AVTECH ELECTROSYSTEMS LTD. AVIR-3-B User manual

INSTRUCTIONS
MODEL AVIR-3-B
200 VOLT
HIGH PERFORMANCE PULSE GENERATOR
WITH IEEE 488.2 AND RS-232 CONTROL
SERIAL NUMBER: 13901
A V T E C H E L E C T R O S Y S T E M S L T D .
N A N O S E C O N D W A V E F O R M E L E C T R O N I C S
S I N C E 1 9 5
[e-mail]
http://www.avtechpulse.com/
Tel: [phone] (USA & Canada) or [phone] (Intl)
Fax: [phone] (USA & Canada) or [phone] (Intl)
BOX 5120, LCD MERIVALE
OTTAWA, CANADA K2C3H5

WARRANTY
Avtech Electrosystems Ltd. warrants products of its manufacture to be free
from defects in material and workmanship under conditions of normal use. If,
within one year after delivery to the original owner, and after prepaid return by
the original owner, this Avtech product is found to be defective, Avtech shall at
its option repair or replace said defective item. This warranty does not apply to
units which have been dissembled, modified or subjected to conditions
exceeding the applicable specifications or ratings. This warranty is the extent of
the obligation assumed by Avtech with respect to this product and no other
warranty or guarantee is either expressed or implied.
TECHNICAL SUPPORT
Phone: [phone] (USA & Canada) or [phone] (International)
Fax: [phone] (USA & Canada) or [phone] (International)
E-mail: [e-mail]
World Wide Web: http://www.avtechpulse.com
2

TABLE OF CONTENTS
WARRANTY......................................................................................................................2
TECHNICAL SUPPORT...................................................................................................2
TABLE OF CONTENTS....................................................................................................3
INTRODUCTION...............................................................................................................5
AVAILABLE OPTIONS.....................................................................................................6
SPECIFICATIONS.............................................................................................................7
REGULATORY NOTES....................................................................................................8
FCC PART 18.......................................................................................................................... 8
EC DECLARATION OF CONFORMITY..................................................................................8
DIRECTIVE 2011/65/EU (RoHS)............................................................................................9
DIRECTIVE 2002/96/EC ( EEE)............................................................................................9
FIRM ARE LICENSING.......................................................................................................10
INSTALLATION..............................................................................................................11
VISUAL CHECK....................................................................................................................11
PO ER RATINGS................................................................................................................11
CONNECTION TO THE PO ER SUPPLY...........................................................................11
PROTECTION FROM ELECTRIC SHOCK...........................................................................12
ENVIRONMENTAL CONDITIONS........................................................................................13
LABVIE DRIVERS.............................................................................................................13
FUSES.............................................................................................................................14
AC FUSE REPLACEMENT...................................................................................................14
DC FUSE REPLACEMENT...................................................................................................15
FUSE RATINGS.................................................................................................................... 15
FRONT PANEL CONTROLS..........................................................................................16
REAR PANEL CONTROLS............................................................................................18
GENERAL INFORMATION............................................................................................2
BASIC PULSE CONTROL....................................................................................................20
TRIGGER MODES................................................................................................................21
GATING MODES...................................................................................................................22
OPTIONAL FEATURES..................................................................................................23
RACK MOUNTING, -R5 OPTION..........................................................................................23
DC OFFSET, -OS OPTION...................................................................................................23
3

MONITOR OUTPUT, -M OPTION.........................................................................................23
ELECTRONIC AMPLITUDE CONTROL, -EA OPTION........................................................23
PROTECTING YOUR INSTRUMENT.............................................................................24
TURN OFF INSTRUMENT HEN NOT IN USE...................................................................24
DO NOT EXCEED 20 kHz.....................................................................................................24
USE A 50Ω LOAD.................................................................................................................24
OPERATIONAL CHECK.................................................................................................25
PROGRAMMING YOUR PULSE GENERATOR............................................................29
KEY PROGRAMMING COMMANDS....................................................................................29
ALL PROGRAMMING COMMANDS.....................................................................................30
MECHANICAL INFORMATION......................................................................................32
TOP COVER REMOVAL.......................................................................................................32
RACK MOUNTING................................................................................................................32
ELECTROMAGNETIC INTERFERENCE..............................................................................32
MAINTENANCE..............................................................................................................33
REGULAR MAINTENANCE..................................................................................................33
CLEANING............................................................................................................................ 33
TRIGGER DAMAGE..............................................................................................................33
WIRING DIAGRAMS.......................................................................................................34
IRING OF AC PO ER.......................................................................................................34
IRING OF DC PO ER.......................................................................................................35
PCB 158R4 - LO VOLTAGE PO ER SUPPLY................................................................36
PCB 235B - HIGH VOLTAGE DC PO ER SUPPLY...........................................................37
PCB 104F - KEYPAD / DISPLAY BOARD, 1/3....................................................................38
PCB 104F - KEYPAD / DISPLAY BOARD, 2/3....................................................................39
PCB 104F - KEYPAD / DISPLAY BOARD, 3/3....................................................................40
MAIN IRING....................................................................................................................... 41
PERFORMANCE CHECKSHEET...................................................................................42
Manual Reference: /fileserver2/officefiles/instructword/avir/AVIR-3-B,ed4.odt.
Last modified July 18, 2019.
Copyright © 2019 Avtech Electrosystems Ltd, All Rights Reserved.
4

INTRODUCTION
The AVIR-3-B is a high performance, GPIB and RS232-equipped instrument capable of
generating 200V into 50Ω loads at repetition rates up to 20 kHz. The output pulse width
is variable from 10 to 200 ns. The rise time is 2 ns or less (20%-80%), and the fall time
is 2.5 ns or less (80%-20%).
Instruments with the "-P" model suffix can generate up to +200V, whereas instruments
with the "-N" model suffix can generate up to -200V. Instruments with the "-PN" suffix
can generate both polarities.
A 50 Ohm load is required for proper operation. The output stage may be damaged if
the output is not terminated into a 50Ω load.
The AVIR-3-B is a highly flexible instrument. Aside from the internal trigger source, it
can also be triggered or gated by external TTL-level signals. A front-panel pushbutton
or a computer command can also be used to trigger the instrument.
The AVIR-3-B features front panel keyboard and adjust knob control of the output pulse
parameters along with a four line by 40-character backlit LCD display of the output
amplitude, pulse width, pulse repetition frequency, and delay. The instrument includes
memory to store up to four complete instrument setups. The operator may use the front
panel or the computer interface to store a complete “snapshot” of all key instrument
settings, and recall this setup at a later time.
This instrument is intended for use in research, development, test and calibration
laboratories by qualified personnel.
5

AVAILABLE OPTIONS
The AVIR-3-B is available with several options:
-EA Option: the amplitude can be controlled by an externally generated 0 to +10V
analog control voltage.
-M Option: a monitor output is provided.
-OS Option: an externally generated DC offset can be added to the output.
-R5 Option: A rack mounting kit is available. The "-R5" rack mount kit may be installed
after first removing the one Phillips screw on the side panel adjacent to the front
handle.
6

SPECIFICATIONS
Model1: AVIR-3-B
Amplitude2,3, : < 20 to 200 Volts
Required load impedance: 50Ω8
Pulse width (FWHM): 10 - 200 ns
Rise time (20%-80%): ≤ 2 ns
Fall time (80%-20%): ≤ 2.5 ns
PRF: 0 to 20 kHz
Polarity4: Positive or negative or both (specify)
GPIB & RS-232 control1: Standard on -B units
LabView Drivers: check http://www.avtechpulse.com/labview for availability and downloads
Ethernet port, for remote
control using VXI-11.3,
ssh, telnet, & web:
Optional5. Recommended as a modern alternative to GPIB / RS-232.
See http://www.avtechpulse.com/options/vxi for details.
Settings resolution: The resolution of the timing parameters (pulse width, delay, period) varies,
but is always better than 0.15% of (|set value| + 20 ns).
The amplitude resolution is < 0.1% of the maximum amplitude.
Settings accuracy: Typically ± 5% (plus ±2 V or ± 2 ns) after 10 minute warmup.
For pulse widths below ~10 ns, the amplitude accuracy degrades to ± 10% ± 10 V.
For high-accuracy applications requiring traceable calibration,
verify the output parameters with a calibrated oscilloscope.
DC offset or
bias insertion:
Optional6. Apply required DC offset or bias in the range of
± 50 Volts (250 mA max) to back panel solder terminal.
Propagation delay: ≤ 100 ns (Ext trig in to pulse out)
Jitter: ± 35ps ± 0.015% of sync delay (Ext trig in to pulse out)
Trigger modes: Internal trigger, external trigger (TTL level pulse, > 10 ns, 1 kΩ input impedance),
front-panel “Single Pulse” pushbutton, or single pulse trigger via computer command.
Variable delay: Sync to Out: 0 to 1.0 seconds, for all trigger modes (including external trigger).
Sync output +3 Volts, 100 ns, will drive 50 Ohm loads
Connectors: Out: SMA, Trig, Sync, Gate: BNC
Power requirement: 100 - 240 Volts, 50 - 60 Hz
Dimensions: H x W x D: 100 × 430 × 3 5 mm (3.9 × 1 × 14.8”)
Rack-mount kit: Optional. To specify, add the -R5 suffix to the model number.
Temperature range: +5°C to +40°C
1) -B suffix indicates IEEE-488.2 GPIB and RS-232 control of amplitude, pulse width, PRF and delay (see http://www.avtechpulse.com/gpib for details).
2) For analog electronic control (0 to +10V) of amplitude, suffix the model number with -EA. Includes standard front-panel controls. Not available on
AVIR-4 models.
3) For operation at amplitudes of less than 10% of full-scale, best results will be obtained by setting the amplitude near full-scale and using external
attenuators on the output.
4) Indicate desired polarity by suffixing model number with -P or -N (i.e. positive or negative) or -PN for dual polarity option. Polarity reversal is achieved
by means of a two-position switch.
5) Add the suffix -VXI to the model number to specify the Ethernet port.
6) For externally-applied DC offset option suffix model number with -OS. For internally-generated DC offset option (0 to ±5V) add suffix -OT.
) The maximum amplitude decreases by 15% for repetition rates above 30 kHz. The maximum amplitude also decreases by an additional 15% for
pulse widths below 3 ns.
8) A 50 Ohm load is required. Other loads may damage the instrument. Consult Avtech ([e-mail]) if you need to drive other load
impedances.

REGULATORY NOTES
FCC PART 18
This device complies with part 18 of the FCC rules for non-consumer industrial,
scientific and medical (ISM) equipment.
This instrument is enclosed in a rugged metal chassis and uses a filtered power entry
module (where applicable). The main output signal is provided on a shielded connector
that is intended to be used with shielded coaxial cabling and a shielded load. Under
these conditions, the interference potential of this instrument is low.
If interference is observed, check that appropriate well-shielded cabling is used on the
output connectors. Contact Avtech ([e-mail]) for advice if you are unsure
of the most appropriate cabling. Also, check that your load is adequately shielded. It
may be necessary to enclose the load in a metal enclosure.
If any of the connectors on the instrument are unused, they should be covered with
shielded metal “dust caps” to reduce the interference potential.
This instrument does not normally require regular maintenance to minimize interference
potential. However, if loose hardware or connectors are noted, they should be
tightened. Contact Avtech ([e-mail]) if you require assistance.
EC DECLARATION OF CONFORMITY
We Avtech Electrosystems Ltd.
P.O. Box 5120, LCD Merivale
Ottawa, Ontario
Canada K2C 3H5
declare that this pulse generator meets the intent of Directive 2004/108/EG for
Electromagnetic Compatibility. Compliance pertains to the following specifications as
listed in the official Journal of the European Communities:
EN 50081-1 Emission
EN 50082-1 Immunity
8

and that this pulse generator meets the intent of the Low Voltage Directive 2006/95/EC.
Compliance pertains to the following specifications as listed in the official Journal of the
European Communities:
EN 61010-1:2001 Safety requirements for electrical equipment for
measurement, control, and laboratory use
DIRECTIVE 2011/65/EU (RoHS)
We Avtech Electrosystems Ltd.
P.O. Box 5120, LCD Merivale
Ottawa, Ontario
Canada K2C 3H5
declare that, to the best of our knowledge, all electrical and electronic equipment (EEE)
sold by the company are in compliance with Directive 2011/65/EU of the European
Parliament and of the Council of 8 June 2011 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment (also known as “RoHS
Recast”). In addition, this declaration of conformity is issued under the sole
responsibility of Avtech Electrosystems Ltd. Specifically, products manufactured do not
contain the substances listed in the table below in concentrations greater than the listed
maximum value.
Material/Substance Threshold level
Lead (Pb) < 1000 ppm (0.1% by mass)
Mercury (Hg) < 1000 ppm (0.1% by mass)
Hexavalent Chromium (Cr6+) < 1000 ppm (0.1% by mass)
Polybrominated Biphenyls (PBB) < 1000 ppm (0.1% by mass)
Polybrominated Diphenyl ethers (PBDE) < 1000 ppm (0.1% by mass)
Cadmium (Cd) < 100 ppm (0.01% by mass)
Bis(2-ethylhexyl) phthalate (DEHP) < 1000 ppm (0.1% by mass)
Butyl benzyl phthalate (BBP) < 1000 ppm (0.1% by mass)
Dibutyl phthalate (DBP) < 1000 ppm (0.1% by mass)
Diisobutyl phthalate (DIBP) < 1000 ppm (0.1% by mass)
DIRECTIVE 2002/96/EC (WEEE)
European customers who have purchased this equipment directly from Avtech will have
completed a “WEEE Responsibility Agreement” form, accepting responsibility for WEEE
compliance (as mandated in Directive 2002/96/EC of the European Union and local
9

laws) on behalf of the customer, as provided for under Article 9 of Directive
2002/96/EC.
Customers who have purchased Avtech equipment through local representatives
should consult with the representative to determine who has responsibility for WEEE
compliance. Normally, such responsibilities with lie with the representative, unless other
arrangements (under Article 9) have been made.
Requirements for WEEE compliance may include registration of products with local
governments, reporting of recycling activities to local governments, and financing of
recycling activities.
FIRMWARE LICENSING
Instruments with firmware versions 5.00 or higher use open-source software internally.
Some of this software requires that the source code be made available to the user as a
condition of its licensing. This source code is available upon request (contact
[email protected]m).
Earlier firmware versions do not contain any open source software.
10

INSTALLATION
VISUAL CHECK
After unpacking the instrument, examine to ensure that it has not been damaged in
shipment. Visually inspect all connectors, knobs, liquid crystal displays (LCDs), and the
handles. Confirm that a power cord, a GPIB cable, and two instrumentation manuals
(this manual and the “Programming Manual for -B Instruments”) are with the
instrument. If the instrument has been damaged, file a claim immediately with the
company that transported the instrument.
POWER RATINGS
This instrument is intended to operate from 100 - 240 V, 50 - 60 Hz.
The maximum power consumption is 5 Watts. Please see the “FUSES” section for
information about the appropriate AC and DC fuses.
This instrument is an “Installation Category II” instrument, intended for operation from a
normal single-phase supply.
CONNECTION TO THE POWER SUPPLY
An IEC-320 three-pronged recessed male socket is provided on the back panel for AC
power connection to the instrument. One end of the detachable power cord that is
supplied with the instrument plugs into this socket. The other end of the detachable
power cord plugs into the local mains supply. Use only the cable supplied with the
instrument. The mains supply must be earthed, and the cord used to connect the
instrument to the mains supply must provide an earth connection. (The supplied cord
does this.)
Warning: Failure to use a grounded outlet may result in injury or death due to
electric shock. This product uses a power cord with a ground connection. It must be
connected to a properly grounded outlet. The instrument chassis is connected to the
ground wire in the power cord.
The table below describes the power cord that is normally supplied with this instrument,
depending on the destination region:
11

Destination Region Description Option Manufacturer Part Number
United Kingdom, Hong Kong,
Singapore, Malaysia
BS 1363,
230V, 50 Hz -AC00 Qualtek 3 0001-E01
Australia, New Zealand AS 3112:2000,
230-240V, 50 Hz -AC01 Qualtek 3 4003-A01
Continental Europe, Korea,
Indonesia, Russia
European CEE /
“Schuko” 230V, 50 Hz -AC02 Qualtek 364002-D01
North America, Taiwan NEMA 5-15,
120V, 60 Hz -AC03 Qualtek 31200 -01
Switzerland SEV 1011,
230V, 50 Hz -AC06 Qualtek 3 8001-E01
South Africa, India SABS 164-1,
220-250V, 50 Hz -AC1 Volex 2131H 10 C3
Japan JIS 8303,
100V, 50-60 Hz -AC18 Qualtek 39 002-01
Israel SI 32,
220V, 50 Hz -AC19 Qualtek 398001-01
China GB 1002-1 / 2099-1,
220V, 50 Hz -AC22 Qualtek 399012-01
PROTECTION FROM ELECTRIC SHOCK
Operators of this instrument must be protected from electric shock at all times. The
owner must ensure that operators are prevented access and/or are insulated from
every connection point. In some cases, connections must be exposed to potential
human contact. Operators must be trained to protect themselves from the risk of
electric shock. This instrument is intended for use by qualified personnel who recognize
shock hazards and are familiar with safety precautions required to avoid possibly injury.
In particular, operators should:
1. Keep exposed high-voltage wiring to an absolute minimum.
2. Wherever possible, use shielded connectors and cabling.
3. Connect and disconnect loads and cables only when the instrument is turned off.
4. Keep in mind that all cables, connectors, oscilloscope probes, and loads must
have an appropriate voltage rating.
5. Do not attempt any repairs on the instrument, beyond the fuse replacement
procedures described in this manual. Contact Avtech technical support (see
page 2 for contact information) if the instrument requires servicing. Service is to
be performed solely by qualified service personnel.
12

ENVIRONMENTAL CONDITIONS
This instrument is intended for use under the following conditions:
1. indoor use;
2. altitude up to 2 000 m;
3. temperature 5 °C to 40 °C;
4. maximum relative humidity 80 % for temperatures up to 31 °C decreasing
linearly to 50 % relative humidity at 40 °C;
5. Mains supply voltage fluctuations up to ±10 % of the nominal voltage;
6. no pollution or only dry, non-conductive pollution.
LABVIEW DRIVERS
A LabVIEW driver for this instrument is available for download on the Avtech web site,
at http://www.avtechpulse.com/labview. A copy is also available in National Instruments'
Instrument Driver Library at http://www.natinst.com/.
13

FUSES
This instrument contains four fuses. All are accessible from the rear-panel. Two protect
the AC prime power input, and two protect the internal DC power supplies. The
locations of the fuses on the rear panel are shown in the figure below:
AC FUSE REPLACEMENT
To physically access the AC fuses, the power cord must be detached from the rear
panel of the instrument. The fuse drawer may then be extracted using a small flat-head
screwdriver, as shown below:
14
Fuses #1 and #2
(AC fuses)
Fuse #4
( C fuse)
Fuse #3
( C fuse)
Fuse
rawer
Pry out the fuse
drawer using a
screwdriver.

DC FUSE REPLACEMENT
The DC fuses may be replaced by inserting the tip of a flat-head screwdriver into the
fuse holder slot, and rotating the slot counter-clockwise. The fuse and its carrier will
then pop out.
FUSE RATINGS
The following table lists the required fuses:
Fuses
Nominal
Mains
Voltage
Rating Case Size
Recommended Replacement Part
Littelfuse Part
Number
Digi-Key Stock
Number
#1, #2 (AC) 100-240V 0.5A, 250V,
Time-Delay 5×20 mm 0218.500HXP F2416-ND
#3 (DC) N/A 1.0A, 250V,
Time-Delay 5×20 mm 0218001.HXP F2419-ND
#4 (DC) N/A 0.8A, 250V,
Time-Delay 5×20 mm 0218.800HXP F2418-ND
The recommended fuse manufacturer is Littelfuse (http://www.littelfuse.com).
Replacement fuses may be easily obtained from Digi-Key (http://www.digikey.com) and
other distributors.
15

FRONT PANEL CONTROLS
1. POWER Switch . This is the main power switch. When turning the instrument on,
there is normally a delay of 10 seconds before anything is shown on the main
display, as the internal operating system boots up.
If the main menu does not appear after 30 seconds, turn off the instrument and
leave it off for at least 60 seconds before applying power again.
2. OVERLOAD Indicator . When the instrument is powered, this indicator is normally
green, indicating normal operation. If this indicator is yellow, an internal automatic
overload protection circuit has been tripped. If the unit is overloaded (by operating at
an exceedingly high duty cycle or by operating into a very low impedance), the
protective circuit will disable the output of the instrument and turn the indicator light
yellow. The light will stay yellow (i.e. output disabled) for about 5 seconds after
which the instrument will attempt to re-enable the output (i.e. light green) for about 1
second. If the overload condition persists, the output will be disabled again (i.e. light
yellow) for another 5 seconds. If the overload condition has been removed, the
instrument will resume normal operation.
This overload indicator may flash yellow briefly at start-up. This is not a cause for
concern.
Note that the output stage will safely withstand a short-circuited load condition.
3. OUT CONNECTO R . This BNC connector provides the main output signal, into load
impedances of 50Ω .
Caution: Voltages as high as ±200V may be present on the center conductor of
this output connector. Avoid touching this conductor. Connect to this connector
using standard coaxial cable, to ensure that the center conductor is not exposed.
4. SYNC OUT . This connector supplies a SYNC output that can be used to trigger
other equipment, particularly oscilloscopes. This signal leads (or lags) the main
output by a duration set by the "DELAY" controls and has an approximate amplitude
16
2
3
4
56
1

of +3 Volts to RL > 50Ω with a pulse width of approximately 100 ns.
5. LIQUID CRYSTAL DISPLAY (LCD) . This LCD is used in conjunction with the
keypad to change the instrument settings. Normally, the main menu is displayed,
which lists the key adjustable parameters and their current values. The
“Programming Manual for -B Instruments” describes the menus and submenus in
detail.
6. KEYPAD .
Control Name Function
MOVE This moves the arrow pointer on the display.
CHANGE This is used to enter the submenu, or to select the operating
mode, pointed to by the arrow pointer.
×10 If one of the adjustable numeric parameters is displayed, this
increases the setting by a factor of ten.
÷10 If one of the adjustable numeric parameters is displayed, this
decreases the setting by a factor of ten.
+/- If one of the adjustable numeric parameters is displayed, and
this parameter can be both positive or negative, this changes
the sign of the parameter.
EXTRA FINE This changes the step size of the ADJUST knob. In the extra-
fine mode, the step size is twenty times finer than in the normal
mode. This button switches between the two step sizes.
ADJUST This large knob adjusts the value of any displayed numeric
adjustable values, such as frequency, pulse width, etc. The
adjust step size is set by the "EXTRA FINE" button.
When the main menu is displayed, this knob can be used to
move the arrow pointer.
1

REAR PANEL CONTROLS
Note: some connectors may be in different positions than shown above, depending on
the exact combination of options ordered.
1. AC POWER INPUT . An IEC-320 C14 three-pronged recessed male socket is
provided on the back panel for AC power connection to the instrument. One end of
the detachable power cord that is supplied with the instrument plugs into this socket.
2. AC FUSE DRAWER . The two fuses that protect the AC input are located in this
drawer. Please see the “FUSES” section of this manual for more information.
3. DC FUSES . These two fuses protect the internal DC power supplies. Please see the
“FUSES” sections of this manual for more information.
4. GATE . This TTL-level (0 and +5V) logic input can be used to gate the triggering of
the instrument. This input can be either active high or active low, depending on the
front panel settings or programming commands. (The instrument triggers normally
when this input is unconnected). When set to active high mode, this input is pulled-
down to ground by a 1 kΩ resistor. When set to active low mode, this input is pulled-
up to +5V by a 1 kΩ resistor.
5. TRIG . This TTL-level (0 and +5V) logic input can be used to trigger the instrument, if
the instrument is set to triggering externally. The instrument triggers on the rising
edge of this input. The input impedance of this input is 1 kΩ. (Depending on the
length of cable attached to this input, and the source driving it, it may be desirable to
add a coaxial 50 Ohm terminator to this input to provide a proper transmission line
termination. The Pasternack (www.pasternack.com) PE6008-50 BNC feed-thru 50
Ohm terminator is suggested for this purpose.)
3
5 10
GATE
RS-232
GPIB
TRIG
MON
OS GND
8
18
1
4
92 6

6. GPIB Connector . A standard GPIB cable can be attached to this connector to allow
the instrument to be computer-controlled. See the “Programming Manual for -B
Instruments” for more details on GPIB control.
. RS-232 Connector. A standard serial cable with a 25-pin male connector can be
attached to this connector to allow the instrument to be computer-controlled. A user
name (“admin”) and a password (“default”, as shipped from the factory) are required
when logging into a serial terminal session. The internal controller attempts to auto-
sense the parity setting. It may be necessary to send a few return characters before
attempting a login in order to provide enough data to allow this auto-sensing to work.
(A standard Linux “agetty” process is used to implement serial control internally.) See
the “Programming Manual for -B Instruments” for more details on RS-232 control.
8. Network Connector . This Ethernet connector allows the instrument to be remotely
controlled using the VXI-11.3, ssh (secure shell), telnet, and http (web) protocols. See
the “Programming Manual for -B Instruments” for more details.
9. OS Connector . (Optional feature. Present on "-OS" units only.) The desired DC offset
is applied to this connector. Internally, it is connected to the output centre conductor
via a high quality RF inductor. Do not exceed ±50V, 250 mA. When not used, the OS
input should be connected to ground.
10.MON Connector . (Optional feature. Present on "-M" units only.) The monitor output
provides an attenuated replica (÷11) of the voltage on the main output. The monitor
output is designed to operate into a 50 Ohm load.
19

GENERAL INFORMATION
BASIC PULSE CONTROL
This instrument can be triggered by its own internal clock or by an external TTL trigger
signal. In either case, two output channels respond to the trigger: OUT and SYNC.
OUT. This is the main output. The maximum output voltage is 200V.
SYNC. The SYNC pulse is a fixed-width TTL-level reference pulse used to
trigger oscilloscopes or other measurement systems. When the delay is set to a
positive value the SYNC pulse precedes the OUT pulse. When the delay is set to
a negative value the SYNC pulse follows the OUT pulse.
These pulses are illustrated below, assuming internal triggering and a positive delay. All
waveforms are shown with positive amplitudes.
Figure A
If the delay is negative, the order of the SYNC and OUT pulses is reversed:
Figure B
SYNC OUT
(generated by the
internal oscillator)
100 ns, FIXED
MAIN OUTPUT
PULSE WIDTHDELAY > 0
AMPLITUDE,
VARIABLE
3V, FIXED
SYNC OUT
(generated by the
internal oscillator)
100 ns, FIXED
MAIN OUTPUT
PULSE WIDTH
DELAY < 0
AMPLITUDE,
VARIABLE
3V, FIXED
20
