Avery Weigh-Tronix WI-130 User manual

WI-130 WDAC
User’s Manual

2WI-130 WDAC User’s Manual
Risk of electrical shock. Do not remove cover. No user service-
able parts inside. Refer servicing to qualified service personnel.
Weigh-Tronix reserves the right to change
specifications at any time.
CAUTION
12/13/04 130_U.P65 PN 29582-0013O e1 Printed in USA

3
WI-130 WDAC User’s Manual
Table of Contents
Introduction ................................................................................................ 5
About This Manual ........................................................................... 5
WI-130 Weight Data Acquisition Controller ................................................ 5
WI-130 Front Panel .......................................................................... 6
Main Display ......................................................................... 6
Front Panel Keys................................................................... 7
Hard Keys .................................................................. 7
Soft Keys ................................................................... 8
Weighing Operation ......................................................................... 9
Pushbutton Tare Operation .................................................... 9
Keypad Tare Entry ................................................................ 9
Specialized Operations ................................................................. 10
Accessing Program Serial# ........................................................... 10
WI-130 Wall Mount Instructions ....................................................... 10
Pages are numbered consecutively beginning with the cover page.

4WI-130 WDAC User’s Manual
Power Input
Excitation
Operational Keys
Operational Annunciators
Display
Display rate
A to D Conversion Rate
Unit of Measure
Capacity Selections
Incremental Selections
Decimal locations
Displayed Resolution
Audio Output
Time and Date
Internal Resolution
Harmonizer™digital filtering:
Standard input and outputs:
Available Options
Operating Temperatures
Enclosure
Dimensions
Weight
Agencies
Warranty
115 Volts AC, 500 mA 50/60 Hz single phase
230 Volts AC, 250 mA, 50/60 Hz single phase
Optional 10-32 volts DC and AC noted above
10 Volts DC or 10 volts AC square wave capable of driving up to twenty 350-ohm weight
sensors or 1 QuartzellTM transducer
Zero, Tare, Print, Units, Select, Enter, Escape, Clear, 0-9,
Decimal Point and Five Soft Keys labeled per selected operational routine. All keys provide
users with tactile and audio acknowledgment when they are activated.
Displayed symbols indicate motion, center of zero, unit of measure and more.
1" H x 4.3" W vacuum fluorescent dot graphic display (32 X 128 dot layout)
Selectable, 0.1 to maximum readable updates
60 times per second
Pounds, kilograms, grams, ounces, pounds and ounces and two selectable custom units
Up to 10,000,000 selectable
Multiples and sub multiples of 1, 2, 5
88888888 pick any location relative to division size
Up to 1 part in 10,000,000
Audio tone for key contact assurance or operational alarms
Battery protected real time clock is standard
1,000,000 counts analog, QuartzellTM transducer higher
Fully programmable to ignore noise and vibration
Four communications choices:
Com 1: RS232, RS-485/422
Com 2: RS232, 20 mA current loop
(One bi-directional signal per port)
Two set point I/O ports via OPTO 22 I/O modules
- Multi scale inputs
- DC operation at 10 to 32 VDC, 3.5 Amp
- OPTO 22 I/O Modules
- Remote Expanded Control Interface for 8, 16, 24, or 32 OPTO 22 I/O Modules
- Alpha-numeric, PC style keyboard
- Quartzell transducer interface
- Analog interface
14 to 104° F (-10 to 40° C), 10 to 90% relative humidity
Stainless steel wash down enclosure
12 3/8" H x 10 3/4" W x 5 1/4" D (31.43 cm x 27.31 cm x 13.34 cm)
17.5 lb, 7.8 kg
NIST Class III/IIIL Certified COC# 95-008
Canadian Weights and Measures AM-5054
UL (115 VAC)
CUL (115 VAC)
FCC Class A
2 year
Specifications

5
WI-130 WDAC User’s Manual
About This Manual This manual covers the information you need to understand the operation of
your WI-130 Weight Data Acquisition Controller (WDAC).
Major sections of this manual are headed by titles in a black bar like Intro-
duction above. Subheadings appear in the left column. Instructions and
text appear on the right side of the page. Occasionally notes, tips, and
special instructions appear in the left column.
The WI-130 is a stand alone weight processor. Built into the WI-130 are the
following standard features:
• 2 serial ports
• Time
• Date
• Stainless steel enclosure
• Large graphic display
The WI-130 front panel is shown in Figure 1. The front panel includes the
following:
• 32 x 128 dot, vacuum fluorescent, dot addressable display
• Five variable function soft keys
• Numeric keypad
• SELECT key
• UNITS key
• PRINT key
• TARE key
• ZERO key
• CLEAR key
• ESCAPE key
• ENTER key
• Decimal point key
Figure 1
WI-130 Front Panel
Introduction
WI-130 Weight Data Acquisition Controller

6WI-130 WDAC User’s Manual
The main display is a 32 x 128 dot, dot-addressable, vacuum fluorescent
display. The ability to address each of the dots individually makes this
display nearly as versatile as a computer screen. It can display graphics,
words and numbers. This flexibility allows graphics and alphanumeric
characters to be displayed at the same time. Below are a couple of ex-
amples of over 30 displays available on the WI-130.
This screen shows a large numeric readout, LBS and
GROSS, a bar graph, and the soft key labels.
WI-130 Front Panel
Main Display

7
WI-130 WDAC User’s Manual
This screen shows the soft key legends, a checkweighing
display, and a line of text for instructions.
Your system will be configured for your particular needs. The screen you see
will depend on what weighing application you are performing.
The keys on the front panel of the WI-130 are of two types, hard keys and
soft keys. Hard keys are labeled directly and soft key labels appear on the
display. Soft keys function differently at different times and their labels
change as needed.
Below are brief descriptions for each of the hard key functions:
Repeatedly press the SELECT key to scroll through the
available weight reading displays. (Examples - gross, net,
tare, minimum, maximum, etc.)
Press the UNITS key to scroll through the available units of
measure.
Press the PRINT key to send data to a connected printer.
Press the TARE key to enter a tare weight, then press
SELECT to see the net display mode.
Press the ZERO key to establish a zero reference. A
center-of-zero icon will be displayed. During motion an M
will appear below the center-of-zero icon.
Front Panel Keys
Hard Keys

8WI-130 WDAC User’s Manual
Press the ESCAPE key to back out of menus or cancel a
numeric entry without accepting the value.
Press the CLEAR key to clear values from the display.
Press the ENTER key to enter a keyed in value or accept a
displayed choice.
The numeric keypad is for
entering numbers.
Soft keys are so-called because their function is not fixed. Function can
change as mode of operations change or as the program for your particular
setup changes.
Their are five soft keys located directly below the display. If the keys are
needed during any operation, a label for each active key appears in the
display directly above. There are only five key labels available at one time
but this does not limit the potential usefulness of these keys. Programs
can be created to enable one key to access another level of operation with
five more key names and functions.
Soft Keys

9
WI-130 WDAC User’s Manual
The following instructions step you through a typical weighing operation:
1. Power up the indicator. If the
display mode is not the one you
want to use, repeatedly press
the SELECT key until the display
value you want (gross, net, etc.)
is displayed. . . Your indicator may be configured
with only one display value. Select-
ing other display values may not be
an option with your particular setup.
2. Zero the scale by pressing the
ZERO key. . . Display should read zero weight and
the center of zero symbol is dis-
played.
3. Place object to be weighed on
the scale. . . An Mappears on the display during
scale motion and the weight is
displayed.
To perform a tare operation with the TARE key, follow these instructions:
1. Zero the scale by pressing the
ZERO key. . . Display shows zero weight.
2. Place container to be tared on
the scale and press the TARE
key. . . The display changes to a NET
display and shows zero weight.
3. Place material to be weighed on
the scale. . . Net weight is displayed.
For entry of a known tare weight follow these instructions:
1. With the indicator showing gross
weight, key in the tare weight
using the numeric keys. . . A tare entry display shows the
weight that you key in.
2. Press ENTER to accept this tare
entry. . . The net weight is displayed in net
mode.
Weighing Operation
Pushbutton Tare Operation
Keypad Tare Entry

10 WI-130 WDAC User’s Manual
Due to the unlimited variety of applications available for the WI-130, it is not
practical to describe all the possible specialized operations in this manual.
Each application program will be unique.
Specialized operations will be set up to offer you soft key choices specific to
the application and will guide you with messages on the display.
The time may come when you are asked by a service technician what the
serial number of your software program is. There is a series of key strokes
which will bring that number up on the screen. Below are the instructions for
accessing this serial number.
1. Press and hold the ESCAPE key until the WI-130 beeps.
2. Within five seconds, key in the number 111 and press ENTER.
3. Press the soft key labeled VIEW.
4. Press the soft key labeled VERS. The serial number will appear on the
display.
To mount the WI-130 to the wall using option kit PN29670-0016, follow
these steps:
Use 5/16" steel bolts through the four 11/32" wide keyhole slots in the
mounting bracket.
Use bolts, lockwashers and nuts for mounting onto sheet metal. The metal
should be a minimum of 16 gauge (0.059") steel or 0.080" thick aluminum.
For bolting into threaded holes in the metal, 1/4" minimum thread length is
recommended.
Use 5/16" diameter lag bolts for fastening to wooden structures. There
should be a minimum of 3/4" engagement of threads into the wood.
Directly mounting into sheetrock or plaster without reinforcement is not
recommended.
Specialized Operations
Accessing Program
Serial #
WI-130 Wall Mount
Instructions

11
WI-130 WDAC User’s Manual
Declaration of Conformance to SMA Standard
Year of Declaration 2002
Production Meets Type
® *
We the manufacturer of
Model Type Certificate and Number Issued by
WI-130 Electronic Indicator NTEP CC 95-008A2 NCWM
Declare in our responsibility the conformance of the above listed models and types to the
mentioned certificates and the requirements of the SMA standard.
This declaration becomes valid when the SMA Conformance Logo, having our name or trademark
is applied to the device or its accompanying documentation.
* SMA PRODUCTION MEETS TYPE DEVICE MANUFACTURER Conformance Logo and Design are a registered
trademark of the Scale Manufacturers Association

Weigh Bar®is a registered trademark of Weigh-Tronix Inc.
Avery Weigh-Tronix USA
1000 Armstrong Dr.
Fairmont, MN 56031 USA
Telephone: [phone]
Facsimile: 507-238-4195
e-mail: [email protected]
www.wtxweb.com
Avery Weigh-Tronix UK
Foundry Lane
Smethwick, West Midlands
England B66 2LP
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web site:www.averyweigh-
tronix.com
Avery Weigh-Tronix Canada, ULC
217 Brunswick Boulevard
Pointe Claire, QC H9R 4R7 Canada
Telephone: [phone]
Toll free: 800-561-9461
Facsimile: 514-695-6820
www.weigh-tronix.ca
