AVX AVX-BTA-3000 User manual

Instruction Manual
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE
AND KEEP IT FOR FUTURE REFERENCE
Bluetooth Stereo Hi-Fi System
Model: AVX-BTA-3000

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT
1. Install this unit in a well ventilated, cool, dry, clean place – away from direct sunlight, heat sources,
vibration, dust, moisture and/or cold. For proper ventilation, do not place anything on top of this unit or
cover it in any way. This will prevent proper heat dissipa- tion and could cause damage to this unit.
2. Avoid installing this unit where it will be exposed to any liquids dripping or splashing or other foreign
object that could damage this unit.
3. To prevent damage by lightning or power surge, keep the power cable disconnected from any wall
outlet during a lightning storm, intermittent or total power outage.
4. Do not attempt to modify or fix this unit. Contact authorized AVX Audio service personnel when any
service is needed.
WARNING:
Attempting to modify or fix this unit will void manufacturer’s warranty.
5. Be certain to read the troubleshooting section of this manual or contact an authorized AVX Audio
representative before determining this unit to be faulty.
6. Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified
is dangerous and may cause fire, damage to this unit and/or personal injury. AVX Audio will not be held
liable for use of this of this unit with a voltage other than specified herein.
7. Do not clean this unit with chemical solvents or liquids. Use only a clean, dry cloth. 8. Do not plug
this unit into an AC wall outlet until all connections are completed.

BTA-3000
12345 6 78910 11
12 13 14
15 16 17 18 19 20 21 22 23
1. Power ON/OFF
2. Speaker A/B Selector
3. Headphone Output
4. Bluetooth Receiver
5. SD Card Input
6. USB Input
7. Input Selector
8. Play/Pause (From USB, SD or Bluetooth Only)
9. Tone Control - Use to adjust treble or bass levels
10. Repeat – Will allow current song to be repeated
11. Previous – Use to select previous song or FM radio station
12. Next – Use to select next song or FM radio station
13. IR receiver for remote control
14. Master Volume
15. DVD Input
16. Auxiliary Input
17. CD Input
18. Audio Output
19. Right Speaker Output Channel A
20. Left Speaker Output Channel A
21. Right Speaker Output Channel B
22. Left Speaker Output Channel B
23. Power Cord
Inputs and Controls – Front and Rear Panel
BLUETOOTH STEREO RECEIVER BTA-3000
BLUETOOTH STEREO RECEIVER
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

Remote Control
Press to select TREBLE,BASS, and press " VOL+, VOL- to increase/decrease
bass or treble
3
D'"
Press to repeat song in USB/SD Playback Mode
Using the number buttons press the number(s) of the desired track.
The selected track will then be played.
for USB/SD music source.
Tone
Repeat

(AUX)(PHONO) (CD)
9
1. Plug this unit into 110V wall outlet located nearby.
2. Before powering this unit on, please refer to the chart above and confirm all speaker connec-
tions are correct / in phase. Make sure L (left) speaker is connected to left speaker and R (right) is
connected to right speaker and insure “+” to “+” and “–” to “–” are properly connected. If speakers
are not connected properly sound quality will be poor and lacking in bass.
3. Turn input selector to corresponding source that is connected to amplifier and power on desired
source.
4. If utilizing Bluetooth feature please select Bluetooth input on amplifier and then activate Bluetooth
function on your enabled device. Search for and connect to “AVX-AMP” to pair Bluetooth enabled
device wirelessly with the amplifier.
5. To use A/B function please select A or B speaker channel corresponding to speaker outputs
connected to your speakers. In the event A and B speaker outputs are to be used together please
turn selector to A+B channel position.
NOTE: DO NOT CONNECT TWO SETS OF 4 OHM SPEAKERS TO THIS UNIT, THIS MAY
CAUSE DAMAGE TO THIS UNIT.
BLUETOOTH STEREO AMPLIFIER
MODEL: AVX-BTA-3000
SPEAKER (RIGHT) SPEAKER (LEFT)
SUBWOOFER

PROBLEM CAUSE REMEDY
THE UNIT
FAILS TO
TURN ON
Protection Circuitry has
been activated because of
a short circuit.
The power cable is not
connected or the plug
is not completely inserted. Connect the power cable firmly
Check and confirm speaker
wires are not touching and
then turn power back on.
NO SOUND
SOUND
SUDDENLY
GOES OFF
Incorrect output or input cable
connections
Verify cables are connected
properly, if problem persists
cables may be defective
Speaker A/B selector is not
set properly.
Confirm Speaker A/B selector
is set to the appropriate output
that speakers are connected to
Speaker output has been muted. Disable the mute function.
The connected component
is not playing.
Verify component is connected
to the corresponding input
that is being selected.
The unit has become too hot
and has gone into protection
mode.
Make sure the openings on
the top panel are not covered.
Allow unit to cool.
Amplifier has turned off
Verify speaker connections
are not touching one another.
This will cause a short circuit.
THERE IS
A LACK
OF BASS
Speakers are connected out
of phase / + and - is reversed
Connect the speaker wires to
the correct + and - phase.
REMOTE
CONTROL
DOES NOT
FUNCTION
PROPERLY
The batteries are weak or
not inserted Replace all batteries.
5
*Please refer to the chart below if your amplifier is not functioning properly. In the event
you are experiencing an issue not outlined below, please contact an authorized AVX Audio
dealer to obtain further support.
Additional Information / Troubleshooting

FM band: 87.5~107.5MHZ
17” x 13” x 3.5”
12lbs
13.2lbs
120V ~ 50-60 Hz
6
