Aventura CAM-IPM-13X-DNPC User manual

Network Camera
User Manual
V4.0.1

User Manual of Network Camera
1
This manual is applied to the following camera models:
Type
Model
Box Camera I
CAM-IPM-13X-DNPC
Box camera III
CAM-IPM-3X-DNP
CAM-IP-5X-WDR
Dome I
CAM-IPM-2D-31P-VP
CAM-IPM-13D-31P-VPC
Dome camera II
CAM-IPM-5D-41P-VP
CAM-IPM-3D-29P-VP
CAM-IPM-2D-29P-WDR
CAM-IPM-2D-29P-WDRI
CAM-IPM-03D-21VP
CAM-IPM-03D-21IR-VP
Bullet Camera
CAM-IPM-2B-29IR
CAM-IPM-3B-29IR
Mini Dome Camera
CAM-IPM-2D3-VP
CAM-IPM-D3-VP

User Manual of Network Camera
2
Thank you for purchasing our product. If there are any questions, or requests, please
do not hesitate to contact the dealer.
This manual applies to Network Cameras.
This manual may contain several technically incorrect places or printing errors, and
the content is subject to change without notice. The updates will be added to the
new version of this manual. We will readily improve or update the products or
procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability
of the security or signaling aspects of this product. UL has only tested for fire, shock
or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the security or signaling
aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF
ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

User Manual of Network Camera
3
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the
limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the Low Voltage
Directive 2006/95/EC, the EMC Directive 2004/108/EC.
2002/96/EC (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery information.
The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info.

User Manual of Network Camera
4
Safety Warnings and Cautions
Please pay attention to the following warnings and cautions:
Hazardous Voltage may be present: Special measures and
precautions must be taken when using this device. Some potentials
(voltages) on the device may present a hazard to the user. This
device should only be used by employees from our company with
knowledge and training in working with these types of devices that
contain live circuits.
Power Supply Hazardous Voltage: AC mains voltages are present within the power
supply assembly. This device must be connected to a UL approved, completely
enclosed power supply, of the proper rated voltage and current. No user serviceable
parts inside the power supply.
System Grounding: To avoid shock, ensure that all AC wiring is not exposed and that
the earth grounding is maintained. Ensure that any equipment to which this device
will be attached is also connected to properly wired grounded receptacles and are
approved medical devices.
Power Connect and Disconnect: The AC power supply cord is the
main disconnect device to mains (AC power).The socket outlet shall
be installed near the equipment and shall be readily accessible.
Installation and Maintenance: Do not connect/disconnect any
cables to or perform installation/maintenance on this device during an electrical
storm.

User Manual of Network Camera
5
Power Cord Requirements: The connector that plugs into the wall outlet must be a
grounding-type male plug designed for use in your region. It must have certification
marks showing certification by an agency in your region. The connector that plugs
into the AC receptacle on the power supply must be an IEC 320, sheet C13, female
connector. See the following website for more information
http://kropla.com/electric2.htm.
Lithium Battery: This device contains a Lithium Battery. There is a
risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the vendor’s instructions
and in accordance with local environmental regulations.
Perchlorate Material: Special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California
Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices
for Perchlorate Materials. This device includes a battery which contains perchlorate
material.
Taiwan battery recycling:
Please recycle batteries.
Thermal and Mechanical Injury: Some components such as heat
sinks, power regulators, and processors may be hot; care should
be taken to avoid contact with these components.
Electro Magnetic Interference: This equipment has not been
tested for compliance with emissions limits of FCC and similar international
regulations. This device is not, and may not be, offered for sale or lease, or sold, or
leased until authorization from the United States FCC or its equivalent in other
countries has been obtained. Use of this equipment in a residential location is
prohibited. This equipment generates, uses and can radiate radio frequency energy
which may result in harmful interference to radio communications. If this equipment
does cause harmful interference to radio or television reception, which can be

User Manual of Network Camera
6
determined by turning the equipment on and off, the user is required to take
measures to eliminate the interference or discontinue the use of this equipment.
Lead Content:
Please recycle this device in a responsible manner. Refer to
local environmental regulations for proper recycling; do not
dispose of device in unsorted municipal waste.

User Manual of Network Camera
7
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly
to avoid danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are
neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are
neglected.
Warnings Follow these safeguards to
prevent serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings:
Please adopt the power adapter which can meet the safety extra low voltage
(SELV) standard. And source with DC 12V or AC 24V (depending on models)
according to the IEC60950-1 and Limited Power Source standard.
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)
To reduce the risk of fire or electrical shock, do not expose this product to rain or
moisture.
This installation should be made by a qualified service person and should
conform to all the local codes.
Please install blackouts equipment into the power supply circuit for convenient
supply interruption.
Please make sure that the ceiling can support more than 50(N) Newton gravities
if the camera is fixed to the ceiling.
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)

User Manual of Network Camera
8
Cautions:
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean
cloth with a bit of ethanol and wipe it gently. If the camera will not be used for
an extended period of time, put on the lens cap to protect the sensor from dirt.
Do not aim the camera lens at the strong light such as sun or incandescent lamp.
The strong light can cause fatal damage to the camera.
The sensor may be burned out by a laser beam, so when any laser equipment is
being used, make sure that the surface of the sensor not be exposed to the laser
beam.
Do not place the camera in extremely hot, cold temperatures (the operating
temperature should be between -10°C ~ 60°C), dusty or damp environment, and
do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for a proper operating
environment.
Keep out of water and any liquid.
While shipping, the camera should be packed in its original packing.
Improper use or replacement of the battery may result in hazard of explosion.
Please use the manufacturer recommended battery type.

User Manual of Network Camera
9
Table of Contents
SYSTEM REQUIREMENT.................................................................................................................... 11
NETWORK CONNECTION .................................................................................................................. 12
SETTING THE NETWORK CAMERA OVER THE LAN ..........................................................................................12
Wiring over the LAN .......................................................................................................................12
Detecting and Changing the IP Address .........................................................................................13
SETTING THE NETWORK CAMERA OVER THE WAN.........................................................................................13
2.1.1 Static IP Connection ...........................................................................................................13
Dynamic IP Connection...................................................................................................................14
ACCESS TO THE NETWORK CAMERA.................................................................................................17
ACCESSING BY WEB BROWSERS..................................................................................................................17
LIVE VIEW ........................................................................................................................................ 19
LIVE VIEW PAGE......................................................................................................................................19
STARTING LIVE VIEW ................................................................................................................................20
RECORDING AND CAPTURING PICTURES MANUALLY .......................................................................................22
OPERATING PTZ CONTROL ........................................................................................................................22
PTZ Control Panel ...........................................................................................................................22
Setting / Calling a Preset ................................................................................................................23
CONFIGURING LIVE VIEW PARAMETERS .......................................................................................................24
NETWORK CAMERA CONFIGURATION.............................................................................................. 25
CONFIGURING LOCAL PARAMETERS.............................................................................................................25
CONFIGURING TIME SETTINGS ...................................................................................................................26
CONFIGURING NETWORK SETTINGS ............................................................................................................28
Configuring TCP/IP Settings............................................................................................................28
Configuring Port Settings ...............................................................................................................29
Configuring PPPoE Settings ............................................................................................................30
Configuring DDNS Settings .............................................................................................................31
Configuring SNMP Settings ............................................................................................................32
Configuring 802.1x Settings ...........................................................................................................33
Configuring QoS Settings................................................................................................................34
Configuring FTP Settings ................................................................................................................35
CONFIGURING VIDEO AND AUDIO SETTINGS .................................................................................................36
5.3.1 Configuring Video Settings ................................................................................................36
Configuring Audio Settings.............................................................................................................37
CONFIGURING IMAGE PARAMETERS ............................................................................................................37
5.4.1 Configuring Display Settings ..............................................................................................37
5.4.2 Configuring OSD Settings...................................................................................................39
Configuring Text Overlay Settings ..................................................................................................40
Configuring Privacy Mask...............................................................................................................41
CONFIGURING AND HANDLING ALARMS.......................................................................................................41
