Axxera AXV3D User manual

The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety
feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in
park and the parking brake is engaged. It is illegal in most states for the driver to view video while the
vehicle is in motion.
Safety Notes:
This Quick Start Guide gives you the basics to start using your AXV3D.
Please visit www.axxeraaudio.com/downloads/manuals/axv3d.pdf to download
a complete owner's manual or call customer service at 1-866-382-5476.
AXV3D
Quick Start Guide
Multimedia DVD Receiver
with UltraMotion™ Display

2
AXV3D
Installation
•Remove trim ring from unit.
•Remove 2 transit screws located on top of the unit.
•Insert the supplied keys into the slots as shown, and slide
the unit out of the mounting sleeve.
•Install mounting sleeve into opening, bending tabs to secure.
• Connect wiring harness and antenna. Consult a qualied
technician if you are unsure.
• Certain vehicles may require an installation kit and/or wiring
harness adapter (sold separately).
• Test for correct operation and slide into mounting sleeve to secure.
•Snaptrim ring intoplace.
Dash Board
Head Unit
KEYS
Mounting Sleeve

3
AXV3D
Wiring Diagram - Inputs/Outputs
ORANGE/BLACK
PINK
ILLUMINATION
POWER ANTENNA
ORANGE
BLUE
Bluetooth Module
(sold separately)
SiriusXM Vehicle Tuner Kit
(sold separately)
Red
White
Yellow
Yellow
Black
Yellow Back-up
Camera Input
Subwoofer Out
Video Output
AUX Video Input
AUX Line Input (L)
AUX Line Input (R)
Steering Wheel Interface Input
Antenna Input
Dual Zone Out (L)
Dual Zone Out (R)
Line Out (FL)
Line Out (RL)
Line Out (FR)
Line Out (RR)
Red
Red
Red
White
White
White

4
AXV3D
Control Locations
AS/PS
Eject
FF/LOC
FB
CH+
CH-
Audio
Title
Track Up
SUB-T
Volume Down
Volume UP
Mode
Home
Mute
Power
Up
Back
Play / Pause / Band
Enter
Track Down
Repeat
RDM
Down
Home
iPod
Radio
SD Card
Open
Mute
Disc Slot
Eject
Trim Ring
DVD
Pandora
Main Menu
Set up
Music
USB
Reset
AV IN 1
Volume / Select (Push)
Back
Remote Control

5
AXV3D
Operation
UltraMotion™ Menu
Main Menu
Tuner Mode
The UltraMotion™ display allows you to customize the layout of the Main
Menu by re-arranging the mode icons on the left and right sides of the
screen. Simply choose a mode from the scrolling menu in the middle of
the screen, press and hold it for 2-3 seconds, then drag it to where you
want the mode icon to be positioned and release.
Band
Press BAND to toggle between FM1, FM2, FM3, AM1, and AM2. Each band
allows the user to store 6 preset radio stations for quick access.
Manual Tuning
Press TUNE or TUNE momentarily to change the radio frequency up
or down, one step at a time.
Seek Tuning
Press SEEK or SEEK for more than 2 seconds to seek to the next
strong station.
Automatically Store
Press AST to scan and preset 6 radio stations with the strongest signal.
Preset Scan
Press P.SCAN to play each of your preset station for a short amount of time.
Press the button again to stay on the station that is currently playing.
The UltraMotion™ Menu displays availabe modes of operation. Press
a mode icon to select and begin playback of the corresponding mode.
Press the Main Menu icon at the top of the screen to access the Main Menu.

6
AXV3D
Operation
Music Mode
Operation of iPod / iPhone
(Same as USB/SD Card and iPod mode)
Playing MP3/ WMA Files
To play MP3/WMA les, insert a CD, USB drive or an SD card with MP3/WMA
les.
Track Select
Press TRACK to skip to the beginning of the next song.
Press TRACK to return to the beginning of the current song.
Pressing TRACK again skips to the beginning of the previous song.
Fast Forward and Reverse
Press and hold TRACK or TRACK to fast forward or reverse a track.
Each touch changes speed from 2x to 4x to 8x to 20x then back to
regular playback.
Play/Pause
Press / to stop playback.
Press / again to resume playback.
Random
Press to play all tracks or les in random order.
Press again to end random playback.
Connect an iPod/ iPhone Device (sold separately)
- To play video from an iPod/iPhone device, connect the USB/Video cable
(sold separately) to the USB port & AV IN 1 port of unit.
- To play music from an iPod/iPhone device, connect the USB cable
(included with your iPod/iPhone device) to the unit’s USB port.
Playback will begin automatically.
Song Select
Press to skip to the next song. Press to return to the beginning
of the current song. Pressing again skips to the beginning of the
previous song.
Fast Forward and Reverse
Press and hold or to fast forward or reverse a song.
Repeat
Press to repeat the current song.
Press again to turn o the repeat function.
Random
Press once to play all songs within the list in random order.
Press again to cancel the random function.
Play/Pause
Press / to stop playback.
Press / again to resume playback.

7
AXV3D
Pandora Operation
iPod Operation
USB Connection
Connect an iPod touch or iPhone device (sold separately) to the USB port using
the USB sync cable included with your iPod/iPhone device.
Changing Stations
Press to display the stations menu. Turn the volume knob to cycle through
the list of stations, then press when the desired station is highlighted.
Note: Stations must be created on your account prior to connecting your
iPod/iPhone device to the head unit.
Shuffle
Press to display the stations menu.
Choose “Quick Mix” from the stations menu to shue songs from all of your
stations.
Skipping Tracks
Press to skip the current song.
Play/Pause
Press / to stop playback.
Press / again to resume playback.
Thumbs Up
Press to customize the station to play more songs like the song that is
currently playing.
Thumbs Down
Press to customize the station to play songs that are dierent from the
song that is currently playing.
Note: Pandora may use large amounts of data and carrier data charges may
apply. For best results, we recommend that you connect your device to
trusted WiFi networks when available.
iPod Music Search
Press MENU, and the main search menu will appear. To select a
category, choose from the following options: Playlists, Artists,
Albums, Genre, Songs, Composer, Audiobook and Podcasts.
Press MENU to cancel the Menu function.
Control for Pandora requires:
is connected to wireless internet.
iPod Menu Mode
Press to enter the menu mode and toggle between Music,
Video and Photo les. Navigate using the up and down arrow buttons.
®
.
Operation

8
AXV3D
Auxiliary Inputs &
Rear Camera OperationAuxiliary Inputs & Rear Camera Operation
Connect an optional audio/video source into the 3.5mm input on the
front panel (AV1) or to the red/white/yellow RCA connectors on the
back of the unit (AV2). Select AV1 or AV2 from the Main Menu to
access audio or video.
Rear Camera
Connect an optional rear camera to the Camera Input (yellow RCA
connector labeled ‘CAM IN’). Connect the reverse lamp wire to the
REVERSE line of unit. The unit will automatically select camera mode
when connected to the reverse lamp circuitry.
Preparation
To connect a Bluetooth device, install and connect the BTM100 (sold
separately). When connected to the AXV3D, the BTM100 supports HFP
(hands-free prole), A2DP (advanced audio distribution prole), AVRCP
(audio video remote control prole) and PBAP (phone book access prole).
Before you can use a Bluetooth device, it must be paired and connected.
Make sure that Bluetooth is activated on your device before you begin
the pairing process.
Pairing a New Device
The BTM100 Bluetooth interface module (sold separately) broadcasts
the pairing signal constantly when no devices are currently connected
Complete the pairing sequence from your Bluetooth device. Refer to the
owner's manual for your device for more details.
Once pairing is complete, the TALK button on the BTM100 will be
illuminated in blue.
The device name is "BTM100"
*Please note that no password is required for pairing.
Note: The AXV3D can be in any mode of operation when pairing is
performed.
Press , then press “Disconnect” to disconnect the currently-paired
device.
If you press when no device is connected, the unit will show the list of
previously-paired devices. Press any device name to repair that device.
Disconnecting a Device
Bluetooth Operation
(Optional)
R
Note: The unit must be disconnected from the current device before
beginning the pairing sequence for a new device.
Operation

9
AXV3D
The BTM100 supports the PBAP Bluetooth prole to temporarily download
the phonebook of the cell phone.
Note: The contents of the phonebook are deleted each time a cell phone
is disconnected and are not permamently saved.
Ending a Phone Call
During an active phone call, press to end a phone call. If the phone
call was received when listening to music in another mode, the AXV3D
will resume the previous mode.
Making a Phone Call
Press and the keypad will show up. Enter the phone number using the
0-9 buttons on the keypad.
Streaming Audio Operation
The AXV3D supports A2DP (advanced audio distribution prole) wireless
streaming audio from your Bluetooth mobile device directly to your head
unit. You can also control your music from the front panel of the head unit
using AVRCP (audio video remote control prole).
Note: Placing a phone call from your cell phone will also use the Bluetooth
function of the BTM100.
• Press from Bluetooth mode with a compatible cell phone connected.
Press at the bottom of the screen to display downloaded phone book
names.
• Press the desired name on the phone book, then select between cell, home,
work and other phone number types to make a phone call.
After pairing, connecting and enabling streaming audio from a compatible
mobile device, begin playing music using the music player on your mobile
device. Once the music is playing, the following functions can be used to
control the music.
Receiving a Phone Call
Incoming phone calls will automatically appear on the display, and a ring
tone will be heard.
If you press, the AXV3D will change to Bluetooth music mode.
Bluetooth Operation
(Optional)
R
Operation

10
AXV3D
Bluetooth Music
Setting Mode
The AXV3D supports A2DP wireless streaming audio from your Bluetooth
mobile device directly to the head unit. You can also control music from
the front panel of the head unit using AVRCP (audio video remote control
prole).
To stream music to your head unit, your mobile device must support
the following criteria:
or manufacturer of your device for compatibility.
This option will vary depending on the device. Example: "wireless stereo."
After enabling streaming audio from a compatible mobile device,
to control music:
• The button will skip to the next available audio track.
• The button will skip to the previous audio track.
• The / button will toggle between play and pause during playback.
• The button will stop the audio playback
it may be necessary to control the music from the device.
Brightness Control
Source Level Control
The source level menu allows you to adjust the volume level of each source.
Select AUTOMATIC to enable adjustment of the time and brightness settings
for both day and night.
Select DIMMER to set the unit to control brightness automatically.
Select MANUAL to x brightness at the currently-selected setting.
Music Field
The music eld allows you to set balance, fader and other sound controls.
SUB X-over allows you to choose from three low pass X-over settings.
This control will only aect devices connected to the subwoofer output.
R
Operation
