Avalue Technology ENX-US15WP User manual

ENX-US15WP
Intel® Atom™ Processor Nano ITX Motherboard
User’s Manual
Ver. 1.04

ENX-US15WP
2
Contents
Safety Information ..........................................................................................................4
Safety Declaration ...........................................................................................................5
Technical Support ............................................................................................................5
Conventions Used in This Guide....................................................................................5
Packing List.......................................................................................................................6
Revision History ...............................................................................................................7
Specifications Summary..................................................................................................8
Block Diagram.................................................................................................................11
Production Introduction ...............................................................................................13
1.1 Before you Proceed ................................................................................................13
1.2 Motherboard Overview............................................................................................14
1.2.1 Placement Direction ....................................................................................................................... 14
1.2.2 Screw Holes ................................................................................................................................... 14
1.3 Motherboard Layout ................................................................................................15
1.3.1 Layout Content List ........................................................................................................................ 16
1.4 System Memory ......................................................................................................17
1.4.1 DIMM Sockets Location ................................................................................................................. 17
1.4.2 Memory Configurations .................................................................................................................. 18
1.4.3 Installing a DDR2 DIMM................................................................................................................. 19
1.4.4 Removing a DDR2 DIMM............................................................................................................... 20
1.5 Jumpers ..................................................................................................................21
1.5.1 Clear CMOS (CLRTC).................................................................................................................... 21
1.5.2 COM1 RI/+5V/+12V Select (JCOMPWR1) .................................................................................... 22
1.6 Connectors..............................................................................................................23
1.6.1 Rear Panel Connectors.................................................................................................................. 23
1.6.2 Chassis Fan Connector (CHA_FAN1) ........................................................................................... 24
1.6.3 Serial Port Connector 1 (COM1) .................................................................................................... 24
1.6.4 System Panel Connector (F_PANEL) ............................................................................................ 25
1.6.5 Primary EIDE Connector (IDE) ...................................................................................................... 26
1.6.6 LCD Inverter Connector (JBKL) ..................................................................................................... 27
1.6.7 Digital I/O Connector (JDIO) .......................................................................................................... 28
1.6.8 LVDS Connector (JLVDS).............................................................................................................. 28
1.6.9 Audio Line-In Connector (LINE_IN) ...............................................................................................29
1.6.10 ATX Power Connector (MATXPWR2) ....................................................................................... 29
1.6.11 USB 2.0 Connector (USB34) ..................................................................................................... 30

User’s Manual
ENX-US15WP
3
Contents
BIOS Setup......................................................................................................................32
2.1 BIOS Setup Program ..............................................................................................32
2.1.1 Legend Box .................................................................................................................................... 33
2.1.2 List Box........................................................................................................................................... 33
2.1.3 Sub-menu....................................................................................................................................... 33
2.2 BIOS Menu Screen .................................................................................................34
2.2.1 Standard CMOS Features.............................................................................................................. 35
2.2.2 Advanced BIOS Features .............................................................................................................. 37
2.2.3 Advanced Chipset Features........................................................................................................... 41
2.2.4 Integrated Peripherals.................................................................................................................... 43
2.2.5 PnP/PCI Configurations ................................................................................................................. 48
2.2.6 PC Health Status............................................................................................................................ 50
2.2.7 Load Setup Defaults....................................................................................................................... 51
2.2.8 Set Supervisor Password............................................................................................................... 52
2.2.9 Set User Password......................................................................................................................... 53
2.2.10 Save and Exit Setup .................................................................................................................. 54
2.2.11 Exit Without Saving.................................................................................................................... 55

ENX-US15WP
4
Safety Information
Electrical safety
zTo prevent electrical shock hazard, disconnect the power cable from the electrical
outlet before relocating the system.
zWhen adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
zBefore connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
zSeek professional assistance before using an adapter or extension cord. These
devices could interrupt the grounding circuit.
zMake sure that your power supply is set to the correct voltage in your area. If you are
not sure about the voltage of the electrical outlet you are using, contact your local
power company.
zIf the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
zBefore installing the motherboard and adding devices on it, carefully read all the
manuals that came with the package.
zBefore using the product, make sure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
zTo avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
zAvoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
zPlace the product on a stable surface.
zIf you encounter technical problems with the product, contact a qualified service
technician or your retailer.
The symbol of the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic
products.

User’s Manual
ENX-US15WP
5
Safety Declaration
This device complies with the requirements in Part 15 of the FCC rules. Operation is
subject to the following two conditions:
zThis device may not cause harmful interference.
zThis device must accept any interference received, including interference that may
cause undesired operation.
Technical Support
If a problem arises with your system and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor. Alternatively, please try
the following help resources for further guidance. Visit the Avalue website:
http://www.avalue.com.tw
Conventions Used in This Guide
To make sure that you perform certain tasks properly, take note of the following symbols
used throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when
trying to complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.

ENX-US15WP
6
Packing List
Before you begin installing your single board, please make sure that the following materials
have been shipped:
z1 x ENX-US15WP Nano ITX Main board
z1 x CD-ROM contains the followings:
•User’s Manual in PDF file
•Drivers
z1 x Cable Kit
•1 x COM Cable w/o Bracket (9P/2.00mm)
•1 x IDE Cable (44P-44P)
•1 x MD6M to MD6F*2 Cable
•1 x ATX Power Cable (6P-20P)
z1 x Startup Manual
If any of the above items is damaged or missing, please contact your
retailer.

User’s Manual
ENX-US15WP
7
Revision History
Revision Revision History Date
V 1.00 First release for PCB 1.00 May 18, 2009
V1.01 Corrections of pin header pitch at Page 16 September 28, 2009
V1.02 Correction of RJ45 LED status at Page 23 December 18, 2009
V1.03 Adjust Connectors direction of Pin#1 January 4, 2010
V1.04 Add internal 2nd COM port header May 1, 2010

ENX-US15WP
8
Specifications Summary
CPU Intel® Atom™ processor Z510P 1.1GHz/Z530P 1.6GHz
(400/533 MT/s MHz FSB)
Chipset Intel® System Controller Hub US15WP
Memory 1 x 200-pin SODIMM 2 GB DDR2 400/533 org.x16 SDRAM
Display 1 x VGA (By Chrontel CH7317), 1 x LVDS
Audio Realtek ALC 888 7.1 Channel High Definition Audio Codec
(co-lay ALC 888VC)
LAN Realtek RTL 8111C Gigabit LAN
Expansion 1 x Mini PCIe, 1 x CF
I/O
4 x USB (2 x connectors , 1 x pin header)
1 x COM port w/ power header
1 x PATA interface
1 x Chassis Fan header
Features
Others 8bit GPIO (4 in, 4 out), Clock (CK540)
System
CPU Intel® Atom™ processor Z510P 1.1GHz/Z530P 1.6GHz
FSB 400/533 MHz
BIOS Award 8 Mb FHW BIOS
System Chipset Intel® System Controller Hub US15WP
I/O Chipset Winbond W83627DHG
Memory 1 x 200-pin SODIMM 2 GB DDR2 400/533 org.x16 SDRAM
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring CPU temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats
Expansion Slots 1 x Mini PCIe, 1 x CF
DIO 8-bit General Purpose I/O for 4 DI and 4 DO
S3 / S4 S3/S4
Wake up on LAN or
Ring Both (PXE / RPL / WOR)
SmartFan Control Support 3 modes (Silent/Optimal/Performance)

User’s Manual
ENX-US15WP
9
Specifications Summary
Display
Chipset Intel® System Controller Hub US15WP
Display Memory Intel® Graphics Media Accelerator 500 (Intel® GMA 500)
Max. Resolution LVDS Display : 1366 x 768 @85 MHz
Ext Display: 1280 x 1024 @ 85 Hz maximum resolution
Dual Display Yes, LVDS+VGA
VGA Yes
LVDS Yes, 18/24 bit Single Channel
LVDS Backlight Power Yes
Audio
Audio Codec Realtek ALC 888 (co-lay ALC 888VC)
Audio Interface Mic in , Line out (2 jack) , Line in pin header
Ethernet
LAN1 Realtek RTL 8111C Gigabit LAN
Back I/O Port
Back Panel
1 x PS2 (KB+MS)
1 x VGA port
2 x USB 2.0/1.1
1 x LAN RJ45 port
1 x Audio Mic in (1 jack)
1 x Audio Line out (1 jack)
Internal I/O Connector
Internal I/O
1 x USB connectors support additional 2 USB ports
1 x 6-pin ATX Power connector
1 x COM port w/ power pin header
1 x LVDS connector
1 x Chassis FAN connector
1 x GPIO connector
1 x PATA interface
1 x Audio Line in

ENX-US15WP
10
Specifications Summary
Mechanical & Environmental
Power Requirement 36W
Power Type ATX Power
Operating Temperature 0-60℃(32 ~ 104 )℉
Operating Humidity 0%~90% relative humidity, non-condensing
Size (L x W) 4.72" x 4.72" (120 mm x 120 mm)
Weight 0.3 lbs (0.14Kg)
* Specifications are subject to change without notice.

User’s Manual
ENX-US15WP
11
Block Diagram

ENX-US15WP
12
This chapter describes the main board
features and the new technologies
it supports.
1
Product
introduction
1
Product
introduction

User’s Manual
ENX-US15WP
13
Production Introduction
1.1 Before you Proceed
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
zUnplug the power cord from the wall socket before touching any
component.
zUse a grounded wrist strap or touch a safely grounded object or a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity
zHold components by the edges to avoid touching the ICs on
them.
zWhenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.
zBefore you install or remove any component, ensure that the ATX
power supply is switched off or the power cord is detached from
the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

ENX-US15WP
14
1.2 Motherboard Overview
Before you install the motherboard, study the configuration of your chassis to ensure that
the motherboard fits into it. Refer to the chassis documentation before installing the
motherboard.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and
damage motherboard components.
1.2.1 Placement Direction
When installing the motherboard, make sure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.2.2 Screw Holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the
chassis.
Do not over tighten the screws! Doing so can damage the
motherboard.
Place this side towards the rear of the
chassis

User’s Manual
ENX-US15WP
15
1.3 Motherboard Layout

ENX-US15WP
16
1.3.1 Layout Content List
Slots
Label Function Note Page
CF Compact Flash Card (Rear side) N/A
MINI_PCIE Mini PCI-e Slot N/A
SO_DIMM 200-pin DDR2 SODIMM slot (Rear side) N/A
Jumpers
Label Function Note Page
CLRTC Clear CMOS 3 x 1 header, pitch 2.54mm 21
JCOMPWR1 COM1 RI/+5V/+12V Select 3 x 2 header, pitch 2.54mm 22
JCOMPWR2 COM2 RI/+5V/+12V Select 3 x 2 header, pitch 2.00mm 22
Rear Panel Connector
Label Function Note Page
KBMS PS/2 keyboard and mouse 6-pin Mini-Din 23
VGA VGA Connector D-sub 15-pin, female 23
USB12 USB Connector x 2 23
LAN RJ-45 Ethernet Connector 23
MIC_IN Microphone Port 23
LINE_OUT Line-out Port 23
Internal Connector
Label Function Note Page
CHA_FAN1 Chassis Fan Connector 3 x 1 wafer, pitch 2.54mm 24
COM1 Serial Port Connector 1 5 x 2 header, pitch 2.54mm 24
COM2 Serial Port Connector 2 5 x 2 header, pitch 2.54mm 24
F_PANEL System Panel Connector 5 x 2 header, pitch 2.54mm 25
IDE Primary EIDE Connector 20 x 2 header, pitch 2.54mm 26
JBKL LCD Inverter Connector 5 x 1 header, pitch 2.00mm 27
JDIO Digital I/O Connector 5 x 2 header, pitch 2.54mm 28
JLVDS LVDS Connector HIROSE DF13S-40DP-1.25V 28
LINE_IN Line-In Connector 5 x 1 header, pitch 2.54mm 29
MATXPWR2 ATX Power Connector 3 x 2 header 29
USB34 USB 2.0 Connector 5 x 2 header, pitch 2.54mm 30

User’s Manual
ENX-US15WP
17
1.4 System Memory
1.4.1 DIMM Sockets Location
The motherboard comes with two 200-pin Double Data Rate 2 (DDR2) SODIMM sockets.
A DDR2 module has the same physical dimensions as a DDR DIMM but has a 200-pin
footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched differently to
prevent installation on a DDR DIMM socket. The following figure illustrates the location of
the sockets:

ENX-US15WP
18
1.4.2 Memory Configurations
You can install 256MB, 512MB, 1GB and 2GB DDR2 SDRAM DIMMs into the SODIMM
sockets using the memory configurations in this section.
zInstalling DDR2 DIMM other than the recommended
configurations may cause memory sizing error or system boot
failure. Use any of the recommended configurations.
zDue to chipset resource allocation, the system may detect less
than 1 GB system memory when you installed one 1 GB DDR2
memory modules.
zThis motherboard does not support memory modules made up of
128 Mb chips or single-sided x8 memory modules.
Make sure that the memory frequency matches the CPU FSB
(Front Side Bus). Refer to the Memory frequency/CPU FSB
synchronization table.

User’s Manual
ENX-US15WP
19
1.4.3 Installing a DDR2 DIMM
Make sure to unplug the power supply before adding or removing
DIMMs or other system components. Failure to do so may cause
severe damage to both the motherboard and the components.
1. Locate the DIMM socket on the board.
2. Hold two edges of the DIMM module carefully, and keep away of touching its
connectors.
3. Align the notch key on the module with the rib on the slot.
4. Firmly press the modules into the socket automatically snaps into the mounting notch.
Do not force the DIMM module in with extra force as the DIMM module only fit in one
direction.
zA DDR2 DIMM is keyed with a notch so that it fits in only one
direction. DO NOT force a DIMM into a socket to avoid damaging
the DIMM.
zThe DDR2 DIMM sockets do not support DDR DIMMs. DO NOT
install DDR DIMMs to the DDR2 DIMM socket.

ENX-US15WP
20
1.4.4 Removing a DDR2 DIMM
1. Press the two ejector tabs on the slot outward simultaneously, and then pull out the
DIMM module.
Support the DIMM lightly with your fingers when pressing the ejector
tabs. The DIMM might get damaged when it flips out with extra force.
