.0 (FUSB1/2).......................................... 21
2.4.12Front Panel Switches (FPANEL)...................................................... 21
2.4.13 DC power-in connector (JDCIN) ...................................................... 22
2.4.14 Inverter connector (Inverter)............................................................ 22
2.4.15 SATA Power connector 1/2 (JSATA_P1/2).......................................23
2.4.16 Speaker Headers (JSPEAK) ........................................................... 23
2.4.17 DC power-in connector (DCIN)........................................................ 24
3.BIOS Setup............................................................................................................ 25
3.1 Introduction............................................................................................26
3.2 Starting Setup........................................................................................ 26
3.3 Using Setup........................................................................................... 27
3.4 Getting Help .......................................................................................... 28
3.5 In Case of Problems............................................................................... 28
3.6 BIOS setup............................................................................................ 29

EMX-H61B User’s Manual
EMX-H61B User’s Manual 3
3.6.1 Main Menu...................................................................................... 29
3.6.1.1 System Language.....................................................................29
3.6.1.2 System Date ............................................................................ 29
3.6.1.3 System Time............................................................................ 29
3.6.2 Advanced BIOS settings ..................................................................30
3.6.2.1 CPU Configuration....................................................................30
3.6.2.2 Onboard Device Configuration................................................... 31
3.6.2.3 USB Legacy Features...............................................................32
3.6.2.4 Inter® Rapid Start Technology...................................................33
3.6.2.5 Advanced Power Management..................................................33
3.6.2.6 Super IO Configuration ............................................................. 34
3.6.2.7 HW Monitor.............................................................................. 36
3.6.2.8 Watchdog Configuration............................................................ 37
3.6.2.9 Serial Port Console Redirection.................................................37
3.6.3 Chipset............................................................................................ 39
3.6.3.1 SB Configuration ......................................................................39
3.6.3.2 NB Configuration...................................................................... 40
3.6.4 Boot settings...................................................................................41
3.6.5 Security.......................................................................................... 42
3.6.5.1 Administrator Password............................................................ 42
3.6.5.2 User Password......................................................................... 42
3.6.6 Save & Exit.....................................................................................43
3.6.6.1 Save Changes and Reset .........................................................43
3.6.6.2 Discard Changes and Reset...................................................... 43
4. Drivers Installation ............................................................................................... 44
4.1 Install Chipset Driver ..............................................................................45
4.2 Install VGA Driver .................................................................................. 46
4.3 Install LAN Driver (For Realtek 8111E Gigabit Ethernet)...........................47
4.4 Install ME Driver .................................................................................... 48
4.5 Install Audio Driver (For Realtek ALC661 HD Audio) ................................ 50
5. Mechanical Drawing ............................................................................................. 51

EMX-H61B User’s Manual
4 EMX-H61B User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Always note that improper disassembling action could cause damage to the
motherboard. We suggest not removing the heatsink without correct
instructions in any circumstance. If you really have to do this, please contact
us for further support.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
Driver/Utility CD X 1
Serial ATA Signal Cable X 1
Serial ATA Power Cable X 1
IO Shield
COM Cable X 1
Screw X 2
CPU Cooler back plate
Motherboard X 1

EMX-H61B User’s Manual
EMX-H61B User’s Manual 5
1.3 Document Amendment History
Revision
Date
By
Comment
1st
May 2013
Avalue
Initial Release
2nd
August 2015
Avalue
Update Block Diagram

EMX-H61B User’s Manual
6 EMX-H61B User’s Manual
1.4 Manual Objectives
This manual describes in details Avalue Technology EMX-H61B Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to set up
EMX-H61B series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
If you have any suggestions or find any errors regarding this manual and want to inform us
of these, please contact our Customer Service department with the relevant details.

EMX-H61B User’s Manual
EMX-H61B User’s Manual 7
1.5 Specifications
System
CPU
Intel® LGA1155 Socket Supports 2nd /3rd Generation Core™i7/ i5/ i3,
Pentium® and Celeron® Processors (Max. TDP at 65W)
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
System Chipset
Intel® H61 Chipset
I/O Chip
ITE IT8728F
System Memory
2 x 204-pin DDR3/DDR3L(Jumper Selectable) 1333/1600 SODIMMs, Up to 16
GB
Watchdog Timer
H/W Reset, 1sec. –65535sec./min.
1sec. or 1min. step
H/W Status
Monitor
CPU & system temperature monitoring
Voltages monitoring
TPM
N/A
Buzzer
Buzzer onboard
Expansion
1 x Mini PCI-esupported mSATA only
1 x Mini PCI-esupported WiFi
I/O
Rear Side External
I/O Connector
1 x RJ-45
2 x dual deck USB 2.0 connectors
1 x VGA
1 x HDMI
1 x Mic-Inand 1 x Line-out
DC Jack
Internal I/O
Connector
Storage:
- 2 x SATA II connectors
- 2 x SATA power connectors
- 1 x mSATA by Mini PCI-e slot (support mSATA only)
COM:
- COM1~2: support RS-232 connector, without / +5V&+12V supported
GPIO: 8 bits
1 x Mini PCI-eslot for WiFi
2 x 2 x 5 pin, pitch 2.54mm connector for USB 2.0
1 x 4 pin CPUfan connector with smart fanfunction supported
1 x 3 pin System fan connector.
1 x horizontal type battery connector
1 x 2 x 5 pin, pitch 2.54mm connector for front panel

EMX-H61B User’s Manual
8 EMX-H61B User’s Manual
1 x 2 x 2 pin ATX power connector for DC +12~19V input
1 x 2 x 15 pin , pitch 1.00mm connector for LVDS
1 x 6 pin , pitch 2.00mm connector for Inverter
1 x 4 pin , pitch 2.00mm connector for speaker
1 x DC Jackconnector
Display
Chipset
Intel H61 integrated
Resolution
Dual display pipes supported
- HDMI: 1920x1080
- VGA: 2048x1536
LVDS
Pardac PS8625 eDP to LVDS ,Support 2CH 24bits LVDS 1920x1200
Audio
Chipset
Realtek ALC661 HD Audio Decoding Controller.
Audio Interface
Mic-In, Line-In
Audio Amplifier
Realtek ALC112 Stereo Class-D 5Wx 2
Ethernet
Chipset
1 x Realtek RTL8111E PCI-Express Gigabit Ethernet
Ethernet Interface
10/100/1000 Gigabit Ethernet
Mechanical &
Environmental
Power
Requirement
DC in+12V~19V
Power Type
Single power +12V~19V Power input / ATX mode
ACPI
Single power ATX Support S0,S1, S3, S4, S5
ACPI 3.0 Compliant
Operating Temp.
0°C ~60°C
Storage Temp.
-40°C ~75°C
Operating
Humidity
0%~90% relative humidity, non-condensing
Size (L x W)
6.7" x 6.7"(170mm x 170mm)
Weight
0.40 kg
Note: Specificationsare subject to change without notice.

EMX-H61B User’s Manual
EMX-H61B User’s Manual 9
1.6 ArchitectureOverview—Block Diagram
The following block diagram shows the architecture and main components of EMX-H61B.

EMX-H61B User’s Manual
10 EMX-H61B User’s Manual
2.Hardware
Configuration

EMX-H61B User’s Manual
EMX-H61B User’s Manual 11
2.1 Product Overview

EMX-H61B User’s Manual
12 EMX-H61B User’s Manual

EMX-H61B User’s Manual
EMX-H61B User’s Manual 13
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the DIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change BIOS settings to support flat
panel.
4. Connect power supply to the board via the AC/DC Adapter.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the "Save & Exit \
RestoreDefaults" feature.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.

EMX-H61B User’s Manual
14 EMX-H61B User’s Manual
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JBAT
Clear CMOS
1 x 3 header, pitch 2.00 mm
JME
ME update
1 x 2 header, pitch 2.00 mm
JLVDS
LVDS connector for 18/24 bit switches
2 x 3 header, pitch 2.00 mm
JLVDS_P
LVDS Power connector
1 x 3 header, pitch 2.00 mm
JDIMM
DDR3/DDR3L using
1 x 4 header, pitch 2.00 mm
Connectors
Label
Function
Note
F_MIC
Mic-in audio jack
3.5mm phone jack
F_OUT
Line-out audio jack
3.5mm phone jack
DU3SB1
USB connector
Stack USB 2.00 connector

EMX-H61B User’s Manual
EMX-H61B User’s Manual 15
DUSB1
USB connector
Stack USB 2.00connector
LAN1
RJ-45 Ethernet connector 1
RJ45 w/ indicator connector
DCIN
DC power-in connector
JDCIN
DC power-in connector
2 x 2 wafer , pitch 4.20 mm
FPANEL
Front Panel Switches
2 x 5 header, pitch 2.54 mm
LVDS1
LVDS connector
2 x15 wafer, pitch 1.0 mm
JSPEAK
Speaker Headers
1 x 4 wafer, pitch 2.00 mm
HDMI1
HDMI connector
MSATA
mSATA slot
Full size
SATA1/2
Serial ATA connector 1/2
SATA 7P connector
JSATA_P1/2
SATA Power connector 1/2
1 x 4 wafer, pitch 2.54 mm
JCOM1/2
Serial port 1/2 connector
2 x 5 header, pitch 2.00 mm
JGPIO1
General Purpose I/O
2 x 6 header, pitch 2.54 mm
F_USB1/2
USB Connector 1/2 - USB2.0
2 x 5 header, pitch 2.54 mm
SFAN1
System Fan connector
1 x 3 wafer, pitch 2.54 mm
CFAN1
CPU Fan connector
1 x 4 wafer, pitch 2.54 mm
VGA
VGA connector
D-SUB 15pin
MPCIE
Mini-PCIe
Half size
DIMM1
DDR3 SODIMM connector1
SO-DIMM 204Pin
DIMM2
DDR3 SODIMM connector2
SO-DIMM 204Pin
Inverter
Inverter connector
1 x 6 wafer, pitch 2.00mm

EMX-H61B User’s Manual
16 EMX-H61B User’s Manual
2.4 Setting Jumpers & Connectors
2.4.1 Clear CMOS (JBAT)
* Default
Normal*
Clear CMOS
Pin
Define
1-2
Normal
2-3
Clear CMOS
2.4.2 ME update (JME)
* Default
Refresh the ME*
Can’t refresh the ME

EMX-H61B User’s Manual
EMX-H61B User’s Manual 17
2.4.3 DDR3/DDR3L using (JDIMM)
* Default
DDR3*
DDR3L
Pin
Define
Open
DDR3L
Close
DDR3
2.4.4 LVDS connector for 18/24 bit switches (JLVDS)
* Default
8 BIT JEIDE* 8BIT VESA
SINGLE LINK LVDS
Pin
Define
1-3
8BIT JEIDE
3-5
8BIT VESA
NC
6BIT
2-4
NC=DUANL LINK LVDS
CLOS=SINGLE LINK LVDS

EMX-H61B User’s Manual
18 EMX-H61B User’s Manual
2.4.5 LVDS Power connector (JLVDS_P)
* Default
+5V*
+3.3V
Pin
Define
Max current
1-2
+3.3V
1A
2-3
+5V
1A
Note: This jumper is working for LVDS1 VDD
power.
2.4.6 LVDS connector (LVDS1)
Note: Mapping connector CSI-1171-30 (1.0mm).
Signal
PIN
PIN
Signal
GND
1
2
GND
DTX0+
3
4
DTX1+
DTX0-
5
6
DTX1-
DTX2+
7
8
DCLK+
DTX2-
9
10
DCLK-
DTX3+
11
12
GND
DTX3-
13
14
TX3+
GND
15
16
TX3-
TX0+
17
18
TX1+
TX0-
19
20
TX1-
TX2+
21
22
CLK+
TX2-
23
24
CLK-
GND
25
26
GND
VDD
27
28
VDD
VDD
29
30
VDD

EMX-H61B User’s Manual
EMX-H61B User’s Manual 19
2.4.7 General Purpose I/O (JGPIO1)
Signal
PIN
PIN
Signal
+5V
1
2
12V
GPO
3
4
GPI
GPO
5
6
GPI
GPO
7
8
GPI
GPO
9
10
GPI
GND
11
12
GND
2.4.8 Serial port 1/2 connector (JCOM1/2)
Signal
PIN
PIN
Signal
DCD
1
2
RXD
TXD
3
4
RTD
GND
5
6
DSR
RTS
7
8
CTS
RI
9
Note: COM 1/2 Pin9 without power.
JCOM2
JCOM1

EMX-H61B User’s Manual
20 EMX-H61B User’s Manual
2.4.9 System Fan connector (SFAN1)
PIN
Signal
1
RPM
2
+12V
3
Ground
2.4.10 CPU Fan connector (CFAN1)
PIN
Signal
1
Ground
2
+12V
3
RPM
4
Control
