Avid Technology HP Z200 User manual

Page 1 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
Avid Configuration Guidelines
HP Z200 Dual-Core i5 CPU Workstation
4 DIMM / No Embedded Firewire
Media Composer 6.0 and NewsCutter 10.0
1.) HP Z200 AVID Qualified System Specification:
Z200 / AVID Qualified Operating System choices:
Microsoft® Windows 7 Professional 64-bit Edition
Z200 Hardware Configuration
CPU Choices
- Intel® Core™ i5-660 3.33 4MB/1333 DC CPU
- NVIDIA Quadro FX 600 1GB PCI-E video board
- 250GB SATA-II 3Gb/s 7200RPM Hard Disk Drive
- Memory: 4GB (2 x 2GB) DDR3 1333 ECC memory –
(Requires two 2GB DIMMs, DIMM sizes cannot be mixed sizes)
Review the following to determine the correct installation order for DIMMs.

Page 2 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
2.) Qualified Operating Systems for Avid Client Editing Applications, Hardware and Shared-Storage
connectivity with the HP Z200:
- Supported: Microsoft® Windows 7 Professional 64-bit Edition
- Not Supported - Microsoft® Windows XP 64-bit (any version)
- Not Supported - Microsoft® Windows Vista 32-bit (any version)
- Not Supported - Microsoft® Windows Vista 64-bit (any version)
- Not Supported - Microsoft® Windows 7 –any 32-bit version, or any 64-bit version of Home, Ultimate
or Enterprise editions.
Note regarding Service packs: Latest Service Pack releases are recommended for all Avid qualified software
releases for the Z200.
3.) Qualified Avid Editing Applications and Hardware Supported on the HP Z200 workstation:
M/C v5.x
N/C v9.x
Comments
Avid Media composer Software
only
Yes
M/C 6.0 / NewsCutter 10.0
3rd party Hardware
Yes
M/C 6.0 / NewsCutter 10.0
Unity ISIS 1 Gbit Ethernet Client
Yes
Unity ISIS 5000 3.5 / 7000 2.5
EAC
Unity MediaNet Ethernet Client
Yes
MediaNet 5.5
EAC
StarTech FireWire adapter PCI 3
external ports plus 1 internal
Yes
Primary 1394 connection for camera / deck / disk drive etc, (HBA
has 3external 1394a ports ). (1394 disk drives are recommended
only for file transfers)

Page 3 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
AVID qualified HBA info
AVID qualified HBA
AVID Part Number
Slot
Function
Atto H680
7030-30028-01
#4
Local Storage –VideoRAID SR
Atto R380
7030-20166-01
#4
Local Storage –VideoRAID ST
LSI 9200-8e SAS controller
7030-30036-01
#4
Local Storage- AIC Xtore StudioRAID 16Re, 5Te
Atto R680
#4
Local Storage –VideoRaid (JMR)
1.) Slot Configuration:
Slot #
Electrical
Mechanical
1
x1 PCI-E Gen 1
(10Watts)
x1
Not Used
2
x16 PCI-E Gen 2
(75Watts)
x16
Video Card Nvidia Quadro FX 600
3
x1 PCI-E Gen 1
(10Watts)
x4
Not Used
4
x4 PCI-E Gen 2 (25Watts)
x16
Local Storage Controllers:
Atto H680 - SAS VRII SR support
Atto R380 - SAS VRII ST
LSI 9200-8e SAS Xtore 5Te,16Re Support
5
PCI 32bit /33MHz
PCI 32/33
Not Used
6
PCI 32bit /33MHz
PCI 32/33
StarTech FireWire adapter PCI
3 external ports plus 1 internal (MFG#PCI1394MP)
7
PCI 32bit /33MHz
PCI 32/33
Not Used
Current qualified PCI- 1394b Firewire card is:
1) StarTech FireWire adapter PCI 3 external ports plus 1 internal (MFG#PCI1394MP)
http://h30094.www3.hp.com/product.asp?sku=1846038&mfg_part=PCI1394MP&pagemode=ca
HP Z200 Slot Layout

Page 4 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
A.) Qualified Avid system BIOS version(s): (As of this writing):
1.09 (Minimum BIOS version for Avid environments)
Required system BIOS settings:
Z200 Required system BIOS changes:
1. Set CPU Processors Hyper-Threading –Enable
During boot up press F10 at the HP splash screen to invoke Set Up.
-Select the Advanced tab
-Select Processors. <Enter>
-Select Hyper-Threading
-Default setting is Disable
-Change this setting from Disable to Enable
-Hit F10 to save the Hyper-Threading setting
-Hit ESC select Save changes <enter> F10 to save and reboot

Page 5 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
B.) Nvidia Qualified Drivers:
Nvidia qualified drivers
AVID Software
Version(s)
Nvidia Driver Required
Media Composer
6.0
275.89
NewsCutter
10.0
275.89
C.) Nvidia FX 600 monitor connectivity:
The new generation Nvidia FX 600 graphics card has a single DVI port and single Display-Port port
(Important: Display-ports are not HDMI ports; at first glance they do look very similar to HDMI ports)
The HP Z200 includes one Display-Port-to-DVI adapter. HP P/N 481409-001
For dual monitor connectivity:
1. Use the DVI port and one Display-Port (Display-Port connection can be native display-port to monitor via display-port
connection, or use the display-port-to-DVI-adapter supplied with the system to connect to a native DVI monitor).
DVI Port Display Port
D.) Connecting to Analog VGA monitors and VGA switchers - Single and dual monitor connectivity:
Due to the large number of available types, AVID cannot guarantee functionality with older technology analog VGA monitors /
switchers.
Recommendations are:

Page 6 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
1. Use a passive DVI-to-VGA adapter on the FX 600 DVI port for the primary VGA connection
2. For a 2nd analog VGA connection, several manufacturer’s offer active “Display-Port-to-VGA” adapters. Performance with
these adapters may vary based on your particular model VGA monitors and switches.
3. “Display-Port-to-VGA” adapters are available from the following 3rd party manufacturer’s:
http://h10010.www1.hp.com/wwpc/us/en/sm/WF06c/A10-51210-64265-3965876-64265-3895841-3895842-3895844.html
http://accessories.us.dell.com/sna/products/Cables/productdetail.aspx?c=us&l=en&cs=19&sku=330-4685
http://www.siig.com/ViewProduct.aspx?pn=CB-DP0082-S1
E.) Serial Port Deck Control:
The HP Z200 workstation does not have an embedded serial port. Serial port deck control can be established via
two methods (both of which have been qualified by Avid and will maintain frame accuracy in Avid environments)
1. Addenda model RS-USB / 4 direct USB-to-RS422 serial adapter. This is a simple device which connects directly from a
USB port of the Z200 directly to the RS422 port of a deck.
http://www.addenda.com/addenda-elect/products/rsUSB4.php
2. Combination of a Keyspan (Tripp-Lite) Model USA-19HS USB-to-serial-port adapter with Addenda Rosetta
Stone model RS –2/8 RS232-to-RS422 converter
- Keyspan (Tripp-Lite) Model USA-19HS (AVID P/N 7080-20013-01)
http://www.tripplite.com/en/products/model.cfm?txtSeriesID=518&EID=13384&txtModelID=3914
- Addenda Rosetta Stone (or equivalent) model RS –2/8 RS232-to-RS422 converter (AVID P/N
7070-00507-01)
http://www.addenda.com/addenda-elect/products/rs28.php
To connect the Keyspan 19HS / Addenda RS -2/8 combination:
- Install the Keyspan 19HS driver before plugging the device into a Z200 USB port.
- Once the keyspan 19HS driver is installed then plug the keyspan 19HS into a Z200 USB port.
- The keyspan 19HS will now show up in device driver.
- Using a serial cable, connect the 9-pin serial port of the Keyspan 19HS USB adapter to the port of the
Addenda marked RS232 from PC
- Using a 2nd serial port cable connect the port of the Addenda marked “RS422 to VTR” to the deck control
serial port of the deck.

Page 7 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
F.) Intel(R) 82578DM for ISIS connectivity: For proper operation and connectivity of the Intel(R) 82578DM Gigabit with ISIS
the following are required:
For the Intel(R) 82578DM, under the performance settings, change the following parameters:
- Receive Buffers to 1024
- Transmit Buffers to 1024
To set the Intel(R) 82578DM Receive / Transmit buffers:
Go to device manager and select the device named Intel(R) 82578DM Gigabit Network connection which will be used for
ISIS connectivity. Right click and select properties

Page 8 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
Select Advanced tab
Set Receive Buffers to 1024 and Transmit Buffers to 1024

Page 9 of 9 Mike Fortin –Avid Technology –Oct. 26, 2011
Z200 Rev A Config Guide
H. Disable the windows firewall:
Disable windows firewall: navigate to Control Panel\Windows Firewall -- Select Turn Windows Firewall on or off
Select Turn off windows firewall in both network locations, OK to save
Revision Update
Revision
Date
Name
Update
A
Oct 26, 2011
Mike Fortin
Initial Public Release MC 6.0 NC 10.0
