awave AW30 User manual

COMPONENT SPEAKER SYSTEM
OWNER’S MANUAL
AW30
3 INCH MIDRANGE SPEAKER

FEATRUES
PRECAUTIONS
Thank you for purchasing a AWAVE 3 Way 3 inch Midrange
Speaker. It is a state-of-the-art product specifically designed and
engineered for HIGH END vehicle use, and has been thoroughly
tested to ensure consistent and reliableperformance.
Should you have any questions regarding the installation or
operation of your AWAVE 3 inch Midrange Speaker, which are not
answered in this manual,please contact your dealer for assistance.
Before making holes, check the mounting space with supplied
template.
To prevent noise pick-up, keep the wiring away from motors,
high-voltage leads and other potential noise sources.
To prevent a short-circuit, keep all wiring away from moving parts
and sharp edges.
Make sure you carefully read and understand the installation
instructions before installing this subwoofer in your vehicle.
3 inch Midrange Speaker
RMS. Power : 40Watts
MAX. Power : 80Watts
Mounting Depth (mid-range) : 41.5mm
Impedance: 4ohm
Efficiency: 91dB/SPL
Frequency Range: 55-22KHz
1

MID-RANGE
The appearance of the product
Frequency Response Graph
2
H
I
G
H
E
N
D
-
L
o
u
d
s
p
e
a
k
e
r
s
AW30

3
84.5 mm
75 mm
75
40 watts
80 watts
200 watts
120
86
2.5
656
3.12
25.7
20
– 84
4.3
120
3.8
0.71
0.60
2
1.05 L
3.1
ir
(3-inch)
41.5 mm
