AVYCON AVC-NPTZ51X23L-F User manual

1
AVC
NPTZ51X23L-F
5MP MINI PTZ DOME NETWORK CAMERA
QUICK START GUIDE

Package Contents.....................................................................................................................
Caution......................................................................................................................................
System Requirements...............................................................................................................
Hardware Overview...................................................................................................................
Camera Installation...................................................................................................................
- Mount Accessories.................................................................................................................
Outdoor Installation..................................................................................................................
Accessing the Network Camera...............................................................................................
TABLE OF CONTENTS
1
1
1
2
3
5
9
10

Thank you for purchasing this AVYCON IP Network Camera. This guide provides basic instructions
on installing and accessing this IP Network Camera. For more details, please refer to the User
Manual.
Package Contents
Before installation, please verify that all the necessary items are supplied in the box as the
package contents listed below. If any item is missing or damaged, please contact the shipper
and your Avycon Sales Representative.
ITEMS
DEFAULT
OPTIONAL
QUANTITY DESCRIPTION
Avycon Network Camera 1 Pc The purchased model
Power Adapter
Quick Start Guide
Warranty Card
Lens
Bracket & Screw Pack
1 Pc
1 Pc
1 Pc
DC 12V (Optional for part of devices)
Printed material
Printed material
If purchased
If purchased
Caution
* Do not expose the product to rain moisture
* Make sure the device is firmly fixed when mounting it on the wall or ceiling
* Make sure that the power supply voltage is correct before using ther camera
* Do not use a 3rd party Power Adapter
* Never attempt to disassemble or modify the camera
System Requirements
OPERATING SYSTEM: Windows XP / Vista / 7 / 8 /10 / Server 2000 / Server 2008
CPU: 1.66 Ghz or Higher
RAM: 1G or Higher
Graphic Memory: 128MB or more
Internet Protocol: TCP / IP (IPv4 / IPv6)
1
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
1

Hardware Overview - Speed Dome Network Camera
AVC-NPTZ51X23L-F
NOTE:
2
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
1) Only AC 24V is available for Speed Dome Network Camera power supply. AC 24V and PoE+ (802.3at)
are available for PoE Speed Dome Network Camera power supply;
2) Built-in SD card slot can be seen after removing the 4 screws and open the front panel;
3) Speed Dome on AI Camera Series only support 30X/36X Optical Zoom Lens.

3
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
Step1: Check the wall or ceiling condition. Ensure that there is sufficient strength to avoid
flaking. It should be able to bear the weight eight times larger than the camera’s;
Step2: Use the wall or ceiling hanging holder to mark the holes. Drill 4 holes on the wall or
ceiling;
Step3: Put the cables through the holder. Match the holder with the screw holes of the camera
body and secure them;
Step4: Make sure that the camera body has been correctly installed to the holder, and match
the holder to the holes on the wall or ceiling, then tighten up the screws;
Camera Installation
AVC-NPTZ51X23L-F

4
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

5
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
The Junction Box is equipped for Wall Mount and Ceiling Mount in order to bring a rather
flexible and easy installation of Speed Dome and Mini PTZ Dome Network Camera.
Loosen the screws to open the front cover and rear cover, take out other parts from the box.
Install on the Wall Mount / Ceiling Mount
Step 1: Rotate to open the front cover over about 75°to conveniently take off it from the box;
Step 3: Take out the weather-proof connector, separate it to four parts as screw nut, rubber ring,
screw bolt and O-ring;
Camera Installation - Mount Accessories
AVC-NPTZ51X23L-F
Step 2: Install the rear cover first;

6
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
Step 8: The box supports top or bottom cable-out ways as below picture, through the top hole,
or tension disc which put cables through bottom or bottom back. For tension disc, please
remove it then cut an opening on the rubber plug, get cables through the opening. Please
remember to plug the rubber plug whenever the holes on it are not in use;
Step 4: Install camera on wall/ceiling mount accessory, put the camera cables through them.
The process would be easier if put the larger interface first;
Step 5: Put the camera cables through screw nut, screw bolt and O-ring;
Step 6: Take rubber ring circle over the cables and put it into screw bolt;
Step 7: Rotate screw nut on screw bolt to tighten, then pass all the cables through the entry hole
and rotate the whole weather-proof connector back on the front cover, and lock the accessory
back on the front cover;

7
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
Step 9: Carefully hold the front cover with wall/ceiling mount accessory and camera, put the
front cover stick into the rear cover. The set screw will lock the body securely;
Step 10: Connect camera cables with previous cables. Manage the cables well then close the
front cover and lock the screws.

8
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
Install on the Pole Mount
Step 1: Rotate to open the front cover over about 75°to conveniently take off it from the box;
Step 3: Fix the rings with rear cover on the pole, fasten the screws;
Step 4: The following steps are the same as it installed on the wall mount.
Step 2: Loosen the screws of the fix rings, put rings through the back of the box body;

9
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F
Here are some notes for outdoor installation:
Outdoor Installation
AVC-NPTZ51X23L-F
The picture below shows an example of outdoor installation:
The devices represented by numbers in the picture are explained as follows:
①Lightning rod
②Video surge arrester
③Telecommunication surge arrester
④Power surge arrester
⑤Grounding conductor (resistance no more than 4 ohms)
⑥Steel tube protector
1) Never use the overhead line in open area.
2) Set the line under eave.
3) The signal line is at least 50 meters away from the high voltage.
4) Attach a lightning rod to the top of the pole on which the camera is going to be mounted.
5) Make sure that your camera is not at the top of the pole and must be installed within the
lightning rod below 45 degrees.
6) Make sure that system adopts equal potential grounding.

Accessing the Network Camera
The Tools utility is a software tool which can automatically detect AVYCON IP cameras on your
LAN, modify IP addresses, and manage firmware upgrades. It’s recommended to use when
assigning IP addresses for multiple cameras.
1. Install the Tools utility (This can be downloaded from our website)
2. Start Tools, then click the IPC Tools icon, and then all AVYCON IP cameras on the local
network you are connected to will be shown with information such as IP address,
MAC address, Status, Port number, Netmask, and Gateway.
Assigning an IP Address by Using Tools Utility
In order to access the camera on your network, you must assign it an IP address compatible
with your network configuration. The default address of this camera is 192.168.10.201. You
can either change the IP address of a camera using the Tools Utility or manually assign your
computer an address to communicate with the camera and log in using the browser to modify
the IP address.
Assigning an IP Address
In order to access the camera on your network, you must assign it an IP address compatible
with your network configuration.
10
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

4. If the selected camera shows "Active" in the status bar, you can directly type the User Name
and Password you have previously assigned and then make any modifications to the IP address
and click on Modify.
3. Select a camera or multiple cameras according to the MAC addresses; the camera must
be assigned an IP address to be accessible.
SELECT SINGLE CAMERA
SELECT MULTIPLE CAMERAS
11
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

5. After activation, you can change the IP address or other network values, and then click
“Modify” button to change the IP address successfully;
If the selected camera shows "Inactive" in the status bar (Camera with version V4x.7.0.69 or
above), click to set the password when using it for the first time. You can also set
the security questions when activating the camera in case that you forget the password (You
can reset the password by answering three security questions correctly). Click ‘Save’ and it will
show that the activation was successful.
NOTE: (1) Password must be 8 to 32 characters long, contain at least one number and one letter.
(2) You need to be using Tools version V2.4.0.1 or above to activate the camera.
(1)
(2)
(4)
(3)
12
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

6. By double clicking on the selected camera's row or the browser icon of the camera, you
can access the camera via a web browser directly with the browser window that will pop up.
If the network segment of the computer and that of the camera are different, please
follow the steps to change the IP address:
1. Change the IP address of computer to 192.168.10.0 segment, here are two ways as below:
A. Start > Control Panel > Network and Internet Connection > Network Connection >
Local Area Connection, and double click it.
Assigning an IP Address via Browser
13
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

B. Click “Advanced”, and then click “IP settings” > “IP address” > “Add”. In the pop-up
window, enter an IP address that is in the same segment with your Avycon IP camera
(e.g. 192.168.10.200, but please confirm that the IP address you pick does not conflict with
another address on the network);
2. Start your web browser. In the address bar, enter the default IP address of the camera:
http://192.168.10.201;
14
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

If this is the first time you are logging into the camera, you need to set a password first.
If wanted, you can also set three security questions for your device after activation. You can
now use this password to log into the camera.
NOTE: 1. Password must be 8 to 32 characters long, contain at least one number and one letter.
2. You can click the “forget password” in login page to reset the password by answering three
security questions when you forget the password, if you set the security questions in advance.
4. After login, please select “Configuration” > “Basic Settings” > “Network” > “TCP/IP”.
The Network Settings page appears (Shown as below Figure);
15
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

5. Change the IP address or other network values as need, then click on the “Save” button;
6. You should now have completed changing the default IP address.
The camera can be used with the most standard operating systems and browsers.
The recommended browsers are Internet Explorer, Firefox, Chrome, Safari.
Accessing from the Web Browser
Before using the browser to get access to your camera, you may need to install the
MsActiveX plugin first. Please refer to the steps below:
1. Launch Internet Explorer and enter the IP address of the camera: e.g. 192.168.10.201
2. If this is the first time accessing the camera, you will be prompted to create a password,
and also the option to set three security questions for your device after activation. After
assigning the new password, you can now log into camera with these new credentials.
NOTE: 1. Password must be 8 to 32 characters long, contain at least one number and one letter.
2. You can click on "Forget Password" on the login page to reset your password by answering
the three security questions you assigned during activation.
3. If this is the first time logging into your IP camera, the browser will prompt you to install the
plugin. Please click on link that the window displays to start the download.
Accessing over IE Browser
16
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

4. Follow the prompts to install the plugin and when finished, you will see the window below
After the plugin has successfully installed, you can refresh the browser and you should be
able to see video.
If IE9 or higher version browser is used, it is suggested that the Avycon camera web link should
be added as a trusted site. See the instructions as follows:
1. Start the IE9 or higher version browser, and select “Tools” > “Internet Options”;
2. Select Security, then click on "Trusted Sites"
17
5MP MINI PTZ DOME NETWORK CAMERA | AVC-NPTZ51X23L-F

3. Enter the IP address of the camera in the blank and click “Add”;
4. Enter the IP address into your browser's address bar. After logging into your AVYCON IP
camera successfully, you should see live video.
