Axioma QALCOSONIC F2 Parts list manual

Axioma LEZ UAB
ULTRASONIC FLOW SENSOR
QALCOSONIC F2
TECHNICAL DESCRIPTION, INSTALLATION AND USER INSTRUCTIONS
PEF2V02
KAUNAS

PEF2V02 2017-11-20
2
Contents
SAFETY INFORMATION..............................................................................................................................3
1. APPLICATION FIELD .........................................................................................................................................3
2. TECHNICAL DATA .............................................................................................................................................5
3. OPERATING PRINCIPLE ...................................................................................................................................7
4. MARKING AND SEALING..................................................................................................................................7
5. SAFETY REQUIREMENTS.................................................................................................................................7
6. INSTALLATION...................................................................................................................................................8
7. OPERATION......................................................................................................................................................10
8. VERIFICATION..................................................................................................................................................10
9. TRANSPORTATION AND STORAGE REQUIREMENTS................................................................................10
Annex A.................................................................................................................................................................11
Annex B.................................................................................................................................................................13
Annex C.................................................................................................................................................................18
WARRANTY...........................................................................................................................................................19
For EU Customers only - WEEE Marking.
The device is classified as waste electronic equipment in terms of the European Directive 2012/19/EU
(WEEE). Marking of electrical and electronic equipment in accordance with Article 14 (2) of Directive
2012/19/EU
This symbol on the product indicates that it must not be disposed of as unsorted municipal waste. It must be
handed over to the applicable take-back scheme for the recycling of electrical and electronic equipment.
Observe all local and applicable laws. For more detailed information about the recycling of this product, please
contact your local municipal office.

PEF2V02 2017-11-20
3
SAFETY INFORMATION
Before beginning installation works you must to read this document and follow its instructions.
•Risk factors during the flowmeter installation and service is a heat conveying fluid flowing within flow sensor with
inner pressure up to 1,6 (2,5) MPa and temperature up to 130 0C.
•To eliminate this risk the service and installation works must be performed by qualified technical personnel.
Personnel must be familiar with appropriate technical documentation and general safety instructions.
•It is necessary to follow general safety requirements during installation and maintenance process.
•Protective grounding is not required, because housing is made from plastics, and conductive parts are not
exposed to the surface.
•Safety guarantees at installation and service of meter is:
- Reliable insulation of electrical circuits,
- Hermetic fitting of primary flow sensor into the pipeline,
- Reliable fastening of sub-assemblies of heat meter at installation.
Warning! Mounting of the flowmeter is permissible only after ensuring of absence of heat conveying
fluid in the pipeline.
By connecting the flow sensor to the external pulse registration device which is powered via AC 230V
check the proper grounding of external device.
Caution: If this equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
1. APPLICATION FIELD
Ultrasonic flow sensor QALCOSONIC F2 is designed as sub-assembly of heat meter for measuring heat-
conveying liquid volume in heating/cooling systems and conversion it into electrical pulse signal. It is used in conjunction
with the type approved heating/cooling energy calculator.
As a component of heat energy meter the QALCOSONIC F2 flow sensor could be used for commercial account
of energy quantity in district heating plants, in factories, in single or multifamily houses.
The flow sensor can be mounted in both flow and return pipe.
QALCOSONIC F2 corresponds to essential requirements of the Technical Regulation for Measuring
Instruments, dated 30 October 2015 (transposing in the NB’s country law Directive 2014/32/EU of 26 February 2014 on
measuring instruments):
- Annex I Essential requirements
- Annex VI (MI-004)Thermal energy meters
QALCOSONIC F2 complies with the standard EN 1434 “Heat meters”.
QALCOSONIC F2 meets the requirements according to accuracy class 2 of EN1434
QALCOSONIC F2 fulfils “C” class environment protection requirements according to EN1434-1
Climatic ambient temperature range: from 5 ° to 55 ° C,
Humidity level: condensing, location: closed,
Mechanical environment class: M1 ,
Electromagnetic environment class: E2.
Storage and transportation temperature: -25°C...60 °C (drained flow part)

PEF2V02 2017-11-20
4
Type number combination of the ultrasonic flow sensor:
Remark:
* - marked numbers are used for order numbering only
Type
Technical data of the flow sensor:
Permanent
flow-rate, m3/h
Overall length,
mm
End connections
Code
0,6
110
G ¾
1
1,0
110
G ¾
2
1,5
110
G ¾
3
1,5
165
G ¾
N
1,5
130
G1
M
2,5
130
G1
4
3,5
260
G1 ¼
5
6,0
260
G1 ¼
6
10,0
300
G2
7
10,0
300
DN40
8
15,0
270
DN50
9
3,5
260
DN25
A
6,0
260
DN25
B
0,6
190
G1
C
1,0
190
G1
D
1,5
190
G1
E
2,5
190
G1
F
0,6
190
DN20
G
1,0
190
DN20
H
1,5
190
DN20
K
2,5
190
DN20
L
3,5
260
DN32
O
6,0
260
DN32
P
25
300
DN65
R
40
350
DN80
S
40
300
DN80
U
60
350
DN100
T
60
360
DN100
V
Ratio of flow-rate limits (qp/qi):
Code
100
1
250
(with the exeptions of sensors qp=0,6 m3/h; 1,0 m3/h; 3,5 m3/h)
2
Length of the connection cable between measuring section and electronic unit:
Cable length
Code
1,2 m
1
2,5 m
2
5 m
3
QALCOSONIC F2–111 –NM - 1 - 0*
Pulse value of the flow sensor
M
N− 10
m3/pulse*
* - where N- possible number 1...9, M –possible number 1...6.
Power supply:
Code
Internal battery 3,6 V
1
External 24 V AC/DC
2
Length of the pulse output device connection cable, m:
3; 5; 10; 15... 200, 0 (or omitted) - none

PEF2V02 2017-11-20
5
2. TECHNICAL DATA
Accuracy class 2 by LST EN1434-1.
Flow measurement
The ratio of the permanent flow-rate to the lower limit of the flow-rate (the user selects during order):
qp/qi =100,
or qp/qi =250 (with the exceptions of sensors qp =0,6 m3/h; 1,0 m3/h; 3,5 m3/h)
Flow sensor can be delivered for threaded connection (up to qp=10,0 m3/h) or flanged.
Technical data of the flow sensor are presented in table 1.1
Table 1.1
Limits of flow rate, m3/h
Threshold
value of flow
rate, m3/h
Overall
length L,
mm
Pressure
losses at
qp, kPa
Joining to the pipeline
(Thread –G, flange–
DN)
Permanent
flow rate qp,
m3/h
Upper
flow rate qs,
m3/h
Lower
flow rate qi,
m3/h
0,6
1,2
0,006
0,003
110
7
G3/4“
0,6
1,2
0,006
0,003
190
0,9
G1“, DN20
1,0
2,0
0,01
0,005
110
11,3
G3/4“
1,0
2,0
0,01
0,005
190
2,5
G1“, DN20
1,5
3,0
0,006
0,003
110; 165
17,1
G3/4“
1,5
3,0
0,006
0,003
190
5,8
G1“, DN20
1,5
3,0
0,015
0,003
110; 165
17,1
G3/4“
1,5
3,0
0,015
0,003
190
5,8
G1“, DN20
1,5
3,0
0,015
0,005
130
7,2
G1“
2,5
5,0
0,01
0,005
130
19,8
G1“
2,5
5,0
0,01
0,005
190
9,4
G1“, DN20
2,5
5,0
0,025
0,005
130
19,8
G1“
2,5
5,0
0,025
0,005
190
9,4
G1“, DN20
3,5
7,0
0,035
0,017
260
4
G1 1/4“,DN25,DN32
6,0
12,0
0,024
0,012
260
10
G1 1/4“,DN25,DN32
6,0
12,0
0,06
0,012
260
10
G1 1/4“,DN25,DN32
10,0
20,0
0,04
0,02
300
18
G2“, DN40
10,0
20,0
0,100
0,02
300
18
G2“, DN40
15,0
30,0
0,06
0,03
270
12
DN50
15,0
30,0
0,15
0,03
270
12
DN50
25
50
0,1
0,05
300
20
DN65
25
50
0,25
0,05
300
20
DN65
40
80
0,16
0,08
300; 350
18
DN80
40
80
0,4
0,08
300; 350
18
DN80
60
120
0,24
0,12
350; 360
18
DN100
60
120
0,6
0,12
350; 360
18
DN100
Temperature limits of heat conveying liquid: 5 oC....130 oC.
Note:
For heating medium temperature below 90 oC the electronic unit can remain on the flow sensor
or be mounted on the wall,
For heating medium temperature above 90 oC the electronic unit must be mounted on the wall
Connection cable length between the electronic
unit and the flow sensor 1,2 m- standard version
(2,5 m; 5 m. –optional)
Maximum admissible working pressure PS
(Nominal pressure PN) 16 bar or 25 bar
Behaviour of the meter, when the flow rate exceeds the maximum value qs:
- At the flow rate q < 1,2 ∙ qs -linear,
- At the flow rate q > 1,2 ∙ qs - constant (q = 1,2 ∙ qs is applied to calculations of thermal energy). The
error „Maximum allowable value of flow rate is exceeded“ is registered and duration of error is calculated.

PEF2V02 2017-11-20
6
Pulse outputs
Class of flow output device OD according to EN1434-2
Pulse value is freely ordered of the range of values m3/imp (where N - possible number from 1 to 9, M
- possible number from 1 to 6)
Permissible minimal pulse value of volume and recommended pulse value, depending on the permanent flow rate:
Table 1.2
Permanent flow rate qp, m3/h
0,6
1
1,5
2,5
3,5
6
10
15
25
40
60
Permissible minimal pulse value
of volume, l/pulse
0,01
0,01
0,02
0,05
0,1
0,1
0,2
0,5
1
Recommended pulse value, l/pulse, if the flow
sensor is operating in conjunction with
calculator , which is powered from battery,
(in brackets –recommended pulse value
code NM)
0,2
(24)
0,5
(54)
1
(13)
1
(13)
2
(23)
5
(53)
10
(12)
10
(12)
20
(22)
Supply voltage:
Internal battery size AA, 3,6 V, 2,4 Ah, lithium battery (Li-SOCl2)
service life not less than 12 years;
Or two internal batteries size AA, 3.6 V 2.4 Ah, service life not less than 16 years,
External power supply 12 V…42 V DC or 12 V…36 V,50/60 Hz AC, 10 mA max
+ internal backup battery: size AA, 3,6 V, 2,4 Ah, lithium battery
(Li-SOCl2) service life not less than 12 years (without data reading
via a digital interface) –for powering of the meter, when the external
power supply is turned off.
External power supply module is mounted inside in the meter.
Mechanical data:
Dimensions of electronic unit, not more than 117 mm x 44 mm x 89,5 mm,
Dimensions of flow sensors According to Annex B
Weight:
Table 1.3
Connection type and mounting length in mm of flow sensor
Weight of sensor, not more than, kg
G3/4“ , 110 mm
0,7
G3/4“ , 165 mm
0,8
G1“ , 130 mm
0,8
G1“ , 190 mm
0,9
DN20
2,5
G1 ¼“
3,2
DN25
5,6
DN32
6,1
G2“
3,7
DN40
6,8
DN50
8,5
DN65
13,0
DN80
15,0
DN100
18,0
Environmental class Meets EN1434 class C
Ambient temperature:
Electronic unit at +5 oC to +55 oC
(Non-condensing, indoor installation)
Flow sensors at -30 oC to 55 oC
Relative humidity < 93 
Mechanical environment class: M1
Electromagnetic environment class: E2
Protection class of electronic unit enclosure IP65
Protection class of flow sensor enclosure IP65 (IP67 –by special order)

PEF2V02 2017-11-20
7
3. OPERATING PRINCIPLE
The flow measuring principle is based on ultrasonic measurement method. The ultrasonic signal along the
measuring section moves many times upstream and downstream between the ultrasonic sensors, who alternately
performs transmitter and receiver functions. From the resulting time difference the flow rate is calculated. Measured
flow rate is converted into the pulses quantity that is transferred in output pulse terminal.
4. MARKING AND SEALING
4.1. Marking:
Marking of electronic unit
There are following information on the front panel of electronic unit - manufacturer’s trade mark, type of
sensor, serial number, year of manufacture, EC-type examination certificate number, accuracy class,
environmental class by LST EN1434-1, electromagnetic and mechanical environmental class, enclosure protection
class, the limiting values of the flow rate (qi,qp,qs), output pulse value, maximum temperature range for flow
sensor, the maximum admissible working pressure.
Numbers of terminal pins are marked close to the terminal
Marking of flow sensor
There are following information on the flow sensor:
-nominal diameter,
- arrow for indication of a flow direction
4.2. Security seals:
The following sealing of electronic unit is provided
Manufacturer‘s adhesive seal-sticker on the access to the adjustment activation jumper (see Annex C,
fig.C1, pos.1) and on the fixer on the cover protecting electronic wiring plate (see Annex C, fig.C1, pos.2)
The following measuring section sealing is provided
Manufacturer‘s adhesive seal-sticker on the screws of protective cover of flow sensor (see Annex C,
fig.C2a; b; c; d; e).
Manufacturer‘s hanged seals on ultrasonic transducers for flow sensors with steel body (see Annex C,
fig.C2 f).
Mounting seal
After installation the case and cover of the electronic unit (see Annex C, fig.C1, pos.3) are sealed with two
hanged seals of heat supplier.
5. SAFETY REQUIREMENTS
Before beginning installation works you must to read this document and follow its instructions.
•Risk factors during the flowmeter installation and service is a heat conveying fluid flowing within flow sensor
with inner pressure up to 1,6 (2,5) MPa and temperature up to 130 0C.
•To eliminate this risk the service and installation works must be performed by qualified technical personnel.
Personnel must be familiar with appropriate technical documentation and general safety instructions.
•It is necessary to follow general safety requirements during installation and maintenance process.
•Protective grounding is not required, because housing is made from plastics, and conductive parts are not
exposed to the surface.
•Safety guarantees at installation and service of meter is:
- Reliable insulation of electrical circuits,
- Hermetic fitting of primary flow sensor into the pipeline,
- Reliable fastening of sub-assemblies of heat meter at installation.
Warning! Mounting of the flowmeter is permissible only after ensuring of absence of heat
conveying fluid in the pipeline.
By connecting the flow sensor to the external pulse registration device which is powered via AC
230V check the proper grounding of external device.

PEF2V02 2017-11-20
8
6. INSTALLATION
6.1. Basic requirements
Before installing the device:
- check if all parts listed in the documentation are available,
- check if there are no visible mechanical defects,
- check if there are valid labels of manufacturer and certification authority.
Only qualified personnel may install the equipment, following the requirements listed in this document, in
technical documentation of other system components and in heat meter installation project
It is forbidden to wire signal cables nearby (less than 5 cm) with power cables or cables of other devices.
6.2. Electrical wiring
Factory installed pulse cable
The cable cannot be removed, shortened or extended, if the pulse cable is already installed.
Customer pulse cable
Connection of the customer pulse cable. It is recommended to use copper wire cable with the cross-section
(0.2 ... 0.5) mm2.
By means of tweezers remove a protective knoll from 1 sealant hole of electronic unit. Run the cable
through the hole and anchor with clamp. Use two wire connection methods –connect to the terminals 18 and 19 as
shown in Annex A, Fig.A1.
6.3 Mounting
Mounting of electronic unit
Electronic unit may be installed in heated premises; working ambient temperature shall be not more than
55 ° C. It may not be exposed to direct sunlight.
Electronic unit can be mounted in several different ways:
- Direct mounting on ultrasonic flow sensor housing, turning every 90o(only when the temperature
of the flow does not exceed 90 ° C):
a) On the flow sensor with a thread connection
b) On the flow sensor with flange connection
- Wall mounting:

PEF2V02 2017-11-20
9
- Mounting on standard DIN-rail:
 Important: It is forbidden to attach the electronic unit directly to a wall if there is a risk that on walls
can be condensed humidity or temperature of a surface of a wall can fall lower than 5 °. In this case, it
is recommended to attach the calculator so that between it and wall surfaces there were an air gap not
less than 5 cm.
Mounting of flow sensor measuring section
Sizes and mounting dimensions of flow sensors are provided in Annex B.
Requirements for flow sensor installation in pipeline:
- For flow sensors DN15…DN50 no requirements for straight pipeline length in upstream and downstream
directions.
- For flow sensors DN65, DN80 and DN100 necessary straight pipelines lengths are: upstream straight
pipeline length must be not less 5DN and downstream straight pipeline length must be not less 3DN.
Avoid the flow sensor installation near after the pumps which can cause cavitations.
Flow sensor can be mounted in horizontal, vertical or inclined positions in return or flow. Necessary
condition in normal working mode: pipeline must be under pressure and fully filled with heat conveying liquid.
The location and position of the flow sensor must be selected in such a way as to reduce the risk of
accumulation of air bubbles in the zone of ultrasonic sensors (Fig. 6.1).
a) Permissible installation position b) The installation position is prohibited.
(the air bubbles may accumulate)
Fig.6.1. Mounting Position of the flow sensors qp 3,5 m3/h... qp 60 m3/h
The direction of the sensor installation (is indicated with the arrow on the label of flow sensor) must match
with the flow direction in pipeline.
The flange gaskets must match with the pipe diameter. During the installation gasket must be exactly
centred with the centre of the pipe cross-section to avoid sticking out gaskets inside the pipe.
6.4. Sealing after installation
The sensor must be sealed according to p.4.2 to ensure that after the installation, it is not possibility of
dismantle, remove or altering the meter without evident damage on the meter or the seal.
Mounting seal:
After installation the case and cover of the electronic unit (see Annex C, fig.C1, pos.3) are sealed with two
hanged seals of heat supplier.
Connection of flow sensor with the pipeline should be sealed in addition.

PEF2V02 2017-11-20
10
7. OPERATION
Destination of contacts of connector J
The 2-line, 10-pole connector is on the electronic unit plate. Destination of contacts of connector J is presented in
fig. 7.1.
Fig. 7.1. Destination of contacts of connector J
Values of output pulses in test mode are presented in Table 7.1
Table 7.1. Values of output pulses
Nominal (permanent) flow rate qp
Pulse value, l/pulse
0,6/1,0
0,002
1,5
0,004
2,5
0,005
3,5/6
0,02
10/15/25
0,05
40/60
0,2
Activation of test (verification) mode
In test mode it is possible to achieve precise results within short measuring time.
For activation of Verification (Test) mode you must opening device and set up jumper on the connector (J)
contacts as shown in Figure 7.2.
Fig. 7.2. Test mode activation
For working in this mode, the calculator cannot be closed.
When the jumper “J” is set, output pulses are formed.
Ending of verification mode
Remove jumper “J” to leave test mode and return to normal mode.
Note: In normal mode the jumper “J’ must be removed.
8. VERIFICATION
Metrological control of flow sensor parameters is performed according to requirements defined in EN 1434-5.
9. TRANSPORTATION AND STORAGE REQUIREMENTS
Requirements for safe transportation and storage of temperature and pressure sensors are
provided in relevant technical documentation.
Packed equipment may be transported in any type of covered vehicle. Equipment should be anchored
reliably to avoid shock and possibility to shift inside vehicle.
Equipment should be protected against mechanical damage and shock.
No aggressive chemical substances should be stored together because of corrosion hazard.

PEF2V02 2017-11-20
11
Annex A
Electrical wiring diagrams of flow sensor QALCOSONIC F2
Fig.A1. Electrical wiring diagram

PEF2V02 2017-11-20
12
Annex A
Fig.A2. Wiring diagrams for connecting of the sensor to the external power supply
Table A1. Numbering of terminals
Terminal No.
Destination
18
Output pulses of volume (+)
19
GND (-)
Numbering of external power supply module terminals
Terminal No.
Destination
54
24 V AC/DC external power supply voltage
55
24 V AC/DC external power supply voltage

PEF2V02 2017-11-20
13
Annex B
Fig. B1. Mechanical dimensions of electronic unit of the flow sensor
Fig.B2. Sizes and dimensions of the flow sensor
Fig.B2.1. Threaded end connections G3/4“, Fig.B2.2. Threaded end connections G1“,
Mounting length L=110 mm or L=165 mm mounting length L=130 mm
a) b)
Fig.B2.3. Threaded end connections G1“(a); Flanged end connection DN20 (b)
Mounting length L=190 mm

PEF2V02 2017-11-20
14
Annex B
a) Threaded end connections G1 1/4
b) Flanged end connection DN25

PEF2V02 2017-11-20
15
Annex B
c) Flanged end connection DN32
Fig.B2.4. Threaded end connections G1 1/4“(a); Flanged end connection DN25 (b);
Flanged end connection DN32 (c); mounting length L=260 mm
a)
b)

PEF2V02 2017-11-20
16
c)
Fig.B2.5. Threaded end connections G2“(a); flanged end connection DN40 (b;c) (two design options)
Mounting length L=300 mm

PEF2V02 2017-11-20
17
Annex B
a) Dimensions of flow sensors DN50, DN65, DN80, DN100 ( Brass housing)
DN65/PN16
DN65/PN25
DN80
DN100
L
300
300
350
350
D
185
185
200
220
H
185
185
200
220
D1
145
145
160
180
B
200
200
215
235
D2
18
18
18
18
n
4
8
8
8
b) Dimensions of flow sensors DN65, DN80, DN100 (Steel housing)
Fig. B2.6. Dimensions of flow sensors DN50, DN65, DN80, and DN100

PEF2V02 2017-11-20
18
Annex C
Security sealing
Fig.C1. Sealing of the electronic unit for flow sensor QALCOSONIC F2
Electronic general view: the cover is closed, and the cover is opened
(1-Manufacturer security seal- adhesive sticker, 2-manufacturer warranty seal- adhesive sticker, 3 –mounting seal)
a) Flow sensor G 3/4“ b) Flow sensor G 1“or DN20
1 1 1 1
c) Flow sensor G 1 ¾“; DN25 or DN32 d) Flow sensor G 2“or DN40
111 1
e) Flow sensor DN50, DN65, DN80, DN100 f) Flow sensor DN65, DN80, DN100
(Brass housing) (Steel housing)
Fig.C2. Flow sensors sealing (a;b;c;d;e - 1- manufacturer’s adhesive seal-sticker on the bolts of the cover; f –
manufacturer’s hanged seal)
1
1

PEF2V02 2017-11-20
19
WARRANTY
Manufacturer gives the warranty that equipment parameters will meet the technical requirements, listed in
the paragraph 2 of this document, if transportation, storage and operation conditions will be followed.
Warranty period - 12 months from bringing into operation, but not more than 18 months from manufacturing
date.
Manufacturer’s address:
UAB “Axioma LEZ ”, Kulautuvos g. 45a, Kaunas LT-47190, Lithuania
tel. [phone]; fax. [phone].
