Aventics G3 Series Instruction manual

G3 Series
Wireless Auto Recovery Module
Quick Start Manual

G3 Series Wireless ARM Quick Start Manual
2
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Conditions for use of this product
(1) AVENTICS G3 Manifold ("the PRODUCT") shall be used in conditions;
i) Where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious
accident.
ii) Where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for
the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
ASCO L.P. shall have no responsibility or liability including but not limited to any and all responsibility or liability based on
contract, warranty, tort, product liability for any injury or death to persons, loss or damage to property caused by the product
that are operated or used in application not intended or excluded by instructions, precautions or warnings contained in
AVENTICS Technical, User, Instruction, Safety manuals or bulletins.
Safety precautions
Before using this product, please read this manual and the relevant manuals carefully and pay attention to safety and product
application. The following symbols are used in the manual to identify important safety, installation and application information.
Caution symbol indicates a possible hazard which may cause injury or equipment damage.
Note symbol indicates important information regarding equipment installation and setup.
NOTE!
CAUTION

G3 Series Wireless ARM Quick Start Manual
3
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Table of Contents
PAGE
Auto Recovery Module (ARM) Introduction .......................................................................................... 4
1. ARM Process Flowchart .................................................................................................................... 5
2. Wireless ARM .................................................................................................................................... 6
2.1 Protocol/Firmware Compatibility
3. Connecting to the Wireless ARM (Computer or Mobile Device) ......................................................... 7
3.1 Network SSID/Security Key
3.2 IP Address
4. Wireless ARM Webserver in "View Only" mode ................................................................................ 9
4.1 How to switch from "View Only" to "Configuration & Parameters Changes" mode
5. Wireless ARM Webserver in "Configuration & Patameter Changes" mode ...................................... 10
5.1 Password Access
5.2 Webserver Functionality
5.3 Two-Factor Authentication (Output Forcing)
6. Returning Wireless ARM to Factory Defaults .................................................................................. 19

G3 Series Wireless ARM Quick Start Manual
4
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Auto Recovery Module (ARM) Introduction
The Auto Recovery Module (ARM) is an optional memory module that is installed between the node and the valve
adapter module and is used to backup the manifold system parameters even during catastrophic failure. During the
power-up process the communication module reads the configuration of the manifold, including any user settable
parameters of I/O modules, and stores the information in its non volatile memory. Once the information is stored, it is
disconnected from the power circuits while still mechanically attached to the manifold.
Description Replacement Part Number
ARM Clip Module 240-383
Wireless ARM Clip Module 240-382
ARM Module (Legacy) 240-182
ARM Module (Legacy)
ARM Clip Module Wireless ARM Clip Module

G3 Series Wireless ARM Quick Start Manual
5
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
1. ARM Process Flowchart
ARM function is described in the following flowchart
CONFIG ERROR
XFER G3 TO ARM
CONFIRM XFER
G3 TO ARM YES
RESETTING
CONFIG ERROR
XFER ARM TO G3
CONFIRM XFER
ARM TO G3 YES
RESETTING

G3 Series Wireless ARM Quick Start Manual
6
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
2. Wireless ARM
The Wireless ARM supports standard ARM functionality with the addition of a WIFI accessible diagnostic web server. The web
server allows the user to connect to the Wireless ARM to access manifold parameters and diagnostics using any WIFI enabled
device including computers, tablets and smartphones.
Description Replacement Part Number
Wireless ARM Clip Module 240-382
Wireless ARM Minimum Build Firmware Requirements
Protocol Part Number Firmware
EtherNet/IP DLR 240-325 Rev 1.01 Build 43980
ProfiNet 240-240 Rev 1.01 Build 43980

G3 Series Wireless ARM Quick Start Manual
7
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
3. Connecting to the Wireless ARM (Computer or Mobile Device)
Once a G3 manifold equipped with a Wireless ARM is powered on; the Wireless ARM will broadcast it’s SSID.
Locate the Wireless ARM broadcast ID
On the computer or mobile device; open available WIFI connections. In this example the SSID is Broadcast as “G3 Numatics
6c5c3c”. Each Wireless ARM Clip’s SSID is unique and comprised of the last 6 digits of the Wireless ARM Clip’s MAC ID.
Select the connection and enter the network security key.
The default network security key is 12345678
Verify the computer/Mobile device is connected to the Wireless ARM Clip.
 Default Security Key is 12345678 NOTE!

G3 Series Wireless ARM Quick Start Manual
8
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Open an internet browser and connect to the G3 Wireless ARM webserver by typing the IP address.
(default IP address HTTP:// 192.168.4.1).
“View Only” and “Configuration & Parameter changes” buttons are displayed.
-View Only – connects to the G3 Webserver with read only access.
-Configuration & Parameter changes – connects to the G3 Webserver with write access.
Select “Configuration & Parameter changes” to open the password protected Configuration & Parameter Webpages with Read
and Write Access.
Configuration & Parameter changes are password protected.
NOTE!

G3 Series Wireless ARM Quick Start Manual
9
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
4. Wireless ARM Webserver in “View Only” mode
“View Only” mode allows the user read only access. Configuration and parameters are locked and unable to be modified. In
this mode you can monitor the condition of all of the modules in the G3 sub-bus network.
“View Only” mode is identified by the “View only” tag at the top left of the Dashboard page.
To exit “View Only” mode and change to “Configuration & Parameter Changes” mode, close the second open webpage tab from
the top of the screen. The first tab is the landing page where you can select which mode you would like to view the webserver
in.
NOTE: If using a smartphone or tablet, you will need to open a Tabs view to close the “View Only” page and go back to the
landing page.

G3 Series Wireless ARM Quick Start Manual
10
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
5. Wireless ARM Webserver in “Configuration & Parameter Changes” mode
Once a G3 manifold equipped with a Wireless ARM is powered on the Wireless ARM will broadcast it’s SSID.
Password Protected Access
Enter password to Access the Configuration & Parameter web pages.
 Default Password is G3/240-382
NOTE!

G3 Series Wireless ARM Quick Start Manual
11
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Dashboard
The G3 Wireless ARM Dashboard is displayed.
Select the “CONFIGURATION” tab for access to G3 Communication module parameters.

G3 Series Wireless ARM Quick Start Manual
12
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Configuration
G3 Communication Module Parameters
Select the menu options button to access the “DIAGNOSTICS” tab
Select the “DIAGNOSTICS” tab for access to G3 manifold diagnostics

G3 Series Wireless ARM Quick Start Manual
13
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Diagnostics
The G3 Diagnostics Webpage is displayed.
Select the Valve Driver Module to display the coil diagnostic information

G3 Series Wireless ARM Quick Start Manual
14
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
The Valve Driver Module coil diagnostic information is displayed. Here you can turn on Output Forcing to test-fire valve coils
and outputs.
 To force fire valves and/or other outputs you will need to turn on “Output
Forcing” from the top of the page. Two Factor Authentication (2FA) will be
required for safety.
NOTE!

G3 Series Wireless ARM Quick Start Manual
15
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
When you turn on “Output Forcing” you will be prompted to authorize this feature via Two-Factor Authentication (2FA). To
initiate Output Forcing, first click “SUBMIT REQUEST” to being 2FA.
2FA can be completed directly from the Graphic Display on the G3 Communication Module, or through the embedded G3
Webserver. Note that to use the G3 Webserver option you will have to remain connected via WIFI to the ARM module AND be
directly connected via Ethernet cable to the G3 Communication Module.
Once you click “Submit Request”, the text will change to “AUTHENTICATING” until the second step of the 2FA has been
complete either through the G3 Graphic Display or through the embedded G3 Webpage.
 For safety reasons only one WIFI connection with Output Forcing ON is
permitted at a time.
NOTE!

G3 Series Wireless ARM Quick Start Manual
16
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Option 1 – Authentication via the G3 Graphic Display:
Once 2FA has been initiated through the Wireless ARM webpage, the Graphic Display on the G3 Communication Module will
read “ENABLE WIFI OUTPUTS”. To complete the 2FA process and enable output forcing, click the SET button on the module.
The display will then flash the message “WIFI OUTPUTS ARE ENABLED” for several seconds.
Once “WIFI OUTPUTS ARE ENABLED” stops flashing the graphic display will show the option to “DISABLE WIFI OUTPUTS”. To
exit Output Forcing mode you may either press the SET button on the G3 Communication Module, or turn Output Forcing off
using the Wireless ARM webpage.
On the Wireless ARM webpage the blue button text will now read “ACCEPT”. Click this button to continue with Output Forcing
turned on. Output Forcing will remain on until it is turned off via the Wireless ARM webpage or the G3 Graphic Display, or until
the WIFI connection with the ARM is terminated.
ENABLE
WIFI OUTPUTS
WIFI OUTPUTS
ARE ENABLED
DISABLE
WIFI OUTPUTS

G3 Series Wireless ARM Quick Start Manual
17
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
Option 2 – Authentication via the G3 Comm Module Webpage:
Once 2FA has been initiated through the Wireless ARM webpage, you can authorize the second phase of the authentication
process via the G3 Node’s embedded webpage. To do so, first connect to the Comm Module via an Ethernet cable, and by
entering the module’s IP Address into a web browser.
Once on the webpage, click the “Diagnostics” tab and locate the Wireless ARM in the module list. Click the box that is marked
“Show Details” to see the full list of options.
To approve the authentication, click the button labeled “Enable WIFI Outputs”.

G3 Series Wireless ARM Quick Start Manual
18
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
On the Wireless ARM webpage the blue button text will now read “ACCEPT”. Click this button to continue with Output Forcing
turned on. Output Forcing will remain on until it is turned off via the Wireless ARM webpage or the G3 Graphic Display, or until
the WIFI connection with the ARM is terminated.

G3 Series Wireless ARM Quick Start Manual
19
TDG3ARMQS1-1EN 03/21
Subject to change without notice
www.Emerson.com
6. Returning Wireless ARM to Factory Defaults
To return the Wireless ARM to Factory Default settings, log into the G3 Communication Node embedded webserver (240-325
Ethernet/IP DLR or 240-240 Profinet node). To do this, disconnect the PLC communication from the node and connect a laptop
computer via the node directly or through a switch. Set your laptop’s IP Address to match the same first 3 octets of the node
(i.e. 192.168.003.XXX), and the last octet to an address that is not the same as the node.
To access the webserver, type the IP Address of the node into any internet browser. From the Home page, select the
“Diagnostics” tab from the top of the page. Locate the Wireless ARM in the module list and click “Show Details”. The window
will expand to show you more detail about the ARM. Click the “Reset to factory defaults” button.
Technical Support
For technical support, contact your local AVENTICS distributor. If further information is required,
please call AVENTICS Technical Support Department at [phone].
Issues relating to network setup, PLC programming, sequencing, software related functions, etc. should be handled
with the appropriate product vendor.
Information on device files, technical manuals, local distributors, and other AVENTICS products
and support issues can be found on the Emerson web site at www.Emerson.com.
