AVT AVC776 User manual

Table of Contents
1. Introduction
1-1 Safety Warning …………………………………………………………………………………
1-2 Features ………………………………………………………………………………………….
1-3 Specifications …………………………………………………………………………………...
2. Installation
2-1 Package contents ……………………………………………………………………………….
2-2 Connection ………………………………………………………………………………….….
2-3 Rack ount installation …………………………………………………………….…………..
2-4 RS232 /RS485 Re ote protocol ……………………………………………………………..…
3. Configuration
3-1 Install HDD …………………………………………………………………………………….…
3-2 Front panel keypad ……………………………………………………………………………..
3-3 Back panel connection ………………………………………………………………………….
3-4 Menu setup ……………………………………………………………………………………….
3-5 Syste setup …………………………………………………………………………………….
3-6 Search setup … ………………………………………………………………………………....
3-7 TIMER setup (Schedule Ti e-Lapse record ode setup )………………………………….…
3-8 Record Setup …………………………………………………..………………………….…. ..
3-9 Ca era setup ……….……………………………………………………………………….….
3-10 Motion Detection setup ……………..…………………………………………………….…
3-11 Event ……………………………………………………………………………………….…..
4. Operation
4-1 Power on …………………………………………………………………………………………
4-2 Recording ………………………………………………………………………………………...
4-3 Ca era Select (1-16) ………... ……………………………………………………………….….
4-4 Select……. ………………………………………………………………………………………...
4-5 Picture in Picture………..…………………………..……………………………………………...
4-6 Zoo ………………………………………………………………………………………………
4-7 Play ……………………………………………………………………………………………….
4-8 Video Loss ………………………………………………………………………………………..
4-9 Key Lock …………………………………………………………………………………………….
5. Trouble shooting & appendix
5-1 Trouble shooting …………………………………………………………………………………
5-2 Co patible HDD brands …………………………………………………………………...…...
1. Introduction
3
4
5
6
6
7
8
9
11
13
19
19
25
27
29
31
33
36
37
37
38
38
39
39
39
40
40
41
42

2
Thank you for choosing this high quality Digital Multiplex Recorder. The DMR converts analog
NTSC or PAL video to digital i ages and records the to a re ovable hard disk drive. Digitally
recorded video has any advantages co pared to analog video recorded on tape. There is no
need to adjust tracking. Digital video can be indexed by ti e schedule or events, and you can
instantly view video after selecting the ti e or event. You can freeze fra es, fast-forward, fast-
reverse, slow-forward, and slow-reverse without i age streaking or tearing. It can be used as a
replace ent for both a ti e-lapse VCR and a ultiplexer in a security installation.
1.1 Safety Warning
All the safety and operating instructions should be read before the operation. The improper
operation may cause permanent damage.
1.1.1 Please use the provided adaptor.
1.1.2 Please lift and place this equip ent gently.
1.1.3 Do not expose this equip ent to open sunlight.
1.1.4 Do not use this equip ent near water or in contact with water.
1.1.5 Do not spill liquid of any kind on the equip ent.
1.1.6 Please power down the unit before unplugging.
1.1.7 This equip ent should be operated only with power source fro standard package.
1.1.8 Unauthorized repair or parts substitutions ay result in fire, electric shock or other
hazards.
1.1.9 Do not switch the Power On & Off within short period o ti e (within 3 seconds).
1.1.10 Do not atte pt to service this equip ent by yourself. Refer all servicing and repair to
qualified service personnel.
1.1.11 This unit should be operated only fro power source indicated on the anufacturer’s
label.
1.1.12 Installation should be ade by a qualified service personnel and should confor to all
local safety codes and regulations.
1.2 Features
1.2.1 Wavelet Co pression For at replaces Ti e-Lapse VCR + Multiplexer
1.2.2 4 Audio inputs / 2Audio outputs
1.2.3 On Screen Display and RTC (Real ti e clock) Function
1.2.4 Multiplexing
 Support fro 4 channels up to 7/ 9 channels.
 9 channels can record or display real-ti e recorded i ages.
 9 channels loop back ter inal.
1.2.5 Resolution
Screen Modes Resolution

3
Full Screen
Quad 7 CH 9 CH 10 CH 13 CH 16 CH
Full screen 704(H) x 468(V) <NTSC> / 704(H) x 564(V) <PAL>
4 channels 352(H) x 234(V) <NTSC> / 352(H) x 282(V) <PAL>
9 channels 224(H) x 156(V) <NTSC> / 224(H) x 188(V) <PAL>
1.2.6 Independent ain and call onitor outputs allow si ultaneous ulti-ca era or full
screen viewing.
1.2.7 Multi Screen Display Mode
 Below display odes are selectable while surveillance & DMR play back:
1.2.8 Picture-In-Picture (PIP) is available in live and DMR playback odes, Zoo capability
up to 2 X 2 in live and DMR playback odes
1.2.9 16 channels are swappable and each channel has independent title generator (up to 6
characters).
1.2.10 Motion detection using 15x12 target (NTSC) 15x14 target (PAL) otion detection grids
for each video channel.
1.2.11 Video Quality Adjustable on Each Channel
1.2.12 Alar Input Function & Output Function
1.2.13 16 channels alar input, ALARM display and one alar output.
 Video loss detected on each channel can record 160 events.
1.2.14 Power-loss e ory function: set up para eter will re ain, in case of power failure.
1.2.15 Call Monitor: Switch Display
1.2.16 Support 1 Re ovable HDD, IDE Type (over 250GB)
1.2.17 Ti er: Schedule recording
1.2.18 Display refresh rate up to 72 IPS (60 IPS for PAL)
1.2.19 Record refresh rate up to 25 IPS (18 IPS for PAL)
1.2.20 Quick Multiple Search by date/ti e, alar , full list
1.2.21 Fast and slow playback in ultiple speeds.
1.2.22 Security password protection
1.2.23 RS-232, RS-485 co unication protocol
1.3 Specifications
Video format NTSC/EIA or PAL/CCIR
Hard disk storage IDE type, UDMA 66, 1 re ovable HDDs supported over 250GB
Record mode Manual / Alar / Ti er / Motion
Camera Input Signal Co posite video signal 1 Vp-p 75Ω BNC, 9 channels
Camera Loop Back Co posite video signal 1 Vp-p 75Ω BNC, 9 channels
Main Monitor Output Co posite video signal 1 Vp-p 75Ω BNC
Call Monitor Output Co posite video signal 1 Vp-p 75Ω BNC

4
Audio input 4 audio inputs, (RCA)
Audio output 2 audio outputs, (RCA)
Motion etect Area 15 * 12 targets per ca era (NTSC) / 15 * 14 targets per ca era (PAL)
Motion etect Sensitivity 256 Levels
Video Loss etection Yes
Refresh Rate 72 i ages/sec. for NTSC / 60 i ages/sec. for PAL
Recording Rate 25 i ages/sec. for NTSC / 18 i ages/sec. for PAL
well Time Progra able (1~10 Sec)
Picture in Picture Yes (Movable)
Key Lock Yes
Picture Zoom 2*2 (Movable)
Camera Title 6 letters
Video Adjustable Color/ Contrast/ Brightness Adjustable
Alarm Input TTL input, Hi (5V), Low (GND)
Alarm Output COM,/N.O/N.C.
Remote Control RS-232 or RS-485
Time isplay Format YY/MM/DD, DD/MM/YY, MM/DD/YY, OFF
Power Source AC100~240V + 10% switching adaptor
Power Consumption <27W
Operation Temperature 10 ~ 40
℃
RS-232C / RS-485 (bps) 115200
、 57600 、 19200 、 9600 、 4800 、 3600 、 2400 、 1200
imension (mm) 432(W) x 110(H) x 325(D)
Net Weight 5.2 kgs
Specifications are sub ect to change without notice.
2. Installation
2.1 Package contents
The package contents the following ite s.
 Digital Multiplex Recorder
 HDD cartridge
 Key for cartridge (Inside of HDD cartridge)
 Power cord
 User anual
 Rack ounting kit (Optional)

5
2.2 onnection
2.2.1 Connect with ca eras
PC
RS232
Sensor
Alar
Alar Input
Main Monitor
Video Ca era
.. . .
9... . 2 1
Call Monitor
Video Output
Audio Output
Audio Input
(4 Channels)
2.3 Rack mount installation
Front Angle with Rock Mount
Side View with Rack Mount

6
2.4 RS232 Remote Protocol
You can use the PC keyboard to si ulate DMR keypad.
DATA: REMOTE PROTOCOL using 8 bit data 、 1 start bit 、 1stop bit
ACT C0H ID FUNCTION STOP
(FFH) (7FH)
FUNCTION
FUNCTIONFUNCTION
FUNCTION CODE
CODECODE
CODE AS
ASAS
ASC
CC
CII
IIII
II FUNCTION
FUNCTIONFUNCTION
FUNCTION CODE
CODECODE
CODE AS
ASAS
ASC
CC
CII
IIII
II
KEY_MENU 0x4D M KEY_CH1 0x31 1
KEY_SELECT 0x73 s KEY_CH2 0x32 2
KEY_ENTER 0x0D ENTER KEY_CH3 0x33 3
KEY_4CUT 0x61 a KEY_CH4 0x34 4
KEY_ZOOM 0x5A Z KEY_CH5 0x35 5
KEY_9CUT 0x62 b KEY_CH6 0x36 6
KEY_ I 0x70 p KEY_CH7 0x37 7
KEY_16CUT 0x63 c KEY_CH8 0x38 8
KEY_SLOW 0x53 S KEY_CH9 0x39 9
KEY_REC 0x72 r
KEY_LEFT 0x4C L
KEY_U 0x55 U
KEY_ LAY 0x50
KEY_DOWN 0x4E N
KEY_RIGHT 0x52 R
KEY_ OWER 0x57 W
KEY_KEY_LOCK 0x4B K
3. Configuration
3.1 Install HDD
3.1.1 Installing Hard Drive into Cartridge
3.1.1.1. Please find the Key in the Cartridge.
3.1.1.2. Push the front cover of the HDD cartridge and use the iniature key
provided and insert into the key hole, turning the key counter-clockwise.
3.1.1.3. Pull the handle outwards to re ove the carrier body away fro the cartridge
fra e.
3.1.1.4. Push the open button to slide the top cover backwards and re ove.
3.1.1.5. Insert the DC power cable and IDE cable on the HDD.
3.1.1.6. Position the HDD into carrier body and secure the HDD with the four 6#-32
screws provided.
3.1.1.7. Slide the top cover back to the carrier body by sliding it forward to secure.
3.1.1.8. Slide the carrier body back into the cartridge fra e.
3.1.2 Function Settings and Operation
3.1.2.1 Power Indicator and HDD Access indicator
When power is on, the indicator will display the following essage
：

7
3.1.3 Key lock
Status
Seg ent
Power
status
Security status
A ON Locked (Irre ovable)
B OFF Unlocked (Re ovable)
You must turn key lock to “ A ” position before powering on the unit. Otherwise H
will not operate properly.
3.1.4 The Record Ti e is different based on Record Speed and Record Quality.
Please refer to following table.
NTSC SYSTEM
IPS 25A 15 8 4 2 1
Best
24hr 48hr 90hr 180hr 360hr 720hr
High
30hr 60hr 112.5hr 225hr 450hr 900hr
Nor al
48hr 96hr 180hr 360hr 720hr 1440hr
Record
Quality
Basic
80hr 160hr 300hr 600hr 1200hr 2400hr
HDD Type 120GB
PAL SYSTEM
IPS 18A 12 6 3 2 1
Best
24hr 50hr 101hr 203hr 304hr 608hr
High
30hr 63hr 127hr 253hr 380hr 760hr
Nor al
49hr 101hr 203hr 405hr 608hr 1220hr
Record
Quality
Basic
81hr 168hr 338hr 675hr 1013hr 2025hr
HDD Type 120GB
Note: Above data is from actual test data obtained from recording normal TV program.
(Reference only)
3.2 Front panel keypad
Ite Indicator
Power Indicator Green LED
HDD Access Indicator Yellow LED
A
B

8
MENU ENTER SELECT ZOOM
1 2 3 4 5 6
Right
Left
REC
Down
POWER
87 9
SLOW
Up
Digital Multiplex Recorder
AVC 776
1 3 6
47 8 9
25
10 11 12
1417
18 16 1315
Please follow the instructions below to operate this unit.
1. Install H
This device equips with a re ovable hard disk drive tray. Before turning on this device, you
ust install hard disk drive (not including in standard package), and ake it ready to operate.
(If two HDDs are set up, one should be selected as “ Master” and the other should be selected
as “ Slave”. Otherwise, please set two HDDs to Cable Select.)
2. LE Light : Under following condition, the LED Light is ON.
(1) HDD
: HDD is activated
(2) HDD Full
： HDD is full
(3) ALARM
： When Alar Enable : Yes (when alar is triggered, the led is flashing)
(4) TIMER
： When Ti er Enable : Yes
(5) PLAY
： Play operation
(6) REC
： Recording operation
3. MENU : Press MENU to enter ain enu operation ode, and press ad inistrator password
(default:0000) to access ain enu.
4. ENTER : Press ENTER for confir ation.
5. SELECT
: Press the Select to select appointed ca era (1~16) to display on full screen ode.
6. ZOOM
: Press ZOOM button to enlarge the ain onitor picture display.
7.
: Picture in Picture. Press PIP button to enter PIP display screen.
8.
: 4, 7 channels display ode
9. : 9 channels display ode
10. REC : Press REC to start recording.
11. STOP / own
:
STOP : Under DMR Record/Play ode, it can play video stop recording.
own : Under setup ode , it can work as own button.

9
12. POWER : To power on, press power button.
To power off, press power button again.
13. FF / Right :
FF : Under DMR play ode, it can play video forward at high speed, and press FF again to
adjust speed fro
1, 2, 4, 8, 16, 32 ti es.
Right : Under setup ode , it can work as Right button.
14. PAUSE / Up
:
Pause : Punder DMR play ode, it can play video pause.
Up : Under setup ode , it can work as Up button.
15. PLAY
: Press PLAY to play recorded video.
16. REW / Left
:
REW : Under DMR play ode, it can play video backward at high speed, and press REW
again to adjust speed fro 1, 2, 4, 8, 16, 32 ti es
Left : Under setup ode , it can work as Left button.
17. SLOW : To press SLOW to slow down speed of play ode.
18. CAMERA (1-16)
: Press the Camera Select (1-16) to select appointed ca era
PS 1 . After 60 seconds suspended operation, the function setup will be turned up auto atically.
2. When setting the sa e channel, the duplicate pictures will be frozen.
3.3 Back panel connection
WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO Q UALIFIED
S ERVICE PE RSONNEL.
CALL
EXTERNAL I/O
POWER
75Ω
HI INPUT
2
1
4 L
3 R
MAIN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
LOOP
IN OUT
2
13 4 5
7 689
1. Power input
Please use the provided adaptor.
2. External I/O
Controlled re otely by an external device or control syste .
Alar input, external I/I explanation.
3. 75 / HI
When usingLoop function, please switch to HI or set up to 75 .
4. VI EO INPUT (1-16)
Connect to video source, such as ca era.
5. CALL

10
Connect to CALL onitor. Show the Switch Display.
6. AU IO OUT (R/L)
Connect to onitor or speaker.
* IPS should be set to 25A (for NTSC) or 18A (for PAL)
7. AU IO IN (1-4)
Connect to audio source, such as icrophone.
* IPS should be set to 25A (for NTSC) or 18A (for PAL)
8. MAIN
Connect to Main onitor
9. Loop
Connect video signal between Input port and Loop port to ake a loop.
3.4 External I/O
25 pin com port
9 pin com port
PIN 1. GN
GROUND
PIN 2. ALARM INPUT 8
To connect wire fro ALARM INPUT 8 ( PIN 2 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,

11
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 3. ALARM INPUT 6
To connect wire fro ALARM INPUT 6 ( PIN 3 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 4. ALARM INPUT 4
To connect wire fro ALARM INPUT 4 ( PIN 4 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 5. ALARM INPUT 2
To connect wire fro ALARM INPUT 2 ( PIN 5 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 6. PIN OFF
PIN 7. PIN OFF
PIN 8. PIN OFF
PIN 9. PIN OFF
PIN 10. PIN OFF
PIN 11. RS232-TX
DMR can be controlled re otely by an external device or control syste , such as a
control keyboard, using RS-232 serial co unications signals.
PIN 12. RS485-A
DMR can be controlled re otely by an external device or control syste , such as a
control keyboard, using RS485 serial co unications signals.

12
PIN 13. EXTERNAL ALARM NO
Under nor al operation COM disconnect with NO. But when Alar triggered, COM
connect with NO.
PIN 14. PIN OFF
PIN 15. ALARM INPUT 7
To connect wire fro ALARM INPUT 7 ( PIN 15 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 16. ALARM INPUT 5
To connect wire fro ALARM INPUT 5 ( PIN 16 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 17. ALARM INPUT 3
To connect wire fro ALARM INPUT 3 ( PIN 17 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 18. ALARM INPUT 1
To connect wire fro ALARM INPUT 1 ( PIN 18 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 19. PIN OFF
PIN 20. PIN OFF

13
PIN 21. PIN OFF
PIN 22. ALARM INPUT 9
To connect wire fro ALARM INPUT 9 ( PIN 22 ) to GN ( PIN 1 ) connector, DMR
will start recording and buzzer will be on.
When Menu/ Ca era/ Alar is set up to “Low” : When alar input signal is “ Low ”,
the unit starts to record and buzzer.
When Menu/ Ca era/ Alar is set up to “High” : When alar input signal is “ High ”,
the unit starts to record and buzzer.
PIN 23. RS232-RX
DMR can be controlled re otely by an external device or control syste , such as a
control keyboard, using RS-232 serial co unications signals.
PIN 24. RS485-B
DMR can be controlled re otely by an external device or control syste , such as a
control keyboard, using RS485 serial co unications signals.
PIN 25. EXTERNAL ALARM COM
Under nor al operation COM disconnect with NO. But when alar triggered, COM
connect with NO.
3.4 Menu setup
Press ”MENU” to enter ain enu. You will
need to enter password to access ain enu.
To press “
Right ” “ Left ” to ove digit, and
Press ”
Up ” “ own ” to select nu ber.
Press
”ENTER” button to confir password.
Ex.: Password : 0000 (Default : 0000)
PASSWORD : 0000
After keying in correct password, confir by
pressing
”ENTER” button, screen will show
following options.
SEARCH ------- Find recorded list
TIMER -------- Scheduling Record
RECORD------- Record Mode Setup
CAMERA ------- Ca era Channel Setup
SYSTEM ------- Syste Setup
EVENT -------- Event List
(MENU)
► SEARCH
TIMER
RECORD
CAMERA
SYSTEM
EVENT
*For the unit can be operated properly, we start to introduce from System setup
3.5 System setup

14
Press ”MENU” to enter ain enu. You will
need to enter password to access ain enu.
Press “
Right ” “ Left ” to ove digit, and
Press ”
Up ” “ own ” to select nu ber.
Press
”ENTER” button to confir password.
Ex.: PASSWORD : 0000 (Default : 0000)
PASSWORD : 0000
After keying in correct password, and confir
by pressing
”ENTER” button
, screen will show
following options.
SEARCH ------- Find recorded list
TIMER -------- Scheduling Record
RECORD------- Record Mode Setup
CAMERA ------- Ca era Channel Setup
SYSTEM ------- Syste Setup
EVENT -------- Event List
(MENU)
► SEARCH
TIMER
RECORD
CAMERA
SYSTEM
EVENT
Press ” Up ” “ own ” to choose SYSTEM setup
SEARCH
TIMER
RECORD
CAMERA
►SYSTEM
EVENT
(Menu)
SEARCH
TIMER
RECORD
CAMERA
►SYSTEM
EVENT
Press ” ENTER ” to confir SYSTEM setup, and the screen will show following options.
(SYSTEM)
►
AUDIO INPUT : 1
INT AUDIBLE ALARM : ON
EXT AUDIBLE ALARM : ON
MOTION AUDIBLE ALARM: ON
ALARM DURATION : 10 SEC
DWELL TIME : 02 SEC
MESSAGE LATCH : NO
TITLE DISPLAY :ON

15
TIME DISPLAY : Y/M/D
2003-JAN-02(THU) 1 :3 :09
NEW PASSWORD : XXXX
CLEARD HDD : NO
SYSTEM RESET : NO
REMOTE MODE : RS-232
BAUD RATE : 9600
REMOTE ID : 000
3.5.1 AUDIO INPUT setup:
This device allows user to set the AUDIO INPUT. User can choose one
of 4 channels to record.
3.5.1.1 Press ”
Up ” “ own ” to choose AUDIO INPUT :
3.5.1.2 Press ”
ENTER ” button to confir AUDIO INPUT
3.5.1.3 Press ”
Up ” “ own ” to choose the AUDIO INPUT : 1~4
3.5.1.4 Press ”
MENU ” to exit and confir current operation.
3.5.1.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.2 INT AUDIBLE ALARM setup:
This device allows user to set the INTERNAL AUDIBLE ALARM. Alar will be trigged by
event occurrence when the setting is ON.
3.5.2.1 Press ” Up ” or “ own ” to choose INT AUDIBLE ALARM
3.5.2.2 Press ”
ENTER ” button to confir INT AUDIBLE ALARM
3.5.2.3 Press ”
Up ” or “ own ” to choose the INT AUDIBLE ALARM : ON/OFF
ON: Internal Buzzer ON
OFF: Internal Buzzer OFF
3.5.2.4 Press ”
MENU ” to exit and confir current operation.
3.5.2.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.3 EXT AUDIBLE ALARM setup:
This device allows user to set the EXTERNAL AUDIBLE ALARM. Alar will be trigged
by event occurrence when the setting is ON.
3.5.3.1 Press ” Up ” or “ own ” to choose EXT AUDIBLE ALARM
3.5.3.2 Press ”
ENTER ” button to confir EXT AUDIBLE ALARM
3.5.3.3 Press ”
Up ” or “ own ” to choose the EXT AUDIBLE ALARM: ON/OFF
ON: External Buzzer ON
OFF: External Buzzer OFF

16
3.5.3.4 Press ” MENU ” to exit and confir current operation.
3.5.3.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.4 MOTION AUDIBLE ALARM
To set the MOTION AUDIBLE ALARM. It will be trigged by otion detection occurrence
when the setting is ON.
3.5.5 ALARM DURATION Setup option:
This device allows user to set the ALARM DURATION. Reaction ti e was deter ined
by how long the alar ode responded to a buzzer.
3.5.5.1 Press ”
Up ” or “ own ” to choose ALARM DURATION setup.
3.5.5.2 Press ”
ENTER ” to confir ALARM DURATION setup.
3.5.5.3 Press ”
Up ” or “ own ” to choose ALARM DURATION setup
10 SEC, 15 SEC, 20 SEC, 30 SEC, 1MIN, 2MIN, 3 MIN, 5 MIN, 10 MIN, 15 MIN,
30 MIN, ALWAYS.
3.5.5.4 Press ”
MENU ” to exit and confir current operation.
3.5.5.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.6 DWELL TIME setup
This device allows user to set the DWELL TIME. DWELL TIME is the lasting ti e that
each channel sequentially shown on onitor.
3.5.6.1 Press ”
Up ” or “ own ” to choose DWELL TIME setup.
3.5.6.2 Press ”
ENTER ” to confir DWELL TIME setup.
3.5.6.3 Press ”
Up ” or “ own ” to choose DWELL TIME setup.
01~10 SEC.
3.5.6.4 Press ”
MENU ” to exit and confir current operation.
3.5.6.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.7 MESSAGE LATCH setup
This device allows user to decide the Ex External Alar graph video loss graph
showed on onitor or not.
3.5.7.1 Press ” Up ” or “ own ” to choose MESSAGE LATCH setup
3.5.7.2 Press ”
ENTER ” button to confir MESSAGE LATCH setup
3.6.7.3 Press ”
Up ” or “ own ” to choose the MESSAGE LATCH : ON/OFF
ON : Message latch ON
OFF : Message latch OFF
3.6.7.4 Press ”
MENU ” to exit and confir current operation.
3.6.7.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.8 TITLE DISPLAY setup

17
This device allows user to set the title shown on onitor or not.
3.5.8.1 Press ”
Up ” or “ own ” to choose TITLE DISPLAY setup
3.5.8.2 Press ”
ENTER ” button to confir TITLE DISPLAY setup
3.5.8.3 Press ”
Up ” or “ own ” to choose TITLE DISPLAY : ON/OFF
ON : Title Display ON
OFF : Title Display OFF
3.5.8.4 Press ”
MENU ” to exit and confir current operation.
3.5.8.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.9 TIME DISPLAY for at setup
This device allows user to set the ti e for at on onitor.
3.5.9.1 Press ”
Up ” or “ own ” to choose TIME DISPLAY setup.
3.5.9.2 Press ”
ENTER ” to confir TIME DISPLAY setup.
3.5.9.3 Press”
Up ” or “ own ” to choose TIME DISPLAY setup.
OFF, Y/M/D, M/D/Y, D/M/Y.
3.5.9.4 Press ”
MENU ” to exit and confir current operation.
3.5.9.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.10 TIME setup:
This device allows user to set ti e on onitor.
3.5.10.1 Press ”
Up ” or “ own ” to choose date display
3.5.10.2 Press ”
ENTER ” to confir date display for at.
3.5.10.3 Press ”
Up ” or “ own ” to choose the correct Date & Ti e, and press press
“
Right ” or “ Left ” to ove digit location.
3.5.10.4 Press ”
MENU ” to exit and confir current operation.
3.5.10.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.11 NEW PASSWORD : XXXX setup: (Default password : 0000)
This device allows user to set the new password.
3.5.11.1 Press ” Up ” or “ own ” to choose NEW PASSWORD : XXXX setup.
3.5.11.2 Press ”
ENTER ” to confir NEW PASSWORD : XXXX setup.
3.5.11.3 Press ”
Up ” or “ own ” to choose nu ber, and press“ Right ” or “ Left ” to
ove digit location.
3.5.11.4 Press ”
MENU ” to exit and confir current operation.
3.5.11.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.12 CLEAR HDD setup
This device allows user to have the HDD cleared.

18
3.5.12.1 Press ” Up ” or “ own ” to choose CLEAR HDD setup.
3.5.12.2 Press ”
ENTER ” to confir CLEAR HDD setup.
3.5.12.3 Press ”
Up ” or “ own ” to choose CLEAR HDD setup YES or NO.
YES: Confir to clear HDD, and screen will show followings.
ALL DATA IN HDD
WILL BE CLEARED
ARE YOU SURE?
(◄ : NO ► : YES )
Press“ ►” to clear HDD
NO: Confir not to clear HDD.
3.5.12.4 Press ”
MENU ” to exit and confir current operation.
3.5.12.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.13 SYSTEM RESET setup
This device allows user to reset the syste .
3.5.13.1 Press ”
Up ” or “ own ” to choose SYSTEM RESET setup.
3.5.13.2 Press ”
ENTER ” to confir SYSTEM RESET setup.
3.5.13.3 Press ” ”
Up ” or “ own ” to choose SYSTEM RESET Yes or No
YES: To confir Syste Reset (load default syste reset)
NO: Confir not to Syste Reset
3.5.13.4 Press ”
MENU ” to exit and confir current operation.
3.5.13.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.14 REMOTE MODE setup
This device allows user to set the re ote ode.
3.5.14.1 Press ”
Up ” or “ own ” to choose REMOTE MODE setup
3.5.14.2 Press ”
ENTER ” to confir REMOTE MODE setup
3.5.14.3 Press ”
Up ” or “ own ” to choose Interface for REMOTE MODE setup
RS-232: Use RS-232 interface
RS-485: Use RS-485 interface
3.5.14.4 Press ”
MENU ” to exit and confir current operation.
3.5.14.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.15 Re ote protocol Trans itting Baud Rate setup
This device allows user to set the re ote protocol trans itting baud rate.
3.5.15.1 Press ”
Up ” or “ own ” to choose Baud Rate setup.
3.5.15.2 Press ” ENTER ” to confir

19
3.5.15.3 Press ” Up ” or “ own ” to choose BAUD RATE setup
115200
、 57600 、 19200 、 9600 、 4800 、 3600 、 2400 、 1200
3.5.15.4 Press ”
MENU ” to exit and confir current operation.
3.5.15.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.5.16 Re ote protocol ID setup:
This device allows user to control different DMR by setting RS232 re ote protocol.
ID nu ber can be set fro 000 to be 999.
3.5.16.1 Press ”
Up ” or “ own ” to choose ID setup.
3.5.16.2 Press ”
ENTER ” to confir ID setup
3.5.16.3 Press ”
Up ” or “ own ” to set nu erical nu ber, fro 000 ~ 255
3.5.16.4 Press ”
MENU ” to exit and confir current operation.
3.5.16.5 Press ”
MENU ” again to exit and close SYSTEM setup ode.
3.6 SEAR H setup
Press ”MENU” to enter ain enu. You will
need to enter password to access ain enu.
Press “
Right ” or “ Left ” to ove digit, and to
press
Up ” or “ own ” to select nu ber.
Press
”ENTER” button to confir password.
Ex.: Password: 0000 (Default: 0000)
PASSWORD: 0000
After keying in correct password, and confir by
pressing
”ENTER” button, screen will show
following options.
SEARCH ------- Find recorded list
TIMER -------- Scheduling Record
RECORD------- Record Mode Setup
CAMERA ------- Ca era Channel Setup
SYSTEM ------- Syste Setup
EVENT -------- Event List
(MENU)
► SEARCH
TIMER
RECORD
CAMERA
SYSTEM
EVENT
3.6.1 LAST RECORD for recorded video

20
Press ” Up ” or “ own ” to choose LAST
RECORD ite . Following screen will be
displayed. Press “
ENTER ” to confir LAST
RECORD.
► LAST RECORD
FULL LIST
ALARM LIST
MOTION LIST
TIME SEARCH
3.6.2 FULL LIST for recorded video
Press ”
Up ” or “ own ” to choose Full List
ite . Following screen will be displayed.
LAST RECORD
► FULL LIST
ALARM LIST
MOTION LIST
TIME SEARCH
Press “ ENTER ” to confir Full List, and the
following screen will be displayed.
Press ”
Up ” or “ own ” to choose wanted
recorded eve
nt (There will be shown only 8 list in
one page.), and press “ Right ” or “ Left ” to
change the pages.
Press “
ENTER ” to Play selected recorded video
► M 2002-JAN-01 01:02:03 M-HDD
M 2002-JAN-01 01:02:03 M-HDD
A 2002-JAN-01 01:02:03 M-HDD
T 2002-JAN-01 01:02:03 M-HDD
T 2002-JAN-01 01:02:03 S-HDD
M 2002-JAN-01 01:02:03 S-HDD
◄: PAGE UP►: PAGE DOWN
M : Manual Record ti e / A : Alar Record ti e
T : Ti er Record ti e
M
- HDD : Storage in Master HDD
S
- HDD : Storage in Slave HDD
3.6.3 ALARM LIST for recorded video
