AVYCON AVC-TV21F28 User manual

HD Analog 2MP/5MP/8MP Cameras
QUICK START GUIDE
FIXED VANDAL DOME CAMERA
HD-TVI / CVI / AHD / CVBS
Introduction
Safety Instructions
Installation
Setup Diagram
2
3
4
5
Package Contents6
Resources7
1
CONTENTS
INTRODUCTION 2
Thank you for purchasing our product. We make every effort to
update and ensure accuracy of the information contained in this
manual, which may be subject to change from time to time
without prior notice. For any questions or needs, please feel free
to contact us at any time.
OPERATING ENVIRONMENT
Power Supply DC12V±10%
Temperature -22°F ~ 140°F (-30°C~60°C)
Humidity 10%~95%
Altitude -60m~3000m
Atmosphere 86kpa~106kpa
SAFETY INSTRUCTIONS 3
1)
2)
3)
4)
5)
6)
7)
8)
Please comply with the power supply specifications as required
for this equipment and select the correct power supply.
In the case that equipment fails to operate properly, immediately
contact the manufacturer or the nearest service center. Please
do not attempt to disassemble the product or attempt to modify
the product in any manner, which may void warranty.
For replacement of any parts, contact the distributor. Changing
any parts in the device without authorization is not permitted
and may void warranty.
Prevent water or any other liquid from flowing into the
equipment.
Avoid use of the equipment in any environment other than as
suggested in this manual.
Do not put the camera toward any strong light source (including
lighting lamp or sun) which may cause over-exposure or light
leakage (not due to defect of the product) and impair useful life
of the camera.
Do not drop any object onto the device or knock heavy objects
onto the equipment.
For cleaning of the lens, be sure to use compressed air or a
dedicated lens cleaner. For cleaning of the plastic shield, use a
soft and dry microfiber cloth to wipe it. Do not use any
detergents containing alcohol or benzene.
1.
Sticker
INSTALLATION 4
Place mounting template sticker in area where you will be
mounting camera to surface that can sustain weight of camera.
2.
3.
•If using the included hardware, insert the three drywall
anchors into holes in the mounting surface and align holes in
camera mounting plate with anchors. Adjust the angle to an
optimal viewing position.
Drill into ceiling at marked drill holes deep enough to
accommodate for mounting hardware.
FIXED VANDAL DOME CAMERA
Remove the screws securing the dome cover in place. Then pull
the dome cover off carefully.

•Carefully slide the dome cover back onto the camera, then
secure it by screwing it in place.
Ceiling Mounting complete.
5.
Dome Cover
Fix the dome cover back onto the mounting base by installing
the three dome cover screws into the camera and tightening it
once the position is secured.
4.
Dome Cover Screws
Bracket Adjustments
•With the dome cover removed, you can make adjustments to
the pan, tilt, and rotation of the camera lens and body to allow
for the best possible view for your application.
6.
Rotate: 360°
Tilt:90°
Pan 360°
Drywall Anchors
PLEASE CONFIRM THAT VOLTAGE OF POWER SUPPLY USED MATCHES POWER
REQUIRED BY CAMERA, OTHERWISE PERMANENT DAMAGE OR RISK OF FIRE
MAY OCCUR
CAUTION
SETUP DIAGRAM 5
Power Supply
DVR
BNC Video Output
Power Connector
CCTV Power Supply
12VDC
Power Outlet
LAN USB DC12V
VGA
Camera
Fixed Indoor Dome Camera Mounting Template
Drywall Anchor x 3
Mounting Screw x 3 L-Wrench
DC Plug Terminal Block
PACKAGE CONTENTS 6
Need help?
Visit us online for up-to-date software and complete instruction manuals.
1) Visit www.avycon.com
2) Search for the model number of your product.
3) Click on your product and find appropriate documents on product page.
RESOURCES 7
[email protected]om
www.avycon.com
1 [phone]
1 [phone]
[M-F, 6am-5pm PST]
Technical Support E-mail :
Technical Support Website :
US Helpdesk Number :
Toll Free Number (Canada) :
FIXED VANDAL DOME CAMERA
