Avonic CM70-NDI-B User manual

www.avonic.eu | User Manual | Version 1.0
Avonic PTZ Camera 20x zoom
CM70-NDI

www.avonic.eu
CONTENTS
Introduction........................................................................................................................... 4
Contact................................................................................................................4
Join Avonic .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4
Safety Notes .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4
Package contents and Accessories .................................................................... 5
Contents.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5
Handling precautions .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5
Accessoiries .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5
Product Overview.............................................................................................................. 6
Features .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .6
Installation ..............................................................................................................................7
Connections .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7
System Select Switch............................................................................................8
RS232 Interface.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .8
RS232 network connection diagram .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .9
RS485 network connection diagram .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .9
IP network connection diagram............................................................................9
Operation................................................................................................................................10
Remote controller .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 10
Other Key Combinations . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 12
OSD Menu ...............................................................................................................................13
Serial Communication Control .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 18
IP Control. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 18
WebGUI.....................................................................................................................................19
Login.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 19
Local.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 19
Audio .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 20
Video .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 21
Network. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 27
System .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 29
Maintenance .......................................................................................................................33
Camera Maintenance . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
Unauthorized Use .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33

www.avonic.eu
Troubleshooting................................................................................................................33
General Advice .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
Power Issues.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
Image.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 34
Control . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 34
WebGUI. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 34
VISCA Settings and command list.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 35
VISCA over IP.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 35
Appendix B Dimensions...............................................................................................47
CMOS Image Sensors Characteristics..............................................................48

www.avonic.eu 4
• Installation and servicing should only be done by Qualified Service Personnel and conform to all
local codes.
• This unit is designed for indoor use only and it must not be installed where exposed to water or
other liquids and moisture.
• Before powering on the device, check the input power voltage carefully.
• Avoid shock and vibration when transporting and installing the device.
• Electronic devices produce heat. Do not block the ventilation slots of the device and make sure
the installation environment is well ventilated to avoid overheating.
• Before cleaning, unplug the power cable. Use a soft, damp cloth to clean the device, do not use
strong or abrasive detergent to clean that will damage the device.
• If you wish to dispose this product, please contact Avonic to obtain info about the disposal
procedure.
facebook.com/avonicPTZ linkedin.com/company/avonic twitter.com/avonic
For any questions or suggestions, contact your reseller or the local distributor of Avonic. Find the local distri-
butor on the website of Avonic. For the most recent version of the manual or datasheet, look at the Avonic
website: www.avonic.eu
Thank you for your Avonic purchase. Before beginning to operate this device, please read the manual in
order to make sure the best performance is obtained. Save this manual for future reference.
Join Avonic
Safety Notes
Contact
INTRODUCTION

www.avonic.eu 5
Be cautious to take the camera by its
base. When placing back the camera in
its protective foam, be sure the lens is in
horizontal position.
Wall and Ceiling mount
SKU white: AV-MT200-W
SKU black: AV-MT200-B
Wall mount
SKU white: CM-WMW
SKU black: CM-WMB
Ceiling mount
SKU white: CM-CMW
SKU black: CM-CMB
Quantity Description Avonic SKU
1 pc PTZ Camera AV-CM70-NDI-W/B
1 pc Power Supply 12V/A AV-CM40-PSU
1 pc Remote Control AV-CM40-RC
1 pc USB cable type A to type A AV-USB20-AA
1 pc RS232 9-pin male to 8-pin male AV-CM-RS232
1 pc 2-way RS485 serial connector AV-PHNX-2
1 pc 5-way Balanced audio conn. AV-PHNX-5
Accessoiries
Handling precautions
Contents
PACKAGE CONTENTS AND ACCESSORIES

www.avonic.eu 6
• Panasonic high-quality 1/3 inch, 2.12 million effective pixels HD CMOS sensor
• Output frame rate up to 60fps in 1080P
• 20x/12x/30x Optical Zoom, glass lens.
• Remote Control Using RS232/ RS485/ IP/ IR/ USB interface, all the parameters of the
camera can be remotely controlled.
• Leading autofocus algorithm for a fast, accurate and stable auto-focusing lens.
• Low noise and High SNR: Low Noise CMOS effectively ensures high SNR of the camera.
• Advanced 2D/3D noise reduction technology is also used to further reduce the noise while
ensuring image sharpness.
• High accuracy, silent step driving motor makes for accurate fast and quiet panning and
tilting, in High Speed Mode <100° p/s pan speed and <70° p/s tilt speed
• Multi-Format Video Outputs: HDMI 1.4a, 3G-SDI, USB2.0, ethernet
• Ethernet port with PoE and NDI®| HX functionality
• Tally Light functionality for on-air indication (licensed premium feature)
• High Speed Mode; upgraded Pan and Tilt speed
• Encrypted SRT streaming (licensed premium feature)
• Fully customizable RGB colour matrix for perfect integration with other cameras
(licensed premium feature)
• The 3G-SDI is available for 100m transmission at 1080p60 format (SMPTE 424M). The output
image is 8-bit YCbCr 4:2:2 level B (SMPTE 425M).
• Auto-Flip function
• Low-power sleep function: power consumption less than 500mW in standby mode.
• Supports multiple Control Protocols: VISCA OVER IP, Onvif, VISCA, PELCO-D, PELCO-P;
protocols which can also be automatically recognized.
• Kensington Lock
The CM70-NDI is a high-quality PTZ camera with concurrent HDMI, 3G-SDI, USB 2.0 and IP stream ethernet
outputs.
The CM70-NDI is equipped with NewTek’s high-efficient IP technology called NDI®| HX.
This all-in-one PTZ camera from Avonic allows the move to an all IP infrastructure even for mobile applications.
With IP deployment on existing networks all cameras detected within your network become directly available
for use without complex configuration. Video, audio, control and power all with PoE connecting your CM70-NDI
camera to hundreds of systems, devices and applications that support NDI.
The CM70-NDI includes a rich feature set known from the CM70 series and has the ability to deliver outstanding
quality even under low light conditions. The combination of a high-quality PTZ camera with a protocol that im-
proves every live production give the CM70-NDI endless possibilities.
Features
PRODUCT OVERVIEW

www.avonic.eu 7
1. Kensington Lock
2. Balanced Audio Line in 5-pin Phoenix connector
3. RS-485 two-wire serial communication with 2-pin Phoenix connector
4. System Selector (see Installation for more details)
5. RS-232 mini-DIN-8 IN (connect the supplied RS-232 cable)
6. RS-232 mini-DIN-8 OUT for daisy chaining RS-232 connection
7. 3G-SDI video output SMTPE 425M level B compliant
8. HDMI Type A
9. USB2.0 Type A, UVC video output and control
10. RJ45 Ethernet connection, with PoE, NDI®| HXcertified
11. DC12V power with locking screw (connect the supplied DC PSU)
12. Power ON/OFF
13. Fall protection eye
Connections
INSTALLATION
1 2 3 4 5 6
7 9 10 11 12
8
13

www.avonic.eu 8
CAUTION:
a. After changing the switch, you need to restart the camera to take effect.
b. 720p30, 720p29.97 and 720p25 not supported by the SDI output.
c. There are four ways to select the video output (via OSD, direct button combination
on the remote control, via the webgui or via the rotary dial) of the camera, but the
rotary dial takes priority after a reboot, except on setting F where all the outputs are defined digitally
Power adapter
This product is equipped with a 12V/2A DC power supply. Insert the power supply according to the require-
ments, turn on the power switch. Alternatively use a PoE ethernet connection, the Power switch on the back
of the camera needs to be switched to the ‘ON’ position.
Power On
Pan-Tilt will rotate to the maximum position of top right after the camera started, then it returns to the
center, the process of initialization is finished. The camera will show its current IR-channel setting and IP
Address on the osd (Note: If the position preset 0 has been stored, the position preset 0 will be called after
initialization). From this point onwards the user can control the camera with RC, Serial, USB or IP Communi-
cation.
RS232 Interface
System Select Switch
0 1080p60 8 720p30
1 1080p50 9 720p25
2 1080i60 A 1080p59.94
3 1080i50 B 1080i59.94
4 720p60 C 720p59.94
5 720p50 D 1080p29.97
6 1080p30 E 720p29.97
7 1080p25 F Via OSD/Webgui

www.avonic.eu 9
When connecting multiple cameras through RS-232, use daisy chaining network architecture. Max cable
length for RS-232 is 10-15m.
To connect multiple cameras by RS485, the cameras are attached to a 2-wire twisted pair bus (max length
1200m) that is terminated at both ends with a 120 Ω impedance resistor. The maximum distance from the bus
to the camera or controller is 5m, when using only one camera, the impedance resistor is not needed.
Connect an Avonic PoE camera to a LAN using a standard (PoE) switch, if the unit is simultaneously connected
to both PoE and its own power supply, the power supply will take priority. If the power supply is disconnected
when PoE is present, the camera will remain operational without interruption.
Addressing is done via IP, the Visca address in a Visca over IP environment is always 1.
RS232 network connection diagram
RS485 network connection diagram
IP network connection diagram
Controller
IP controller
Ethernet
Ethernet
Ethernet
(PoE) Switch
PC
Camera
In Out
RS-232 RS-232 RS-232
In Out In Out
Camera
Camera
Camera

www.avonic.eu 10
a. Power
b. Set
c. Camera select
d. Number Keys
e. Focus + -
f. Auto/Manual Focus
g. Zoom + -
h. Set & Clear Preset
i. PTZ keys (up/down/left/right)
j. Home
k. BLC (Back Light Control) ON/OFF
l. Menu
m. Function Keys (F1/F2/F3/F4)
n. Blank buttons
Remote controller
OPERATION

www.avonic.eu 11
a. Power
Press the power button to turn on the camera. If the position preset 0 has been stored, the position preset 0
will be called after initialization. Press the power button again to turn the camera off, it will turn to the back
when turned off, this is called the “privacy mode”.
b. Set
This button has no function with this camera.
c. Camera select
Up to 4 different cameras can be controlled with 1 IR remote Control. With the camera select buttons [1,2,3,4]
you can select the IR channel the remote control is using. The default camera IR channel is 1.
To control a camera on first use, please select camera 1 (IR channel 1) on the remote control. To control a
second camera you first need to change the IR channel stored in the camera from 1 to 2.
• First turn off the other camera’s in the room you don’t want to change, to prevent
that other camera’s also get changed accidentally.
• Select camera 1 on the remote control, because the camera is still configured to
listen to IR channel 1.
• Press [*]+[#]+[F2] to change the IR channel inside the camera to IR channel 2.
The camera will confirm this on screen.
• Select camera 2 on the remote control to control this camera.
Key Combinations: (Default IR address is 1)
[*]+[#]+[F1] : Camera Address No. 1 [*]+[#]+[F3] : Camera Address No. 3
[*]+[#]+[F2] : Camera Address No. 2 [*]+[#]+[F4] : Camera Address No. 4
d. Number Keys
The number keys are used to call presets. Press the number [0-9] of the preset desired and the camera will
respond accordingly (See ‘h’ on how to set & clear presets)
e. Focus + -
Push the button [manual focus] first before using the focus buttons. Focus the camera with the [+] and [–]
button. If the camera does not respond check if the camera is set to auto-focus.
f. Auto/Manual Focus
Set the camera in auto-focus or manual-focus. If the camera is configured to auto-focus the buttons [Focus
+ -] are disabled. When the camera is in “manual focus” modus and the Zoom buttons are used, the camera
automatically switces to auto-focus.
g. Zoom + -
Zoom the camera with these buttons. When the camera is in “manual focus” modus and the Zoom buttons
are used, the camera automatically switches to auto-focus.
h. Set & Clear Preset
A preset is a specific position of a camera that you save into the camera. A preset is assigned to a num-
ber from 0-9. To set a preset first point the camera in a specific directing and a specific zoom position. Now
assign the position to a number with the button “Set Preset”. You can call the preset by pressing the number
0-9 on the remote control.
Set Preset: [SET PRESET]+[<number>]
Call Preset: [<number>]
Clear Preset: [CLEAR PRESET]+[<number>]
If the position preset 0 has been stored, this position will be called after initialization.

www.avonic.eu 12
i. PTZ keys (up/down/left/right)
Move the camera in a direction.
j. Home
Set the direction of the camera to a center position.
k. BLC (Back Light Control) ON/OFF
Change the Back light control setting.
l. Menu
The Menu button opens the “On Screen Display (OSD)” menu. This menu is visible on the HDMI/SDI/IP output. If
the menu is not in English, please press [*]+[#]+[4] to change the Menu language to English.
m. Function Keys (F1/F2/F3/F4)
Used to configure the IR channel of the camera. See [c. Camera select] above for instructions.
n. Blank buttons
These buttons have no function with this camera.
[*]+[#]+[4] : Menu set to English
[*]+[#]+[6] : Restore factory defaults
[*]+[#]+[9] : Flip switch (just temporary flip to view the image flipped)
[*]+[#]+[Auto] : Enter into the aging mode, only for quality control purposes
[*]+[#]+[Manual] : Restore the default username, password, and IP address
[#]+[#]+[#] : Clear all presets
[#]+[#]+[0] : Switch the video format to1080p60*
[#]+[#]+[1] : Switch the video format to 1080p50*
[#]+[#]+[2] : Switch the video format to 1080i60*
[#]+[#]+[3] : Switch the video format to 1080i50*
[#]+[#]+[4] : Switch the video format to 720p60*
[#]+[#]+[5] : Switch the video format to 720p50*
[#]+[#]+[6] : Switch the video format to 1080p30*
[#]+[#]+[7] : Switch the video format to 1080p25*
[#]+[#]+[8] : Switch the video format to 720p30*
[#]+[#]+[9] : Switch the video format to 720p25*
*NOTE: THE CAMERA RETURNS TO THE VIDEO OUTPUT SETTING OF THE ROTARY DIAL AFTER A REBOOT
Other Key Combinations

www.avonic.eu 13
The OSD menu can be accessed by the Re-
mote Control or an Avonic PTZ controller. In the
following pages, the navigating is described
for using the IR Remote Control.
OSD MENU Language
Setup Protocol
Visca Address
Visca Address Fix
Pelco-P Address
Pelco-D Address
Baudrate
Camera Exposure Mode
EV
BLC
Flicker
G. Limit
DRC
Color WB Mode
RG Tuning
BG Tuning
Saturation
Hue
AWB Sensitivity
Image Brightness
Contrast
Sharpness
Flip-H
Flip-V
B&W Mode
Gamma
DCI
Focus Focus Mode
AF-Zone
AF-Sensitivity
Noise Reduction NR-2D
NR-3D
Dynamic Hot Pixel
Style
P/T/Z
Video Format
Network Settings
Version
Root menu
Restore Default
DHCP ON/OFF
Low Light Mode

www.avonic.eu 14
1. MENU
Press [MENU] button to display the main menu on the screen. Use the arrow buttons to move the cursor to the
item to be set. Press the [HOME] button to enter the corresponding sub-menu. Press [ ] to change setting.
Press [Menu] to go back
2. SETUP
3. CAMERA
MENU
Language EN / CN
Setup
Camera
P/T/Z
Video Format
Version
Restore Default
Select Item
Change Value
[Home] Enter
[Menu] Exit
SETUP
Protocol AUTO / VISCA / PELCO-D / PELCO-P
Visca Address 1 ~ 7
Visca Address Fix ON / OFF
PELCO-P Address 1 ~ 255
PELCO-D Address 1 ~ 255
Baudrate 2400 / 4800 / 9600 / 38400 / 115200
Select Item
Change Value
[Menu] Back
CAMERA
Exposure
Color
Focus
Noise Reduction
Style Soft / Default / Normal / Clarity / Bright
Select Item
Change Value
[Menu] Back

www.avonic.eu 15
3.1 EXPOSURE
3.2 COLOR
EXPOSURE
Mode Auto / Manual / SAE / AAE / Bright
Iris F11 ~ F1.8 / CLOSE
Shutter 1/25 ~ 1/10000
EV ON / OFF
EV Level -7 ~ +7
BLC ON / OFF
Flicker 50Hz / 60Hz / OFF
G. Limit 0 ~ 15
DRC 1 ~ 8 / CLOSE
Select Item
Change Value
[Menu] Back
COLOR
WB Mode Auto / 2400K ~ 7100K 100K increments / Manual / OnePush
RG Tuning -10 ~ 10
BG Tuning -10 ~ 10
RG 0 ~ 255
BG 0 ~ 255
Saturation 60% - 200%
Hue 0 ~ 14
AWB Sensitivity Low / Middle / High
Select Item
Change Value
[Menu] Back

www.avonic.eu 16
3.3 IMAGE
The Flip function can be set, although the camera has an automatically flip function.
3.4 FOCUS
3.5 NOISE REDUCTION
Brightness 0 ~ 14
Contrast 0 ~ 14
Sharpness 0 ~ 15
Flip-H ON / OFF
Flip-V ON / OFF
B&W-Mode Color / B&W
Gamma 0.45 / 0.50 / 0.55 / 0.63 / Default
DCI 1 ~ 8 / Close
Low Light Mode ON / OFF
Select Item
Change Value
[Menu] Back
FOCUS
Focus Mode Auto / Manual / OnePush
AF-Zone Top / Center / Bottom / All
AF-Sensitivity Low / Middle / High
Select Item
Change Value
[Menu] Back
NOISE REDUCTION
NR-2D 1 ~ 7 / Auto / OFF
NR-3D 1 ~ 8 / Auto/ OFF
Dynamic Hot Pixel 1 ~ 5 / OFF
Select Item
Change Value
[Menu] Back
3.6 STYLE
STYLE
Style Default / Normal / Clarity / Bright / Soft
Select Item
Change Value
[Menu] Back

www.avonic.eu 17
4. PTZ
8. RESTORE DEFAULT
5. VIDEO FORMAT
PTZ
Speed by Zoom ON / OFF
Zoom Speed 1 ~ 8
Image Freezing ON / OFF
Select Item
Change Value
[Menu] Back
RESTORE DEFAULT
Restore default? NO / YES
Select Item
Change Value
[Menu] Back
[Home] OK
VIDEO FORMAT
Video Format 1080p60/ 1080p50/ 1080i60/ 1080i50/ 1080p30/ 1080p25/
720p60/720p50/ 720p30/ 720p25/ 1080p59.94/ 1080i59.94/
1080p29.97/720p59.94/ 720p29.97
Select Item
Change Value
[Menu] Back
6. NETWORK SETTINGS
DHCP ON/OFF
IP Address xxx.xxx.xxx.xxx
[Menu] Back
7. VERSION
VERSION
MCU Version nr date
Camera Version nr date
AF Version nr date
[Menu] Back

www.avonic.eu 18
Network settings
By default the ip address of the camera is 192.168.5.163 with username and password
admin/admin. Avonic IP cameras can be controlled by any device using the Visca over IP
protocol (see command list Appendix A).
The control parameters for the CM4x and CM7x-IP cameras are as follows:
• IP Address: 192.168.5.163
• Username: admin
• Password: admin
• TCP or UDP port: 1259
• Parity bit: none.
IP Control
COM port settings
In default working mode, the camera is able to connect to a VISCA controller with an RS-232 or RS-485
serial interface.
The camera can be controlled via RS-232, the parameters of RS-232 are as follows:
• Baud rate: 2400/4800/9600*/115200
• Start bit: 1 bit.
• Data bit: 8 bits.
• Stop bit: 1 bit.
• Parity bit: none.
The camera can be controlled via RS-485, Half-duplex mode. The parameters are:
• Baud rate: 2400/4800/9600*
• Start bit: 1 bit.
• Data bit: 8 bits.
• Stop bit: 1 bit.
• Parity bit: none.
For command list, see Appendix A
* default value
Serial Communication Control
NDI®| HX Connection
The NDI®| HX connection allows you to connect and control your Avonic NDI®| HX camera
through compatible hardware or software on your local network (LAN). Once the camera is
installed on the local network (LAN) it is possible to use the NDI®| HX connection.
For installation use, downloading and installing the NewTek NDI Tools pack will provide a use-
ful array of practical tools and utilities.
The pack can be downloaded at https://www/newtek.com/ndi

www.avonic.eu 19
Login
default IP*: 192.168.5.163
default username: admin
default password: admin
The login screen:
WEBGUI
A preview of the camera ip-video output. When an image is not visible, make sure to have flash enabled for this
webpage.
On the right is PTZ control, speed by zoom slider, focus and zoom functionality.
Click on the camera icon below the screen to switch preview between main stream and sub stream. Note that
preview only works when the main- or sub-stream is set to H264 (see page 22).
Local
*Note:
If DHCP is enabled and there is no DHCP server available, the camera will self appoint an IPv4 link-local address
between 169.254.0.0 and 169.254.255.255. The IP address is shown on screen at start-up.

www.avonic.eu 20
Enable or disable embedding of the audio input on the back of the camera.
Select encoding type mp3, AAC or G.711A
Select sample rate: 16000, 32000, 44100, 48000
Sample bits: always 16
Bitrate Kbps : 32, 48. 64, 96, 128
Channel: Mono or Stereo
Input volume: 1 ~ 10
Audio Delay (ms) 0 ~ 200
Audio
