Axis T6112 User manual

AXIST6112AudioandI/OInterface
RepaintingInstructions

AXIST6112AudioandI/OInterface
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
www.axis.com/warranty-implication-when-repainting
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXIST6112AudioandI/OInterface
Howtorepainttheproduct
Howtorepainttheproduct
Preparations
NO NO
NOTICE TICE TICE
Donotremovethemicrophonefromthecover.Makesuretomaskitproperly.
•Ifapplicable,disassembletheeuipmentaccordingtotheinstructionsinthisdocument.
•Cleanallpartstoberepaintedthoroughlytoremovegrease,dustoroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskopeningsforscrews,LEDindicators,ormicrophonesbefore
painting.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentsshouldbedoneforthenewpaintto
adhereaswellaspossible.Forallvariantsthough,propercleaningtoremoveoil,greaseanddustisstronglyrecommended.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com
Powdercoatedparts-Usingnesandpaper,removetheoriginalpowdercoatingdowntothebasematerialandcleantheparts
beforepainting,oruseaprimer.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
3

AXIST6112AudioandI/OInterface
Howtorepainttheproduct
isassembly
1.Useaat-headedscrewdrivertoremovethecover.
4

AXIST6112AudioandI/OInterface
Howtorepainttheproduct
Repainting
1.Makesureyouhavemadeallnecessarypreparationsofthepartstoberepainted.
2.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
3.Letthepaintdry.
4.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
5.Whenthepaintisdry,reassembletheproduct.
Reassembly
1.ConnectthemicrophonetotheAudioinconnector.
5

AXIST6112AudioandI/OInterface
Howtorepainttheproduct
2.Attachthesidelid(ifused)andthecovertothebracketmount.
6

RepaintingInstructionsVer.M1.5
AXIST61 12AudioandI/OInterfaceDate:March2018
©AxisCommunicationsAB,2018PartNo.T10126039
