Avaya PARTNER ACS R7.0 User manual

PARTNER® ACS R7.0
PC Administration
Getting Started
518-456-166
Issue 5
July 2004
PCAdminGS.book Page 1 Wednesday, May 19, 2004 1:28 PM

PCAdminGS.book Page 2 Wednesday, May 19, 2004 1:28 PM

Notice
Every effort was made to ensure that the information in this book was complete and accu-
rate at the time of printing. However, information is subject to change.
Preventing Toll Fraud
“Toll fraud” is the unauthorized use of your telecommunications system by an unautho-
rized party (for example, a person who is not a corporate employee, agent, subcontractor,
or working on your company’s behalf). Be aware that there may be a risk of toll fraud
associated with your system and that, if toll fraud occurs, it can result in substantial addi-
tional charges for your telecommunications services.
The final responsibility for securing both this system and its networked equipment rests
with you – an Avaya Inc. system administrator, your telecommunications peers, and your
managers. Avaya Inc. does not warrant that this product or any of its networked equip-
ment is either immune from or will prevent either unauthorized or malicious intrusions.
Avaya Inc. will not be responsible for any charges, losses, or damages that result from
such intrusions. For important information regarding your system and toll fraud, see the
PARTNER Customer Support Document.
Avaya Fraud Intervention
If you suspect you are being victimized by toll fraud and you need technical support assis-
tance, call the Avaya Customer Care Center at 1 800 628-2888.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to the “Limited Use Software
License Agreement” card provided with your package. For additional warranty informa-
tion, see the PARTNER Customer Support Document.
Trademarks
PARTNER is a registered trademark of Avaya Inc. in the U.S. and other countries.
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corpora-
tion. Pentium is a registered trademark of Intel Corporation. Other product and brand
names are trademarks of their respective owners. All rights reserved.
Copyright 2004 Document 518-456-166
Avaya Inc. Issue 5
All Rights Reserved July 2004
Printed in USA
PCAdminGS.book Page 3 Wednesday, May 19, 2004 1:28 PM

Ordering Information
For additional documents, refer to the PARTNER Customer Support Document.
Customer Support
If you need assistance when programming or using your system, contact your local
Authorized Dealer or call the Avaya Customer Care Center at 1 800 628-2888. Consulta-
tion charges may apply.
Avaya Web Page
For information about Avaya products and service, go to www.avaya.com. For product
documentation for all Avaya products and related documentation for PARTNER ACS, go
to www.avayadocs.com.
Heritage Statement
Intellectual property related to this product (including trademarks) and registered to
Lucent Technologies Inc. has been transferred or licensed to Avaya Inc. Any reference
within the text to Lucent Technologies Inc. or Lucent should be interpreted as reference to
Avaya Inc. The exception is cross references to books published prior to May 1, 2001,
which may retain their original Lucent titles. Avaya Inc., formed as a result of Lucent’s
planned restructuring, designs, builds, and delivers voice, converged voice and data, cus-
tomer-relationship management, messaging, multiservice networking, and structured
cabling products and services. Avaya Labs is the research and development arm for the
company.
Call: Avaya Publications Center
Voice 1 800 457-1235 International Voice 207 866-6701
Fax [phone] International Fax [phone]
Write: GlobalWare Solutions
200 Ward Hill Avenue
Haverhill, MA 01835 USA
Attn: Avaya Account Manager
Order: Avaya Publications Center
Document No. 518-456-166
Issue 5, July 2004
PCAdminGS.book Page 4 Wednesday, May 19, 2004 1:28 PM

Contents
Table of Contents 5
1 Getting Acquainted
Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
What is PARTNER ACS PC Administration? . . . . . . . . . . . . . . . . . . . . . . 8
New Features in this Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Where to Get More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Installing the Software
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PARTNER ACS Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Solving Installation Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Overview of System Administration
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Basic PC Administration Tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Starting PARTNER ACS R7.0
PC Administration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Exploring the Workspace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 Connecting to the PARTNER System
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Operator Assisted Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Automated Attendant Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Creating a Hunt Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Direct Dial Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Direct Dial (Local) Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Making Intercom Calls from Your PC. . . . . . . . . . . . . . . . . . . . . . . . . 31
Direct Dial (Remote) Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Configuring the PARTNER System for Remote Direct Dial. . . . . . . . 33
COM Port Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Solving Connection Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Creating a Remote Administration Password. . . . . . . . . . . . . . . . . . . . . 38
PCAdminGS.book Page 5 Wednesday, May 19, 2004 1:28 PM

6 Table of Contents
Table of Contents Getting Started
5 Working with Translations
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Retrieving the System Translation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Disconnecting from the PARTNER System . . . . . . . . . . . . . . . . . . . . . . 41
Working with Translations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Editing a Translation You Just Retrieved . . . . . . . . . . . . . . . . . . . . . . 42
Editing a Translation You Already Saved . . . . . . . . . . . . . . . . . . . . . . 43
Creating a New Translation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Printing a Translation to a Text File. . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Sending Your Changes to the System. . . . . . . . . . . . . . . . . . . . . . . . . . 45
Restoring Your Changes to the System. . . . . . . . . . . . . . . . . . . . . . . . . 46
6 Administering the System Date and Time
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Viewing the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Changing the Date and Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7 PC Diagnostics
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Retrieving PARTNER Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8 T1 Module Administration
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Accessing the PARTNER T1 Module Maintenance Window . . . . . . . . . 54
9 DSL Module Administration
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Administering the DSL Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
PCAdminGS.book Page 6 Wednesday, May 19, 2004 1:28 PM

Welcome 7
1 Getting Acquainted
Welcome
This guide is your key to PARTNER®ACS R7.0 PC Administration.
Use this guide to learn:
• How to install the software
• How to connect to a PARTNER system
• The basics of the administration process
• What you can do with PC Diagnostics
• Where to find additional information
PCAdminGS.book Page 7 Wednesday, May 19, 2004 1:28 PM

1 Getting Acquainted
8 What is PARTNER ACS PC Administration?
Getting Started
What is PARTNER ACS PC Administration?
PARTNER ACS PC Administration gives you the ability to manage a PARTNER
ACS R7, R6, R5, R4, or R3 system from your PC. Among the many features it
contains are ones that let you:
• Program the system (for example, assign outside lines)
• Program extensions (for example, program an autodial button on any
extension)
• Back up and restore these and many other settings
PARTNER ACS PC Administration also gives you the ability to retrieve diagnostic
information from your PARTNER ACS system, allowing you to:
• View the type of modules installed on the PARTNER system
• Retrieve reports on system events such as error and reboots
• Identify the current version of your software
• Identify the PCMCIA cards installed in the PARTNER ACS module
• View manual and automatic translation backup information that is stored in
internal memory of the PARTNER R7.0 processor module
All these features are accessed through a graphical interface that is easy to learn
and use. You can use PARTNER PC Administration to manage a PARTNER
system locally or remotely. You can even choose to work offline and activate your
changes when it’s convenient.
PCAdminGS.book Page 8 Wednesday, May 19, 2004 1:28 PM

1 Getting Acquainted
What is PARTNER ACS PC Administration? 9
Getting Started
.
•PARTNER PC Administration only works with PARTNER ACS
Release 3.0 and later.
•If you have a version of PARTNER ACS Remote (PC)
Administration on your PC, you must uninstall it before installing
this software.
•If you have PassageWay Administration for PARTNER software
on your PC, you must uninstall it before installing this software.
PARTNER PC Administration replaces the old software.
•To help ensure the security of the PARTNER system, you
cannot recreate or change the remote administration password
with this software. This must be done on the system itself. See
“Creating a Remote Administration Password” on page 38 for
instructions on how to change the remote administration
password.
•If the PARTNER system has a T1 module, you must use the
PARTNER ACS PC Administration software to configure the T1
module.
PCAdminGS.book Page 9 Wednesday, May 19, 2004 1:28 PM

1 Getting Acquainted
10 New Features in this Release
Getting Started
New Features in this Release
In addition to supporting all system programming and remote administration
features already available in PARTNER ACS R6.0 PC Administration,
PARTNER ACS R7.0 PC Administration supports the following features and
capabilities:
• PARTNER ACS R7, R6, R5, R4, and R3 Support
PARTNER ACS R7.0 PC Administration provides the capability to program
PARTNER ACS R7, R6, R5, R4, and R3 systems.
• Support for the Admin Port on a PARTNER ACS R7.0 Processor Module
Using PARTNER ACS R7.0 PC Administration, you can also connect to a
PARTNER ACS R7.0 system via the Admin port on the PARTNER ACS
R7.0 processor module. You can connect to the Admin port either directly
from the COM port of your PC or via an external modem that is connected
to the Admin port.
• Loudspeaker Paging Line Administration
Unlike previous PARTNER processor modules, the PARTNER ACS R7.0
processor module has no dedicated Loudspeaker Paging System port.
Instead, you can connect your loudspeaker paging system to any line port
on the processor module. When the loudspeaker paging system is
administered to a line port, that line is disabled on the PARTNER system.
If your loudspeaker paging systems requires a “dry contact
relay,” you must connect the loudspeaker paging system into
line jack 5 on the PARTNER ACS R7.0 processor module.
• Enhanced Backup for PARTNER ACS R7.0
For PARTNER ACS R7.0, you can now save a back up of the translations
on either the PARTNER ACS R7.0 processor module or a backup/restore
card.
PCAdminGS.book Page 10 Wednesday, May 19, 2004 1:28 PM

1 Getting Acquainted
Where to Get More Information 11
Getting Started
• Automatic T1 Line Numbering Change for PARTNER ACS R7.0
Since the PARTNER ACS R7.0 processor module provides five lines, T1
lines now begin at line 6 instead of line 4 in PARTNER R7.0 systems that
have a T1 module.
• PARTNER API Feature Administration (PARTNER ACS R7.0 API only)
Using PARTNER ACS R7.0 PC Administration, you can administer the
PARTNER API feature on PARTNER R7.0 API systems.
• Enhanced Diagnostics
PARTNER ACS R7.0 PC Administration provides the capability to:
• identify and display details about the new PARTNER
ACS R7.0 processor module in the board inventory
view
• identify and display details about the new PARTNER
ACS R7.0 Upgrade PCMCIA card
• identify and display details about the new PARTNER
ACS R7.0 Backup/Restore card
• identify and display details about translation backups
that are stored in the internal memory of the PARTNER
R7.0 processor module
Where to Get More Information
PARTNER ACS R7.0 PC Administration contains integrated online help that can
provide you with detailed information on all of the program’s features. Press F1
for context-sensitive help. For more information on PARTNER administration,
you can also refer to the PARTNER ACS documentation.
For additional technical support, you can contact your local Authorized Dealer or
you can call Avaya Technical Support at 1 800 628-2888. In the continental U.S.,
Avaya provides a toll-free customer hotline 24 hours a day. Consultation charges
may apply.
PCAdminGS.book Page 11 Wednesday, May 19, 2004 1:28 PM

1 Getting Acquainted
12 Where to Get More Information
Getting Started
PCAdminGS.book Page 12 Wednesday, May 19, 2004 1:28 PM

Overview 13
2 Installing the Software
Overview
This chapter explains how to install PARTNER ACS R7.0 PC Administration.
Requirements
Before you install PARTNER ACS R7.0 PC Administration, make sure your PC
and PARTNER system meet the requirements.
PC Requirements
PARTNER ACS R7.0 PC Administration requires and IBM-compatible PC that
has:
• one of the following operating systems:
—Microsoft
®Windows®XP Professional with Service Pack 1 or later
— Microsoft Windows 2000 Server
— Microsoft Windows 2000 Professional
— Microsoft Windows NT®Server 4.0 with Service Pack 4 or later
— Microsoft Windows NT Workstation 4.0 with Service Pack 4 or later
— Microsoft Windows 98
• a Pentium®processor (100 MHz or faster)
• 10 MB of free disk space
• 16 MB of RAM
PCAdminGS.book Page 13 Wednesday, May 19, 2004 1:28 PM

2 Installing the Software
14 Requirements
Getting Started
• a Windows-compatible VGA monitor supporting at least 16 colors and 800
x 600 pixel screen resolution
• a Windows-compatible pointing device (for example, a mouse)
• an internal or external V.34 BIS modem (14.4 Kbps or faster)
PARTNER ACS Requirements
PARTNER ACS R7.0 PC Administration requires a PARTNER system that
meets the following minimum requirements:
• PARTNER ACS Release 7, Release 6, Release 5, Release 4, or Release 3
• a PARTNER display phone (for example, a PARTNER 34D)
•ForaPARTNER R6.0 or earlier system:
a PARTNER Remote Access Card, which functions as a modem and
backup/restore card
•ForaPARTNER R7.0 system:
If you want to connect to the PARTNER R7.0 system via a modem, the
PARTNER R7.0 system must have one of the following devices:
— a PARTNER Remote Access Card, which functions as a modem and
backup/restore card
— an external modem that is connected to the Admin port on the
PARTNER R7.0 processor module
You can connect directly to a PARTNER R7.0 system (without a modem) by
connecting a COM port on the PC running the PARTNER ACS R7.0 PC
Administration software to the Admin port on the PARTNER ACS R7.0
processor module. See “COM Port Connection” on page 34 for more
information.
PCAdminGS.book Page 14 Wednesday, May 19, 2004 1:28 PM

2 Installing the Software
Installing the Software 15
Getting Started
Installing the Software
The PARTNER ACS R7.0 PC Administration software includes an installation
program that copies the application onto your PC’s hard drive. You can obtain
the PARTNER ACS R7.0 PC Administration software from your PARTNER ACS
dealer.
To install the software:
1 Start Windows Explorer.
The Windows Explorer window appears.
2 Locate the directory that contains the PARTNER ACS R7.0 PC
Administration software, and then double-click on setup.exe.
The PARTNER ACS R7.0 PC Administration Setup window appears.
3 Respond to a series of standard Windows installation prompts.
During the installation, you can:
— Confirm or change the file directory where PARTNER ACS R7.0 PC
Administration will be installed.
— Choose to create shortcuts that will allow you to run the application by
directly clicking on a title or icon on the Start menu and/or the desktop.
The installation program copies files to the destination directory. When the
software is installed successfully, the Installation Completed message box
appears.
4 Click the Next button.
The View Readme File message box appears.
5 Click on the Finish button.
The Readme-Notepad window appears.
6 After reading the Readme file, select Exit from the File menu in the
Notepad window.
PCAdminGS.book Page 15 Wednesday, May 19, 2004 1:28 PM

2 Installing the Software
16 Solving Installation Errors
Getting Started
Solving Installation Errors
If you receive an error message during the installation process, check whether:
• A version of PARTNER ACS Remote (PC) Administration software is still
installed on your PC. If it is, you must uninstall this program:
1 Select Programs from the Start menu.
2 Choose PARTNER ACS PC Administration and select
Uninstaller for PC Administration.
• You have at least 10 MB of hard disk space available. If there is not,
perform one of the following steps:
— Free space on the designated hard drive by transferring files to
another drive or deleting them from your disk.
— Install PARTNER ACS R7.0 PC Administration on another
drive that has at least 10 MB of free space.
• You are using Windows XP, Windows 2000 Server/Professional, Windows
98, or Windows NT 4.0 Server/Workstation.
PCAdminGS.book Page 16 Wednesday, May 19, 2004 1:28 PM

Overview 17
3 Overview of System
Administration
Overview
This chapter explains the basic procedures for administering a PARTNER
system via PARTNER ACS R7.0 PC Administration. Refer to the online help for
more detailed information.
Basic PC Administration Tasks
Managing your PARTNER system using PARTNER ACS R7.0 PC
Administration involves the following tasks:
• Starting the software. (See “Starting PARTNER ACS R7.0 PC
Administration” on page 19.)
• Connecting to the PARTNER system. (See “Connecting to the PARTNER
System” on page 25.)
• Retrieving the system translation from the PARTNER system. (See
“Retrieving the System Translation” on page 40.)
• Making changes to the system translation. (See “Working with Translations”
on page 42.)
• Sending the modified system translation to the PARTNER system and then
restoring (that is, activating) that system translation on the PARTNER
system. (See “Sending Your Changes to the System” on page 45.)
PCAdminGS.book Page 17 Wednesday, May 19, 2004 1:28 PM

3 Overview of System Administration
18 Basic PC Administration Tasks
Getting Started
The information you retrieve from the PARTNER system is called the system
translation. It contains the specific line, extension, button, and other custom
settings for the system. Using PARTNER ACS R7.0 PC Administration, you can
make changes to the translation and then send the modified translation file back
to the PARTNER system.
In addition to making changes to the system translation, you can use PARTNER
ACS R7.0 PC Administration to:
• Create a new translation
• Administer the date and time
• Retrieve diagnostic reports
• Administer the T1 module
• Administer the 1600 DSL Module
While the PARTNER ACS R7.0 PC Administration software is quite
powerful, it does have a few limitations. You will be unable to perform a
Frigid Start or print a new header on a Call Reporting (SMDR) report. Of
course, you can perform these functions locally at your PARTNER
system.
PCAdminGS.book Page 18 Wednesday, May 19, 2004 1:28 PM

3 Overview of System Administration
Starting PARTNER ACS R7.0 PC Administration 19
Getting Started
Starting PARTNER ACS R7.0
PC Administration
When you first start PARTNER ACS R7.0 PC Administration, you will be
prompted to specify whether you want to create a file for a PARTNER ACS R7
system, a PARTNER ACS R6 system, a PARTNER ACS R5 system, a
PARTNER ACS R4 system, or a PARTNER ACS R3 system. An untitled file will
appear on your PC’s screen, indicating the PARTNER ACS release (that is, R7,
R6, R5, R4, or R3). This is the workspace where you will perform all your
administration actions such as programming and editing existing translations as
well as creating new translations.
To start the program:
1 Perform one of the following steps:
— Click on the Start menu, and select Programs>PARTNER ACS R7.0
PC Administration>PC Administration.
This is the default location. If you choose to save your files to
an alternate location during installation, your path will be
different.
— If you created a Start menu short-cut, click on the Start menu, and
select PC Administration.
— If you created a desktop short-cut, click on the PC Administration
icon on the desktop.
The New Translation Creation dialog box appears.
PCAdminGS.book Page 19 Wednesday, May 19, 2004 1:28 PM

3 Overview of System Administration
20 Starting PARTNER ACS R7.0 PC Administration
Getting Started
New Translation Creation Dialog Box
2 Choose the PARTNER system version for which you want to create a
translation file.
3 Click the OK button.
The New Translation Creation Confirmation dialog box appears.
4 Click the OK button.
A new translation file for the PARTNER system you selected appears in the
workspace. All of the defaults are selected in this file.
PCAdminGS.book Page 20 Wednesday, May 19, 2004 1:28 PM
