Avermedia PA511D User manual

© 2023 by AVerMedia 1
Mingle Bar (PA511D)
User’s Guide
Table of Contents
Introduction...................................................................................................................................................2
Mingle Bar (PA511D) ....................................................................................................................................3
Key Features..................................................................................................................................................3
System Requirements ...............................................................................................................................4
Technical Specifications ............................................................................................................................5
Product Overview........................................................................................................................................6
Installation......................................................................................................................................................7
Placement......................................................................................................................................................8
LED Status Indicator...................................................................................................................................9
AI Framing Function with Gesture Control ........................................................................................9
Using Connect............................................................................................................................................10
Contact Us....................................................................................................................................................12
About AVerMedia ......................................................................................................................................12
Appendix –F.A.Q. .......................................................................................................................................13

© 2023 by AVerMedia 2
Introduction
This document is your User’s Guide for the Mingle Bar (PA511D). We have written this
guide to provide you with the information you need to quickly and smoothly use the
video bar.
After a quick introduction of the video bar and who this product is intended for, we will
dive into its key features, system requirements, and technical specs and show you how
to set up and install the device. Lastly, this guide will finish with a link to our technical
support team and with some brief information on AVerMedia’s background.
Thank you for taking the time to use and try out our latest video bar, we hope you enjoy
using it as much as we enjoyed making it. If you have any questions or suggestions on
our products or need any further editorial assistance, please don’t hesitate to contact us.

© 2023 by AVerMedia 3
Mingle Bar (PA511D)
Be seen, Be heard, Be Connected
Rather than worrying about setting up separate cameras, microphones, speakers, and
other equipment, Mingle Bar (PA511D) is plug-and-play and combines all the necessary
equipment into one convenient device.
The intelligent audio pickup with AI noise reduction, beamforming, and far-field adaptive
technologies reproduces resonant voice from anywhere in the room. Mingle Bar
provides real-time, highly sensitive HDR, 3DNR, and AWB technologies with great image
optimization in any lighting environment, so you’ll always look sharp and professional.
The 124° FoV and 4K UHD quality cover all people and whiteboard to communicate and
collaborate effectively. Find and frame everyone with the AI auto-framing function with
AI Gesture recognition.
Key Features
•4K image quality with ultra-wide FOV
Ultra-wide 124° diagonal field of view to capture more of the room or include
additional participants. Supports multiple resolutions, including 4K (Ultra HD) 1080p
(Full HD), and 720p (HD) to best support the quality offered by your application and
monitor.
•Look professional in any light
Provides real-time highly sensitive 3DNR, HDR, and AWB technologies with great
image optimization in any lighting environment so that you will always look sharp
and professional.
•AI-powered auto framing
Find and frame everyone in the room with the AI auto-framing function with AI

© 2023 by AVerMedia 4
Gesture recognition.
•Intelligent audio pickup
The intelligent audio pickup with AI noise reduction, beamforming, and far-field
adaptive technologies picks up and reproduces resonant voices from anywhere in
the room.
•Rich I/O with one-cable connection
One cable connection to get all you need (display, webcam, speakerphone, wired
network) to start a meeting easily.
•Multiple mounting options
Freedom to mount wherever it works best—tabletop, wall, tripod, or monitor—for
the best possible huddle room experience.
•Works with most video conferencing applications
Compatible with virtually any video conferencing software app.
•Kensington security slot
Built-in Kensington security slots to help secure the device.
System Requirements
Mingle Bar
•Operating System:
Windows 10 or later;
macOS 10.14 or later;
Chrome OS 85.0.4183.131 or later
•Software Compatible: Facebook, YouTube, Facebook Messenger, FaceTime, Line,
GoToWebinar, Cisco Webex, Microsoft Teams, ZOOM, OBS, StreamLab OBS, Skype,
Skype for Business, Slack, Google Meet, Lifesize, Amazon Chime, Whereby
(Appear.in)
Hardware System Requirement
•CPU: 3.2 GHz Intel® Core™ i5-4460 processor or better
•RAM: 4 GB or more
•USB: USB 3.1 Gen 1 compatible with USB 2.0 (lower resolution)

© 2023 by AVerMedia 5
Technical Specifications
Camera
Maximum Resolution/Frame Rate
3840x2160/30fps
Field of View
124° (D), 115°(H), 79°(V)
Format
MJPEG, YUY2, and NV12 of UVC 1.0
Zoom
4x Digital Zoom
Image Processing
Auto Framing, Gesture Recognition, 3D Noise
Reduction, High Dynamic Range, Auto Lighting
Correction, Auto Face Exposure
Privacy Shutter
Yes
Audio
Microphone
Dual Omnidirectional Stereo Microphones
Microphone Pickup Distance
4 m/13.12 ft.
Speaker
5W with Bass Enhancement
Audio Processing
AI Noise Reduction, Acoustic Echo Cancellation,
Beamforming, Far-Field Adaptive, Full Duplex
Others
Interfaces
1 x HDMI (4K)
1 x USB-A (3.2 Gen 1)
1 x USB-C (3.2 Gen 1)
1 x RJ45
1 x Aux port for recommended expansion
microphone (optional)
1x LED Indicator
2 x K-Slot
Power Connector
Software Add-on Value
Image Adjustment
Firmware Update
Issue Report
Dimensions (W x D x H)
295 x 70.4 x 78.7 mm / 11.6 x 2.8 x 3.1 in.
Weight
555 g/19.6 oz.
What's in the Box
PA511D
Quick Start Guide
USB-C Cable or USB-C to USB-A Cable (Selectable)
Power Adapter (12V/1.5A)
*Specifications are subject to change without prior notice.

© 2023 by AVerMedia 6
Product Overview
Front View
Rear View
Ethernet Port
HDMI Output
USB-A Port
Mic Input
USB-C Port
DC Input
Power On/Off
Kensington Security Slot
Tripod Attachment
LED Indicator
Privacy Shutter
Lens

© 2023 by AVerMedia 7
Installation
1. Plug Mingle Bar into a power outlet.
2. Connect a monitor/TV to Mingle Bar via an HDMI cable.
3. Connect Mingle Bar's USB-C port to your laptop using the included USB cable.
Note:
*Ensure the computer’s USB port supports DisplayPort Alt Mode for HDMI to function properly
on Mingle Bar.
**Optional: Mingle Bar is also capable of hosting other devices such as keyboards, external
microphones, routers, etc. when needed.

© 2023 by AVerMedia 8
Placement
It is recommended to place Mingle Bar below or near the monitor/TV as close to eye
level as possible. The accessories for the mounting options below are sold separately
and require additional installations.
Mount to the TV
Mount on the Wall
Table / Shelf
Tripod
(Tripod not included)

© 2023 by AVerMedia 9
LED Status Indicator
Flashing White
Booting/firmware updating
Solid White
Ready
Solid Yellow
Playing audio
Solid Green
In use: video calling/video previewing
Flashing Green
Incoming calls
Flashing Blue Twice
Turning on AI Framing
Flashing Purple Twice
Turning off AI Framing
Solid Red
Microphone muted (3rd party app)
AI Framing Function with Gesture Control
This feature enables the webcam to automatically adjust and recenter the image when
additional people enter its field of view. It can be turned on or off using a hand
gesture—just hold up your hand within one meter in front of the camera for three
seconds until the power indicator flashes (blue: on, purple: off) twice.

© 2023 by AVerMedia 10
Using Connect
Connect is a simple and intuitive software that allows you to manage devices easily. It
provides image preview, image adjustment, digital zoom, image mirror/flip, AI
adjustment, and firmware updates to enhance your video calls.
Download Connect at https://www.avermedia.com/product-detail/Connect
Simple Video Adjustment
Adjust your device's color, exposure, zoom, and field of view to look your best in
meetings.
Change the Color Settings
Add a color filter preset to suit
your needs. Or manually turn
on/off or adjust the exposure
settings.

© 2023 by AVerMedia 11
Digital Zoom and AI Framing Controls
You can either turn AI Framing
on and let it get the best shots for
you or use the digital zoom
function (up to 400%) to frame
manually.
Look Great in Various Lighting Conditions
Connect provides exposure methods to make you look
natural in different lighting conditions.
•Auto Exposure: Automatically adjust the exposure value of the video according to
the ambient light.
•Manual Exposure: Manually adjust the video exposure and gain.
•Face Exposure: Enhanced exposure for faces, suitable for dark indoor
environments.
•High Dynamic Range (HDR): Automatically enhance the contrast according to the
ambient light to obtain the best video quality. Suitable for environments with
high contrast.
Deliver Uninterrupted Voice
You can choose to turn on the “AI Noise Reduction” function
to suppress distracting background noise if needed. There are
three levels to choose from.
Stay Up to Date
Connect delivers notifications to let you know when an
update is available and ready for installation. It also provides
information on connection status and warnings.

© 2023 by AVerMedia 12
Contact Us
Please contact us here should you have any questions or suggestions.
About AVerMedia
AVerMedia empowers people to easily connect and boldly create through innovative
audiovisual technology. Our solutions help people work productively, build new
relationships, and expand their horizons in ways that weren’t possible before. Our
products include a wide range of powerful yet easy-to-use devices such as webcams,
video capture cards, and microphones for content creators, schools, and businesses. We
also provide hardware design services for a range of AI and IoT applications, from smart
retail to smart cities.
AVerMedia is guided by a philosophy of contributing to society- whether through
products that change customers’ lives for the better or by ensuring our operations are
socially responsible.
Connect with AVerMedia:
Website: https://www.avermedia.com/
LinkedIn: https://www.linkedin.com/company/avermedia-technologies

© 2023 by AVerMedia 13
Appendix –F.A.Q.
1. How to enable auto framing (AI Framing, ePTZ)?
Method 1. By hand gesture:
You may turn on Auto Framing by hand gesture. Just hold your right or left hand
with your palm facing the Video Bar for three seconds until the power indicator
flashes twice.
The following are sample hand gestures. The correct one is an open hand palm, like
showing number five:
Please show a complete hand palm, without being hidden by shirts.
Method 2. By Connect software:
To enable Auto Framing, another way is to use AVerMedia Connect software, by
tweaking the toggle as marked below :

© 2023 by AVerMedia 14
2. Is my computer’s USB Type-C port able to output videos to Mingle Bar (PA511D)?
Make sure the USB Type-C port in use supports DisplayPort Alt Mode or
Thunderbolt 3 or 4 projection, for videos to be exported through PA511D and to
display on a monitor or a TV.
How to identify if a USB Type-C port supports DisplayPort Alt Mode or Thunderbolt 3 /
4 projection?
Check if there is one of the following symbols next to the USB Type-C port:
- A lightning bolt symbol indicating Thunderbolt 3 or 4
- A D-shaped icon indicating DP Alt Mode
3. Why do I need AVerMedia PA511D’s AI noise reduction, considering some video
conferencing applications should be capable of it as well?
Compared to using Microsoft Teams or Zoom with CPU loading consumed, the AI
noise reduction by AVerMedia PA511D helps on reducing noise, whereas it does not
consume any extra CPU loading. The AI noise reduction filters non-human
background noise coming from coffee machines, keyboard typing, cooling fans, etc.
