Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 1
SkyTrax Series ADS-B Receiver
Installation Manual
Document Number 600-00335-000 Control Category CC2
Revision Description ECO Date
00 Initial Release ECO-19-047 04/22/19
01 Baud Rate Correction Paragraph 3.6.3.1 ECO-19-229 09/17/19
02 Updated for all SkyTrax 1xx/2xx models ECO-21-088 05/06/21
4 Middlesex Green, Suite 221
561 Virginia Road
Concord MA 01742

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 2
All materials copyrighted.
Copyright 2021 Avidyne Corporation. All rights reserved.
The latest installation manuals are available to authorized dealers on the Avidyne
dealer web at dealers.avidyne.com/.
Avidyne® is a registered trademark of Avidyne Corporation.

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 3
Table of Contents
1. Introduction...........................................................................7
1.1 Acronyms ................................................................................................................. 7
1.2 Overview .................................................................................................................. 8
2. Installation Considerations ..................................................9
2.1 Installation ................................................................................................................ 9
2.2 Accessories and Packing List .................................................................................. 9
2.2.1 Unpacking Equipment .......................................................................................... 9
2.2.2 Package Contents ................................................................................................ 9
3. Equipment Description.......................................................10
3.1 Overall Specifications............................................................................................. 11
3.1.1 Physical .............................................................................................................. 11
3.1.2 Environmental .................................................................................................... 11
3.1.3 Electrical............................................................................................................. 11
3.1.4 UAT Performance............................................................................................... 11
3.1.5 1090ES Performance ......................................................................................... 12
3.1.6 Avionics Interfaces ............................................................................................. 12
3.1.7 Latency Timing Performance ............................................................................. 12
3.1.8 Software Part Numbers ...................................................................................... 13
3.3 System Configurations ........................................................................................... 14
3.3.1 GPS Position Source ......................................................................................... 15
3.3.2 Display................................................................................................................ 15
3.3.3 Maintenance Port ............................................................................................... 16
3.3.4 SkyTrax Configuration........................................................................................ 16
3.4 Antenna Requirements .......................................................................................... 16
3.4.1 Antenna .............................................................................................................. 16
3.5 Installation .............................................................................................................. 16
3.5.1 Pre-Installation Information ................................................................................ 16
3.5.2 Installation Overview .......................................................................................... 16
3.5.3 Tools Required ................................................................................................... 18
3.5.4 SkyTrax Receiver Mounting ............................................................................... 18
3.5.5 SkyTrax Antenna Mounting................................................................................ 21
3.5.6 Cabling and Wiring ............................................................................................. 21
3.5.7 Circuit Breaker.................................................................................................... 22
3.5.8 Air Circulation and Cooling.................................................................................22

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 4
3.6 Electrical Connections............................................................................................ 22
3.6.1 Protection ........................................................................................................... 22
3.6.2 Electrical Current................................................................................................ 23
3.6.3 DB-37 I/O Connector (P1) .................................................................................. 23
3.7 P1 Interface Descriptions ....................................................................................... 26
3.7.1Power ................................................................................................................. 26
3.7.2 Discrete Interfaces ............................................................................................. 26
3.7.3 Serial Interfaces ................................................................................................. 26
3.7.4 ARINC-429 ......................................................................................................... 27
3.8 SkyTrax Post Installation Check ............................................................................ 29
3.8.1 Mounting/Wiring Check ...................................................................................... 29
3.8.2 Power and Ground Check.................................................................................. 29
3.8.3 Electromagnetic Interference/Compatibility Check ............................................29
3.8.4 Communication with Display Check................................................................... 30
3.8.5 Personal Computer Setup..................................................................................31
3.8.6Configuration and Verification Interface ............................................................. 44
3.8.7 Weight and Balance ........................................................................................... 56
Appendix A – Interconnect Diagrams......................................58
A.1 Interconnect Diagram: SkyTrax w/IFD (5XX/4XX/Atlas/Helios).......................................59
A.2 Interconnect Diagram: SkyTrax w/IFD (5XX/4XX/Atlas/Helios) & EX-Series MFD’s ......61
A.3 Interconnect Diagram: SkyTrax w/Entegra II ................................................................... 62
A.4 Interconnect Diagram: SkyTrax w/Aspen EFD1000 ........................................................ 63
Appendix B -SkyTrax Environmental Qual Form .................64
Appendix C - Antenna Mounting (TSO-C66c, TSO-C74c).......66
Appendix D - Latency Timing Block Diagrams .......................69

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 5
List of Tables
Table 2-1: SkyTrax Package Contents .....................................................................................................................9
Table 2-2: SkyTrax Connector Kit Contents ............................................................................................................9
Table 3-1: Software Part Numbers..........................................................................................................................13
Table 3-2: Compatible Displays. .............................................................................................................................15
Table 3-3: SkyTrax Installation Parts List ..............................................................................................................17
Table 3-4: Acceptable Antennas..............................................................................................................................18
Table 3-5: Acceptable crimp tooling.......................................................................................................................18
Table 3-6: Connectors ...............................................................................................................................................22
Table 3-7: Circuit Breaker Protection .....................................................................................................................22
Table 3-8: Electrical Load Requirement for P/N 700-00190-100 ........................................................................23
Table 3-9: I/O Connector Pin-Out (P1) for SkyTrax ............................................................................................24
Table 3-10: ARINC-429 Out Labels for ARINC-735B Traffic..............................................................................27
Table 3-11: ARINC-429 In Labels for ARINC-743A GNSS/GPS........................................................................28
Table 3-12: SkyTrax Weight.....................................................................................................................................57

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 6
List of Figures
Figure 3-1: SkyTrax UAT Receiver .........................................................................................................................10
Figure 3-2: SkyTrax Receiver with External Compliant GPS..............................................................................14
Figure 3-3: SkyTrax Mounting-Hole Pattern.........................................................................................................19
Figure 3-4: Clamp Ground Termination................................................................................................................21
Figure 3-5: 37 Pin D-Sub Male Connector (P1) [View looking at SkyTrax] ......................................................23
Figure 3-6: Communication Verification ...............................................................................................................30
Figure 3-7: SkyTrax Center of Gravity...................................................................................................................57
Figure D8: SkyTrax Traffic Latency........................................................................................................................69
Figure D9: SkyTrax Ownship Position Latency....................................................................................................70

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 7
1. Introduction
1.1 Acronyms
ADC Air Data Computer
ADS-B Automatic Dependent Surveillance Broadcast
ADS-R Automatic Dependent Surveillance Rebroadcast
AHRS Attitude Heading Reference System
ATC Air Traffic Control
CCA Circuit Card Assembly
CDTI Cockpit Display of Traffic Information
DME Distance Measuring Equipment
EFIS Electronic Flight Information System
FCC Federal Communications Commission
FAA Federal Aviation Administration
FIS-B Flight Information Services Broadcast
GNSS Global Navigation Satellite System
GPS Global Positioning System
IFD Integrated Flight Display
MFD Multifunction Display
PC Personal Computer
SBAS Satellite-based Augmentation System
STC Supplemental Type Certificate
SkyTrax Traffic Advisory System
TCAS Traffic Collision Alert System
TIS-A Traffic Information Services provided by Mode S transponder
TIS-B Traffic Information Services Broadcast
TSO Technical Standard Order
UAT Universal Access Transceiver
WAAS Wide Area Augmentation System

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 8
1.2 Overview
This manual applies to the Avidyne SkyTrax 1xx and SkyTrax 2xx series of products,
which will be collectively referred to as simply SkyTrax in the remainder of this
manual. Where a specific model is being referenced, the full model name will be used.
The SkyTrax system consists of a remote-mounted receiver and one external antenna.
ADS-B, ADS-R and TIS-B traffic information is provided by all SkyTrax models.
SkyTrax models with a UAT receiver are capable of receiving FIS-B weather data. The
SkyTrax does not provide ADS-B out functionality.
The SkyTrax 1xx series of products provide ADS-B In capability for a single frequency
(either 978MHz UAT or 1090MHz). The SkyTrax 2xx series of products provides dual-
frequency ADS-B In capability.
All interfaces will be to aircraft equipment installed via separate installation approvals ;
Avidyne Corporation’s FlightMax EX600/EX500 Multifunction Display (MFD),
Avidyne IFD4XX / IFD5XX Nav/Com/GPS/displays, Aspen EFD1000 displays, and
Avidyne Release 9 Integrated Cockpit system. Function of other displays that may be
compatible based on interface type must be validated by the installer.
This installation is intended for aircraft listed in STC SA00401BO Approved Model List,
Avidyne document AVMLB-003.
Note that the AML for STC SA00401BOis restricted to Part 23 Class I and Class II
(aircraft under 6000 lbs.) airplanes.

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 9
2. Installation Considerations
2.1 Installation
This manual stipulates the requirements for an airworthy installation under STC
SA00401BO.
The Antenna must be installed no less than 2 feet from any L-Band (Transponder,
TCAS, TAS, DME) antenna. Failure to adhere to this critical installation note will result
in failure of the SkyTrax Receiver.
The STC does not support antenna installations on pressure vessels or composite
aircraft without additional approved data. If additional approved data is required,
contact Avidyne for guidance.
The STC has been evaluated to support FAR23 Class I and II aircraft in accordance with
the current Approved Model List.
Installation of the SkyTrax in other aircraft classes will require alternate means of
approval; i.e. STC, Field Approval.
2.2 Accessories and Packing List
2.2.1 Unpacking Equipment
Carefully unpack the equipment from the shipping container. Inspect the SkyTrax
Receiver unit and the package contents for evidence of shipping damage. Retain the
shipping container and packaging material for reshipment if necessary.
2.2.2 Package Contents
The items included in the SkyTrax package are listed in Tables 2-1and 2-2.
Table 2-1: SkyTrax Package Contents
Ship Kit Part Number Qty Description
850-00228-100 1 700-00190-100 SkyTrax Receiver and the associated
Connector Kit (see Table 2-2 for details)
850-00228-101 1 700-00190-100 SkyTrax Receiver only
Table 2-2: SkyTrax Connector Kit Contents
Part Number Qty Description
205167-1 1 Receptacle Female, DSUB 37-pin
DC-24660-33 1 DSUB 37-pin back-shell
DC-51222-1 1 Connector DSUB Latch Slide 37 position
M39029/63-368 20 Crimp contact, DSUB, 20 to 24 AWG wire

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 10
3. Equipment Description
This unit receives messages from other ADS-B Out equipped aircraft and receives TIS-B
and ADS-R messages from ADS-B Ground Stations. Models equipped with a UAT
receiver will also receive FIS-B weather data from ADS-B Ground Stations. Data
received by the SkyTrax Receiver is output to a display device.
Figure 3-1: SkyTrax UAT Receiver

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 11
3.1 Overall Specifications
This section includes the physical, electrical, performance and environmental
specifications for the SkyTrax ADS-B Receiver.
3.1.1 Physical
Height: 2.036 inches
Width: 7.367 inches (includes mounting
bracket)
Depth: 6.812 inches
Weight: 1.3 lbs (excluding cables)
3.1.2 Environmental
Operating temperature: -55°C to +70°C
Storage temperature: -55°C to +85°C
Temperature variation: 5°C per minute
Maximum continuous altitude: 55,000 feet
External Cooling: Not required
3.1.3 Electrical
Voltage: 9-33VDC
Input Current (6W nominal): Steady State:
0.52A @ 14VDC
0.26A @ 28VDC
3.1.4 UAT Performance
Frequency: 978MHz
Tolerance: ± 20ppm
Data Rate: 1.04167 Mbps
Receiver Sensitivity: Exceeds 90%MSR@-93dBm
Equipment Class: A1S (single bottom UAT antenna)

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 12
3.1.5 1090ES Performance
Frequency: 1090MHz
Tolerance: ± 5.5MHz
Data Rate: 1 Mbps
Receiver Sensitivity: -72dBm
Equipment Class: A0 (single bottom UAT antenna)
3.1.6 Avionics Interfaces
Annunciator Outputs: Capable of sinking 500mA for turning
on annunciator lamp
Control Port: RS232 asynchronous serial
Maintenance Port: USB asynchronous serial
External Position Input: RS232 asynchronous serial, or;
ARINC743A GNSS sensor
Display/Control: RS232 asynchronous serial (Pass-
through or Traffic Alert interfaces)
ARINC735 Traffic interface
3.1.7 Latency Timing Performance
Traffic Latency Maximum traffic latency within the
SkyTrax = 1.75 seconds
Ownship Position Latency Maximum ownship position latency
within the SkyTrax = 1.75 seconds
Maximum ownship position latency
from the position source = 1.0 seconds
Display Latency Maximum permitted latency from
receiving a traffic update to displaying
an updated to the pilot = 0.75 seconds

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 13
3.1.8 Software Part Numbers
Table 3-1: Software Part Numbers.
Nomenclature/Name Module/Component P/N Revision
SkyTrax System – SkyTrax 100B 700-00190-100 00
SkyTrax Field Loadable Components 530-00245-XXX 00
Flight Code CPU 510-00347-000 00
Boot-Loader CPU 510-00284-000 02
FPGA Flight Image FPGA 052-00197-000 00
3.2 SkyTrax System – SkyTrax 200 700-00190-100 01
SkyTrax Field Loadable Components 530-00247-XXX 00
Flight Code CPU 510-00350-000 00
Boot-Loader CPU 510-00284-000 03
FPGA Flight Image FPGA 052-00197-000 01

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 14
3.3 System Configurations
The SkyTrax Receiver may be configured with a GPS position source (required for
traffic reception, but not required for FIS-B weather reception). The SkyTrax Receiver
may also be configured with an indicator (e.g. IFD4XX, IFD5XX) to display ADS-B,
ADS-R, TIS-B traffic and FIS-B weather. Figure 3-2 depicts the typical SkyTrax
Receiver system configuration.
Figure 3-2: SkyTrax Receiver with External Compliant GPS

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 15
3.3.1 GPS Position Source
If traffic is to be displayed, then the SkyTrax must be configured with a GPS position
source input. The GPS position source may be obtained externally via RS-232 (using
ADS-B+ G or ADS-B+ G2 format) or ARINC-743. GPS position input sources to the
SkyTrax other than from equipment identified in this manual must be verified by the
installer.
3.3.2 Display
The SkyTrax outputs traffic and weather information to compatible displays. Traffic
information can be provided using the Capstone protocol over an RS-232 interface (refer
to section 3.7.3.2), or the ARINC-735B TCAS protocol over an ARINC-429 interface
(refer to section 3.7.4). SkyTrax systems with UAT capability can also provide weather
information using the Capstone protocol over an RS-232 interface. The SkyTrax
Capstone output can be configured to provide traffic-only, weather-only or both traffic
and weather. A display with multiple available communications interfaces can take
advantage of the traffic-only and weather-only interfaces by dedicating the full
bandwidth of one interface to traffic and the full bandwidth of a second interface to
weather. The ability to display traffic and/or weather depends on the display device
and software version. The following displays support the display of traffic and/or
weather:
Table 3-2: Compatible Displays.
Avidyne Display SkyTrax Output Comments
IFD4XX, IFD5XX Capstone RS-232 Requires software 10.2.0 or later, Trfc + Wx
IFD4XX, IFD5XX Capstone RS-232
High Speed
Requires software 10.2.1 or later, Trfc + Wx
IFD4XX, IFD5XX ARINC429 Requires software 10.0 or later, Trfc only
EX5000 MFD Capstone RS-232 Requires software 8.2.1 or later, Wx only
EX5000 MFD ARINC429 Requires software 8.2.1 or later, Trfc only
EX500, EX600 MFD Capstone RS-232 Requires software 4.2.1 or later, Wx only
EX500, EX600 MFD ARINC429 Requires software 4.2.1 or later, Trfc only
IFD5000 R9 IFD Capstone RS-232 Requires software 9.4 or later, Wx only
IFD5000 R9 IFD ARINC429 Requires software 9.4 or later, Trfc only
Aspen Display SkyTrax Output Comments
EFD1000 Capstone RS232 Requires software 2.8.3 or later Trfc + Wx
EFD1000 ARINC429 Requires software 2.8.3 or later Trfc only

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 16
3.3.3 Maintenance Port
The SkyTrax provides a communication port that is used to configure and monitor the
status of the SkyTrax system via a computer. The maintenance port is required to be
used to configure the ICAO Address, NACv Value, and to manually configure the
RS232 com Tx ports if required. The SkyTrax should automatically “Discover” the
RS232 Rx inputs. The maintenance port is located on the front of the SkyTrax and is a
USB type C jack.
3.3.4 SkyTrax Configuration
The SkyTrax uses the internal Command Interface for configuration and
troubleshooting. The Command Interface can be accessed using a computer running
terminal emulation software by connecting it to the SkyTrax USB Maintenance Port. A
USB type A to USB type C cable will typically be required to connect the computer to
the SkyTrax.
3.4 Antenna Requirements
3.4.1 Antenna
The SkyTrax requires one antenna meeting the following specification: standard 50Ω
vertically polarized L band antenna rated for 978MHz and 1090MHz. Table 3-4 contains
a list of antennas that are recommended for use with the SkyTrax.
3.5 Installation
This section describes the installation of the SkyTrax Receiver and Antenna including
mounting, wiring, and connections. A post installation checkout procedure is included
at the end of this section.
3.5.1 Pre-Installation Information
Read this entire section before proceeding with the installation of the SkyTrax.
Perform the post installation checkout described in Section 3.8 prior to closing the work
area to resolve wiring, mounting and configuration issues should they occur.
Follow avionics installation practices per FAA Advisory Circular (AC) 43.13-1B, 43-13-
2A, or FAA approved revisions to these documents.
Perform an electrical load analysis on the aircraft prior to installation to ensure that the
aircraft’s electrical system is capable of carrying the SkyTrax load. Section 3.6.2
describes the power consumption of the SkyTrax.
3.5.2 Installation Overview
Installation of the SkyTrax Receiver and antenna requires determination of the location
of the Receiver, circuit breaker, antenna, and cable/wire routing to interfacing
equipment.
Installation of the identified compatible traffic/weather display is not covered in this
manual and should be installed in a manner approved by the FAA.

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 17
Table 3-3 identifies the parts list for the installation of the SkyTrax. Everything except
The SkyTrax is installer provided.
Table 3-3: SkyTrax Installation Parts List
Description Qty. Part Number Model Number Supplier
978MHzUniversal
Access Transceiver
(UAT) and /1090MHz
Receiver (including
items listed in
Table 2-1 and Table 2-2)
1
700-00190-100
SkyTrax
Avidyne
UAT Indicator/Display
– all compatible displays listed
1
700-00179-()
700-00182-()
700-00004-() & 700-00030-()
700-00007-()
700-00167-()
700-00083-()
700-0194-()
700-00195-()
910-00001-00X
IFD4XX
IFD5XX
EX5000
EX500
EX600
IFD5000 (R9)
Atlas
Helios
EFD1000
Avidyne
Aspen
(FAA TSO-C66c, TSO-C74c)
UAT Antenna
1
See Table 3-2
Circuit Protection
3A Circuit Breaker 14 Volt
2A Circuit Breaker 28 Volt
1
7277-5-2, 7277-5-3
7277-2-2, 7277-2-3
Or equivalent
Klixon
Klixon
Receiver Attachment
Hardware:
Ring Terminal
Bolts
Steel Flat Washers
Elastic Stop Nuts
1
8
8
4
323758 or equivalent
AN3-3A or equivalent
AN960-10L or equivalent
MS21083-N3 or equivalent
- Tyco
Antenna Attachment
Hardware:
Screws
Steel Flat Washers
Elastic Stop Nuts
Doubling Plate
AR
AR
AR
1
MS24693-C27X or equivalent
AN960L or equivalent
MS21083-N3 or equivalent
Locally Fabricated
Wire
AR
MIL-W-22759/16 or
equivalent
Shielded Wire
AR
MIL-C-27500 or equivalent
Coax Cable
AR
RG400 or equivalent

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 18
Table 3-4: Acceptable Antennas
Manufacturer Part Number Connector
Comant CI-110-40-30 C type
Comant CI-110-41-30 C type
Comant CI-110-60-30 C type
Comant CI-110-61-30 C type
3.5.3 Tools Required
The D-Sub connector supplied with the SkyTrax uses crimp contacts.
Table 3-5: Acceptable crimp tooling
3.5.4 SkyTrax Receiver Mounting
Select a mounting location on a sufficiently flat surface that has the ability to withstand
the inertial forces imposed by the 1.3 pound receiver unit plus 0.5 pounds of cables. The
CG of the unit is shown in the following figures. Reference AC 43.13-2B chapters 1 and
2 for installation and support structure requirements and guidance. Modification of
primary aircraft structure will require separate approval. When locating the SkyTrax,
allow for four inches of clearance on the connector side of the unit to provide room for
wiring.
Mount the SkyTrax Receiver with 4 each AN3()A bolts, 4 each MS21083-N3 nuts and 8
each washers where the washers are placed on both the bolt and nut side. Nutplates
such as MS21059-3 or MS21076-3 may be used in lieu of the nuts, installed using
MS20426AD3 rivets. Bolt hole size should be 0.195 to 0.229 inches diameter. Refer to
Figure 3-3 for the SkyTrax mounting hole pattern.
Type Hand Crimping Tool Positioner Insertion/Extraction Tool
Military P/N M22520/2-01 M22520/2-08 M81969/1-02
Positronic 9507 9502-5 M81969/1-02
AMP 601966-1 601966-5 91067-2
Daniels AFM8 K13-1 M81969/1-02
Astro 615717 615724 M81969/1-02

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 19
Refer to the bolt/nut fastener manufacturer for torque guidelines. The SkyTrax should
be connected to the airframe ground via the mounting bolts or by use of a bonding
strap such as MS25083-7AA().
Figure 3-3: SkyTrax Mounting-Hole Pattern

Avidyne SkyTrax Series ADS-B Receiver Installation Manual
600-00335-000, Rev: 02 © Copyright 2021 Avidyne Corporation Page 20
