Axesstel MV242 User manual

MV242 CDMA 1xEV-DO Rev. A USB Modem
Axesstel Inc.
CDMA 1xEV-DO Rev. A
USB Modem MV242
User Manual

CDMA 1xEVDO Rev. A USB Modem User Manual
Axesstel Inc.
Thank you for choosing Axesstel EVDO wireless network USB modem. No matter
where you are, this product can meet your multiple requirements at any time, such as
surfing on line with high-bit-rate, sending and receiving short message, phonebook
management, and voice. Applying this product properly can improve your working
efficiency, and further bring more value to you.
Warning:
Do not let the device spilled by rain or get wet.
Do not open the network card by yourself without permission. When
maintaining, please follow the instruction of professionals.
Do not plug or unplug the (U) SIM card when power is on.
Note:
Please comply with the rules of some special places, such as the hospital and
the plane.
Wireless interference on the network, the instability of the Internet, and other
factors, may influence the functions of the wireless network card.
For some versions of the operating system, there may be installation problems.
It is recommended you change the operation system to be that of the
mainstream brand and version.
The network card supports hot plug. If the computer is down, please shut down
the computer and reboot it.
Statement
When connecting the wireless network card to a notebook, the interface should
be in parallel with the computer interface. If product damage caused by the
improper operation, we will not bear any responsibility for all the consequences
arising therefrom.
When using the wireless network card, communication interruption and data

CDMA 1xEVDO Rev. A USB Modem User Manual
Axesstel Inc.
loss may occur, we will not undertake the responsibility and the indemnity for
damage.

CDMA 1xEVDO Rev. A USB Modem User Manual
iii
Contents
1Overview............................................................................................................1
2Software Installation and Uninstallation.............................................................2
2.1 Installing the Software ....................................................................2
2.2 Uninstalling the Software................................................................2
3Description of Terminal GUI ..............................................................................2
3.1 Logging In to the Terminal ..............................................................2
3.2 GUI Introduction..............................................................................3
4Internet Service .................................................................................................3
4.1 Connection Management................................................................3
4.2 Traffic Information...........................................................................4
5SMS Service......................................................................................................4
5.1 Creating a Message........................................................................4
5.2 Sending a Message........................................................................4
5.3 Replying a Message.......................................................................5
5.4 Forwarding a Message...................................................................5
5.5 Editing a Message..........................................................................5
5.6 Deleting a Message........................................................................6
5.7 Resending a Message....................................................................6
5.8 Searching a Message.....................................................................6
6Phonebook ........................................................................................................7
6.1 Phonebook Management Interface.................................................7
6.2 Creating a Contact..........................................................................7
6.3 Editing a Contact ............................................................................7
6.4 Deleting a Contact..........................................................................8
6.5 Sending a Short Message ..............................................................8

CDMA 1xEVDO Rev. A USB Modem User Manual
iv
6.6 Copying Phonebook Records to Local or (U) SIM Card.................8
6.7 Searching a Contact.......................................................................8
7Phone ................................................................................................................9
7.1 Phone Management Interface ........................................................9
7.2 Outgoing calls.................................................................................9
7.3 Incoming calls...............................................................................10
8Setting..............................................................................................................10
8.1 Choosing Language......................................................................10
8.2 Enabling or Disabling PIN code....................................................10
8.3 Changing PIN Code...................................................................... 11
8.4 Verifying PIN Code .......................................................................11
8.5 Using PUK to Unlock the (U) SIM Card........................................11
8.6 Options .........................................................................................12
9Help .................................................................................................................13
10 Mac OS X Installation......................................................................................14
10.1 Installing the Application ...............................................................14
10.2 Exit the Application .......................................................................14
11 Function Fields and Operation Introduction of Mac OS X ...............................15
11.1 GUI Introduction............................................................................15
11.2 Connecting to the Internet ............................................................15
11.3 Settings.........................................................................................17
11.3.1 PIN Settings ........................................................................17
11.3.2 Network Settings.................................................................17
11.3.3 Device Information ..............................................................17
12 Mac OS X Help................................................................................................17
13 FCC Warning...................................................................................................17
13.1 FCC Regulations ..........................................................................17

CDMA 1xEVDO Rev. A USB Modem User Manual
v
13.2 RF Exposure Information (SAR)...................................................19

EVDO USB Modem User Manual
1
1 Overview
The wireless network USB modem is a high-bit-rate data card, which is applicable to
network connection applications of CDMA 1xEV-DO Rev. A, and backward
compatible to CDMA 1 xEV-DO Rev.0 and CDMA 1x.
This wireless network card provides the following functions:
High-Speed Data Service
Sending and Receiving Short Message Service
Managing Phonebook
Voice Call
Features
Apply to 3G network environment
Provide high speed connection. Support transmission data rate of up to 7.2
Mbps at downlink and 5.76 Mbps at uplink.
Support mainstream operating systems including Windows XP, Vista, and
Win 7.
Support Mac OS X 10.4 version or above
Support connection of the USB interface. Support hot swappable.
Serve as the mobile memory, and support Micro SD card storage of up to 4
GB.
Humanized design of LED indicator, to indicate the status of the wireless
data terminal.
Built-in driver. Support automatic setup after startup.

EVDO USB Modem User Manual
2
2 Software Installation and Uninstallation
2.1 Installing the Software
Software installation is “Plug and Play”. Please follow the on-screen instructions to
finish the software installation. To install the software, do as follows:
Step1 Insert the wireless network card into the USB interface, and the following
page for selecting languages automatically appears. The default
language is English.
Step2 After selecting the proper language, click the OK button.
Step3 Click the Next > button to continue.
Step4 After choosing the installation folder, click the Next > button.
Step5 You can choose whether to add a shortcut icon on the desktop. Click the
Next > button to continue.
Step6 Click the Install button to begin the software installation.
Step7 Reboot the computer to finish the software installation.
2.2 Uninstalling the Software
To uninstall the software, do as follows:
Step1 Click Start > All Programs > 3G Modem Partner.
Step2 Click 3G Modem Partner Uninstall to finish the software uninstallation.
3 Description of Terminal GUI
3.1 Logging In to the Terminal
Double-click the shortcut icon of the terminal on the desktop to log in to the terminal.
Note: The working temperature of the phone is range from -10℃-55℃.

EVDO USB Modem User Manual
3
When you are required to enter the Personal Identification Number (PIN)
code, enter the correct PIN and click OK. If you fail to enter the correct PIN or
PIN Unblocking Key (PUK) code, the network-related functions would be
unavailable.
The (U) SIM card is supplied by the service provider. For more details, please
contact your service provider.
3.2 GUI Introduction
The main menus of the terminal are displayed as follows:
4 Internet Service
4.1 Connection Management
After finishing the network settings and the connection settings, you can access the
Internet via the terminal. To access the Internet, do as follows:
Step1 Click the connection icon
Step2 Select the correct access point in the drop-down list.
Step3 Click the Connect button to connect to the network.
Step4 Start the browser on your PC to view the Web pages.
Step5 After the connection is established, choose the Disconnect button to
disconnect from the network.

EVDO USB Modem User Manual
4
4.2 Traffic Information
You can use the statistical function to check the network traffic. To view the traffic
information, do as follows:
Step1 Click the traffic icon to display the traffic interface.
Step2 View the current connection information: You can view the duration of the
current connection, uploaded/downloaded speed and data of the current
connection. You can also view the corresponding graphic traffic
information.
Note:
The statistical data of the traffic is only for your reference. The actual traffic
information is accounted on the basis of the traffic data collected by the operator.
5 SMS Service
Click the message icon to display the message interface.
5.1 Creating a Message
Step1 In the shortcut menu bar, click to display the text interface.
Step2 Enter the message content.
5.2 Sending a Message
There are two methods for entering the recipient number.
Enter the recipient number directly. For multiple numbers, each number
should be separated by ";".

EVDO USB Modem User Manual
5
Click the Send to button to display the interface for selecting phone numbers.
You can select a contact or press the Ctrl key or the Shift key to select
multiple contacts in the phonebook list, and then click the OK button.
Click the Send button to send the message. If message fails to send to the recipient,
this message will be saved in the outbox.
5.3 Replying a Message
To replay a message, do as follows:
Step1 Select a message in the inbox, and then click the Reply button in the
shortcut menu bar.
Step2 The recipient number will be automatically displayed in the number bar.
You can edit the recipient number.
Step3 Enter the replying message content, and then click the Send button.
5.4 Forwarding a Message
To forward a message, do as follows:
Step1 Select a message, and then click the Forward button in the shortcut
menu bar.
Step2 The message content is automatically displayed in the editing field. You
can edit the message content.
Step3 Enter the phone number of recipient that your message is forwarded to,
and then click the Send button.
5.5 Editing a Message
To edit a message, do as follows:
Step1 Enter the draft box. Select a message and then double-click the
message.

EVDO USB Modem User Manual
6
Step2 Edit the message content, and then click the Save button or the Send
button.
5.6 Deleting a Message
To delete a message, do as follows:
Step1 Select a message in the message list, or press the Ctrl key or the Shift
key to select multiple messages.
Step2 Click the Delete button in the shortcut menu bar.
Step3 Select the OK button in the dialog box to confirm the deletion operation.
Step4 The selected messages will be deleted from Local and you can not
recover it.
5.7 Resending a Message
To resend a message, do as follows:
Step1 On the outbox interface, select a message.
Step2 Click the Send button in the shortcut menu bar. If the message fails to
send, it will be sent again.
5.8 Searching a Message
Click the search icon . Enter the name, or phone number of the message sender,
or part of the message content in the text field.
Note:
You can enter part of the message content to search.
When you search a message, a list of the matched messages is updated
automatically according to the information entered. The matched messages

EVDO USB Modem User Manual
7
in the searched group are displayed. No result is displayed when no matched
message is found.
6 Phonebook
You can manage contacts in the phonebook conveniently with the terminal.
6.1 Phonebook Management Interface
Click the phonebook icon to display the phonebook
management interface.
The phonebook types include Local and (U) SIM card. You can manage the local
phonebook or the (U) SIM phonebook.
6.2 Creating a Contact
To create a contact, do as follows:
Step1 Click the New button in the shortcut menu bar to display the new
phonebook interface.
Step2 Enter the information, and the click the Save button. The new contact is
displayed in the list.
6.3 Editing a Contact
To edit a contact, do as follows:
Step1 Click the Edit button in the shortcut menu bar to display the interface for
editing the contact.
Step2 Edit the information, and then click the Save button to save the changed

EVDO USB Modem User Manual
8
content.
6.4 Deleting a Contact
To delete a contact, do as follows:
Step1 In the phonebook list, select a contact or press the Ctrl key or the Shift
key to select multiple contact records.
Step2 Click the Delete button in the shortcut menu bar.
Step3 Select the OK button in the dialog box to confirm the deletion operation.
Step4 The selected phonebook record will be deleted and you can not recover
it.
6.5 Sending a Short Message
To send a message, do as follows:
Step1 Select a contact or press the Ctrl key or the Shift key to select multiple
contacts.
Step2 Click the Send button in the shortcut menu bar.
Step3 After editing the message, click the Send button.
6.6 Copying Phonebook Records to Local or (U) SIM
Card
To copy phonebook records to Local or (U) SIM card, do as follows:
Step1 Select a record or press the Ctrl key or the Shift key to select multiple
records.
Step2 Right-click and select the Copy to option.
Step3 Copy the records to Local or (U) SIM card.
6.7 Searching a Contact

EVDO USB Modem User Manual
9
To search a contact, do as follows:
Step1 Click .
Step2 Enter the key words of phonebook in the blank field of the shortcut menu
bar.
7 Phone
7.1 Phone Management Interface
In the main interface, you can click to open the telephone
management interface.
On the left side is the dial-up interface, and the right side is the call records
management interface which consists of three tab pages: Received, Missed,
Dialed.
7.2 Outgoing calls
Listed below are the several ways to make outgoing calls：
（1）In the dial-up interface enter the numbers via the number keys, then
click
（2）When the call records list is not blank, select one of the records, right
click the menu to choose “Call”option or click “Call”from the shortcut
menu. To hang up, click

EVDO USB Modem User Manual
10
7.3 Incoming calls
When there is an incoming call,
If the telephone visual prompt function has been set up, the pop box as below will
appear in the lower right corner,
then click“Answer”or in the interface to answer the call, and click
“Hang up”or to hang up.
If the visual prompt function has not been set up, you can only click
to answer the call, click to hang up.
8 Setting
Click Tools on the main interface to display the drop-down menus. The drop-down
menus include different setting options of software.
8.1 Choosing Language
Choose Tools > Language to select the proper language. You may select English.
8.2 Enabling or Disabling PIN code

EVDO USB Modem User Manual
11
Choose Tools > PIN Manage to select Enable/Disable PIN in the drop-down list. To
enable or disable PIN code, do as follows:
Step1 Enter the correct PIN code.
Step2 After clicking the OK button, it will remind you to enable or disable PIN
code.
8.3 Changing PIN Code
To change PIN code, do as follows:
Step1 In the drop-down list, click the Modify PIN to display the interface for
changing PIN code.
Step2 Enter the original PIN code.
Step3 Enter the new PIN code and enter it again for confirmation. After finishing
setting, click the OK button.
Note:
Only if the PIN code is enabled can you change the PIN code.
8.4 Verifying PIN Code
After enabling PIN code protection, you need to enter the correct PIN code for using
the related network functions. To verify the PIN code, do as follows:
Step1 In the drop-down list, select Verify PIN.
Step2 Enter the correct PIN code
Step3 Click the OK button to finish PIN code verification.
8.5 Using PUK to Unlock the (U) SIM Card
To use PUK code to unlock the (U) SIM card, do as follows:
Step1 If the (U) SIM card is locked, run the terminal client and then the PUK
Unlock dialog box appears.

EVDO USB Modem User Manual
12
Step2 Enter the correct PUK code.
Step3 Enter the new PIN.
Step4 Click the OK button. The (U) SIM card is unlocked and the PIN is
changed.
8.6 Options
Choose Tools > Option to set other parameters.
General Settings
Message
For the message reminder, you can select the voice reminder or the audio reminder.
Telephone
Telephone prompting mode can be voice prompt or visual prompt as selected.
Profile Management
Enter the dial-up interface to display the connection profiles that are available.
-Creating a Profile
Step1 Click the New button to display the interface for adding a new
profile.
Step2 Enter APN and other parameters on the interface.
Step3 Click the Save button to add a profile to the profile list.
-Editing a Profile
Step1 Select a profile in the list.
Step2 Click the Edit button to display the interface for editing the
parameters.
Step3 After setting the parameters, click the Save button to save the
changes.
-Deleting a Profile
Step1 Select a profile in the list.

EVDO USB Modem User Manual
13
Step2 Click the Delete button and confirm the deletion operation.
-Setting the Default Profile
Step1 Select a profile in the list.
Step2 Click the Set as default button to set the selected profile to be the
default one. After finishing the settings, you can use this profile as
the default profile to establish connection.
Information
Display the device IMEI number.
9 Help
Select About 3G Modem Partner in the Help drop-down list to display the
information about software version.

EVDO USB Modem User Manual
14
10 Mac OS X Installation
10.1 Installing the Application
Connect the data card to your PC, and then system automatically displays the
corresponding CD. After opening the CD, double-click the application, and follow the
on-screen instructions to finish the installation.
Step1 Click the Continue button in the welcome page.
Step2 Click the Continue button in the license agreement page.
Step3 Click the Agree button to accept the terms of the license agreement.
Step4 Choose a folder for storing the MAC client terminal software, and then
click the Continue button.
Step5 After choosing the storing path of the MAC client terminal software, click
the Install button.
Step6 Enter the username and password for authentication, and then click the
OK button.
Step7 Click the Close button to finish the software installation.
Note:
If you have any problem with the installation process, please contact our customer
service department.
Step8 After finishing the installation, select Finder >Applications, and then the
application appears in the list. In that case, Modem can start to work
normally.
10.2 Exit the Application
Please exit the corresponding application first, and then unplug the data card.
