AXA Remote 2.0 User manual

AXA Remote 2.0
Information
You have just acquired a high quality AXA product.
The instructions below must be followed closely in order to
effectively assemble and operate this product.
Implementation:
Top and side-hung windows, opening outwards
Assembly tools (recommended):
Tape measure, (cordless) drill, screwdriver, Ø 2 mm drill bit,
pencil or stiletto, screw ring and socket wrench
Assembly location Minimum required
assembly space:
Minimum window height: 30 cm.
Maximum range remote control: distance 10 m.
37-223 (05-12)
User manual
Remote control (figure ):
The remote control has 3 buttons: Open, Stop and Close.
When the Open or Close buttons are pressed briefly, the
window will fully open or close.
When the Open or Close buttons are pressed continuously,
the window will open or close as long as the button is pressed.
When the Stop button is pressed, the movement will be
stopped.
Always point the remote control at the front of the
closing unit (figure ).
Configuring remote control:
1Place 2x AAA batteries in the remote control
and 4x AA batteries in the closing unit (figure ).
2The LED light in the closing unit will come on for 20 seconds
(green). Press the Open button (top button) on the remote
control. The light will briefly turn off when configuration has
taken place.
Open
Stop
Close
A B
40 mm
38 mm
380 mm
Window
Window casing
Stay
Hinge side
50
88
26 26
310
38
min. 38 cm, max. 100 cm
min. 30 cm,
max. 100 cm
EMC 2004/108/EC
Top-hung
window
Package contents
1. (2x) AAA Batteries
2. (4x) AA Batteries
3. (1x) Closing unit
4. (1x) Window casing plate
5. (1x) Drilling template
6. (1x) Cover
7. (1x) Window plate
8. (1x) Screw ring
9. (2x) Screws 3.5 x 30 mm
10. (9x) Screws 4.0 x 40 mm
11. (1x) Socket wrench
12. ((1x) Remote control
1
3
4
6
2578910
11
12
1
C
12
3
C
B
2
1
POLICE
HALLMARK
SAFE LIVING
A
Remote-controlled window opener

Assembly manual
4 Check whether the window closes effortlessly.
5 Mark the middle of the window on the window casing.
6 Place the drilling template, with the centre of the V sign
on the marked central point, firmly against the
window and window casing (figure ). Mark the
hole (figure ) and screw the screw hook into the
window through the opening of the drill template
(pre-drill Ø 2 mm). Use this screw hook to properly close
the window; ensure the drilling template is firmly against
the window and window casing (figure ). Mark 2 assembly
points through the drilling template (figure ).
Pre-drill the assembly points (Ø 2 mm).
7 Fix the drilling template in place using the
screws (3.5 x 30 mm).
8 Pre-drill the 7 holes (figure ) using a Ø 2 mm drill bit.
9 Remove the drilling template
Assembly
10 Mount the window plate (using pre-drilled holes) with
4 screws (4.0 x 40 mm) * (figure ).
When using a wireless drill, you must make the last
few tightening revolutions by hand
11 Mount the window casing plate (using pre-drilled holes)
with 3 4.0 x 40 mm screws (figure ).
12 Slide the closing unit on to the window casing plate; keep
the window slightly open when doing so (figure ).
13 Slide the chain block fully over the window
plate (figure ). The block will fix itself in place.
E
G
I
K
F
H
J
The configuration time is 20 seconds. The LED light
will switch off once this time passes. If you want to
configure the remote control or another remote
control, you must briefly remove the batteries and
then re-insert them. Then repeat step 2.
- A remote control can be configured to an unlimited
number of window units.
- A window unit can be configured to maximum 8
remote controls.
3 Press the Open button again and allow the chain to fully exit
the closing unit.
The closing unit is now ready for assembly (figure ).
D
* For pinewood: Use 4 x 4.5 x 45 mm screws
5
8
9
4
7
10
D
F
E
G
H
I
J
J
K
L
L
AXA Remote 2.0
Remote-controlled window opener
37-223 (05-12)
EMC 2004/108/EC
2
POLICE
HALLMARK
SAFE LIVING
4x 3x

2
14 Close the window with the remote control
(figure ).
When doing so, hold the closing unit and ensure it
stays the same distance from the window.
Configure closing unit:
15 The closing unit will stop flashing once it is fully closed.
You can adjust the close-position using the adjustment
screw.
If the window is not close enough:
If the window is not close enough (the window moves or a draft
comes through the window), you must turn the adjustment
screw to the left (figure ).
For effective operation and a long battery life-span, we advise
not to configure the closing unit too tightly.
If the closing unit does not lock completely:
If the closing unit does not yet close properly, the LED light will
flash. In this case, the unit is too tight.
If the closing unit has been configured too tightly, you must turn
the adjustment screw to the right (figure ). Press the close
button on the remote control once again and check whether the
closing unit closes properly. Repeat this process until the unit
closes properly.
Final assembly
16 Screw the closing unit in place using the 2 screws
(4.0 x 40 mm, pre-drill Ø 2 mm), one on the left-hand side
and one on the right-hand side of the unit (figure ).
When screwing in place, ensure that the closing unit is at an
equal distance from the window casing.
17 Once again, check whether the window opens and closes
properly by fully closing and opening the window once.
Repeat step 15 if the window does not flow or close
properly.
Assembly cover:
18 Slide the cover on to the closing unit, from front to back,
until it goes no further (figure ).
19 The AXA Remote 2.0 is ready for use.
Assembly adapter version:
20 Assemble the window unit in the same way as the battery
version (step 1 to/incl. 19). Remove the batteries before
connecting the adapter to the closing unit and the power
supply (figure ).
21 Decide whether you want the adapter wire to exit the
left-hand side or right-hand side of the closing unit (depen
ding on the location of the power socket).
Use cutters to cut a small snippet from the cover, in the
semi-perforated area (figure ).
N
P
Q
O
M
6
10
R
==
N
O
P
Q
R
M
R
AXA Remote 2.0
37-223 (05-12)
EMC 2004/108/EC
3
Remote-controlled window opener
POLICE
HALLMARK
SAFE LIVING

22 Click the adapter wire into the closing unit:
- lead the wire from the left-hand side of the closing unit
and place the adapter in the power socket.
or:
- lead the wire through the opening on the right-hand side
of the closing unit and under the designated hook
(figure ). Place the adapter into the power socket.
Ensure that the wire is placed neatly along
the window casing.
The adapter with 5m wire can be ordered as an accessory under
item number 2902-31-98.
Problem-solving
The window does not close
• Disconnect the chain from the window and check that
the window does not become stuck and operates without
problems.
• Check that installation steps have been followed correctly.
• The batteries may be flat (have insufficient power).
Replace the batteries in the unit and/or remote control
(figure ).
• The unit has been configured too tightly.
The closing unit may (for example, due to the wood setting
our because of temperature differences) not properly
close the window in certain cases, if it has been configured
too tightly. Remove the 2 outer screws (figure ) from
the closing unit. Turn the adjustment screw fully to the right
(figure ). Repeat step 14 to/incl. 17. Mount the 2 outer
screws on to the window unit once again.
The unit does not react or reacts insufficiently
• Temporarily remove the batteries or remove the adapter
plug from the power socket and wait 2 minutes. Press a
button on the remote control as if you are about to use
the unit. Replace the batteries or the adapter.
Now try to use the unit by pressing one of the buttons on the
remote control.
Unit does not immediately respond to the remote control,
sleep mode
• To save energy, the unit switches to sleep mode after a
certain period of time; that is why you sometimes need
to press twice on the remote control to activate the unit.
• Environmental factors could have an impact on the range of
the remote control. Full sun, TL lighting very close to the
front of the unit or a dusty/moist environment could
reduce the operating range. In this case, you must move
closer to the closing unit to operate it.
• The batteries may be flat (have insufficient power). Replace
the batteries in the unit and/or remote control.
Replace batteries
Low-battery indicator
• If the LED starts to flash red/green intermittently, this
means the batteries need to be replaced very soon.
The AXA-Remote will always ensure that the last remaining
power in the batteries is used to close the window.
• Open the cap of the unit and remove the 4 flat batteries.
Insert 4 new batteries (AA) as identified in this assembly
manual (figure ).
Only use good alkaline AA batteries (do not use
rechargeable batteries)
Configure multiple units with the same remote control
• Briefly remove the batteries from the to-be-configured
window unit or briefly remove the adapter from the power
socket and wait 2 minutes. Replace the batteries or the
adapter. Continue to configure the remote control so long
as the LED light remains green (20 seconds) (see figure ).
Ventilation capacity
According to NEN 1087 and NEN 8087, which identify mini-
mum ventilation per area, the AXA Remote 2.0 complies with
the minimum ventilation capacity of 25 m3/hour per area,
based on a window surface area of 0.26m2. Due to its many
opening possibilities, the AXA Remote 2.0 is also suitable for
aeration. For the mentioned window size, each AXA Remote 2.0
is able to sufficiently ventilate an area of 22.5 m.The AXA
Remote 2.0 also complies with the capacity guideline establis-
hed in NPR 1088 because it enables continuous opening and
closing. This allows the required ventilation to be arranged.
NB. The AXA Remote is only intended for items with a
residential or office purpose.
S
S
P
C
C
C
AXA Remote 2.0
37-223 (05-12)
EMC 2004/108/EC
4
O
Remote-controlled window opener
POLICE
HALLMARK
SAFE LIVING
