AVID HIFI EVO 2 User manual

EVO LOUDSPEAKER
USER MANUAL

2
Table of Contents
Section Page
Introduction 4
Safety 4
What is Inside 4
Unboxing 4
Placement Recommendations 5
Connecting Up 5
System Matching 6
Optimising Sound Quality 6
Floor Stand Adjustment 6
Looking After Your Loudspeakers 7
Specification 7
Warranty Statement 8
Extended 5-Year Warranty
AVID is pleased to extend the normal warranty duration to 5-Years from the date
of original shipping. This warranty is transferable in the unlikely event that you would
sell this unit onto another party. Register your product at;
www.avidhifi.com/register

3
INTRODUCTION
Congratulations on the purchase of your new AVID EVO loudspeakers. We are sure that, with care, they will provide you
with many years of unrivalled musical enjoyment.
The EVO range currently consists of three models; the EVO 2, EVO 3 and EVO 4.
The EVO 4 is the most compact model, designed for small to medium sized rooms, and for those looking for a discrete
audio setup. The EVO 4 is designed to be placed on purpose-built stands or a heavy-duty shelf. The EVO 2 and EVO 3
models are larger, floor standing models, to be used in medium-sized living rooms, placed directly on the floor.
As with all AVID products, these loudspeakers are the result of many hundreds of hours of development and testing to
ensure that they exceed the quality and performance we know our customers expect from AVID.
Please read these instructions fully before attempting to setup and use the loudspeakers, failure to do so may result in
damage or possibly injury
SAFETY
Although compact, these loudspeakers are very heavy and it is highly recommended that a minimum of two people are
needed to assemble and position your EVO loudspeakers.
As with all loudspeakers, the exposed drive units are susceptible to damage if touched.
If you have chosen to use a third-party loudspeaker support, please ensure that they are capable of supporting the weight
of the EVO 4, and ensure that they are sufficiently stable, so there is no risk of them being knocked over.
WHAT IS INSIDE
All EVO loudspeakers contain an black tube accessory pack in the top section. Each pack contains a set of jump leads for
the rear connections and for EVO 2 and 3 models, there are spikes, locking nuts and floor protectors.
UNBOXING
Your EVO loudspeaker has been carefully packed to ensure it is delivered undamaged to you. Please follow these
unpacking instructions and remove hand jewellery and watches to avoid the risk of accidental damage.
EVO 4 Loudspeaker
1. Having opened the correct end of the box (where you found these instructions), please remove the accessory pack.
2. Being careful of the exposed tweeter, lift away the foam protection. Then gently lift the loudspeaker out of the box
and place on the floor. Remove the cloth bag, always taking care of the exposed tweeter.
3. Now place the loudspeaker in its listening position or suitable stand.
EVO 2 and 3 Loudspeaker
1. With the loudspeakers in the upright position, remove all the plastic clips and cardboard outer packaging.
2. Being careful of the exposed tweeter, lift away the foam protection and accessory pack.
3. With assistance, gently lift the loudspeaker out of the box and place on the floor, removing the cloth bag, always
taking care of the exposed tweeter.
4. Now place the loudspeaker in its listening position and fit the floor spikes and locking nuts by screwing them into
the feet underneath the base plate. To avoid damage to the floor, spike protectors are also supplied.
IT IS IMPORTANT THAT YOU RETAIN THE PACKAGING
IT WILL BE VERY EXPENSIVE TO REPLACE

4
PLACEMENT RECOMMENDATIONS
Like any loudspeaker the EVO is affected to a great extent by the listening environment. The EVO is quite easy to
accommodate, but following some simple guidelines will help:
• Position the loudspeakers symmetrically in the room (e.g. equal distance from either side wall). Where possible avoid
asymmetrical rooms (e.g.”L” shaped or rooms with a single alcove to one side) - any asymmetry will result in an
imbalance of the stereo image, and an uneven frequency response.
• Don’t place the loudspeakers too far apart—the distance between the two loudspeakers should be slightly less than
the distance from them to the listening point—again, experimentation is required. If the sound is lacking bass, and
the centre image is vague, try placing the loudspeakers closer together, conversely, if the sound is bass heavy, move
the loudspeakers further apart, and away from the rear walls.
• Twist the two loudspeakers so that they are pointing slightly toward, but not directly at, the listening position—this
should produce a nice sharp stereo image, but create enough spread for several people to enjoy the performance.
• Positioning the loudspeakers close to the wall immediately behind them will increase bass output, but at the
expense of clarity and stereo image —experiment to find out the best compromise for you, but start at around 45cm
(18”), and adjust until you are happy with the sound
• Try to avoid locating the listening position such that your head is too close to the wall behind you—if this is
unavoidable, try to ensure there are some soft furnishings or heavy curtains between you and the wall.
CONNECTING UP
The EVO uses a two pairs of connectors, one for the High Frequency connection (HF) and one for the Low Frequency
connection (LF). You have the option of connecting your EVO loudspeakers either using the more conventional twin-core
connection or by Bi-Wiring, which requires a cable with 4 separate cores (or two cables with two cores).
If you wish to bi-wire, please make sure you remove the ‘jumper’ cables that the loudspeaker ships with.
Bi-wiring can be beneficial in reducing the interaction of the L.F. and H.F. sections of the crossover—moving the common
earthing point to the amplifier, rather than the crossover itself, separates the vastly different current characteristics
experienced by each drive unit, resulting in a cleaner, more accurate signal for each drive unit. The scale of the
improvement is dependent on the crossover’s topology—the EVO crossovers are designed to minimise the effect however
bi-wiring can still prove beneficial, and is well worth taking time to investigate.

5
SYSTEM MATCHING
An EVO is a benign load, and most amplifiers will be able to drive them without difficulty. High quality amplifiers of 40W
per channel or more should be more than capable of attaining sensible sound levels in a typical listening room—however
there are real benefits to be enjoyed by using quality amplifiers with even greater power. Don’t be too concerned about
matching amplifier power to loudspeaker power, in reality, damage is far more likely to occur when using an underpowered
amplifier than a supposedly ‘overpowered’ amplifier (though care is still needed in extreme cases).
OPTOMISING SOUND QUALITY
The ultimate sound quality of your sound system relies on a host of variables, though there are some key points that you
should take in to consideration
• Ensure that all your audio equipment is securely positioned—not just the loudspeakers. A good quality equipment
rack and our support Platform can dramatically impact on the performance of your complete system.
• Make sure there is a mix of hard and soft furnishings in your listening room—to much soft furniture can result in a
dull, “closed-in” sound, whereas hard furnishings tend to create a very lively sound, which can sound harsh and also
suffer from echoes.
• Try to remove any unnecessary electrical equipment out of the room– if powered on, they can create electrical noise
that will impact on your Hi-Fi system, and in the case of televisions, the large flat screen panel causes reflections
disrupting the stereo image.
• Use good quality interconnect and loudspeaker cable. With regard to loudspeaker cable, there are large currents
flowing between the amplifier and loudspeaker, so long lengths of cable should be avoided, as resistance increases
directly with length. Having stated this, it is important that both left and right channels are both of the same length,
even if one loudspeaker is nearer to the amplifier than the other.
FLOOR STAND ADJUSTMENT
The EVO TWO and THREE incorporate adjustable spikes which allow for levelling of the loudspeaker. They are not intended
to raise the overall height of the loudspeaker—and as such, the level of adjustment is restricted.
Fitting, levelling and adjusting the spike
Thread the spike into the locking nut from the flat end, all the way to the spike point and then screw the spike into the
loudspeaker foot so it looks like Image 1. With all four fitted, adjust them so the loudspeaker is secure and does not
wobble.
Once the loudspeaker is stable, wind the locking nut up to the foot, locking it into position, shown in Image 2.
Please be aware that during adjustment, it is possible to unscrew the spike completely and for safety, please make sure that
the spike is screwed in by at least 4 complete turns.
Floor standing models are supplied with small ‘cups’ (in the accessory pack) which are designed to be placed underneath
each spike. These are intended to be used if the loudspeakers are placed on a hardwood floor, or some other covering that
requires protection from the spikes. Do not use the cups, if placing the loudspeakers on carpet, as the spikes are design to
pierce the carpet through to the solid floor beneath. No harm will come to the carpet, and the loudspeakers will be held
securely, preventing movement and improving sound quality.
Image 1 Image 2

6
All specicaons are subject to change
Model EVO 2 EVO 3 EVO 4
Configuration 3-Way, Bass Reflex 2.5Way, Bass Reflex 2-Way, Bass Reflex
Crossover type 2nd/3rd order, bi-wire 2nd order, bi-wire 2nd order, bi-wire
Drive units 1xHF, 2xMF/LF (6”),
1xLLF (10”) 1xHF, 2xLF (6”) 1xHF, 1xLF (6”)
Frequency Response 28Hz - 20kHz 32Hz - 20kHz 43Hz - 20kHz
Recommended Amplifier (W) 60-250 40-200 30-150
Sensitivity 86dB/2.83Vm 87dB/2.83Vm 87dB/2.83Vm
Impedance TBA 4 Ohms 8 Ohms
Dimensions (HxWxD) 1060 x 290 x 449mm 1003 x 290 x 449mm 363 x 200 x 449
Weight 45Kg 33Kg 15Kg
Finish Black or White Black or White Black or White
EVO Loudspeaker Range Specicaons
LOOKING AFTER YOUR LOUDSPEAKERS
The only cleaning required should be a light dust with a lint-free cloth - no harsh cleaning fluids should be used.
DO NOT touch the high frequency dome as this is extremely fragile, and any creases will affect the overall sound quality.
The Low frequency driver can be gently dusted if necessary, but again, care is required.
Be careful when using heavy loudspeaker cable—this can put a heavy load on the terminals, which could ultimately
break—avoid sudden shocks, such as allowing the cables to be pulled, or tripped over.

7
Warranty Statement
UK Residents
AVID HIFI Limited products are warranted against defects in materials and workmanship for a period of two years from
the original date of purchase, or no later than three years from the date of shipment to an authorized AVID agent,
whichever comes first, extending to five years subject to the product owner having submitted the Registration form
(www.avidhifi.co.uk/register.htm). Also the following conditions being observed.
• The product must have been purchased through an authorized AVID dealer
• This warranty is in favour of the original purchaser only, except when the new owner completes the online
product registration form. Warranty obligation is passed from dealer to manufacturer.
• During the warranty period, AVID will repair, or replace any workmanship, without charge for parts or labour.
• Should the product need to be returned, a written description of the defect and a photocopy of the original
purchase receipt must accompany it. Receipts must show the model, serial number, date of purchase, name and
address of purchaser and authorized dealer and the price paid.
• Returned product must be packed in the original packing and returned to AVID or original dealer by the
customer at his/her expense. AVID will pay return freight of its choice.
• The warranty is void if the product has been used or handled other than in accordance with the instruction
manual supplied, abused or misused, damage by accident or neglect or in being transported, or the defect is due
to the product being repaired or tampered with by anyone other than AVID or a dealer with prior authorization.
• The warranty is void if the product serial number has been removed, altered or made illegible.
• The warranty is void if the product has been taken out of the country of purchase.
• AVID shall not be held liable for incidental or consequential damages from the sale or use of its products.
• The warranty applies to ex-demonstration product, using the date of manufacture as purchase date.
• Where the product is sold under a consumer transaction (as defined by the Sale of Goods Act 1979) the statutory
rights of the purchaser are not affected by this warranty.
• Products are sold on the basis of specifications applicable at the time of sale. AVID shall have no obligation to
modify or to update products once sold.
Outside UK
• AVID has formal distribution in many countries throughout the world. In each country the AVID importer has
contractually accepted the responsibility for the product warranty. Warranty should normally be obtained from
the importing agent or distributor from whom you obtained your product. In the unlikely event of service
required beyond the capability of the importer, AVID will, of course, back up the warranty.
• Where product has been either supplied directly or there is no current distributor, AVID accepts responsibility for
the warranty period.
• Returned product must be packed in the original packing and returned to AVID by the customer at his/her
expense. AVID will pay return freight of its choice.
• The warranty is only valid in the country of purchase.
• Products outside their original destination requires that units with remaining warranty be returned to the country
of purchase for the warranty to be valid. Customer is responsible for freight both ways and all associated import
and export charges.
• Foreign distributors are not required to provide warranty service, repair or change AC mains voltage on units that
they did not originally import and sell.
• Foreign distributors may at their discretion offer service for a fee.
MISCELLANEOUS. ANY IMPLIED WARRANTIES RELATING TO THE ABOVE PRODUCT SHALL BE LIMITED TO THE
DURATION OF THIS WARRANTY. THE WARRENTY DOES NOT EXTEND TO ANY INCIDENTAL OR CONSEQUENTIAL
COSTS OR DAMAGES TO THE PURCHASER.

V220726
AVID HIFI Ltd
Bicton Industrial Park,
Kimbolton, Huntingdon,
Cambridgeshire.
PE28 0LW
ENGLAND
Tel: [phone] — Website: www.avidhifi.com - Email: [e-mail]
Company Registered No: 5435528 — VAT Registration No: GB 694 9858 48 — Directors: C. Mas & S.J. Mas
