Axxess GMOS-LAN-02 User manual

INSTALLATION INSTRUCTIONS FOR PART INSTGMOS-LAN-02
• Cutting tool • Crimping tool • Tape • Connectors (example: butt-connectors, bell caps, etc.)
IGNITION TERMINALS
WIRE CUTTER
M3.5
M2.6
M3
M5
M4
ISO
6
2.5
1.5
TOOLS REQUIRED
GM LAN 29 Amplified OnStar
Interface 2006-up
GMOS-LAN-02
GMOS-LAN-02 interface • 16 pin harness with stripped leads • 18-pin harness to 30 pin
GM harness with stripped leads • BACKUPCAM harness • Antenna adapter
INTERFACE COMPONENTS
KIT FEATURES
APPLICATIONS
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
• Used in amplified systems
• Retains chimes
• Provides NAV outputs (Parking Brake, Reverse, Mute, V.S.S.)
• ASWC harness included (ASWC not included)
• Retains OnStar/OE Bluetooth
• Adjustable volume for chimes and OnStar
• High level speaker input
• USB updatable
• Retains balance and fade
• Retains factory back-up camera
• Includes antenna adapter
See inside front cover

Applications
GMOS-LAN-02
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
Note: Refer also to the instructions included with the aftermarket radio.
BUICK
Enclave 2007-up
Lucerne 2006-up
CADILLAC
Escalade 2007-up
DTS 2006-2010
SRX 2007-2009
CHEVROLET
Avalanche 2007-up
Equinox 2007-2009
Express 2008-up
Impala 2006-up
Monte Carlo 2006-2007
Silverado (new body) 2007-up
Suburban 2007-up
Tahoe 2007-up
Traverse 2009-up
GMC
Acadia 2007-up
Savana 2008-up
Sierra (new body) 2007-up
Yukon 2007-up
PONTIAC
Torrent 2007-2009
Vibe (For OnStar retention only) 2009
SATURN
Outlook 2007-2009
Vue 2008-2009
Suzuki
XL-7 2007-2008
(Note: This interface will also work in vehicles listed below that are not equipped with OnStar)

From the 16 pin harness:
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange/White wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire just tape off the Orange/White wire.
• Connect the White wire to the left front positive speaker output of the aftermarket radio
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio
• Connect the Gray wire to the right front positive speaker output of the aftermarket radio
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
• Connect the Blue/White wire to the radio’s amp turn on wire
• Connect the Brown wire to the mute wire of the aftermarket radio. If the aftermarket
radio does not have a Mute wire, tape up the Brown wire.
• Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio.
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio.
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio.
• Plug the 16 pin harness into the GMOS-LAN-02
Connections to be made
GMOS-LAN-02

GMOS-LAN-02
From the 30 pin harness:
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Plug the 14 pin harness into the GMOS-LAN-02
• The Black/Yellow wire is for the OnStar volume adjustment. This will be discussed in
the OnStar Level Adjustment section of this instruction.
The 12 pin harness (ASWC plug) will be discussed later in the manual.
BACKUPCAM harness:
This harness is used when you are trying to retain the factory Back up camera. Plug the
yellow RCA of the BACKUPCAM harness to your aftermarket radios video input.
Connections to be made
• With all connections completed to the aftermarket radio, plug the 30 pin harnesses into
the vehicles wiring harnesses.
• Reconnect the negative battery terminal.
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to test the
radio.
Installing the GMOS-LAN-02
1) Turn the ignition on if not already, and then turn the radio on to verify that the radio
works. Check balance and fader controls for proper operation.
2) Push the OnStar button (if equipped) to verify OnStar is working. The radio will shut off or
mute, depending if the Brown wire on the 16 pin harness is connected, and Onstar will
be heard through the front speakers. Turn off Onstar and the radio will turn back on.
Testing the GMOS-LAN-02

GMOS-LAN-02
Chime Volume Adjustment
Note: If Y91 is present on the RPO list, refer to your owner’s manual to adjust chimes.
1) With car on, shut off car and leave keys in ignition. Open
the car door and leave it open. Chimes will be heard.
2) Wait 10 seconds, then with a small screwdriver adjust
the potentiometer fully counterclockwise (all the way left),
then clockwise to raise chime level and counterclockwise
to lower the chime level.
3) When the volume is at the desired level, remove the keys
from the ignition. This will lock the chime volume at its
current level.
Audio Level Adjustment
1) Start your vehicle and turn on the radio having audio playing.
2) Turn your aftermarket radio’s volume up ¾ of the way.
3) With a small screwdriver adjust the potentiometer clockwise to raise the audio level and
counterclockwise to lower the audio level.
4) Once at desired level your audio adjustment is complete.
OnStar Level Adjustment
To adjust the OnStar volume level find the
Black/Yellow wire on the 16 pin harness. Push the blue OnStar button, while the voice is
speaking tap the Black/Yellow wire to ground. There are 4 volume settings for OnStar;
once the 4th setting is reached and the Black/Yellow wire is tapped to ground it will
automatically go back to the first volume setting. Once the volume is set it will stay at
that volume until the Black/Yellow wire is tapped to ground again. This can be set during
installation and then left alone. If user adjustment is desired, the customer may also tap
volume up or down on the steering wheel (if equipped) to adjust the OnStar level.
Additional 12 pin harness (ASWC harness)
This 12 pin harness is to be used in conjunction with the ASWC (not included).
Please refer to ASWC instructions for programming.
Potentiometer located on 16 pin
side of the interface
