Avlite AV-OL-ILAB-12-R Supplement

Version 2.7
AV-OL-ILAB-12-R & AV-OL-FL810-12-R
Universal DC Low Intensity Obstruction Light
Installation & Service Manual

Version No. Description Date Approved
1.0 Manual launch Feb 2013 A. Groell
2.0 Various June 2013 A. Groell
2.1 Spec table update August 2013 A. Groell
2.2 Alarm relay, RS232 & RS422/485 update August 2013 A. Groell
2.3 Dip Switch Table September 2013 A. Groell
2.4 Update: Wind speed November 2013 S. Turner
2.5 Update: Intensity & Operation Mode Setting September 2014 W. Evans
2.6 Spec table June 2015 W. Evans
2.7 Spec table update December 2016 W. Evans

Latest products and information available at www.avlite.com
3
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Table of Contents
Introduction..........................................................................................Page 4
Technology...........................................................................................Page 4
AV-OL-ILAB-12-R & AV-OL-FL810-12-R Models ................................Page 5
Safety Information...............................................................................Page 9
Unpacking, Installation, Wiring & Setup .........................................Page 10
Unpacking.................................................................................Page 10
Installation & Wiring..................................................................Page 10
Opening & Closing the Light Head ..........................Page 11
DC Power Connection.............................................Page 11
Operation & Setup ....................................................................Page 13
Intensity & Operation Mode Setting.........................Page 14
Alarm Relay Output .................................................Page 15
RS232 and RS422/485 Communication (optional) .Page 15
Maintenance & Servicing..................................................................Page 16
Trouble Shooting...............................................................................Page 17
Appendix ............................................................................................Page 18
Light Head Wiring Diagram.......................................................Page 17
Light Head Parts Diagram ........................................................Page 19
Product Order Codes................................................................Page 20
 Certications&Compliance......................................................Page 21
Avlite Light Warranty.........................................................................Page 24

Latest products and information available at www.avlite.com
4
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Introduction
Congratulations! By choosing to purchase an Avlite light, you have become the owner of
one of the most advanced LED obstruction lights in the world.
Avlite Systems draws on more than 25 years experience in the design and manufacture of navigation aids,
and particular care has been taken to ensure your light gives years of trouble free service.
As a commitment to producing the highest quality products for our customers, Avlite has been independently
certiedascomplyingwiththerequirementsofISO9001:2008qualitymanagementsystem.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of your
light, and be able to maximise its operating function.
Please remember to complete the Avlite warranty registration card accompanying your light.
Technology
Avlite Systems is a world-class solar lighting systems manufacturer with a proven
reputation for rapid, innovative, and agile technology solutions designed specically for
defense, government, civil and humanitarian aid operations in the most remote, toughest
environments.
Electronics
Avlite employs leading in-house electronic engineers in the design and development of software and related
circuitry. All individual electronic components are sourced directly by Avlite procurement staff ensuring that only
the highest quality components are used in our products.
LED Technology
All Avlite lights use the latest advancements in LED (Light Emitting Diode) technology as a light source.
The major advantage of LED’s over traditional light sources is well established in that they typically have an
operational life in excess of 100,000 hours, resulting in substantial savings to maintenance and servicing costs.
Precision Construction
Commitment to investing in the design and construction of injection-moulded parts including optic lenses, light
bases and a range of other components ensures that all Avlite products are of a consistent and superior quality.
Optical Performance
Avlite manufactures a range of aviation LED lenses moulded from multi-cavity dies. The company has superior
in-house lens manufacturing capabilities to support outstanding optical performance.
Award-winning, Patented Technology
Several United States and Australian patent registrations are held on Avlite’s range of innovative designs, with
other regional patents pending in Canada, United Kingdom and Europe.

Latest products and information available at www.avlite.com
5
Universal DC Low Intensity Obstruction Light
Single Light Fixture
AV-OL-ILAB-12-R & AV-OL-FL810-12-R
Models
This Avlite light xture is a steady burning, low intensity LED obstruction light
designed to comply with FAA L-810 and ICAO LIOL Type A & B requirements. The
model can be used for marking obstacles which pose a threat to aircraft, such as
telecommunication towers, wind turbines, buildings and other tall structures.
Avlite’s LED obstruction lights offer an ultra bright, energy efcient and cost
effective lighting solution.
The light xture is available in universal DC (12-48VDC). The advanced light optic
uses a single LED for minimal power consumption. The corrosion resistant,
polycarbonate lens is specically designed for use with LEDs to maximize light
intensity and uniformity.
The light xture incorporates internal diagnostic checking and an alarm contact for
remote monitoring. The alarm relay will be released whenever there is a problem
e.g. no power, supply voltage too low, LED failure, etc. The alarm relay will remain
energized during the day when operating normally.
The ICAO model has adjustable intensity settings to allow the user to easily toggle
between 10cd (ICAO Type A) and 32cd (ICAO Type B) light intensities.

Latest products and information available at www.avlite.com
6
Universal DC Low Intensity Obstruction Light
Single Light Fixture
167 (6.57”)
167 (5.39”)
121 (4.76”)
119 (4.69”)
121 (4.76”)
119 (4.69”)
Standard Model Model shown with optional
1 inch pipe thread adapter
Combined visual &
infrared for visibility to
pilots using night vision
(optional)
Tough UV-stabilised
LEXAN® polycarbonate
lens & light base
Model shown with
optional 1 inch pipe
thread adaptor
Standard Model
Single LED Optic
Automatic night
operation
Easily installs to ¾inch
pipe thread

Latest products and information available at www.avlite.com
7
Universal DC Low Intensity Obstruction Light
Single Light Fixture
SPECIFICATIONS•*
ICAO Type A & Type B
LIOL Single Fixture
12–48 VDC
110–240 VAC
Light Characteristics
Light Source As tested;
AV-OL-ILAB-12-R (Type A & Type B)
As tested;
AV-OL-ILAB-UM-R (Type A & Type B)
Available colours Red as standard. Other colours available on
request, including IR
Red as standard. Other colours
available on request, including IR
Peak Intensity (cd)† Complies with ICAO LIOLA & LIOLB: 2013
Complies with ICAO LIOLA & LIOLB:
2013
Horizontal Output (degrees) 360
360
Vertical Divergence (degrees) as per ICAO Type A/B specication
as per ICAO Type A/B specication
Reector Type Single LED Optic
Single LED Optic
Intensity Adjustments User-adjustable between 10cd & 32cd
User-adjustable between 10cd
& 32cd
Operation Mode Adjustment User-adjustable between
dusk-till-dawn & 24 hour operation
User-adjustable between
dusk-till-dawn & 24 hour operation
LED Life Expectancy (hours) >100,000
>100,000
Electrical Characteristics
Operating Voltage 12 – 48 VDC
110 – 240 VAC
Power (W)
ICAO LIOL Type A @ 10cd Steady-on with relay
energised: Pmax = 0.9
ICAO LIOL Type B @ 32cd Steady-on with relay
energised: Pmax = 2.16
ICAO LIOL Type A @ 10cd Steady-on
with relay energised: Pmax = 1.2
ICAO LIOL Type B @ 32cd Steady-on
with relay energised: Pmax = 4
Smax = 10.6VA
Circuit Protection Integrated
Integrated
Temperature Range -40 to 80°C
-40 to 80°C
Physical Characteristics
Body Material LEXAN® Polycarbonate – UV stabilized
LEXAN® Polycarbonate – UV
stabilized
Lens Material LEXAN® Polycarbonate – UV stabilized
LEXAN® Polycarbonate – UV
stabilized
Lens Diameter (mm/inches) 100 / 37/8
100 / 37/8
Lens Design Single LED Optic
Single LED Optic
Mounting Standard Model: ¾ inch pipe thread
Standard Model: ¾ inch pipe
thread
Height (mm/inches) Standard Model: 137 / 5½
Standard Model: 137 / 5½
Width (mm/inches) 121 / 4¾
121 / 4¾
Depth (mm/inches) 121 / 4¾
121 / 4¾
Mass (kg/lbs) 0.4 / 7/8
0.4 / 7/8
Product Life Expectancy 12 years plus
12 years plus
Environmental Factors
Humidity 0 to 100%, MIL-STD-810F
0 to 100%, MIL-STD-810F
Icing 3.41kg per square cm /
48.5lbs per square inch
3.41kg per square cm /
48.5lbs per square inch
•Specications subject to change or variation without notice *Subject to standard terms and conditions †Intensity setting subject to solar availability
Wind Speed Up to 240kph / 150mph
Up to 240kph / 150mph
Certications
CE EN61000-6-3:2007
EN61000-6-1:2007
EN61000-6-3:2007
EN61000-6-1:2007
Quality Assurance ISO9001:2008
ISO9001:2008
ICAO Low Intensity Obstruction Light Type A &
B - 2013
Low Intensity Obstruction Light
Type A & B - 2013
Waterproof IP68
IP68
Intellectual Property
Trademarks AVLITE® is a registered trademark of Avlite
Systems
AVLITE® is a registered trademark
of Avlite Systems
Warranty * 5 year warranty
5 year warranty
Options Available • Variety of solar/battery congurations
• GSM Cell-Phone Monitoring
• Dual visual/IR output
• IR LED
• RS422/485 communications port
• Threaded adaptor to t one (1) inch pipe
• GSM Cell-Phone Monitoring
• Dual visual/IR output
• IR LED
• Threaded adaptor to t one (1)
inch pipe

Latest products and information available at www.avlite.com
8
Universal DC Low Intensity Obstruction Light
Single Light Fixture
SPECIFICATIONS•*
FAA L-810 LIOL
Single Fixture
12–48 VDC
110–240 VAC
Light Characteristics
Light Source As tested;
FAA: AV-OL-FL810-12-R LED
As tested;
FAA: AV-OL-FL810-UM-R LED
Available colors
Red as standard. Other colors available on
request, including IR
Red as standard. Other colors
available on request, including IR
Peak Intensity (cd)† Complies with FAA L-810 obstruction lights
Complies with FAA L-810
obstruction lights
Horizontal Output (degrees) 360
360
Vertical Divergence (degrees) As per FAA L-810 obstruction light
specication
As per FAA L-810 obstruction light
specication
Reector Type Single LED Optic
Single LED Optic
Intensity Adjustments 32.5cd
32.5cd
Operation Mode Adjustment User-adjustable between
dusk-till-dawn & 24 hour operation
User-adjustable between
dusk-till-dawn & 24 hour operation
LED Life Expectancy (hours) >100,000
>100,000
Electrical Characteristics
Operating Voltage 12 – 48 VDC
110 – 240 VAC
Power (W) FAA L-810 @ 32.5cd Steady-on with relay
energized: Pmax = 1.44
FAA L-810 @ 32.5cd Steady-on
with relay energized: Pmax = 2
Smax = 5.3VA
Circuit Protection Integrated
Integrated
Temperature Range -40 to 80°C
-40 to 80°C
Physical Characteristics
Body Material LEXAN® Polycarbonate – UV stabilized
LEXAN® Polycarbonate – UV
stabilized
Lens Material LEXAN® Polycarbonate – UV stabilized
LEXAN® Polycarbonate – UV
stabilized
Lens Diameter (mm/inches) 100 / 37/8
100 / 37/8
Lens Design Single LED Optic
Single LED Optic
Mounting Standard Model: ¾ inch pipe thread
Standard Model: ¾ inch pipe
thread
Height (mm/inches) Standard Model: 137 / 5½
Standard Model: 137 / 5½
Width (mm/inches) 121 / 4¾
121 / 4¾
Depth (mm/inches) 121 / 4¾
121 / 4¾
Mass (kg/lbs) 0.4 / 7/8
0.4 / 7/8
Product Life Expectancy 12 years plus
12 years plus
Environmental Factors
Humidity 0 to 100%, MIL-STD-810F
0 to 100%, MIL-STD-810F
Icing 3.41kg per square cm /
48.5lbs per square inch
3.41kg per square cm /
48.5lbs per square inch
•Specications subject to change or variation without notice *Subject to standard terms and conditions †Intensity setting subject to solar availability
Wind Speed Up to 240kph / 150mph
Up to 240kph / 150mph
Certications
CE EN61000-6-3:2007
EN61000-6-1:2007
EN61000-6-3:2007
EN61000-6-1:2007
Quality Assurance ISO9001:2008
ISO9001:2008
FAA, DGAC. L-810 Low Intensity
Obstruction Light
(Qualied by Intertek)
L-810 Low Intensity
Obstruction Light
(Qualied by Intertek)
Waterproof IP68
IP68
Intellectual Property
Trademarks AVLITE® is a registered trademark of Avlite
Systems
AVLITE® is a registered trademark
of Avlite Systems
Warranty * 5 year warranty
5 year warranty
Options Available • Variety of solar/battery congurations
• GSM Cell-Phone Monitoring
• Dual visual/IR output
• IR LED
• RS422/485 communications port
• Threaded adaptor to t one (1) inch pipe
• GSM Cell-Phone Monitoring
• Dual visual/IR output
• IR LED
• Threaded adaptor to t one (1)
inch pipe

Latest products and information available at www.avlite.com
9
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Safety Information
Safety Information
• Install the light in compliance with the effective local electrical code(s).
• Mains power should always be disconnected when work is being done in close proximity to
electricalttings,andelectricalworkshouldonlybedonebyalicensedelectrician.
• Operate the light only within the indicated electrical ratings and product usage instructions.
• To ensure that the light and peripheral equipment function safely and correctly, use cable in
compliance with the effective local electrical code.
• Do not stare at the LED or shine the LED into your eyes or those of another person.
• Do dispose of the product according to the local laws and regulations for your region, for example,
at a recycling center that accepts electronic devices.

Latest products and information available at www.avlite.com
10
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Unpackallhardwareandinspectfordamage.Ifthereisanydamage,pleasecontactyourAvliteOfce.
Retain original packing material for possible future use in shipping.
Unpacking, Installation, Wiring & Setup
Unpacking
Installation & Wiring
Before proceding with installation or service, make sure the following conditions are met:
• Ensure the tower or mast is grounded (NO RF HAZARD)
• Check the mast lighting circuit is not faulty
• Ensure power lines are not ‘live’ (NO ELECTRICAL HAZARD)
• Avoid touching live circuits!
• Avoid touching any component or any part of the circuitry while the unit is operating. Do not change
components or make adjustments inside the unit with power on.
Open the Obstruction Light as described. Guide the cable through the cable gland and mount the
bottom half of the Obstruction Light on a mounting pole using the inner thread.
NOTE:
• Make sure the mounting pole is vertically aligned to guarantee the required beam pattern of the
obstruction light
• Make sure the light’s beam pattern is not disturbed by any nearby obstacles
Shorten the cable and close/seal the cable gland.
With the unit open, observe the rear of the PCB mounted in the top half of the Obstruction Light for
terminal blocks and switch settings.
NOTE: Use cable in compliance with the effective local electrical code. The cable outer diameter
should be between 5mm and 10mm.
NOTE: There is no requirement to terminate the relay and/or the serial communication if not used.

Latest products and information available at www.avlite.com
11
Universal DC Low Intensity Obstruction Light
Single Light Fixture
OPENING & CLOSING THE LIGHT HEAD
• Remove the locking screw
• In order to open the unit, the top half of the unit should be turned anti-clockwise with respect to
the bottom half. The top half will turn approximately 20mm over a positive “click” before separating
from the bottom half. Attention should be paid to the restriction caused by the internal cabling
which is secured by a cable gland.
• The unit is closed by reversing the above procedure, ensuring the black rubber O-ring remains in
place.
Locking Screw
Figure 1. Obstruction Light
DC POWER CONNECTION
The unit is designed to operate from a nominal DC voltage from 12V to 48V.
Wire as follows:
• Positive supply (+) = +VDC
• Negative supply (-) = 0V
For location details of the terminals please refer to Figure 2.

Latest products and information available at www.avlite.com
12
Universal DC Low Intensity Obstruction Light
Single Light Fixture
1 2 4 5 6
RS422RS232POWER/ALARM NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CONNECTOR
POWER
POWER
POWER
ALARM
ALARM
ALARM
RS232
RS232
RS232
RS422
RS422
RS422
RS422
RS422
SIGNAL
+VDC
0V
GND
COMM
NO
NC
GND
RxD
TxD
GND
-VE (Rx)
+VE (Rx)
-VE (Tx)
+VE (Tx)
78 93 10 11 12 13 14
J1 J3 J2
Figure 2. Light wiring diagram and pinning
Figure 3. DC Obstruction Light PCB with terminals and DIP switches
Relay
+VDC
0V
GND
COMM
NO
NC
POWER ALARM
TxD
RxD
GND
RS-232
+VE -VE +VE -VE GND
Tx Rx
RS-422
INTENSITY
TERMINATE FULL HALF
DUPLEX
SW2
ON
1 2
ON
1 2
ON
1 2

Latest products and information available at www.avlite.com
13
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Figure 2. Light wiring diagram and pinning
When powered up, the light will constantly check day/night status using its internal ambient light
sensor. The ambient light sensor averages its measurement for 30 seconds.
FAA: By default the lights turn ON when the ambient light decreases to not less than 35 foot-
candles (367.7 lux) and turn OFF when the ambient light decreases to not more than 60 foot-
candles (645.8 lux). These limits can be factory adjusted, if required.
ICAO: By default the lights turn ON when the ambient light decreases to not less than 35 foot-
candles (100 lux) and turn OFF when the ambient light decreases to not more than 60 foot-
candles (150 lux). These limits can be factory adjusted, if required.
If the light detects a LED failure the alarm relay can be used to provide a feedback to the user.
Operation & Setup

Latest products and information available at www.avlite.com
14
Universal DC Low Intensity Obstruction Light
Single Light Fixture
INTENSITY & OPERATION MODE SETTING
Light intensity & operation mode setting for ICAO compliant light xture
ThexturewillbesuppliedwiththeICAOcompliantoptic.
Theobstructionlightwillbepre-settotheintensitysettingspeciedbythecustomer(ICAOTypeAor
ICAO Type B) for a red steady burning Low Intensity Obstruction Light in dusk-till-dawn mode. The
intensity and operation mode is pre-set in the factory and does not need to be set by the user.
If the customer should need to change the intensity or operation mode settings of the ICAO compliant
model they can do this by changing the INTENSITY DIP switch. Please refer to table below for DIP switch
settings and Figure 2 for circuit board location.
Light intensity & operation mode setting for FAA compliant light xture
ThexturewillbesuppliedwiththeFAAcompliantoptic.
The FAA compliant model comes pre-set to the correct intensity for L-810 steady burning red obstruction
light in dusk-till-dawn mode. The intensity and operation mode is pre-set in the factory and does not need
to be set by the user.
If the customer should need to change the operation mode settings of the FAA compliant model they can
do this by changing the INTENSITY DIP switch. Please refer to table below for DIP switch settings and
Figure 2 for circuit board location.
NOTE:
The ICAO Model and FAA Model have their own unique optic. The ICAO model cannot be used for
FAA purposes and the FAA model cannot be used for ICAO purposes. The model required needs to be
speciedatthetimeoforder.
NOTE:
Theunitmustbeinstalledbyaqualiedelectrician.
Position 2 Position 1 Light Intensity
No function OFF FAA L-810 Low Intensity Obstruction Light, dusk-till-dawn mode
– DEFAULT
No function ON FAA L-810 Low Intensity Obstruction Light, 24 hour mode
Position 2 Position 1 Light Intensity
OFF OFF ICAO Low Intensity Obstruction Light Type A (10cd), dusk-till-dawn mode
– DEFAULT
OFF ON ICAO Low Intensity Obstruction Light Type A (10cd), 24 hour mode
ON OFF ICAO Low Intensity Obstruction Light Type B (32cd), dusk-till-dawn mode
ON ON ICAO Low Intensity Obstruction Light Type B (32cd), 24 hour mode

Latest products and information available at www.avlite.com
15
Universal DC Low Intensity Obstruction Light
Single Light Fixture
ALARM RELAY OUTPUT
In normal operation the relay is energised
• Terminal contacts COMM and NC of the relay are electrically closed
• Terminal contacts COMM and NO of the relay are electrically open
Whenever the LED is not lit due to a power failure and/or a LED failure the relay will not be energised.
• Terminal contacts COMM and NO of the relay are electrically closed
• Terminal contacts COMM and NC of the relay are electrically open
For location details of the terminals please refer to Figure 2.
Thealarmrelaycomesconguredasfollows:
• Relay normal operation (default, as described above)
Thefollowingalarmrelaycongurationsareavailableasaspecialorder.Thesemustbespeciedat
the time of order:
• Relay inverse operation (inverse functionality of the normal operation, used to conserve power)
• Relay disable (in case the relay is not required, used to conserve power)
NOTE: The alarm relay is intended for low voltage (SELV) connection only.
NOT FOR MAINS CONNECTION
RS232 AND RS422/485 COMMUNICATION (OPTIONAL)
The Obstruction Light offers a RS232 and a R2422/485 interface.
RS232 Typical 3 pin TxD, RxD and GND arrangement
RS422/485 Typical 4 pin arrangement with Termination selection and Duplex/Halfduplex selection
For location details please refer to Figure 2.
Please contact AVLITE for further details.
Duplex
SW3
S1 S2
OFF OFF Simplex operation
ON ON Duplex operation
Termination
SW4
S1 S2
OFF OFF No termination
ON ON 120 Ohm termination

Latest products and information available at www.avlite.com
16
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Maintenance & Servicing
Designed to be maintenance free the Obstruction Lights requires minimal attention, though the
following maintenance and servicing information is provided to help ensure the life of your Avlite
product.
• Occasional cleaning of the dome lens may be required using a cloth and warm soapy water.

Latest products and information available at www.avlite.com
17
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Trouble Shooting
Problem Remedy
Light will not activate. • Ensure proper connectivity with power supply
• Ensure that the power supply has the right polarity and voltage range
• Cover the light sensor to force the light ON

Latest products and information available at www.avlite.com
18
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Figure 4. Light head wiring diagram
Appendix
Light Head Wiring Diagram
Figure 5. Light head parts diagram

Latest products and information available at www.avlite.com
19
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Bottom enclosure
Cable gland
vent
O-ring
Security lock
Inside thread for
pole mounting
Metal ring
optics
dome lens
PCB with
single LED
Top enclosure
Screw
Figure 5. Light head parts diagram
Light Head Parts Diagram

Latest products and information available at www.avlite.com
20
Universal DC Low Intensity Obstruction Light
Single Light Fixture
Product Order Codes
HOW TO ORDER AV-OL Series Obstruction Lights:
ICAO Compliant FAA Compliant
AV-OL-ILAB-[Model]-[Color]-[?]-[?]-[?]-[?]-[?] AV-OL-FL810-[Model]-[Color]-[?]-[?]-[?]-[?]-[?]
Product No.:
Model:
12 = 12–48 VDC
UM = 110–240 VAC
Color:
R = Red
IR = Infrared
RIR = Combined Red/IR
Single or Dual Fixture:
[blank] = Single light xture
[D] = Dual light xture
Solar/Battery Conguration:
CT1 = Type 1
CT2 = Type 2
[blank] = No solar/battery conguration
Monitoring & Control:
G = GSM
RF = Radio Control
[blank] = No monitoring & control
RS Communications Port (12-48VDC Model only):
RS = RS communications port
[blank] = No RS communications port
Feature:
0 = Both lights activated at the same time
1 = One light activated with automatic changeover
ability
[blank] = No feature
Product No.:
Model:
12 = 12–48 VDC
UM = 110–240 VAC
Color:
R = Red
IR = Infrared
RIR = Combined Red/IR
Single or Dual Fixture:
[blank] = Single light xture
[D] = Dual light xture
Solar/Battery Conguration:
CT1 = Type 1
CT2 = Type 2
[blank] = No solar/battery conguration
Monitoring & Control:
G = GSM
RF = Radio Control
[blank] = No monitoring & control
RS Communications Port (12-48VDC Model only):
RS = RS communications port
[blank] = No RS communications port
Feature:
0 = Both lights activated at the same time
1 = One light activated with automatic changeover
ability
[blank] = No feature
