AVERATEC AV3360-EG1 User manual

U
Us se er r’ ’s s M Ma an nu ua al l

Table of Contents
CHAPTER 1
GETTING STARTED
Getting Started
Inventory
Safety and Maintenance
Checklists
Features
Where to Look For Information
Adjusting the Volume
Adjusting the Brightness
Turning off Your Computer
Tips for New Owners
CHAPTER 2
GETTING STARTED
Hardware and Software
Front View
Left View
Right View
Bottom View
LED Status Indicators
Power Indicators
Function Keys
Numeric Keypad
Touchpad
The Optical Drive
Connecting the Printer
The PC Card Slot
Memory
The Graphics System
Communication Components
Built-in Wireless Local Area Network
CHAPTER 3
MAKING CONNECTIONS
Making Connections
Left Side Connectors
Right Side Connectors
Front Side Connectors

CHAPTER 4
SYSTEM SOFTWARE
System Software
System Recovery
CHAPTER 5
POWER MANAGEMENT
Power Management
Power Saving Modes
Power Saving Tips
When to Replace the Battery
Heat Considerations
CHAPTER 6
USING THE BIOS SETUP UTILITY
Using the BIOS Setup Utility
Navigating and Entering Information in BIOS
The Main Menu
Advanced Menu
Boot menu
Security menu
Exit menu
Change User Password
Change Supervisor Password
CMOS Optimal Defaults
Exiting and Saving
APPENDIX A
FREQUENTLY ASKED QUESTIONS
Frequently Asked Questions
APPENDIX B
STATEMENTS
Statements
European Notice
UL CAUTION
Canadian Department of Communications
Battery Disposal
CAUTION FOR ADAPTER
BATTERY CAUTION
CLASS 1 LASER PRODUCT

Introduction
C
Ch ha ap pt te er r 1 1
I
In nt tr ro od du uc ct ti io on n

Introduction
Getting Started
Congratulations on your purchase of the Notebook computer! Your new
notebook features the most innovative advances in portable computing
technology. It combines state-of-the-art ergonomics with sophisticated
architecture to provide you with a personal computer that is compact,
powerful, and easy to use. Designed for a wide range of general,
business, and personal productivity applications, the notebook is an ideal
choice for use in the office, at home, and on the road.
For maximum expandability without compromising portability, the
notebook accommodates a number of modules, including a Combo or
DVD Writer optical drive, three USB ports, one PCMCIA and one 3-in-1
card slot. The high capacity hard disk drive provides you with plenty of
storage space for multimedia files and applications.
This Manual contains all the information you need to set up and use your
new notebook. It describes all the features of the notebook in an easy-to-
read yet thorough manner.

Introduction
Inventory
This computer system is designed for years of productive and pleasurable
computing. Use this section to keep details of your purchase. This
information will be required should you need to make repairs to your
notebook during the warranty period. Update this section when you add
new options.
DATE OF PURCHASE:
PLACE OF PURCHASE:
STORE NAME:
STORE ADDRESS:
TELEPHONE:
E-MAIL ADDRESS/WWW:
CONTACT PERSON:
MODEL NUMBER:
SERIAL NUMBER:
The serial number is on the label (with a bar code) on the bottom side of
the computer.

Introduction
Safety and Maintenance
You can use your computer under a wide range of environmental
conditions. However, to ensure long use and continued high performance,
consider the following factors when setting up your computer:
•Follow all warnings and instructions noted in this documentation and in the
Windows Help program.
•The first time you use your computer, we recommend that you carefully read
the Making Connections section of this manual and initialize the battery to
ensure optimum battery performance.
•Unplug the computer from the power outlet before cleaning. Use a damp cloth
for cleaning. Do not use aerosols, solvents, or strong detergents.
•Do not use the computer near open water or other liquids. Never spill liquid
onto the computer.
•Do not place the computer in an unstable location where it might slip or be
knocked over. Serious damage could result from a fall.
•Slots and openings in the system cabinet are for ventilation purposes. Do not
block or cover these openings or the system could overheat. Do not use or
store the computer near a source of heat or dust.
•On the base or rear panel of this notebook, there is a label with information on
the power requirements of this system. These requirements must be followed.
If you are unsure of your local power supply, consult your dealer or local Power
Company.
•Do not step on or place anything on the power cord.
•If you use the computer with an extension cord, ensure that the total ampere
ratings of all the devices sharing the extension do not exceed the rating of the
extension cord or the rating of the wall outlet.
•Never push foreign objects into the computer through any of the slots or
openings. Dangerous voltages are present, which could cause electric shock
or fire, or damage sensitive components.
•For best results, use a power strip with a built-in surge protector. Do not use
inferior extension cords as this may result in damage to your computer.
•Set the computer on a flat, stable surface. To prevent damage to the
computer’s hard disk drive, avoid using the computer where it will be exposed
to strong vibration.

Introduction
Checklists
After opening the package, carefully inspect the contents. If any of the
items is missing or appear damaged, contact your dealer. The shipping
carton should contain the following:
STANDARD
•A notebook computer with a hard disk drive
•An internal battery
•A COMBO or DVD Writer optical drive
•An AC adapter with power cord
•Quick start guide & Warranty Card
•Recovery CD
Caution: When purchasing any of the accessories
listed above, purchase only those accessories that
are approved for use with your computer. The above
accessories are proprietary items. Your system
vendor can obtain these approved accessories. If
you use items that are not approved for use with
this computer, you may cause your computer to
malfunction, or to emit or receive electro-magnetic
radiation in excess of local regulations. For non-
proprietary accessories such as PC cards or
printers, ensure that the accessory functions
properly in your computer before making the
purchase. Your system vendor may be able to
recommend reliable brands and models.
Features
High Capacity Hard Disk Drive
The computer has a high capacity hard disk drive, to store your favorite programs and
large multimedia files.
Built-in Modem/LAN Capability
A built-in 56k modem and 10/100 Mbps Ethernet port allows you to access the Internet or
a local area network (LAN).
LCD
Your computer has an easy-to-view XGA LCD panel.

Introduction
Built-in Stereo Speakers and Microphone
The stereo speakers and internal microphone enable you to run a variety of multimedia
applications.
Convenient Audio Control
The conveniently located audio control knob enable you to easily adjust the volume to the
stereo speakers.
Scrolling Button
Comfortably scroll through documents with the ergonomically designed scrolling button.
Where to Look For Information
About Your Computer
This User’s Manual describes the key elements of your computer. New users can find a
simple step-by-step orientation in the Quick Start section of this chapter.
About Windows
Windows Online Help, found on the Start menu, offers extensive Windows assistance.
Tour Windows XP offers an online orientation for new Windows users. Find it in:
Start/Programs/Accessories/System Tools.

Introduction
Adjusting the Volume
You can adjust the
volume with the volume
control knob located
below the touchpad.
Volume control button
Alternatively, you can
adjust the volume with
the Windows volume
control applet located on
the taskbar.
Adjusting the Brightness
Use the following hot key combinations to adjust the LCD panel
brightness:
•Fn + F6 decreases the brightness
•Fn + F7 increases the brightness

Introduction
Turning off Your Computer
Turning off the computer properly is important to maintaining your
computer.
1. On the Start menu,
click Shut Down.2. Click the radio button next to Shut Down in the Shut
Down Windows screen,
and then click OK.
If you are going to be away from the computer for a short period, there
are ways of conserving power without shutting down the system. See
Chapter 5, Power Saving Modes, for details.
Warning: Shutting off the computer improperly
may result in data loss.

Introduction
Tips for New Owners
Take responsibility for backup
Back up files often. Users who need to manage large amounts of data
may wish to use backup devices such USB drive. If you use your
notebook as a networked workstation with system backup, talk to the
system administrator about backup procedures for your notebook.
Don't leave passwords anywhere on your notebook or carrying case
Be careful when placing your notebook on an airport security conveyor belt
In most airports, security conveyor belts are safe for computers. If you are
not sure, ask the security staff. You should keep a close eye on your
computer. When you are in a hurry, make sure that you walk away with
the correct notebook computer!
Tape your business card to the notebook and accessories
In the workplace, notebooks and accessories may often look exactly alike,
leading to equipment mix-ups. Prevent such mix-ups by placing your
name on your equipment.
Develop ergonomic work habits
The science of ergonomics studies the relationship between health and a
suitable work environment. For more information on ergonomics, contact
your nearest computer bookstore, or local library. The Internet also has
information on this and other related subjects.
Never take the notebook anywhere without the carrying case
A broken screen or case can be costly to repair. Prevent accidents by
carrying the computer in a suitable carrying case.
Consider using a lock
For added security, consider purchasing a Kensington lock to put into the
Kensington lock hole on the left side of your computer (see Chapter 2, Left
View). Use the Kensington lock to secure the computer to a desk or table.
Note: Using a computer for extended periods of time with a poor
workstation setup and incorrect work habits can cause health
problems.

Getting Started
C
Ch ha ap pt te er r 2 2
G
Ge et tt ti in ng g S St ta ar rt te ed d

Getting Started
Hardware and Software
This chapter introduces the different components and controls of your notebook computer,
including the hardware components, the software, and the audio and video systems.
Getting Started
Before you begin using your computer, read this chapter to familiarize yourself with the
main components installed in the system.
Slide the screen latch on the front edge of the cabinet towards the right to release the
cover latch and open up the computer.

Getting Started
Front View
1. LCD release latch
2. LCD panel
3. Battery
4. Keyboard
5. Speakers
6. Touchpad
7. Touchpad buttons
8. Scrolling button
9. MS/MMC/SD card slot
10. Volume control knob
11. Microphone-in jack
12. Audio-out jack for external
speakers or headphones
13. Power indicators
14. Status indicators
15. Power button
16. WLAN button

Getting Started
Left View
1 2 3 4 56
1. Kensington lock hole
2. VGA port external video display port
3. Fax/modem RJ-11 Jack
4. LAN RJ-45 jack
5. PCMCIA card slot
6. PCMCIA card eject button

Getting Started
Right View
1. USB ports
2. Optical drive
3. Optical drive eject button
4. AC-adapter port
1234

Getting Started
Bottom View
1. Ventilation slots
2. RAM compartment
3. Battery release button
4. Battery
1
2
3
4

Getting Started
LED Status Indicators
The status indicators in the upper left corner of the keyboard light up when a particular
function of the computer is active. Each indicator is marked with a symbol.
Optical Drive The computer is reading information
from the DVD-ROM or the Combo
drive.
HDD The computer is reading from, or
writing to the built-in hard disk.
Number-Lock The keyboard is in Num-Lock mode.
Caps-Lock The keyboard is in Caps-Lock mode.
Scroll-Lock The keyboard is in Scroll-Lock mode.
Power Indicators
The power indicators show which power source the system is using. The power
indicators remain active and viewable even when the LCD panel is closed.
Icon Light Description
Blue Power is on and the
AC adapter is in use
Flash blue Power is in suspend
mode
Blue Wireless LAN is in
use
Green Power is on and the
battery is in use
Flashing
Green Battery is charging
Red Battery malfunction

Getting Started
Function Keys
Hold the Fn key while pressing the numbered function key.
Function key Description
Fn + F3 Toggles display on/off
Fn + F4 Suspend to RAM/HDD
Fn + F5 Toggles between LCD/CRT displays
Fn + F6 Decreases LCD brightness
Fn + F7 Increases LCD brightness
Numeric Keypad
The embedded numeric keypad
consists of ten keys that make
number intensive input more
convenient. Press <NumLock> to
enable or disable the numeric
keypad.
