AVERATEC AV5500 User manual

i
-
1
User’s Manual

i
-
2
Notice
The information in this user’s manual is subject to change without notice.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS
OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE
FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE
PERFORMANCE OR USE OF THIS MANUAL.
The information in this user’s manual is protected by copyright laws. No part of this
manual may be photocopied or reproduced in any form without prior written
authorization from the copyright owners.
CopyrightAugust, 2004
All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation. DOS,
Windows 95/98/ME/2000/NT/XP are trademarks of Microsoft Corporation.
Product names mentioned herein may be trademarks and/or registered trademarks
of their respective owners/companies.
The software described in this manual is delivered under a license agreement. The
software may be used or copied only in accordance with the terms of the agreement.
This product incorporates copyright protection technology that is protected by U.S.
patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
Rev 1.0

i
-
3
TABLE OF CONTENTS
PREFACE
Symbols and Conventions
Protecting Your Computer -Avoid Abusive Handling and Adverse
Environment
Chapter Summaries
1. GETTING TO KNOW THE BASICS
Performance Features
System at a Glance
Top View
Front andRear Views
Side Views
Bottom View
AC Adapter
LED Status Indicators
Keyboard Features
Function (Quick) Keys
Windows Keys
Embedded Numeric Keypad
Touch Pad
Graphic Subsystem
Adjusting the Display Brightness
Extending the Life of the TFT Display Panel
Opening andClosing the Display Panel
Audio Subsystem
Adjusting the Volume in Windows
Voice Recording
Modem and Modem Setting
EthernetAdapter
2. BIOS SETUP AND SECURITY
Entering the BIOS Setup Screen
Leaving the BIOS Setup Screen
BIOS Action Keys

i
-
4
Modifying the BIOS Settings
Main Setup
Advance Setup
BootSetup
Security Setup
Power Setup
ExitSetup
3.BATTERY POWER & POWER MANAGEMENT
The BatteryPack
Lithium-Ion Battery Technology
Battery Low-Power Warning
Installing and Removing the Battery Pack
Charging the Battery and Charging Time
Checking the Battery Level
Prolonging the Battery’s Life and Usage Cycles
Using Windows Power Options
Windows’Power Schemes
Suspend Modes
PowerButtonAction
LowBattery Warning
Power Manual Quick Access
4.UPGRADING YOUR COMPUTER
Upgrading the System Memory
5.TROUBLE-SHOOTING
First Step
Audio Problems
Hard Disk Problems
Optical Drive Problems
DisplayProblems
Keyboard and Mouse Problems
CMOS Battery Problems
Memory Problems
Modem Problems
NetworkAdapter/ Ethernet Problems

i
-
5
PC Card / PCMCIA Problems
Performance Problems
Firewire (IEEE1394) and USB2.0 Problems
APPENDIX A Product Specification
APPENDIX B Agency Regulatory Notices

i
-
6
Preface
Using This Manual
This User’s Manual contains general information about the
hardware and software setup, troubleshooting, and technical
specifications of the notebook computer.
Symbols and Conventions
The following conventions and symbols are used in this manual:
nWhen keys are to be pressed at the same time, a plus (+)
symbol is used. For instance, Fn+F7 means holding Fn and
F7 keys at the same time.
nWhen a series of clicking actions is needed in Windows O/S, [ ]
and > symbols are used. For instance, [Start > Settings >
Control Panel > Display] means clicking the Start icon first,
then the Settings, then the Control Panel, then the Display
icon.
nWhen you need to make a selection with the touch pad (or
mouse), you will be asked to ’select’ or ‘click’ or ‘double-click’,
‘right-click’ the item.
Note: Text in this format and symbol means specific instructions, commentary,
sidelights, or any additional information or notes that you should be aware of.
Warning: Text in this format and symbol means that failures to comply with the
given instructions or information could result in damage to your computer or could
cause bodily harm or loss of life.

i
-
7
Protecting Your Computer -Avoid Abusive Handling and
Adverse Environment
Follow the advice below will help ensure that you get the most out
of your Investment.
Your computer will serve you well if you take good care of it.
nDo not expose the computer to direct sunlight or place it near
sources of heat.
nDo not subject it to temperatures below 0oC (32oF) or above
30oC (86oF).
nDo not expose the computer to magnetic fields.
nDo not expose the computer to moisture or rain.
nDo not spill water or liquid on the computer.
nDo not subject the computer to adverse shock and vibration.
nDo not expose the computer to dust and dirt.
nDo not place objects on top of the computer to avoid damaging
the computer.
nDo not place the computer on rocky surfaces.
Here are some ways of taking care of your AC adapter.
nDo not connect the adapter to any devices other than your
computer.
nDo not let water get into the adapter.
nDo not block the ventilation airway of the adapter.
nKeep the adapter in a cool and ventilated place.
nDo not step on the power cord or place heavy objects on top of
it.
nCarefully tuck away the power cord and any cables away from
pedestrian traffic.
nWhen unplugging the power cord, do not pull on the cord itself
but pull on the plug.

i
-
8
nKeep the adapter away from children.
nThe total ampere ratings of the equipment plugged in should
not exceed the ampere rating of the cord if you are using an
extension cord.
nThe total current rating of all equipment plugged into a single
wall outlet should not exceed the fuse rating.
nDo not connect other AC adapter to your notebook. This
Notebook uses exclusively the AC adapter:
Manufacture: LITE-ON ELECTRONICS, INC.; LI SHIN
INTERNATIONAL ENTERPRISE CORP.
Model: PA-1900-05 (90W), PA1900-06 (90W); 0202B2090 (90W),
0202A2090 (90W)
Model: PA-1650-01 (65W), PA1650-02 (65W); 0335C2065 (65W),
0335A2065 (65W)
When cleaning the computer, observe these steps:
1. Power off the computer and remove the battery pack.
2. Disconnect the AC adapter.
3. Use a soft cloth dampened with water. Do not use liquid or
aerosol cleaners.
Contact your dealer or see your service technician if any of the
following occurs:
nComputer has been dropped or the body has been damaged.
nLiquid has been spilled into the product.
nThe computer does not operate normally.
Cleaning the Ventilation Grills:
It is suggested that you clean the ventilation grills regularly to
maintain optimal thermal regulation of the notebook. To do this, you
may use a soft brush or a vacuum cleaner (with appropriate head
adapter) to remove the dust buildup on the ventilation grills.

i
-
9
Chapter Summaries
The following is a summary of the available chapters and
appendices in this manual.
Chapter 1: Getting to Know the Basics
In this chapter, you will learn the basic operations and features
of your computer. It gives you a general understanding of the
components of your computer.
Chapter 2: BIOS Setup / Security
In this chapter, you will learn how to change various firmware
settings and what the settings mean. Also, you will learn how to
take advantage of the built-in security feature provided by the
BIOS.
Chapter 3: Battery Power & Power Management
In this chapter, you will learn the fundamentals of power
management and how to use them to achieve longer battery life.
Chapter 4: Upgrading Your Computer
In this chapter, you will learn how to upgrade the system
memory,the hard disk drive, and to install wireless mini PCI card.
Chapter 5: Trouble-Shooting
In this chapter, you will learn how to solve common hardware
and software problems.
Appendix A: Product Specification
In this section, you will find a list of the computer’s system
specifications.
Appendix B: Agency Regulatory Notices
In this section, you will find the general electro-magnetic and
safety regulatory information.

¦chapter 1 getting to know the basics
1
-
1
CHAPTER?ONE
GETTING TO KNOW THE BASICS
This chapter introduces the features and
components of the computer.
