Axion PLC-101 User manual

Installation Guidance PLC-101
Rear / Side / Backing Up-Monitoring System.
Receiver Installation
Transmitter Installation
-Cable description included.
AXION AG
Roentgenstrasse 4
D-89264 Weissenhorn
GERMANY
[e-mail]
www.axionag.com
Tel.: [phone]
Fax:[phone]
All manuals and user guides at all-guides.com

Receiver Cable description.
to backup lights direction
from Battery directi
on
Body GND
Black
Fuse socket
Video
Black : GND
Red : Battery
Green : Reverse
Rear / Side / Backing Up-Monitoring System
.
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Key Position :
"ACC"
Gear lever should be in
"R" position
Please find the backing up lights fuse in the fuse box.
(Refer to electrical diagram on the fuse box cover.)
Backing up lights fu
se
Receiver Installation
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Receiver Installation
Pick up the backing up lights fuse
using a fuse puller.
Then, please insert it to RX fuse socket.
(Refer to picture A-6)
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Receiver Installation
Please check power directions (from battery / to backup lights)
in the fuse using indicator.
position 1
position 2
Body GND
(main chassis or bolt.)
1. After you find the right fuse, please earth the indicator to main chassis or bolt.
2. If you check position 1. 2, you can figure out which position
has signal (indicator sound or light)
Attention : sometimes gear lever should be in "R" position.
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Receiver Installation
position 1
position 2
Please connect the cables as below.
If there is sound or light in position 2,
please connect RED wire (from battery direction) .
Please connect YELLOW wire (to backup lights direction) in position
1.
Body GND
Video
Black : GND
Red : Battery
Green : Reverse
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Transmitter Cable description.
Red : light
Black : GND
Black : GND
Yellow : battery
to backup lights
to camera
Black : GND
Red : +12V
Yellow : Vide
o
All manuals and user guides at all-guides.com

Rear / Side / Backing Up-Monitoring System
.
Transmitter Installation
Black : GND
Red : +12V
Yellow : Video
Backup
lights
Tail
lights
Break
lights
Turn
Signals
Mark
lights
must be cut
