Axiom AX1012A User manual
USER MANUAL
AX1012A
powered constant curvature array element
KEY FEATURES
• 12” woofer, 1.4” HF neodymium compression driver
• Constant curvature Seamless Transion Waveguide (SWT) with 20° H x 100° V dispersion
• Class D amplier module with SMPS
• 96KHz / 40 bit oang point CORE processing with PRONET remote control
• Integral suspension hardware for horizontal or vercal array installaon
• Pole mounng available for free-standing applicaons
INTRODUCTION
AX1012A is a versale constant curvature full-range element that can be
used to create both vercal and horizontal line source arrays and also as
a high-direcvity point-source loudspeaker.
The 1.4” high frequency compression driver is coupled to STW -
Seamless Transition Waveguide, which ensures a precise control of
mid-high frequencies both on horizontal and vercal axis, for a perfect
acoustic coupling between the enclosures that form the array. The
unique waveguide design produces vercal line source direcvity with a
horizontal paern that is maintained down to approximately 950Hz. This allows to project clean music and vocals
evenly around the audience without hot-spots and dead-spots. The sharp SPL o-axis rejecon is used to avoid
reecng surfaces in the enclosure coupling plane and perfectly adjusts the acousc coverage to the audience
geometry.
The AX1012A tour-grade 15mm phenolic birch plywood cabinet is ed with four integrated steel rails, to be used for
coupling the cabinets with the KPTAX1012 aluminium coupling bars. A comprehensive set of accessories is available
for creang horizontal or vercal arrays, for ground-stacking the systems and also for pole mounng one unit.
AX1012A is recommended for the use as indoor FOH (Le – Centre - Right systems) or outdoor FOH in small to
medium-sized events. It can be used also as a complement to large systems as Out-ll, In-ll or distributed ll
applicaons in a wide range of venue, providing clear sound to areas not fully reached by the main system, while minimizing unwanted interacons
and room reecons.
TECHNICAL SPECIFICATIONS
Acouscal Remote Controls PRONET control soware
System type Constant Curvature Array Element Network protocol CANBUS
Amplier Type Class D amplier with SMPS
Low frequency transducer 12” (305 mm) LF driver, 3” (75 mm) ISV
aluminium voice coil, 4Ω
Output Power 900W + 300W
Mains Voltage Range (Vac) 230 V~ ±15% or 115 V~ ±15% 50/60 Hz
High frequency transducer
1.4” (35.5 mm) HF compression driver, 2.4”
(61 mm) aluminium voice coil, Titanium
diaphragm, 8Ω
Mains Connector PowerCon® (NAC3MPA + NAC3MPB)
Consumpon* 575 W (nominal) 1200 W (max)
IN / OUT Connectors Neutrik XLR-M / XLR-F
Frequency response (-6 dB) 65 Hz – 17 kHz (Processed) IN / OUT Network Connectors ETHERCON® (NE8FAV)
Horizontal Coverage Angle (-6 dB) 20° (1KHz-17KHz) Mechanical
Vercal Coverage Angle (-6 dB) 100° (1KHz-17KHz) Width 370 mm (14.6”)
Maximum Peak SPL @ 1m 134 dB Height 611 mm (24”)
Electrical Depth 495 mm (19.5”)
Input Impedance 20 kΩ balanced Taper angle 10°
Input Sensivity +4 dBu / 1.25 V Construcon 15mm, reinforced phenolic birch
Signal Processing CORE processing, 96kHz / 40bit oang
point SHARC DSP, 24 bit AD/DA converters
Paint High resistance, black water based paint
Rigging system
Direct access Controls
4 Presets: Single, Mid-Throw, Long-Throw,
User.
Network Terminaon, GND Link
Suspension Capve suspension system
Net Weight 34.5 Kg (76.1 lbs)
* Nominal consumpon is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.
revision 2019-09-30
20°
100°
MECHANICAL DRAWING
SPARE PARTS
NAC3MPA Neutrik Powercon® BLUE SOCKET 98ED120WZ4 12’’ woofer - 3” VC - 4 ohm
NAC3MPB Neutrik Powercon® WHITE SOCKET 98DRI2065 1.4’’ - 2.4” VC compression driver - 8 ohm
91AMD1012A Power amplier module with mechanical assembly 98MBN2065 tanium diaphragm for 1.4” driver
61.1 cm
24.0"
37.0 cm
14.6"
49.5 cm
19.5"
21.0 cm
8.27"
RIGGING ACCESSORIES
KPTAX1012 Coupling bar
weight = 0.75 Kg
KPTAX1012H
Horizontal array ying bar
weight = 0.95 Kg
note: the bar is supplied with 1 straight shackle.
KPTAX1012T
Suspension bar
weight = 2.2 Kg
note: the bar is supplied with 3 straight shackles.
KPTAX1012V
Vercal array ying bar
weight = 8.0 Kg
note: the bar is supplied with 1 straight shackle.
OTHER ACCESSORIES
KPAX265 Pole adapter
note: use it always in conjuncon with lt adapter
KP010 Tilt adapter
PLG714 Straight Shackle 14 mm for Fly bar weight = 0.35 Kg
AXFEETKIT Kit of 6pcs BOARDACF01 M10 foot for stacked installaon
DHSS10M20 Adjustable Sub-Speaker ø35mm spacer with M20 screw
94SPI8577O 8x63 mm Locking Pin (used on KPTAX1012, KPTAX1012H, KPTAX1012T)
94SPI826 8x22 mm Locking Pin (used on KPTAX1012H)
USB2CAN-D PRONET network converter
see hp://www.axiomproaudio.com/ for detailed descripon and other available accessories.
I/O AND CONTROL OPERATIONS
MAINS IN - Powercon® NAC3FCA power input connector (blue). To switch the amplier on,
insert the Powercon® connector and turn it clockwise into the ON posion. To switch the
amplier o, pull back the switch on the connector and turn it counter-clockwise into the
POWER OFF posion.
WARNING! In the case of product failure or fuse replacement, disconnect the unit
completely from the mains power. The power cable must be only connected to a
socket corresponding to the specicaons indicated on the amplier unit. The power
supply must be protected by a suitably rated thermo-magnec breaker. Preferably
use a suitable switch to power on the whole audio system leaving the Powercon®
always connected to each speaker, this simple trick extend the life of the Powercon®
connectors.
MAINS OUT - Powercon®
NAC3FCB power output
connector (grey). This is
connected in parallel with the
MAINS ~ / IN. The maximum
load applicable depends on
the mains voltage. With 230V~
we suggest to link a maximum
of 5 AX1012A loudspeakers,
with 120V~ we suggest to link
a maximum of 3 AX1012A
loudspeaker.
INPUT - Audio signal input
with locking XLR connector.
It has a fully electronically
balanced circuitry including
AD conversion for the best S/N
rao and input headroom.
LINK - A direct connection
from the input connector to
link other speakers with same
audio signal.
ON - This LED indicates power
on status.
SIGN/LIMIT - This LED lights in green to indicate the presence of the signal and lights in red when an internal limiter reduces the input level.
GND LIFT - This switch li the ground of the balanced audio inputs from the earth-ground of the module.
PRESET BUTTON - This buon has two funcons:
1) Pressing it while powering on the unit:
ID ASSIGN the internal DSP assigns a new ID to the unit for the PRONET remote control operaon. Each loudspeaker must have a unique
ID to be visible in the PRONET network. When you assign a new ID, all the other loudspeakers with the ID already assigned
must be ON and connected to the network.
2) Pressing it with the unit ON you can select the DSP PRESET. The selected PRESET is indicated by the corresponding LED:
SINGLE Suited for a typical use of a single loudspeaker on a pole, standalone or in combinaon with a subwoofer, or in a front ll
applicaon.
MID-THROW Suited for the use of the loudspeakers in an array conguraon when the distance between the array centre and the audience
area is about 25mt or less.
LONG THROW Suited for the use of the loudspeakers in an array conguraon when the distance between the array centre and the audience
area is about 40mt.
USER This LED lights when the USER PRESET is loaded. This preset corresponds to USER MEMORY no. 1 of the DSP and, as a factory
seng, it’s the same as SINGLE. If you want to modify it, you must connect the unit to a PC, edit the parameters with PRONET
AX control soware and save the PRESET in the USER MEMORY no. 1. Note: see also the PRONET AX example further in this
manual.
IMPORTANT NOTE: The AX1012A system is conceived as a CONSTANT CURVATURE ARRAYS loudspeaker so ALL AX1012A units that belong
to the same array must be have the same PRESET to work well together.
NETWORK IN/OUT - These are a standard RJ45 CAT5 connectors (with oponal NEUTRIK NE8MC RJ45 cable connector carrier), used for PRONET
network transmission of remote control data over long distance or mulple unit applicaons.
TERMINATE - In a PRONET network the last loudspeaker device must be terminated (with an inner load resistance) especially in a long run cabling:
press this switch if you want to terminate the unit.
25 m MID-THROW
40 m LONG-THROW
AUDIENCE FLOOR
POWER AMPLIFIERS
The AX1012A is powered by a DA SERIES digital power module, a new generaon of CLASS D power amplier with SMPS. The innovave technology
used for these ampliers oers top-of-the-range performances, such as a superior sound denion at any audio frequency, very high dynamics
even for low level signals, and very low distoron even at maximum power. The superior sound quality can be compared with top-of-the-range
AB-class analog systems, while the DA module features higher dynamic range, very compact size, light weight, and eciency above 90%.
Output power is opmised specically to the drive units for ecient power transfer, with the low frequency secon producing 900 was while
300 was is available for the high frequency compression driver.
WARNING It is strongly advisable to not install the loudspeakers with the back-plate exposed directly to sun rays for a long period of me,
because this could cause the amplier temperature protecon to trip in order to safeguard the system integrity.
SIGNAL PROCESSING
The system processing is based on the CORE DSP plaorm, which has been designed by the PROEL R&D Laboratories using one of the most
advanced SHARC DSP for audio applicaon. It features 40bit, 96kHz oang point resoluon and high quality 24bit AD/DA converters, for a perfect
signal integrity, a dynamic range in excess of 110dB and a superior sonic performance. Thanks to its massive processing power, the CORE plaorm
is capable of providing the most sophiscated algorithms for speaker processing, together with remote control and networking capability.
The PRONET AX control soware, working on a solid and reliable CANBUS based network protocol, provides an intuive interface for the remote
control of the whole system, with the possibility of eqing, delaying, increasing the protecons and monitoring the status of the amplier.
PRONET AX
PRONET AX soware has been developed in collaboraon with sound engineers and sound designers, in order to oer an “easy-to-use” tool to
setup and manage your audio system. With PRONET AX you can visualize signal levels, monitor internal status and edit all the parameters of each
connected device.
Download the PRONET AX app from the AXIOM website at hp://www.axiomproaudio.com/ clicking on downloads secon of the product.
The AXIOM acve loudspeaker devices can be connected in a network and controlled by the PRONET AX soware, for the network connecon the
PROEL USB2CAN (with 1-port) or the USB2CAN-D (with 2-port) converter oponal accessory is needed.
PRONET AX network is based on a “bus-topology” connecon, where the rst device is connected to the network input connector of the second
device, the second device network output is connected to the network input connector of the third device, and so on. To ensure a reliable
communicaon the rst and the last device of the “bus-topology” connecon must be terminated. This can be done by pressing the “TERMINATE”
switch near the network connectors in the rear panel of the rst and the last device. For the network connecons simple RJ45 cat.5 or cat.6
ethernet cables can be used (please don’t confuse a ethernet network with a PRONET AX network these are completely dierent and must be
fully separated also both use the same kind of cable).
Assign the ID number
To work properly in a PRONET AX network each connected device must have a unique idener number, called ID. By default the USB2CAN-D PC
controller has ID=0 and there can be only one PC controller. Every other device connected must have its own unique ID equal or greater than 1:
in the network cannot exist two devices with the same ID.
In order to correctly assign a new available ID to each device for working properly in a Pronet AX network, follow these instrucons:
1. Switch o all the devices.
2. Connect them correctly to the network cables.
3. “TERMINATE” the end device in the network connecon.
4. Switch on the rst device keep pressed “PRESET” buon on the control panel.
5. Leaving the previous device switched on, repeat the previous operaon on the next device, unl the latest device is turned on.
The “Assign ID” procedure for a device makes the internal network controller to perform two operaons: reset the current ID; search the rst free
ID in the network, starng from ID=1. If no other devices are connected (and powered on), the controller assume ID=1, that is the rst free ID,
otherwise it searches the next one le free.
These operaons ensure that every device has it’s own unique ID, if you need to add a new device to the network you simply repeat the operaon
of step 4. Every device maintains its ID also when it is turned-o, because the idener is stored in the internal memory and it is cleared only by
another “Assign ID” step, as explained above.
If you use a set of loudspeakers made always of the same devices, the assign ID procedure must be performed only the rst me the system
is turned on.
For more detais about PRONET see the PRONET AX USER’S MANUAL included with the soware.
PREDICTION: EASE Focus 3
To aim correctly a complete system we suggests to use always the Aiming Soware - EASE
Focus 3:
The EASE Focus 3 Aiming Soware is a 3D Acousc Modelling Soware that serves for the
conguraon and modelling of Line Arrays and convenonal speakers close to reality. It only
considers the direct eld, created by the complex addion of the sound contribuons of the
individual loudspeakers or array components.
The design of EASE Focus is targeted at the end user. It allows the easy and quick predicon
of the array performance in a given venue. The scienc base of EASE Focus stems from
EASE, the professional electro- and room acousc simulaon soware developed by AFMG
Technologies GmbH. It is based on the EASE GLL loudspeaker data le required for its use,
please note that the are mulple GLL les for the AX1012A systems. Each GLL le contains
the data that denes the Line Array with regard to its possible conguraons as well as to
its geometrical and acouscal properes that are dierent from vercal or horizontal applicaons.
Download the EASE Focus 3 app from the AXIOM website at hp://www.axiomproaudio.com/ clicking on downloads secon of the product.
Use the menu opon Edit / Import System Denion File to import the GLL les about AX1012A conguraons from the installaon Data folder,
the detailed instrucons to use the program are located in the menu opon Help / User’s Guide.
Note: Some windows system can require the .NET Framework 4 that can be download from microso website at hp://www.microso.com/en-
us/download/default.aspx.
WARNING! CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND CONDITION OF USE:
• This loudspeaker is designed exclusively for Professional audio applicaons. The product must be installed by qualied personal only.
• Proel strongly recommends that this loudspeaker cabinet be suspended taking into consideraon all current Naonal, Federal, State and
Local regulaons. Please contact the manufacturer for further informaon.
• Proel do not accept any liability for damage caused to third pares due to improper installaon, lack of maintenance, tampering or
improper use of this product, including disregard of acceptable and applicable safety standards.
• During assembly pay aenon to the possible risk of crushing. Wear suitable protecve clothing. Observe all instrucons given on the
rigging components and the loudspeaker cabinets. When chain hoists are in operaon ensure that there is nobody directly underneath or
in the vicinity of the load. Do not under any circumstances climb on the array.
Pin locking set up
This gure shows how to insert correctly the locking pin.
press and
insert
long locking pinshort locking pin
release and
lock press and
insert
release and
lock
LOCKING PINS INSERTION
RIGGING INSTRUCTIONS
AX1012A arrays deliver seamless coverage only to desired areas minimizing unwanted reecons of walls and surfaces or avoiding interacons
with other sound systems, with the stage or with other areas. Mulple units in horizontal or vercal array allow to shape the radiaon paern in
slices of 20°, providing exceponal exibility in the construcon of the desired coverage angle.
The AX1012A cabinet is provided with four integrated steel rails, to be used for coupling the cabinets with the KPTAX1012 aluminium coupling
bars. A comprehensive set of accessories is available for rigging horizontal or vercal arrays, for ground-stacking the systems and also for pole
mounng one or two units. The rigging system does not require addional adjustments, since the aiming angle of the array is determined only by
using the proper hole in the ying bars with the use of the predicng soware.
The following instrucons show how to proceed to assemble the speakers in order to form various type of array, starng from a simple 2 units
horizontal array to more complex ones: please read all of them carefully.
2-UNIT HORIZONTAL ARRAY
Follow the sequence below to couple two AX1012A units in an horizontal array: you can use the same procedure for assembling all horizontal
arrays. Each AX1012A has several bumpers on each side of the box that ts in the slots of the adjacent box: this allows to arrange the boxes
perfectly aligned for inserng easily the coupling and ying bars.
1) Place the box on the oor exactly under the liing point. 2) Remove the locking plate at the end of the ying bar.
3) Insert the bar in the rails from the front of the speakers. 4) Put back in place the locking plate and lock it with the pin.
5) Place the cam into the hole chosen for liing: always be sure that
all pins are rmly inserted in their posion.
6) Connect the liing system using the supplied shackle.
7) Li the system to an height that allows to insert the coupling bar
into the cabinet’s boom.
8) Remove the locking plate at the end of the coupling bar.
9) Insert the coupling bar in the rails from the front of the speakers. 10) Put back in place the locking plate and lock it with the pin.
HORIZONTAL ARRAY EXAMPLES
For more complex horizontal arrays made of from 3 to 6 units you can proceed in a similar way, assembling the whole system to the ground and
raising it up all together. The following gures show how to arrange 2 to 6 units horizontal arrays.
NOTE: remember that one PLG714 shackle is supplied with each KPTAX1012H horizontal ying bar and three PLG714 shackles are supplied with
each KPTAX1012T suspension bar.
AB
C
2x AX1012A HOR. ARRAY
40° x 100° coverage
72 Kg total weight
list of rigging material:
A) 1x KPTAX1012H
B) 1x PLG714
C) 1x KPTAX1012
AA
B
B
B
C
C
D
3x AX1012A HOR. ARRAY
60° x 100° coverage
111 Kg total weight
list of rigging material:
A) 2x KPTAX1012H
B) 5x PLG714
C) 2x KPTAX1012
D) 1x KPTAX1012T
CC
C
A
C
A
BB
B
D
4x AX1012A HOR. ARRAY
80° x 100° coverage
147 Kg total weight
list of rigging material:
A) 2x KPTAX1012H
B) 5x PLG714
C) 4x KPTAX1012
D) 1x KPTAX1012T
C
CC
C
C
AA
C
BB
B
C
5x AX1012A HOR. ARRAY
100° x 100° coverage
183 Kg total weight
list of rigging material:
A) 2x KPTAX1012H
B) 5x PLG714
C) 6x KPTAX1012
D) 1x KPTAX1012T
C
CC
C
C
C
C
A
A
C
B
B
B
D
6x AX1012A HOR. ARRAY
120° x 100° coverage
217 Kg total weight
list of rigging material:
A) 2x KPTAX1012H
B) 5x PLG714
C) 8x KPTAX1012
D) 1x KPTAX1012T
For horizontal arrays made of more than 6 loudspeakers, as a rule of thumb one KPTAX1012H ying bar should be used at most every two or three
boxes, as in the following examples. When ying arrays with more than 6 units, it is advisable to use mulple liing points connected directly to
the KPTAX1012H ying bars, without using the KPTAX1012T suspension bars.
A
A) KPTAX1012H HORIZONTAL ARRAY FLYING BAR
C) KPTAX1012 COUPLING BAR
A A A A
A
A A
A
A A
A
A
A A
A
A
C C C
C
C
C
C C
C
C
C C
C
2-UNIT VERTICAL ARRAY
Follow the sequence below to assemble up to four AX1012A units into a vercal array. Each AX1012A has several bumpers at each side of the box
that ts in the slots of the adjacent box: this allows to arrange the boxes perfectly aligned for inserng easily the coupling bars.
The rst step before liing up the system is to assemble the y bar to the rst box. Be careful to insert properly all the bars and their locking pins,
with the shackle in the right hole as specied by the aiming soware. When liing and releasing the system, always proceed slowly and gradually
step by step, being careful to correctly assemble all the rigging hardware and to avoid endangering yourself and your hands from being crushed.
NOTE: remember that one PLG714 shackle is supplied with the KPTAX1012V vercal ying bar.
1) Remove the pins at the end of the ying bar, insert the ying bar into the rails of the rst box.
2) Put back in place the pins in their hole, making sure that they are
inserted correctly. Fix the shackle in the chosen hole and link the
liing system.
3) Li the rst box, place the second box on the oor just
underneath the rst one. Let down slowly the rst box over
the second one, aligning the bumpers and the slots of the two
loudspeakers. Note: a proper wedge placed between the cabinet to
be linked and the oor can be useful.
4) Link the rst box to the second box using two coupling bars: remove the pins and the locking plates and insert the bars into the cabinet
rails from the front.
5) Put back in place the locking plates and x them reinserng the
pins in their hole.
6) Be sure that all hardware is rmly xed before liing the system
and proceeding to link the third and fourth boxes (if required).
Note: in a vercal array, since the rst unit can be connected to the ybar indierently from either side of the box, the HF horn can result either to
the le or to the right side of the array. In a small venue, could be a good choice to place the HF horns of each le and right array symmetrically
to the external, to obtain a more coherent stereo image in the centre of the venue. In medium or large venues the symmetrical HF horn placement
is less important due to the bigger distance between the le and right arrays.
VERTICAL ARRAY EXAMPLES
The following gures are examples of vercal arrays made of from 2 to 4 units. NOTE: 4 is the maximum number of units in a vercal array.
A
B
B
2x AX1012A VER. ARRAY
100° x 40° coverage
78.5 Kg total weight
list of rigging material:
A) 1x KPTAX1012V
B) 2x KPTAX1012
A
B
BB
B
3x AX1012A VER. ARRAY
100° x 60° coverage
114.5 Kg total weight
list of rigging material:
A) 1x KPTAX1012V
B) 4x KPTAX1012
A
B
B
B
B
B
B
4x AX1012A VER. ARRAY
100° x 80° coverage
150.5 Kg total weight
list of rigging material:
A) 1x KPTAX1012V
B) 6x KPTAX1012
DOWN-FIRING ARRAY EXAMPLE
One addional use of AX1012A in vercal array conguraon is as down-ring system, with a maximum of 4 units. In this case two KPTAX1012V
ying bars are used, one at each side of the array, so the array can be suspended from two points and aimed to be completely on the vercal axis,
as in the gure below:
66 cm
26"
137 cm
54"
AA
B (2x)
B (2x)
B (2x)
4x AX1012A DOWN-
FIRING VERTICAL ARRAY
100° x 80° coverage
158.5 Kg total weight
list of rigging material:
A) 2x KPTAX1012V
B) 6x KPTAX1012
Any hole of both flybar can
be used in the range of the
two quotes specified in the
drawing.
WIND LOADS
When planning an open-air event it is essenal to obtain current weather and wind informaon. When loudspeaker arrays are own in an open-air
environment, possible wind eects must be taken into account. Wind load produces addional dynamic forces acng on the rigging components
and the suspension, which may lead to a dangerous situaon. If according to the forecast wind forces higher than 5 b (29-38 Km/h) are possible,
the following acons have to be taken:
- The actual on-site wind speed has to be monitored permanently. Be aware that wind speed typically increases with height above ground.
- Suspension and securing points of the array should be designed to support double the stac load in order to withstand any addional dynamic
forces.
WARNING!
Flying loudspeakers overhead at wind forces higher than 6 b (39-49 Km/h) is not recommended. If the wind force exceeds 7 b (50-61
Km/h) there is a risk of mechanical damage to the components which may lead to a dangerous situaon for persons in the vicinity of the
own array.
- Stop the event and make sure that no person remains in the vicinity of the array.
- Lower and secure the array.
STACKED SYSTEMS
WARNING!
• The ground where the KPTAX1012V ying bar serving as ground support is placed must be absolutely stable and compact.
• Adjust the feet so to put the bar in a perfectly horizontal posion.
• Always secure ground stacked setups against movement and possible pping over.
• A maximum of 3 x AX1012A cabinets with the KPTAX1012V ying bar serving as ground support are allowed to be set up in a ground stack.
For the stack conguraon you must use four oponal BOARDACF01 feet and the y bar must be mounted upside down to the ground.
A
B
B
C
C
C
2x AX1012A STACKED
VER. ARRAY
100° x 40° coverage
78.5 Kg total weight
list of stacking material:
A) 1x KPTAX1012V
B) 2x KPTAX1012
C) 4x BOARDACF01
A
C
C
C
B
B
B
B
3x AX1012A STACKED
VER. ARRAY
100° x 60° coverage
114.5 Kg total weight
list of stacking material:
A) 1x KPTAX1012V
B) 4x KPTAX1012
C) 4x BOARDACF01
POLE MOUNTING
One single AX1012A loudspeaker can be also installed on a pole and used standalone or in combinaon with a sub woofer (suggested model is
SW1800A).
To install the AX1012A on a pole, the round plate on the le side of the loudspeaker must be replaced with the KPAX265 pole adapter (use a 4mm
hex key or screwdriver) and the KP010 lt adapter must be used as a link to the pole. If the AX1012A is installed on a subwoofer, we suggest to
use the DHSS10M20 pole to adjust the height. Set the lt angle to -10° to aim the loudspeaker parallel to oor (see gures below).
1) Remove the round plate. 2) Mount the KPAX265 pole adapter.
3) Insert the KP010 lt adapter into the KPAX265 and install the AX1012A to the pole. Aim the lt adapter 10° down to align the AX1012A
to the oor and x its pin. Adjust the pole’s height if needed.
KPAX065
KP010
DHSS10M20
.
LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner should inform about these defects
the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon. This warranty does not extend to damage resulng
from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is
sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me.
CE CONFORMITY
Proel products comply with direcve EMC 2014/30/CE, as stated in EN 55103-1 and EN 55103-2 standards and with direcve LVD 2014/35/CE, as stated in EN 60065
standard.
PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY
Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com
Table of contents
Other Axiom Speakers System manuals
