Operator's Manual for Attachment
Hydraulic side shift adapter
Product number:
A37235
English
A433750 2018 1 EN 2017-
www.avanttecno.com

Hydraulic side shift adapter 2018 1

Hydraulic side shift adapter 2018 1
CONTENTS
1. FOREWORD ............................................................................................................................................4
Warning symbols used in this manual ............................................................................................................................... 5
2. DESIGNED PURPOSE OF USE.............................................................................................................6
3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT........................................................7
4. TECHNICAL SPECIFICATIONS ..........................................................................................................11
4.1 Safety labels and main components of the attachment.................................................................................. 11
5. ASSEMBLING THE ATTACHMENT....................................................................................................13
5.1.1 Coupling the side shift adapter to the loader ......................................................................................... 13
5.2 Mounting attachment to the side shift adapter ............................................................................................... 15
5.3 Connecting and disconnecting hydraulic hoses............................................................................................... 15
6. INSTRUCTIONS FOR USE....................................................................................................................17
6.1 Checks before use................................................................................................................................................. 18
6.2 Using the side shift adapter ................................................................................................................................. 19
6.3 Maximum load........................................................................................................................................................ 20
6.4 Horizontal adjustment.......................................................................................................................................... 21
6.5 Auxiliary hydraulics outlet (optional extra for loaders)................................................................................ 22
6.6 Working on uneven ground................................................................................................................................ 22
6.7 Transport position ................................................................................................................................................ 23
6.8 Uncoupling and storage........................................................................................................................................ 24
7. MAINTENANCE AND SERVICE ..........................................................................................................25
7.1 Inspection of hydraulic components.................................................................................................................. 25
7.2 Cleaning the attachment ...................................................................................................................................... 26
7.3 Lubrication .............................................................................................................................................................. 26
7.4 Inspection of metal structures............................................................................................................................ 26
8. WARRANTY TERMS..............................................................................................................................27

4 (30)
1. Foreword
Avant Tecno Oy would like to thank you for your purchase of this attachment for your Avant loader. It has
been designed and manufactured based on years of experience on product development and manufacturing.
By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure
the reliable operation and long service life of the equipment. Read the instructions carefully before starting to
use the equipment or performing maintenance.
The purpose of this manual is to help you to:
operate the equipment in a safe and efficient manner
observe and prevent any hazardous situations
keep the equipment intact and ensure a long service life
With these instructions, even an inexperienced user can use the attachment and loader safely. The manual
includes important instructions for experienced AVANT operators as well. Ensure that all persons using the
loader have received proper guidance and familiarised themselves with the manual of the loader, each
attachment that are used, and all safety instructions before using the equipment. Using the equipment for
other purposes or use in any other way than described in this manual is prohibited. Keep this manual at hand
throughout the service life of the equipment. If you sell or transfer the equipment, be sure to hand over this
manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant
dealer or from the manufacturer.
In addition to the safety instructions included in this manual, you must observe all occupational safety
regulations, local laws, and other regulations concerning the use of the equipment. Particularly the regulations
concerning the use of the equipment on public road areas must be observed. Contact your Avant dealer for
more information about local requirements before you operate the loader on road areas.
Contact your local AVANT dealer for any questions, service, spare parts or about any problems that may
occur with the operation of your machine.
This manual contains the original instructions in English. Due to continuous product development some of the
details shown in this manual may differ from your equipment. Pictures may also depict optional equipment or
features that are not currently available. We reserve the right to change the contents of the manual without
notification. Copyright © 2019 Avant Tecno Oy. All rights reserved.

5 (30)
.
Warning symbols used in this manual
The following warning symbols are used throughout this manual. They indicate factors that must be taken into
account to reduce the risk of personal injury or damage to property:
WARNING: SAFETY ALERT SYMBOL
This symbol means: “Warning, be alert! Your safety is involved!”
Carefully read the message that follows, it warns of an immediate hazard
that could cause serious personal injury.
The safety alert symbol by itself and with related safety statement
indicates important safety messages throughout this Manual. It is used to
draw attention to instructions involving your personal safety or the safety
of others. When you see this symbol, be alert, your safety is involved,
carefully read the message that follows, and inform other operators.
DANGER:
This signal word indicates a hazardous situation which, if not avoided, will cause
death or serious injury.
WARNING:
This signal word indicates a potentially hazardous situation which, if not avoided,
could cause serious injury or death.
CAUTION:
This signal word is used when minor injury could result if the instructions are not
followed properly.
This signal word indicates information about the correct operation and maintenance
of the equipment.
Failure to observe the instructions accompanying the symbol can lead to equipment
breakdown or other property damage.

6 (30)
2. Designed purpose of use
The AVANT Hydraulic side shift adapter is an attachment that is suitable for use with AVANT multi purpose
loaders that are shown in Table 1. This adapter is intended for applications where an attachment needs to be
shifted horizontally in order to get the job done.
The Hydraulic side shift adapter is mounted to the loader like other attachments, between the quick attach
plate and the attachment that is going to be used. The hydraulic side shift adapter offers easy, stepless side
shift of an attachment. It is operated from the driver’s seat. When the loader is equipped with the optional
second auxiliary hydraulic outlets in the front, it is possible to use also hydraulically driven attachments at the
same time with the Hydraulic side shift adapter. In that case, the attachment hoses are mounted on the multi
connector and the side shift adapter hoses on the optional second outlet.
The quick coupling plate on the adapter can be mounted in three different positions: on the left, on the right, or
in the middle of the adapter. This gives three different side shift options: 500 mm side shift to the right or to the
left, or 250 mm side shift in both directions. The solid and robust design features strong sliding guides which
can also be lubricated.
It is recommended to use the hydraulic side shift adapter only with Avant 400-700 series loaders with
counterweights installed on the loader. When using the Hydraulic side shift adapter with a heavy attachment,
the loader may tip over as a result of displacement of the centre of gravity. Using a side shift adapter
decreases the lateral stability of the loader, and also decrease the tipping load of the loader. The Hydraulic
side shift adapter is not designed for any other use than what is specified in this manual and must not be used
for any other purposes than intended.
The attachment has been designed to require as little maintenance as possible. The operator can perform
regular maintenance tasks. All repair work can’t be performed by the operator, and demanding repair and
maintenance operations are to be left for professional maintenance. All maintenance work must be done using
proper safety equipment. Spare parts must be identical with original specifications, which can be ensured by
using only original spare parts. A separate spare parts catalogue may be available, consult your Avant dealer.
Familiarise yourself with the manual's instructions regarding service and maintenance. Please contact your
AVANT retailer if you have additional questions about the operation or maintenance of the equipment, or if
you require spare parts or maintenance services.
Table 1 - Hydraulic side shift adapter - Compatibility with Avant loaders
Model
220
225
225LPG
313S
320S
420
423
520
523
R20
525LPG
R28
528
530
630
R35
635
640
745
750
755i
760i
e5
e6
A36505 (•) (•) •••••
It is recommended to use the attachment only with loaders marked with •in Table 1. When using with models
marked with (•), full performance may not be achieved. Additional counterweights may also be required. For
compatibility with a model not shown in table, contact your Avant dealer.

7 (30)
3. Safety instructions for using the attachment
Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly
powerful and improper or careless use or maintenance may cause serious personal injury or property
damage. Due to this, all operators must carefully familiarise themselves about correct use and the operator's
manuals of both the loader and the attachment before starting operation. Do not use the attachment if you
have not completely familiarised yourself with its operation and the related hazards.
DANGER
Misuse, careless use, or using an attachment that is in poor condition, may
cause risk of serious injuries. Familiarise yourself with the controls
of the loader,
correct coupling procedure, and the correct way to operate the attachment at a safe
area. Study especially how to stop the equipment in a safe manner. Read all safety
precautions carefully.
Read all safety instructions carefully before handling the attachment
WARNING
When attaching an attachment to the loader, ensure that the locking pins of the
loader's quick attach plate are in the lower position and that they have locked
the attachment to the loader. Never lift or move an unlocked attachment.

Make sure attachment is securely connected to the side shift adapter. Always refer
also to the operator's manual of the separate attachment.

The side shift adapter and any attachment coupled to it are designed to be used by
one operator at a time
. Do not let others near the danger area of the equipment when
it is in use.
Risk of dropping of load or parts of attachments - Make sure load is secured on
the attachment, and that the attachment is set up properly. Make sure that a load
will not fall
uncontrollably off from the attachment. Secure moving parts of the
attachment before using them with a tilt adapter. For example, if using pallet forks,
make sure that the fork arm retainer bolts are fixed so that fork arms will not slide off
from the frame of the pallet forks.
Sudden movements can cause the loader to tip over - Operate the controls of
the loader in a slow and calm manner.
Be careful when lifting load to high level or
lifting load from high. Avoid sudden changes in speed or direction to maintain
balance of the loader especially when handling heavy loads. Drive slowly and
carefully especially on inclined terrain or slippery surfaces.
Risk of tipping over - Side shift adapter reduces the stability of the loader both
to sides and to front.
Use the side shift adapter only when necessary. Unnecessary
use increases the risk of tipping over. Always keep the side shift adapter at its middle
position when moving loads or heavy attachments with the side shift adapter. Always
transport the attach
ment as low as possible to keep the centre of gravity low, and
keep the telescopic boom of the loader completely retracted during driving.
Risk of tipping over - Keep the loader articulation in straight position when
handling heavy loads. When turning the articulation, the loader may tilt forward
Tipping over hazard - Make sure that overhead clearance is sufficient. Hitting an
overhead obstacle may cause the loader to tip over. Keep a safe distance from
electric cables, lamps, or other electric system
s; hitting live parts may cause electric
shock.

8 (30)
Never leave the driver’s seat when the auxiliary hydraulics control lever is locked on.
The attachment mounted on the side shift adapter may move, if the auxiliary
hydraulics control lever of the loader i
s locked on and there is a horizontally uneven
load on the attachment. Watch out for crushing of limbs when going near the
attachment.
Do not leave the driver’s seat when the loader boom is lifted. Going under a raised
attachment or loader boom is dang
erous. Always remember that the boom may lower
due to loss of stability, mechanical fault, or if another person operates the controls of
the loader.
Use the attachment only for its intended use and only with original tools and spare
parts.
When unlocking and dismounting the attachment off from the loader, ensure that it is
secured against accidental movement. To secure the attachment from tipping over
lower it firmly on the ground and disconnect only on level surface. Ensure the
attachment is properly supported during storage. Never climb on the attachment.
Make sure that the attachment is properly supported before performing any
inspections, maintenance, or adjustments. If necessary, secure the attachment with
suitable lifting equipment, or lower it on firm blocks of wood, for example.
Shut down the loader and place the attachment to a safe position as shown in Safe
stopping procedure before any cleaning, maintenance, or adjustments.
Pay attention to the surroundings and any other persons and machines moving in the
vicinity. Pay attention to the contours of the terrain and other hazards, such as
branches and trees that can reach to the driver's area, loose rocks, and slippery
surfaces.
Make sure to use only an attachment that is in good condition. Do not modify the
attachment in any way that could affect its safety.
Use the attachment only for its intended purpose. Other use may create unnecessary
safety risks, and the equipment may get damaged.
Make sure that the loader is equipped with necessary safety components, and that
they are in working condition. Seat belt must be used. If there are specific hazards
related to the operating area, use appropriate safety equipment.
Also read the safety instructions and correct use of the loader from the operator's
manual of the loader.
DANGER
Wrong, improper, or careless use of the attachment causes serious risk of severe
injuries or death.
Familiarise yourself with the controls of the loader in a safe area. Pay
particular attention to th
e safe stopping of the attachment and the loader; follow the safe
stopping procedure shown in this manual before leaving the driver's seat.
WARNING

9 (30)
WARNING
Risk of crushing -
Never allow anyone to get under a
lifted attachment or loader boom. Keep in mind t
hat the
loader boom can be lowered or tilted even if the engine has
been shut down (crushing hazard). The loader is not intended
to be left to keep a load elevated for longer periods. Always
lower the attachment to a safe position before leaving the
driver's seat.
WARNING
Risk of tipping over -
Side shift adapters reduce the
lateral stability of the loader. Always keep load close to
the ground, and always wear seat belt.
Pay special
attention to stability of the loader when a side shift adapter is
equipped with an attachment. The loader may tip over on
inclined or uneven surfaces causing serious injuries from
impact and crushing. Always wear seat belt. Use the side arm
only with loaders that are equipped with ROPS and FOPS.
Avoid abrupt movements an
d always drive slowly and
carefully on inclined terrains, and on uneven or slippery
surfaces. Use of additional counterweights is recommended.
WARNING
Risk of crushing - Avoid tipping over the attachment. Make sure the load on the
attachment or the moving parts of an attachment will not fall or swing when shifting the
attachment with the side shift adapter.

10 (30)
.
Remember to wear proper personal protective equipment:
The noise level at the driver's seat may exceed 85 dB(A) depending on loader
model and operating cycle. Extended exposure to loud noise can cause
hearing impairment. Wear hearing protection while working with the loader.
Wear protective gloves.
Wear safety boots whenever working with the loader.
Wear safety glasses e.g. when handling hydraulic components.
. ..
Safe stopping of the attachment, before going near the attachment:
WARNING
Always stop the attachment following safe stopping procedure before leaving
the driver's seat. Safe stopping procedure prevents all u
nintentional movements of
the attachment. Note that the loader boom can move down even if the engine of the
loader is turned off. Safe stopping procedure:
Lower the boom and the attachment on the ground.
Shut down the loader engine and lock the parking brake.

Release residual pressure from the hydraulic system; move all hydraulic control
levers to their extreme positions a couple of times.
Prevent starting of the machine, remove ignition key.

11 (30)
4. Technical specifications
Table 2 - Hydraulic side shift adapter - Specifications
Product number A37235
Width: 1270 mm
Height: 434 mm
Length: 218 mm
Weight: 115 kg
Max side shift: ± 250 mm in both directions or 500 mm to the left / right
Max load: 1000 kg
Attachment displacement: 172 mm
Recommended hydraulic oil flow: 10-20 l/min
Maximum input of hydraulic energy: 30 l/min 20 MPa (200 Bar)
Compatible Avant loaders: See Table 1
. ..
4.1 Safety labels and main components of the attachment
Listed below are the labels and markings on the attachment. They must be visible and readable on the
equipment. Replace any unclear or missing label. New labels are available via your retailer or contact
information provided on the cover.
WARNING
Make sure all warning decals are readable. The warning labels contain important
safety information and they help to identify and remember the hazards related to the
equipment. Replace damaged or missing warning labels with new ones.
Attachment identification plate
A423297
A46771 A46772 A46803
To apply a new label: Clean the surface thoroughly to remove all grease. Allow it to dry completely. Peel off
the protective film of the label and press firmly to apply. Take care not to touch the glue of the label.

12 (30)
.
Table 3 - Decal locations and warning messages
Decal Warning message
1 A36771 Misuse hazard - Read instructions before
use.
2 A36772
Crushing hazard - Do not go under a
raised attachment; stay away from raised
equipment.
3 A36803
Pinching and cutting hazard, keep clear
of moving parts, do not leave the
equipment running. Operate the
attachment only from the driver’s seat.
4 A423297 Attachment identification plate
. ..
. ..
Table 4 - Hydraulic side shift adapter - Main components
1
Avant quick coupling plate, for coupling this
attachment to Avant loaders
2
Attachment coupling plate to couple an
attachment to the side shift adapter
3
Locking pins to lock an attachment to the side
shift adapter
4 Extension cylinder
5 Carriage
6 Linear rails
7 Multiconnector holder

13 (30)
5. Assembling the attachment
Attaching the attachment to the loader is quick and easy, but it must be done carefully. The attachment is
mounted to the loader boom by using the quick attach plate on the loader boom and the counterpart on the
attachment.
If the attachment is not locked to the loader, it may detach from the loader and cause a hazardous situation.
The loader must not be driven and the boom must never be lifted when the attachment has not been locked.
To prevent hazardous situations, always follow the coupling procedure shown below. Also remember the
safety instructions shown in this manual. The attachment is mounted to the loader as follows:
WARNING
Crushing risk - Make sure that an unlocked attachment will not move or fall over.
Do not stay in the
area between the attachment and the loader. Mount the attachment
only on level surface.
Never move or lift an attachment that has not been locked.
Avant quick coupling system:
5.1.1 Coupling the side shift adapter to the loader
Step 1:
Lift the quick atta
ch plate locking pins up and turn them backwards into the slot
so that they are locked in the upper position.

If your loader is equipped with a hydraulic attachment locking system, see
additional instructions about the use of the locking system from the relevant
manuals.

Ensure that the hydraulic hoses and the electric harness are not in the way
during installation.
Step 2:
Turn the quick attach plate hydraulically to an obliquely forward position.
Drive the loader onto the attachment. If your loader
is equipped with a
telescopic boom, you can utilise this.

Align the upper pins of the loader’s quick coupling plate so that they are under
the corresponding brackets of the attachment.
Step 3:
Lift the boom slightly – pull the boom control lever back
ward to raise the
attachment off the ground.

Turn the boom control lever left to turn the bottom section of the quick attach
plate onto the attachment.
Lock the locking pins manually or lock the hydraulic locking.
Always check the locking of both locking pins.

14 (30)
WARNING
Risk of crushing - Avoid tipping over the attachment.
Excessive tilting or lifting of an
unlocked attachment increases the risk of tipping the attachment over. Do not use the
automatic locking of the locking pins when the attachment is
lifted more than one meter
from the ground. If the locking pins do not return to the normal position when tilting, do
not tilt or raise the attachment any more. Lower the attachment on the ground and
secure the locking manually.
WARNING
Risk of falling objects -
Prevent dropping of
attachment.
An attachment that has not been completely locked to the
loader may fall on the boom or towards the operator, or
fall under the loader during driving, causing loss of
control of the loader. Never move or lift a
n attachment
that has not been locked. Before moving or lifting the
attachment, make sure that the locking pins are in the
lower position and come through the fasteners on the
attachment on both sides.
WARNING
Make sure the loader is compatible with the attachment.
Stability of the loader,
possible overload of the attachment, and compatibility of loader control systems must be
ensured in addition to mechanical compatibility of the attachment. If you use the
attachment with a loader that is n
ot fit to be used with the attachment model you have,
risks include tipping over, damage to attachment due to overload, and risks related to
uncontrolled motion of attachment and its parts. If your loader is not listed in Table 1 on
page 6, ask your Avant dealer before using this attachment.

15 (30)
.
5.2 Mounting attachment to the side shift adapter
The side shift adapter is equipped with similar locking pins as the quick coupling of the loader. Ensure that all
four locking pins are in the lower position and they have locked securely.
Attaching an attachment to the side shift adapter is easiest, when the side shift adapter is first mounted on the
quick attach plate of the loader. After this the attachment can be mounted to the side shift adapter in a similar
way as without the side shift adapter.
5.3 Connecting and disconnecting hydraulic hoses
The Side shift adapter is equipped with a multiconnector for connecting the hydraulic hoses of the adapter to
the loader. To use a hydraulically operated attachment that is connected to the side shift adapter, the
multiconnector of the side shift adapter must be replaced with conventional type hydraulic couplings. Contact
your Avant dealer or service point for more information.
WARNING
Risk of movement of the attachment and ejection of hydraulic oil - Never connect
or disconnect quick couplings or other hydraulic components while the control
lever of the auxiliary hydraulics control lever is locked on or if the system is
pressurized. Connecting or disconnecting the hydraulic couplings while the system is
pressurized may lead to unintended movements of the attachment, or ejection of high-
pressure fluid, which can cause serious injuries or burns. Follow safe stopping procedure
before disconnecting hydraulics.
Keep all fittings as clean as possible; use the protective caps on both the attachment and
the loader. Dirt, ice, etc. may make using the fittings significantly more difficult. Never
leave the hoses hanging on the ground; place the couplings onto the holder on the
attachment.

16 (30)
Connecting the multiconnector system:
1.
Align the pins of the attachment connector with corresponding
holes of the loader connector. The multiconnector will not connect
if the attachment connector is upside down.
2. Co
nnect and lock the multiconnector by turning the lever towards
the loader.
The lever should move easily all the way to its locking position. If the lever does not slide smoothly, check the
alignment and position of the connector and clean the connectors. Also shut down the loader and release the
residual hydraulic pressure.
To disconnect the multiconnector system:
Before disconnecting put the attachment down on a solid and even
surface.
1. Switch off the auxiliary hydraulics of the loader.
2. While pushing
unlock button, turn the lever to disconnect the
connector.
3.
After ending operation put the multiconnector on its holder on the
attachment.
Disconnecting hydraulic hoses:
Before disconnecting the fittings, lower the attachment to safe position on solid and level surface. Turn the
control lever of the auxiliary hydraulics to its neutral position.
When uncoupling the attachment, always disconnect the hydraulic couplings before
unlocking the quick attach plate, to prevent hose damage and any oil spills.
Reinstall the
protective caps on the fittings to prevent impurities from entering the hydraulic system.
Releasing residual hydraulic pressure:
In case residual pressure is left in the hydraulic system of the attachment, it is often possible to disconnect the
hydraulic couplings, but it may be difficult to connect them the next time. If the fittings will not connect, the
residual pressure must be released by turning the auxiliary hydraulics control lever of the loader, when the
engine is turned off. To make sure that there will not be residual pressure in the hydraulic system of the
attachment, shut down the loader engine and move the auxiliary hydraulics control lever of the loader back
and forth before disconnecting the couplings.

17 (30)
6. Instructions for use
Check the attachment and the operating environment once more before starting to work, and that all obstacles
have been removed from the operating area. Quick inspection of the equipment and the operating area before
use are parts of ensuring safety and the best performance of the equipment.
WARNING
Risk of crushing -
Never allow anyone to get under a
lifted attachment or loader boom.
Keep in mind that the
loader boom can be lowered or tilted even if the engine has
been shut down (crushing hazard). The l
oader is not intended
to be left to keep a load elevated for longer periods. Always
lower the attachment to a safe position before leaving the
driver's seat.
WARNING
Risk of tipping over - Avoid overload.
Loader can tip over
when handling too heav
y loads, or because of dynamic
movements caused by driving with and handling of a heavy
load. Do not extend the telescopic boom when the load
approaches the lifting capacity of the loader, or when the
loader boom is in horizontal position. When you notice that
the rear wheels of the loader are about to lift from the ground,
or if the load indicator of the loader (if fitted) signals:
Lower the load calmly and retract the telescopic boom
Avoid sudden changes in speed or direction whenever load is lifted
Use additional counterweights as needed

18 (30)
6.1 Checks before use
Drive carefully on uneven terrain and note the effect of heavy load at the front and side of the loader to
the stability and handling of the loader.
Practice the use of the attachment and the controls of the loader in a safe area. If you are unfamiliar
with the particular loader model, it is recommended to practice its use without any attachments.
Check the attachment you are planning to use with side shift adapter according to separate specific
instructions before operating the attachment. Make sure that there are no broken components.
When using the side shift adapter with the extra hydraulics outlet of the loader, and the side shift
adapter is coupled to the loader with conventional hydraulic fittings: Check the operating direction of
the attachment. The directions of movement of the side shift adapter depend on how the conventional
hydraulic fittings are coupled. Connect the fittings marked with a coloured caps to keep the operating
direction the same whenever the adapter is coupled.
Use only when all pins and hydraulic fittings are locked and secured in place. The locking of the side
shift adapter and the attachment includes a total of four locking pins. Ensure that all four locking pins
have locked securely.
When mounting an attachment onto the side shift adapter, note that the locking pins must always be
secured manually.
Keep the auxiliary hydraulics of the loader at the one pump setting for easier and more accurate
control of the side shift adapter.
Ensure that bystanders are at a safe distance when operating the equipment. Do not let anyone to
enter danger area of the boom or to stay directly in front of the loader. Also make sure that it is safe to
reverse with the loader. Never assume that bystanders will remain where you last saw them;
especially children are often attracted to the moving equipment.
Check the general condition of the attachment and the loader, and check for possible hydraulic oil
leaks. The attachment must not be used, if there is a fault in the hydraulic system of the loader or the
attachment. Refer to Chapter 7 for maintenance instructions.
Operate the attachment and the controls of the loader only when seated on the driver’s seat. Ensure
that the loader and the attachment are used in a safe manner and as intended. Do not allow children
to operate the equipment.
Never operate the loader or attachments while under the influence of alcohol, drugs, medication that
may impair judgement or cause drowsiness, or if not otherwise medically fit to operate the equipment.
Remember correct working methods and avoid leaving the driver’s seat unnecessarily.
WARNING
Risk of tipping over -
Avoid overload and keep heavy load close to the loader. Keep
loads close to the ground whenever
driving, especially during turns and uneven
terrain.
Pay attention that a heavy load or long distance between the loader and the
centre of gravity of the load will affect the balance and handling of the loader. The use of
additional counterweights is reco
mmended especially when operating smaller loader
models. For 200-
series loader the wheel weights are recommended. With heavy loads,
the telescopic boom must be kept retracted while moving with the loader. Always wear
seat belt.
WARNING
Avoid running over persons - Check surroundings before driving.
Always look in the
direction the loader is moving. Before reversing, always ensure that bystanders,
especially children, are at a safe distance to avoid back-over accidents.

19 (30)
.
6.2 Using the side shift adapter
Before starting the attachment:
Set and adjust the side shift adapter to correct operating position.
Move the auxiliary hydraulics control
lever of the loader towards its
locking position to shift the
attachment to right (as seen from the
driver's seat of the loader).
Stop by releasing the lever to neutral
position.
Move the auxiliary hydraulics control
lever of the loader to reverse
direction to shift the attachment to
left (as seen from the driver's seat of
the loader).
When using the side shift adapter with the extra hydraulics outlet of the loader, and the side shift
adapter is coupled to the loader with conventional hydraulic fittings:
Check the operating direction of the control lever of the extra hydraulics outlet. The directions of movement
can be reversed when the side shift adapter is coupled with conventional hydraulic fittings. Connect the fittings
marked with a coloured caps.
See more information on page 22.
The figure below shows the shifting to left of pallet forks attachment with the Hydraulic side shift adapter.

20 (30)
6.3 Maximum load
Maximum load for the side shift adapter is 1000 kg, and the side shift adapter must be removed when
handling heavier pallets or large buckets. Always refer to the operator's manual of the loader for the safe load
of the loader in different operating conditions.
Use the side shift adapter only when needed for shifting an attachment sideways. The side shift adapter may
get damaged, if it is used for other than lifting or handling of loads.
WARNING
Risk of tipping over - Use the side shift adapter only when needed.
The side shift
adapter reduces the tipping load of the loader by displacing the centre of gravity further
away from the loader. Take the reduction of t
he tipping load of the loader into account
when handling heavy loads: See the operator's manual of the loader for information about
the effect of distance of the load to the tipping load of the loader.
WARNING
Risk of tipping over - Side shift adapte
rs reduce the
lateral stability of the loader. Always keep load close to
the ground, and always wear seat belt.
Pay special
attention to stability of the loader when a side shift adapter is
equipped with an attachment. The loader may tip over on
inclined o
r uneven surfaces causing serious injuries from
impact and crushing. Always wear seat belt. Use the side arm
only with loaders that are equipped with ROPS and FOPS.
Avoid abrupt movements and always drive slowly and
carefully on inclined terrains, and on u
neven or slippery
surfaces. Use of additional counterweights is recommended.
