Axis T8129 User manual

USER GUIDE
ENGLISH DEUTSCH ITALIANO ESPAÑOL
FRAN
Ç
AIS
AXIS T8129 PoE Extender

Electromagnetic Compatibility (EMC)
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures: Re-orient or relocate
the receiving antenna. Increase the separation
between the equipment and receiver. Connect
the equipment to an outlet on a different circuit
to the receiver. Consult your dealer or an
experienced radio/TV technician for help.
Shielded (STP) network cables must be used with
this unit to ensure compliance with EMC
standards.
CLASS B USA:
This equipment has been tested using a shielded
network cable (STP) and found to comply with
the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Equipment Modifications
This equipment must be installed and used in
strict accordance with the instructions given in
the user documentation. This equipment
contains no user-serviceable components.
Unauthorized equipment changes or
modifications will invalidate all applicable
regulatory certifications and approvals.
Liability
Every care has been taken in the preparation of
this document. Please inform your local Axis
office of any inaccuracies or omissions. Axis
Communications AB cannot be held responsible
for any technical or typographical errors and
reserves the right to make changes to the
product and documentation without prior
notice. Axis Communications AB makes no
warranty of any kind with regard to the material
contained within this document, including, but
not limited to, the implied warranties of
merchantability and fitness for a particular
purpose. Axis Communications AB shall not be
liable nor responsible for incidental or
consequential damages in connection with the
furnishing, performance or use of this material.
RoHS
This product complies with both the
European RoHS directive, 2002/95/EC,
and the Chinese RoHS regulations,
ACPEIP.
WEEE Directive
The European Union has enacted a
Directive 2002/96/EC on Waste
Electrical and Electronic Equipment
(WEEE Directive). This directive is
applicable in the European Union member
states.
The WEEE marking on this product (see right) or
its documentation indicates that the product
must not be disposed of together with
household waste. To prevent possible harm to
human health and/or the environment, the
product must be disposed of in an approved and
environmentally safe recycling process. For
further information on how to dispose of this
product correctly, contact the product supplier,
or the local authority responsible for waste
disposal in your area.
Business users should contact the product
supplier for information on how to dispose of
this product correctly. This product should not
be mixed with other commercial waste. For more
information, visit www.axis.com/techsup/.
Support
Should you require any technical assistance,
please contact your Axis reseller. If your
questions cannot be answered immediately, your
reseller will forward your queries through the
appropriate channels to ensure a rapid response.
If you are connected to the Internet, you can:
• download user documentation and firmware
updates
• find answers to problems in the FAQ database.
Search by product, category, phrases.
• report problems to Axis support by logging in
to your private support area.

AXIS T8129 PoE Extender Page 5
ENGLISH
AXIS T8129 PoE Extender User Guide
Hardware overview
PoE extender
Network connector
LED indicators
Camera
PoE extender
Switch
Midspan
Max 100 m (328 ft.) Max 100 m

Page 6 AXIS T8129 PoE Extender
Technical Specifications
Item Specifications
Model AXIS T8129 PoE Extender
Data rate 10/100 Mbps half/full duplex
Connectors Shielded RJ-45, EIA 568A and 568B
Network cables Shielded category 5 (or higher)
Display and
indicators
LED indicators are located on the RJ-45 connector
Power indicator: PoE enabled (Green)
Network indicator: Link/activity (Yellow)
Compliance IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE
Mounting Wall or shelf
Environment Indoor
Approvals FCC part 15, Class B with FTP cabling, EN 55022 Class B
(Emissions), EN 55024 (Immunity)
Operating
conditions
-10 °C to 50 °C (14 °F to 122 °F)
Humidity max. 85% RH (non-condensing)
Storage -40 °C to 74 °C (-40 °F to 165 °F)
Dimension
(HxWxD)
105 x 40 x 22 mm (4.1” x 1.6” x 0.9”)
Weight 45 g (1.6 oz.)

AXIS T8129 PoE Extender Page 7
ENGLISH
Maximum Distances for Power Sources
Multiple PoE extenders can be connected every 100 meters to obtain
greater distances. The actual figures depend on operating conditions.
The range is over 24 AWG or heavier Cat-5e or Cat-6 cable except
where specified.
Examples for low-power PoE cameras (that are PoE Class 1, or require
under 6 watts):
• AXIS M11 Network Camera Series
• AXIS 221 Network Camera
• AXIS M30 Network Camera Series
• AXIS M31-R/-VE Network Camera Series
• AXIS M32 Network Camera Series
• AXIS P33 Network Cameras (indoor models)
• AXIS 212 PTZ/-V Network Camera
PoE Source
PoE switch or Axis 15 W
midspan (802.3at) PoE+ switch (802.3at) Axis 30 W midspan (802.3at)
300 m (984 ft.) 400 m (1312 ft.) 400 m (1312 ft.)

Page 8 AXIS T8129 PoE Extender
Examples for medium power PoE cameras that are PoE Class 1 or 2, or
require under 12 watts:
• AXIS M1054 Network Camera
• AXIS P13 Network Cameras (indoor models)
• AXIS Q16 Network Cameras (indoor models)
• AXIS Q1755 Network Camera
• AXIS Q19 Network Camera Series
• AXIS P33 Network Cameras (outdoor models)
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
200 m (656 ft.) 200 m (656 ft.) 300 m (984 ft.)

AXIS T8129 PoE Extender Page 9
ENGLISH
Examples for full power PoE or PoE+ cameras that are PoE 802.3af
class 3 that require more than 12 watts, or 802.3at compliant:
• AXIS P13-E Network Cameras
• AXIS Q16-E Network Cameras
• AXIS Q1755-E Network Camera
• AXIS P55 Network Camera Series
• AXIS Q60 Network Cameras (indoor models)
Examples for Custom High PoE cameras:
• AXIS Q60-E Network Cameras
*use 23AWG or heavier cable (typically Cat 6)
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
not applicable not applicable 200 m (656 ft.)*
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
not applicable not applicable 200 m (656 ft.)*
(together
with Axis 60 W
midspan)

PoE Extender AXIS T8129 Page 11
FRAN
Ç
AIS
PoE Extender AXIS T8129
Guide de l'utilisateur
Vue d’ensemble du matériel
Rallonge PoE
Connecteur réseau
Voyants lumineux
Caméra
Rallonge PoE
Commutateur
Injecteur
Max. 100 m (328 pi.) Max. 100 m

Page 12 PoE Extender AXIS T8129
Caractéristiques techniques
Élément Caractéristiques
Modèle PoE Extender AXIS T8129
Débit 10/100 Mb/s duplex intégral ou semi-duplex
Connecteurs RJ-45 blindé, normes EIA 568A et 568B
Câbles réseau Blindé catégorie 5 (ou supérieure)
Affichage et
indicateurs
Les voyants DEL sont situés sur le connecteur RJ-45
Voyant d'alimentation : PoE activée (Vert)
Voyant réseau : lien/activité (jaune)
Conformité IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE
Fixation Mur ou étagère
Environnement Intérieur
Approbations FCC partie 15, classe B avec câble FTP, EN 55022 classe B
(Émissions), EN 55024 (Immunité)
Conditions
d'utilisation
de -10 °C à 50 °C (de 14 °F à 122 °F)
Humidité maximale relative de 85% (sans condensation)
Stockage de -40 °C à 74 °C (de -40 °F à 165 °F)
Dimension
(H x L x P)
105 x 40 x 22 mm (4,1 x 1,6 x 0,9 po)
Poids 45 g

PoE Extender AXIS T8129 Page 13
FRAN
Ç
AIS
Distances maximales pour les sources d'alimentation
Plusieurs rallonges PoE peuvent être branchées tous les 100 mètres
pour couvrir de plus grandes distances. Les chiffres réels dépendent
des conditions d'utilisation. La gamme est supérieure à 24 AWG ou un
câble catégorie 5 ou 6 plus lourd, sauf dispositions contraires.
Exemples pour des caméras alimentées par Ethernet (PoE) faible
puissance (ce qui correspond à une PoE classe 1 ou requiert moins de 6
watts) :
• Série de caméras réseau AXIS M11
• Caméra réseau AXIS 221
• Série de caméras réseau AXIS M30
• Série de caméras réseau AXIS M31-R/-VE
• Série de caméras réseau AXIS M32
• Caméras réseau AXIS P33 (modèles d'intérieur)
• Caméra réseau AXIS 212 PTZ/-V
Source de PoE
Commutateur PoE ou
injecteur
Axis 15 W (802.3at)
Commutateur PoE+
(802.3at)
Injecteur Axis 30 W
(802.3at)
300 m (984 pi.) 400 m (1312 pi.) 400 m (1312 pi.)

Page 14 PoE Extender AXIS T8129
Exemples pour des caméras alimentées par Ethernet (PoE) moyenne
puissance (ce qui correspond à une PoE classe 1 ou 2, ou bien requiert
moins de 12 watts):
• Caméra réseau AXIS M1054
• Caméras réseau AXIS P13 (modèles d'intérieur)
• Caméras réseau AXIS Q16 (modèles d'intérieur)
• Caméra réseau AXIS Q1755
• Série de caméras réseau AXIS Q19
• Caméras réseau AXIS P33 (modèles d'extérieur)
Source de PoE
Commutateur PoE ou
injecteur Axis 15 W
(802.3at)
Commutateur PoE+
(802.3at)
Injecteur Axis 30 W
(802.3at)
200 m (656 pi.) 200 m (656 pi.) 300 m (984 pi.)

PoE Extender AXIS T8129 Page 15
FRAN
Ç
AIS
Exemples pour les caméras pleine puissance PoE ou PoE+ qui
correspondent à une PoE 802.3af classe 3 qui requiert plus de 12 watts,
ou est conforme à la norme 802.3at :
• Caméras réseau AXIS P13-E
• Caméras réseau AXIS Q16-E
• Caméra réseau AXIS Q1755-E
• Série de caméras réseau AXIS P55
• Caméras réseau AXIS Q60 (modèles d'intérieur)
Exemples pour les caméras à PoE élevée personnalisée :
• Caméras réseau AXIS Q60-E
*utiliser un câble de 23 AWG ou plus lourd (habituellement de
catégorie 6)
Source de PoE
Commutateur PoE ou
injecteur Axis 15 W (802.3at) Commutateur PoE+ (802.3at)
Injecteur Axis 30 W
(802.3at)
non applicable non applicable 200 m (656 pi.)*
Source de PoE
Commutateur PoE ou
injecteur Axis 15 W
(802.3at)
Commutateur PoE+
(802.3at)
Injecteur Axis 30 W
(802.3at)
non applicable non applicable 200 m (656 pi.)*(avec
l'injecteur Axis 60 W)

AXIS T8129 PoE-Extender Seite 17
DEUTSCH
AXIS T8129 PoE-Extender Benutzerhandbuch
Hardwareübersicht
PoE-Extender
Netzwerkanschluss
LED-Anzeigen
Kamera
PoE-Extender
Switch
Midspan
Max. 100 m Max. 100 m

Seite 18 AXIS T8129 PoE-Extender
Technische Daten
Element Technische Daten
Modell AXIS T8129 PoE-Extender
Datenrate 10/100 Mbit/s Halb-/Vollduplex
Anschlüsse Abgeschirmtes RJ-45, EIA 568A und 568B
Netzwerkkabel Abgeschirmtes Kabel der Kategorie 5 (oder höher)
Display und
Anzeigen
LED-Anzeigen befinden sich auf dem RJ-45-Anschluss
Betriebsanzeige: PoE aktiviert (grün)
Netzwerkanzeige: Verbindung/Aktivität (gelb)
Konformität IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE
Montage Wand oder Regal
Umgebung Innenbereich
Zulassungen FCC Teil 15, Klasse B mit FTP-Kabel, EN 55022 Klasse B
(Strahlung), EN 55024 (Störfestigkeit)
Betriebsbe-
dingungen
–10 °C bis 50 °C
Relative Luftfeuchtigkeit max. 85 % (nicht kondensierend)
Lagerung –40 °C bis 74 °C
Abmessungen
(HxBxT)
105 x 40 x 22 mm
Gewicht 45 g

AXIS T8129 PoE-Extender Seite 19
DEUTSCH
Maximale Entfernungen für Stromquellen
Mehrere PoE-Extender können alle 100 Meter verbunden werden, um
größere Entfernungen abzudecken. Die genauen Werte hängen von den
Betriebsbedingungen ab. Die Reichweite beträgt, soweit nicht anders
angegeben, über 24 AWG bei schwereren Cat-5e- oder Cat-6-Kabeln.
Beispiele für PoE-Kameras mit niedrigem Stromverbrauch (PoE-
Klasse 1 oder unter 6 Watt Verbrauch):
• AXIS M11 Netzwerk-Kamera-Serie
• AXIS 221 Netzwerk-Kamera
• AXIS M30 Netzwerk-Kamera-Serie
• AXIS M31-R/-VE Netzwerk-Kamera-Serie
• AXIS M32 Netzwerk-Kamera-Serie
• AXIS P33 Netzwerk-Kameras (Modelle für Innenbereich)
• AXIS 212 PTZ/-V Netzwerk-Kamera
PoE-Quelle
PoE-Switch oder Axis 15 W
Midspan (802.3at) PoE+ Switch (802.3at) Axis 30 W Midspan (802.3at)
300 m 400 m 400 m

Seite 20 AXIS T8129 PoE-Extender
Beispiele für PoE-Kameras der PoE-Klasse 1 oder 2 bzw. mit einem
Verbrauch von unter 12 Watt:
• AXIS M1054 Netzwerk-Kamera
• AXIS P13 Netzwerk-Kameras (Modelle für Innenbereich)
• AXIS Q16 Netzwerk-Kameras (Modelle für Innenbereich)
• AXIS Q1755 Netzwerk-Kamera
• AXIS Q19 Netzwerk-Kamera-Serie
• AXIS P33 Netzwerk-Kameras (Modelle für Außenbereich)
PoE-Quelle
PoE-Switch oder
Axis 15 W Midspan
(802.3at)
PoE+ Switch (802.3at) Axis 30 W Midspan
(802.3at)
200 m 200 m 300 m
