AVERATEC 2300 Series User manual

Table of Contents
i
Table of Contents
CHAPTER 1
INTRODUCTION ................................................................................. 1
Getting Started.................................................................................2
Inventory...........................................................................................3
Safety and Maintenance ..................................................................4
Checklists.........................................................................................5
Features ...........................................................................................6
Where to Look For Information ........................................................7
Quick Start........................................................................................8
Adjusting the Volume .......................................................................9
Adjusting the Brightness ..................................................................9
Turning off Your Computer.............................................................10
Tips for New Owners......................................................................11
CHAPTER 2
GETTING STARTED.......................................................................... 13
Hardware and Software .................................................................14
Front View ......................................................................................15
Left View.........................................................................................16
Right View ......................................................................................17
Back View.......................................................................................18
Bottom View ...................................................................................19
LED Status Indicators ....................................................................20
Power Indicators ............................................................................20
Function Keys ................................................................................21
Numeric Keypad.............................................................................21
Touchpad .......................................................................................22
The Optical Drive ...........................................................................24
Connecting the Printer ...................................................................25
The PCI Express Card Slot............................................................26
The Graphics System.....................................................................27
Communication Components.........................................................29
Information about the Wireless LAN button...................................30
CHAPTER 3
MAKING CONNECTIONS................................................................... 31
Making Connections.......................................................................32
Left Side Connectors......................................................................32
Right Side Connectors ...................................................................33
Front Side Connectors ...................................................................34

Table of Contents
ii
Back View.......................................................................................35
CHAPTER 4
SYSTEM SOFTWARE........................................................................ 36
System Recovery Software............................................................37
CHAPTER 5
POWER MANAGEMENT.................................................................... 38
Power Management .......................................................................39
Monitoring Battery Power...............................................................40
When to Replace the Battery .........................................................42
Heat Considerations.......................................................................43
CHAPTER 6
USING THE BIOS SETUP UTILITY..................................................... 44
Using the BIOS Setup Utility..........................................................45
APPENDIX A
FREQUENTLY ASKED QUESTIONS .................................................... 53
Frequently Asked Questions..........................................................54
APPENDIX B
STATEMENTS.................................................................................. 56
Statements.....................................................................................57
Canadian Department of Communications....................................59
Battery Disposal.............................................................................60
CAUTION FOR ADAPTER............................................................60
BATTERY CAUTION .....................................................................60
CLASS 1 LASER PRODUCT.........................................................60

Chapter 1
Introduction

Chapter 1
2
Getting Started
Congratulations on your purchase of the Averatec 2300 Series
notebook computer! Your new notebook features the most innovative
advances in portable computing technology. It combines state-of-the-
art ergonomics with sophisticated architecture to provide you with a
personal computer that is compact, powerful, and easy to use.
Designed for a wide range of general, business, and personal
productivity applications, the notebook is an ideal choice for use in the
office, at home, and on the road.
For maximum expandability without compromising portability, the
notebook accommodates a number of modules, including Optical
Drive, three USB ports, one PCI Express card slot and one 4-in-1 card
slot. The high capacity hard disk drive provides you with plenty of
storage space for multimedia files and applications.
This Manual contains all the information you need to set up and use
your new notebook. It describes all the features of the notebook in an
easy-to-read, yet thorough manner.

Chapter 1
3
Inventory
This computer system is designed for years of productive and
pleasurable computing. Use this section to keep details of your
purchase. This information will be required should you need to make
repairs to your notebook during the warranty period. Update this
section when you add new options.
DATE OF PURCHASE:
PLACE OF PURCHASE:
DEALER'S NAME:
DEALER'S ADDRESS:
TELEPHONE:
E-MAIL ADDRESS/WWW:
CONTACT PERSON:
MODEL NUMBER:
SERIAL NUMBER:
BIOS VERSION:
The serial number is on the label (with a bar code) on the bottom side
of the computer. Press the F2 key to enter BIOS setup screen.

Chapter 1
4
Safety and Maintenance
You can use your computer under a wide range of environmental
conditions. However, to ensure long use and continued high performance,
consider the following factors when setting up your computer:
Follow all warnings and instructions noted in this documentation and in
the Windows Help program.
The first time you use your computer, we recommend that you carefully
read the Making Connections section of this manual and initialize the
battery to ensure optimum battery performance.
Unplug the computer from the power outlet before cleaning. Use a
damp cloth for cleaning. Do not use aerosols, solvents, or strong
detergents.
Do not use the computer near open water or other liquids. Never spill
liquid onto the computer.
Do not place the computer in an unstable location where it might slip or
be knocked over. Serious damage could result from a fall.
Slots and openings in the system cabinet are for ventilation purposes.
Do not block or cover these openings or the system could overheat. Do
not use or store the computer near a source of heat or dust.
On the base or rear panel of this notebook, there is a label with
information on the power requirements of this system. These
requirements must be followed. If you are unsure of your local power
supply, consult your dealer or local Power Company.
Do not step or place anything on the power cord.
If you use the computer with an extension cord, ensure that the total
ampere ratings of all the devices sharing the extension do not exceed
the rating of the extension cord or the rating of the wall outlet.
Never push foreign objects into the computer through any of the slots
or openings. Dangerous voltages are present, which could cause
electric shock or fire, or damage sensitive components.
For best results, use a power strip with a built-in surge protector. Do not
use inferior extension cords as this may result in damage to your
computer.
Set the computer on a flat, stable surface. To prevent damage to the
computer’s hard disk drive, avoid using the computer where it will be
exposed to strong vibration.

Chapter 1
5
Checklists
After opening the package, carefully inspect the contents. If any of the
items are missing or appear damaged, contact your dealer. The
shipping carton should contain the following:
Notebook computer
Battery
AC adapter with power cord
Image recovery disk
Telephone cord

Chapter 1
6
Features
High Capacity Hard Disk Drive
The computer has a high capacity hard disk drive, to store your
favorite programs and large multimedia files.
Built-in Modem/LAN Capability
A built-in 56k modem and 10/100 Mbps Ethernet port allows you to
access the Internet or a local area network (LAN).
WLAN Capability
The system includes 802.11b/g Wireless LAN.
LCD
Your computer has an easy-to-view WXGA LCD panel.
Built-in Stereo Speakers
The stereo speakers enable you to run a variety of multimedia
applications.
Convenient Audio Control
The conveniently located audio control knob enables you to easily
adjust the volume to the stereo speakers.
Function Keys
Function keys give you easy control of power management, volume
and your monitor.
Power Saving Mode
This key is located next to the Power-On button and is noted by an
“S” symbol. Turning it on will adjust CPU speed to conserve
battery life.

Chapter 1
7
Where to Look For Information
About Your Computer
This User’s Manual describes the key elements of your computer.
New users can find a simple step-by-step orientation in the Quick
Start section of this chapter.
About Windows
Windows Help can be found by pressing the F1 key.

Chapter 1
8
Quick Start
Turning on the Computer for the First Time
1. Connect the AC adapter
power cord to the AC
adapter.
2. Connect the AC adapter to
the DC power port on the
right side of your computer.
3. Connect the AC adapter
power cord to an AC outlet.
4. Open the LCD panel to a
comfortable viewing angle.
5. Press the power button to
turn on the power. Note: The battery is not fully
charged. Allow your battery to fully
charge before using it (i.e., before
disconnecting AC power).
Calibrating the battery before use is
also highly recommended. Refer to
Chapter 5, Power Management, for
further information.
Use the touchpad to move the cursor on the screen. Move your finger across the pad to
control the cursor, and press the right and left buttons beneath with your thumb. These
buttons have the same functions as the right and left buttons of a standard mouse. You
can also click or double-click by tapping on the touchpad.

Chapter 1
9
Adjusting the Volume
You can adjust the volume with hot key combination as below:
Fn + F8 decreases the volume
Fn + F9 increases the volume
Fn + F10 Mute the volume
Alternatively, you can adjust
the volume with the Windows
volume control applet located
on the taskbar.
Adjusting the Brightness
Use the following hot key combinations to adjust the LCD panel
brightness:
Fn + F6 decreases the brightness
Fn + F7 increases the brightness

Chapter 1
10
Turning off Your Computer
Turning off the computer properly is important to maintaining your
computer.
1.On the Start menu, click the right
arrow button 2.Click the right arrow button, select Shut Down from the menu screen.
If you are going to be away from the computer for a short period, there
are ways of conserving power without shutting down the system. See
Chapter 5, Battery Power Plans, for details.
Warning: Shutting off the computer improperly may result in
data loss.

Chapter 1
11
Tips for New Owners
Take responsibility for backing up your data
Back up files often. Users who need to manage large amounts of data
may wish to use backup devices such USB drives. If you use your
notebook as a networked workstation with system backup, talk to the
system administrator about backup procedures for your notebook.
Don't leave passwords anywhere on your notebook or
carrying case
Be careful when placing your notebook on an airport
security conveyor belt
In most airports, security conveyor belts are safe for computers. If you
are not sure, ask the security staff. You should keep a close eye on
your computer. When you are in a hurry, make sure that you walk
away with the correct notebook computer!
Tape your business card to the notebook and accessories
In the workplace, notebooks and accessories may often look exactly
alike, leading to equipment mix-ups. Prevent such mix-ups by placing
your name on your equipment.
Develop good ergonomic work habits
The science of ergonomics studies the relationship between health
and a suitable work environment. For more information on
ergonomics, contact your nearest computer bookstore, or local library.
The Internet also has information on this and other related subjects.

Chapter 1
12
Never take the notebook anywhere without the carrying
case
A broken screen or case can be costly to repair. Prevent accidents by
carrying the computer in a suitable carrying case.
Consider using a lock
For added security, consider purchasing a Kensington lock to put into
the Kensington lock hole on the back side of your computer (see
Chapter 2, Back View). Use the Kensington lock to secure the
computer to a desk or table.
Note: Using a computer for extended periods of time with a poor
workstation setup and incorrect work habits can cause health
problems.

Chapter 2
Getting Started

Chapter 2
14
Hardware and Software
This chapter introduces the different components and controls of
your notebook computer, including the hardware components, the
software, and the audio and video systems.
Getting Started
Before you begin using your computer, read this chapter to
familiarize yourself with the main components installed in the
system. Lift the LCD screen to open up the computer.

Chapter 2
15
Front View
1. LCD panel
2. Power button
3. Keyboard
4. Status indicators
5. Touchpad
6. Touchpad buttons
7. Wireless LAN switch
8. Power Saving mode
button
9. Microphone-in jack
10. Audio-out jack for
headphones
11. MS/MMC/SD/MS Pro card
slot

Chapter 2
16
Left View
1. Kensington key lock hole
2. DC power in jack
3. IEEE 1394 FireWire port
4. Optical drive
5. Optical drive eject button
