Avonic AV-CM40-IP User manual

www.avonic.eu
User Manual
Version 1.0
Avonic PTZ Camera 20x Zoom
AV-CM40-IP

www.avonic.eu
Contents
Introduction......................................................................................................................................................... 4
Congratulations. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
Contact. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
Join Avonic.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
Safety Notes.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4
Package contents and Accessories ...................................................................................... 5
Contents. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
Handling precautions.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
Accessoiries.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
Product Overview......................................................................................................................................... 6
Features .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 6
Installation ............................................................................................................................................................ 7
Connections. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 7
System Select Switch .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 8
RS232 Interface .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 8
RS232 network connection diagram.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 9
RS485 network connection diagram. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 9
IP network connection diagram. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 9
OSD Menu.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 10
Operation............................................................................................................................................................... 15
Remote controller .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 15
Other Key Combinations .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 17
Serial Communication Control .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 18
IP Control .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 18
WebGUI ..................................................................................................................................................................... 19
Local .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 19
Audio. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 20
Video. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 21
Video Encoder .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 21
Streaming Video .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 22
Multicast Streaming .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 22
Camera Settings.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 23
OSD .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 24
Output Format.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 25
Network. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 26

www.avonic.eu
Port Settings.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 26
Ethernet .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 27
System .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 28
Attributes .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 28
Time. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 28
User.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 29
Update .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 29
Default .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 30
Reboot. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 30
MJPEG snapshot. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 31
Maintenance...................................................................................................................................................... 32
Camera Maintenance .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 32
Unauthorized Use. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 32
Troubleshooting............................................................................................................................................. 32
General advise. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 32
Power Issues. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 32
Image.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
Control .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
WebGUI.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
VISCA command list .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 34
VISCA over IP commands.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 34
Appendix B Dimensions......................................................................................................................... 43

3
www.avonic.eu 3
• InstallationandservicingshouldonlybedonebyQualiedServicePersonnelandconformtoall
local codes.
• This unit is designed for indoor use only and it must not be installed where exposed to water or
other liquids and moisture.
• Before powering on the device, check the input power voltage carefully.
• Avoid shock and vibration when transporting and installing the device.
• Electronic devices produce heat. Do not block the ventilation slots of the device and make sure
the installation environment is well ventilated to avoid overheating.
• Before cleaning, unplug the power cable. Use a soft, damp cloth to clean the device, do not use
strong or abrasive detergent to clean that will damage the device.
• If you wish to dispose this product, please contact Avonic to obtain info about the disposal
procedure.
facebook.com/avo-
nicPTZ
linkedin.com/compa-
ny/avonic/
twitter.com/
avonic
For any questions or suggestions, contact your reseller or the local distributor of Avonic. Find the local
distributor on the website of Avonic. For the most recent version of the manual or datasheet, look at the
Avonic website: www.avonic.eu
Thank you for your Avonic purchase. Before beginning to operate this device, please read the manual in
order to make sure the best performance is obtained. Save this manual for future reference.
Join Avonic
Safety Notes
Contact
Congratulations
Introduction

Be cautious to take the camera
by its base. When placing back
the camera in its protective foam,
be sure the lens is in horizontal
position.
www.avonic.eu 5
Wall mount
SKU white : CM-WMW
SKU black: CM-WMB
Wall and Ceiling mount
SKU white : AV-MT200-W
SKU black: AV-MT200-B
Ceiling mount
SKU white : CM-CMW
SKU black: CM-CMB
Quantity Description Avonic SKU
1 pc PTZ Camera AV-CM40-IP
1 pc Power Supply 12V/A AV-CM40-PSU
1 pc Remote Control AV-CM40-RC
1 pc USB cable type A to type A AV-USB20-AA
1 pc RS232 9-pin male to 8-pin male AV-CM-RS232
Accessoiries
Handling precautions
Contents
Package contents and Accessories

www.avonic.eu 6
• Panasonic high-quality 1/2.8 inch, 2.07 million effective pixels HD CMOS sensor
• Output frame rate up to 60fps in 1080P
• 20x Optical Zoom, glass lens.
• Remote Control Using RS232/485/IP interface, all the parameters of the camera can be
remotely controlled.
• Leading autofocus algorithm for a fast, accurate and stable auto-focusing lens.
• Low noise and High SNR: Low Noise CMOS effectively ensures high SNR of the camera.
• Advanced 2D/3D noise reduction technology is also used to further reduce the noise while
ensuring image sharpness.
• High accuracy, silent step driving motor makes for accurate fast and quiet panning and
tilting.
• Multi-Format Video Outputs: HDMI 1.4a, 3G-SDI, USB2.0, ethernet
• Ethernet port with PoE functionality
• The 3G-SDI is available for 100m transmission at 1080p60 format (SMPTE 424M). The output
image is 8-bit YCbCr 4:2:2 level A (SMPTE 425M).
• Auto-Flip function
• Low-power sleep function: the consumption is lower than 500mW in sleep mode.
• Supports Multiple Control Protocols: VISCA, PELCO-D, PELCO-P; protocols which can also be
automatically recognized.
• Kensington Lock
The Avonic CM40-IP is a high-quality PTZ camera, with an HDMI, USB2.0, 3G-SDI and ethernet output.
Thecameraisdesignedforxedinstallationsandhighqualityvideoinlowlightconditions.The
camera is equipped with high quality components like a Panasonic CMOS sensor and a glass
lens with 20x optical zoom. Control the camera over RS232, RS485 or IP with any controller with
VISCA or PELCO support.
Features
Product Overview

www.avonic.eu 7
Installation
1
2
6 7 8 9 10 11
3 4 5
12
Connections
1. Audio Line in to embed audio on HDMI/SDI or IP stream
2. RS-485 two-wire serial communication with 2-pin Phoenix connector
3. System Selector (see next page for details)
4. RS-232 mini-DIN-8 IN (connect the supplied RS-232 cable)
5. RS-232 mini-DIN-8 OUT for daisy chaining RS-232 connection
6. 3G-SDI video output SMTPE 424M compliant
7. HDMI Type A
8. USB2.0 Type A, UVC video output
9. RJ45 Ethernet connection with PoE
10. DC12V power with locking screw (connect the supplied DC PSU)
11. Power ON/OFF
12. Kensington Lock

www.avonic.eu 8
CAUTION:
a. After changing the switch, you need to restart the camera to take effect.
b. 720p30, 720p29.97 and 720p25 not supported by the SDI output.
c. There are four ways to select the video output (via OSD, direct button combination
on the remote control, via the webgui or via the rotary dial) of the camera, but the
rotarydialtakespriorityafterareboot,exceptonsettingFwherealltheoutputsaredeneddigitally
Power adapter
This equipment is equipped with a 12V/2A DC power supply. Insert the power supply according to the requi-
rements, turn on the power switch. Alternatively use a PoE ethernet connection.
Power On
Pan-Tilt will rotate to the maximum position of top right after the camera started, then it returns to the cen-
ter,theprocessofinitializationisnished.ThecamerawillshowitscurrentIR-channelsettingandIPAddress
on the osd (Note: If the position preset 0 has been stored, the position preset 0 will be called after initializati-
on). From this point onwards the user can control the camera with RC, Serial or IP Communication.
RS232 Interface
System Select Switch
0 1080p60 8 720p30
1 1080p50 9 720p25
2 1080i60 A 1080p59.94
3 1080i50 B 1080i59.94
4 720p60 C 720p59.94
5 720p50 D 1080p29.97
6 1080p30 E 720p29.97
7 1080p25 F Via OSD/Webgui

www.avonic.eu 9
When connecting multiple cameras through RS-232, use daisy chaining network architecture. Max cable
length for RS-232 is 10-15m.
To connect multiple cameras by RS485, the cameras are attached to a 2-wire twisted pair bus (max length
1200m)thatisterminatedatbothendswitha120Ωimpedanceresistor.Themaximumdistancefromthebusto
the camera or controller is 5m.
Connect an Avonic PoE camera to a LAN using a standard (PoE) switch, if the unit is simultaneously connected
to both PoE and its own power supply, the power supply will take priority. If the power supply is disconnected
when PoE is present, the camera will remain operational without interruption.
Addressing is done via IP, the Visca address in a visca over ip environment is always 1.
RS232 network connection diagram
RS485 network connection diagram
IP network connection diagram
Controller
IP controller
Ethernet
Ethernet
Ethernet
(PoE) Switch
PC
Camera
In Out
RS-232 RS-232 RS-232
In Out In Out
Camera
Camera
Camera

www.avonic.eu 10
The OSD menu can be accessed by the Remote Control or an Avonic PTZ controller. In the following pages,
the navigating is described for using the IR Remote Control.
OSD MENU
Language
Setup Protocol
Visca Address
Visca Address Fix
Pelco-P Address
Pelco-D Address
Baudrate
Camera Exposure Mode
EV
BLC
Flicker
G. Limit
DRC
Color WB Mode
RG Tuning
BG Tuning
Saturation
Hue
AWB Sensitivity
Image Brightness
Contrast
Sharpness
Flip-H
Flip-V
Gamma
DZoom
DCI
Focus Focus Mode
AF-Zone
AF-Sensitivity
Noise Reduction NR-2D
NR-3D
Dynamic Hot Pixel
Style
P/T/Z
Video Format
Network Settings
Version
Root menu
Restore Default
DHCP ON/OFF

www.avonic.eu 11
1. MENU
Press [MENU] button to display the main menu on the screen. Use the arrow buttons to move the cursor to the
item to be set. Press the [HOME] button to enter the corresponding sub-menu. Press [ ] to change setting.
Press [Menu] to go back
2. SETUP
3. CAMERA
MENU
Language EN / CN
Setup
Camera
P/T/Z
Video Format
Version
Restore Default
Select Item
Change Value
[Home] Enter
[Menu] Exit
SETUP
Protocol AUTO / VISCA / PELCO-D / PELCO-P
Visca Address 1 ~ 7
Visca Address Fix ON / OFF
PELCO-P Address 1 ~ 255
PELCO-D Address 1 ~ 255
Baudrate 2400 / 4800 / 9600 / 38400 / 115200
Select Item
Change Value
[Menu] Back
CAMERA
Exposure
Color
Focus
Noise Reduction
Style Soft / Default / Normal / Clarity / Bright
Select Item
Change Value
[Menu] Back

www.avonic.eu 12
3.1 EXPOSURE
3.2 COLOR
EXPOSURE
Mode Auto / Manual / SAE / AAE / Bright
Iris F11 ~ F1.8 / CLOSE
Shutter 1/25 ~ 1/10000
EV ON / OFF
EV Level -7 ~ +7
BLC ON / OFF
Flicker 50Hz / 60Hz / OFF
G. Limit 0 ~ 15
DRC 1 ~ 8 / CLOSE
Select Item
Change Value
[Menu] Back
COLOR
WB Mode Auto / 3000K ~ 7000K 500K increments / Manual / OnePush
RG Tuning -10 ~ 10
BG Tuning -10 ~ 10
RG 0 ~ 255
BG 0 ~ 255
Saturation 60% - 200%
Hue 0 ~ 14
AWB Sensitivity Low / Middle / High
Select Item
Change Value
[Menu] Back

www.avonic.eu 13
3.3 IMAGE
TheFlipfunctioncanbeset,althougthecamerahasanautomaticallyipfunction.
3.4 FOCUS
3.5 NOISE REDUCTION
Brightness 0 ~ 14
Contrast 0 ~ 14
Sharpness 0 ~ 15
Flip-H ON / OFF
Flip-V ON / OFF
B&W-Mode Color / B&W
Gamma 0.45 / 0.50 / 0.55 / 0.63 / Default
DCI 1 ~ 8 / Close
Select Item
Change Value
[Menu] Back
FOCUS
Focus Mode Auto / Manual / OnePush
AF-Zone Top / Center / Bottom / All
AF-Sensitivity Low / Middle / High
Select Item
Change Value
[Menu] Back
NOISE REDUCTION
NR-2D 1 ~ 7 / Auto / OFF
NR-3D 1 ~ 8 / OFF
Dynamic Hot Pixel 1 ~ 5 / OFF
Select Item
Change Value
[Menu] Back
3.6 STYLE
STYLE
Style Default / Normal / Clarity / Bright / Soft
Select Item
Change Value
[Menu] Back

www.avonic.eu 14
4. PTZ
7. RESTORE DEFAULT
6. VERSION
5. VIDEO FORMAT
PTZ
Speed by Zoom ON / OFF
Zoom Speed 1 ~ 8
Image Freezing ON / OFF
Acc Curve Slow / Fast
Select Item
Change Value
[Menu] Back
RESTORE DEFAULT
Restore default? NO / YES
Select Item
Change Value
[Menu] Back
[Home] OK
VERSION
MCU Version nr date
Camera Version nr date
AF Version nr date
[Menu] Back
VIDEO FORMAT
Video Format 1080p60/ 1080p50/ 1080i60/ 1080i50/ 1080p30/ 1080p25/ 720p60/
720p50/ 720p30/ 720p25/ 1080p59.94/ 1080i59.94/ 1080p29.97/
720p59.94/ 720p29.97
Select Item
Change Value
[Menu] Back

www.avonic.eu 11
a. Set
b. Power
c. Camera select
d. Number Keys
e. Focus + -
f. Auto/Manual Focus
g. Zoom + -
h. Set & Clear Preset
i. PTZ keys (up/down/left/right)
j. Home
k. BLC (Back Light Control) ON/OFF
l. Menu
m. Function Keys (F1/F2/F3/F4)
n. Blank buttons
Remote controller
OPERATION

www.avonic.eu 12
a. Set
This button has no function with this camera.
b. Power
Press the power button to turn on the camera. If the position preset 0 has been stored, the position preset 0
will be called up after initialization. Press the power button again to turn the camera off, it will turn to the back
when turned off, this is called the “privacy mode”.
c. Camera select
Up to 4 different cameras can be controlled with 1 IR remote Control. With the camera select buttons (1,2,3,4)
you can select the IR channel the remote control is using. The default camera IR channel is 1.
Tocontrolacameraonrstuse,pleaseselectcamera1(IRchannel1)ontheremotecontrol.Tocontrola
secondcamerayourstneedtochangetheIRchannelstoredinthecamerafrom1to2.
• First turn off the other camera’s in the room you don’t want to change, to prevent
that other camera’s also get changed accidentally.
 •Selectcamera1ontheremotecontrol,becausethecameraisstillconguredto
listen to IR channel 1.
• Press [*]+[#]+[F2] to change the IR channel inside the camera to IR channel 2
• Select camera 2 on the remote control and see if the camera responds to the remote
control.
Key Combinations: (Default IR address is 1)
[*]+[#]+[F1] : Camera Address No. 1 [*]+[#]+[F3] : Camera Address No. 3
[*]+[#]+[F2] : Camera Address No. 2 [*]+[#]+[F4] : Camera Address No. 4
d. Number Keys
The number keys are used to call presets. Press the number of the preset desired and the camera will res-
pond accordingly (See ‘h’ on how to set & clear presets)
e. Focus + -
Pushthebutton“manualfocus”rstbeforeusingthefocusbuttons.Focusthecamerawiththe+and–but-
ton. If the camera does not respond check if the camera is set to auto-focus.
f. Auto/Manual Focus
Setthecamerainauto-focusormanual-focus.Ifthecameraisconguredtoauto-focusthebuttons“Focus
+ -“ are disabled. When the camera is in “manual focus” modus and the Zoom buttons are used, the camera
automatically switces to auto-focus.
g. Zoom + -
Zoom the camera with these buttons. When the camera is in “manual focus” modus and the Zoom buttons
are used, the camera automatically switches to auto-focus.
h. Set & Clear Preset
Apresetisaspecicpositionofacamerathatyousaveintothecamera.Apresetisassignedtoanumber
from0-9.Tosetapresetrstpointthecamerainaspecicdirectingandaspeciczoomposition.Nowas-
sign the position to a number with the button “Set Preset”. You can call the preset by pressing the number 0-9
on the remote control.
Set Preset: [SET PRESET]+[<number>]
Call Preset: [<number>]
Clear Preset: [CLEAR PRESET]+[<number>]
If the position preset 0 has been stored, this position will be called after initialization.

www.avonic.eu 13
i. PTZ keys (up/down/left/right)
Move the camera in a direction.
j. Home
Set the direction of the camera to a center position.
k. BLC (Back Light Control) ON/OFF
Change the Back light control setting.
l. Menu
The Menu button opens the “On Screen Display (OSD)” menu. This menu is visible on the HDMI/SDI/IP output. If
the menu is not in English, please press [*]+[#]+[4] to change the Menu language to English.
m. Function Keys (F1/F2/F3/F4)
UsedtoconguretheIRchannelofthecamera.See[c. Camera select] above for instructions.
n. Blank buttons
These buttons have no function with this camera.
[*]+[#]+[4] : Menu set to English
[*]+[#]+[6] : Restore factory defaults
[*]+[#]+[9]  :Flipswitch(justtemporaryiptoviewtheimageipped)
[*]+[#]+[Auto] : Enter into the aging mode, only for quality control purposes
[*]+[#]+[Manual] : Restore the default username, password, and IP address
[#]+[#]+[#] : Clear all presets
[#]+[#]+[0] : Switch the video format to1080p60*
[#]+[#]+[1] : Switch the video format to 1080p50*
[#]+[#]+[2] : Switch the video format to 1080i60*
[#]+[#]+[3] : Switch the video format to 1080i50*
[#]+[#]+[4] : Switch the video format to 720p60*
[#]+[#]+[5] : Switch the video format to 720p50*
[#]+[#]+[6] : Switch the video format to 1080p30*
[#]+[#]+[7] : Switch the video format to 1080p25*
[#]+[#]+[8] : Switch the video format to 720p30*
[#]+[#]+[9] : Switch the video format to 720p25*
*NOTE: THE CAMERA RETURNS TO THE VIDEO OUTPUT SETTING OF THE ROTARY DIAL AFTER A REBOOT
Other Key Combinations

www.avonic.eu 18
Network settings
By default the ip address of the camera is 192.168.5.163 with username and password admin/
admin. Avonic IP cameras can be controlled by any device using the Visca over ip protocol
(see command list see Appendix A).
The control parameters for the CM40-ip are as follows:
• IP Address: 192.168.5.163
• Username: admin
• Password: admin.
• TCP or UDP port: 1259
• Parity bit: none.
IP Control
COM port settings
In default working mode, the camera is able to connect to a VISCA controller with RS-232 or RS-485 serial
interface.
The camera can be controlled via RS-232, the parameters of RS-232C are as follows:
• Baud rate: 2400/4800/9600/115200
• Start bit: 1 bit.
• Data bit: 8 bits.
• Stop bit: 1 bit.
• Parity bit: none.
The camera can be controlled via RS-485, Half-duplex mode. The parameters are:
• Baud rate: 2400/4800/9600
• Start bit: 1 bit.
• Data bit: 8 bits.
• Stop bit: 1 bit.
• Parity bit: none.
For command list, see Appendix A
Serial Communication Control

www.avonic.eu 19
ThecameraisequippedwithaWebGUIforeasysetupandrmwareupdates.
Login
The default IP address is 192.168.5.163
The default username is : admin
The default password is : admin
The login screen:
WebGUI
Apreviewofthecameraip-videooutput.Whenanimageisnotvisible,makesuretohaveashenabledforthis
webpage.
On the right is PTZ control, speed by zoom slider, focus and zoom functionality.
Click on the camera icon below the screen to switch preview between main stream and sub stream. Note that
preview of the output only works when the main- or sub-stream is set to H264 (see page 22).
Local

www.avonic.eu 20
Enable or disable IP-Embedding of the 3.5mm line-input on the back of the camera.
Select encoding type mp3, AAC or G.711A
Select sample rate: 16000, 32000, 44100, 48000
Sample bits is always 16
Bitrate Kbps : 32, 48. 64, 96, 128
Channel: Mono or Stereo
Input volume: 1 - 10
Audio
