Axxion ADVP-204 User manual

USER MANUAL ADVP-204
DVD/MPEG4/CD/MP3/PLAYER
Please read this User Manualcarefully to ensure proper use ofthis
product and keep this manualfor future reference.

Content
INTRODUCTION
Safety Precautions 1
Panel Illustration 2
Remote Control 3
CONNECTIONS
Connecting to a TV set 4
Advanced Features
MP3/WMA/MPEG4 playing 5
PICTURE CD PLAYBACK 6
SYSTEM SETUP 6
OTHERS
Specifications 8
Accessories 8

Safety Precautions
Safety is Important
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Battery Disposal
Please ensure batteries aredisposed of safely.
Never dispose of batteriesin a fire orwith other household
waste.
Check with your localauthority for disposal regulations.
To ensure your safety and the safetyof others, please
read the Safety Instructions beforeyou operate this
product.
Keep this information in a safe place for future reference.
Please read all the safety information before using the product.
Safety Considerations.
Position the cables so that they cannot be walked on or pinched by
items placed on or against them.
Do not use the portable DVD Player in humid or damp conditions.
Do not allow the portable DVD Player to get wet.
Do not expose the portable DVD Player to dripping or splashing.
Do not place water filled objects such as vases on top of the portable
DVD Player.
Do not place naked flame sources, such as candles, on the top of
the portable DVD Player.
Cleaning
ALWAYS unplug the portable DVD Player before you clean it.
Do not use liquid or aerosol cleaners.
Clean the portable DVD Player with a soft, damp (not wet) cloth.
Ventilation
The slots and openings onthe set top box arefor ventilation.
Do not cover or blockthem as it may causeoverheating.
NEVER let children push anythinginto the holes or slotson
the case.
Servicing
There are no userserviceable parts in thisportable DVD
Player.
When servicing, refer toqualified service personnel.
Consult your dealer ifyou are ever indoubt about the
This symbol indicates that thisproduct incorporates double
insulation between hazardous mains voltageand user
accessible parts. When servicing useonly identical
replacement parts.
WARNING: To reduce the risk offire or electric shock, do
not expose this apparatus torain or cords.
1. The apparatus shall not be exposed to dripping or Splashing
and that no objects filled with liquids, such as Vases, shall be
placed the apparatus.
2. The mains plug is used as thedisconnect device, the disconnect
device shall remainreadily operable.
3. To be completely disconnect the power input, the mains plug
of apparatus shall be disconnected from the mains.
4. The mains plug of apparatus should notbe obstructed or should
be easily accessed during intended use.
Special notice
A few highlights or dark spots may occur on the LCD screen. It is a very common
phenomenon of the active matrix display technology, and does not mean any defects
or faults. Never try to repair this machine by yourself. In case of any faults. Please
turn off the unit at once, and notify our Company or the corresponding dealer. The
display is made up of many precision electronic components. Any disassembly or
modification may lead to further damage.
installation, operation or safetyof this unit. 1

Panel Illustration
LCD DISPLAY
RIGHT SPEAKER
LEFT SPEAKER
DISC DOOR
OPEN DISC TOP
SETUP BUTTON
MENU BUTTON
TFT ON/OFF
MOVE ( )
SOURCE
PAUSE
2
PREVIOUS BUTTON
NEXT
PLAY
STOP
BATTERY CHARGE INDUCATOR
SENSOR
POWER ( ON /OFF) SWITCH
DC 12V INPUT JACK (power supply)
PHONE JACK
AV OUTPUT JACK
VOLUME CONTROLL
USB

)
Remote Control
Remote Control
Note:
1. In this manual, will be used torepresent
the different NAVIGATION ARROWS on the remote control.
2 In order tooperate any of theremote functions. First push the
Power sw itch in “ON ” position.
3. TITLE Function ：The content of a DVD is often divided into several
titles that contain multiple menus. Press for approx. 2 Seconds in the
menu button, the title is displayed. Using the buttons or
the numerical buttons (0-9) on the remote control, you can select the
desired title or the desired option. Confirm with OK.
HOW TO REPLACE THE BATTERY
STEP 1: PUSH THE BUTTON TOWARD LEFT;
STEP 2: PULL THE BATTERY LOADER OUT
ANGLE
MENU(TITLE)
NUMBER KEY SELECT
STOP
GOTO
FWD
NEXT
PREV
ZOOM
DISPLAY
AUDIO
SUBTITLE
REPEAT
SETUP
MOVE (
REV
ENTER
PLAY/PAUSE
BATTERIES
INCORRECT USE OF BATTERIES MAY CAUSE THEMTO LEAK,
CORRODE OR EXPLODE.
Be sure to place the batteries in the correct direction.
It is dangerous to charge/heat/open or short-circuit the batteries.
Do not leave dead or expired batteries or mix old/new batteries.
When not using the remote control for a long time, remove the
batteries. When operating range becomes reduced, replace all
batteries with new, fresh ones.
If leakage from the battery occurs, wipe the battery liquid from the
battery compartment, then replace.
3

C
onnecting to a TV Set Connections
Phone Jack Function
Insert the earphone into the earphone jack, to listen the music
or movie privately.
Battery charging
When the unit battery is powered out, connect the AC adapter
onto the unit. the battery will charge automatically.
Volume adjust
Use VOLUME CONTROLL in the side of the unit to adjust the
volume.
4

MP3/WMA/MPEG4 PLAYING
Insert the MP3/WMA/MPEG4 disc, use navigation keys to open the desired directory.
PressENTER to enter the sub directory. Use the navigation keys to select
the desired track and then ENTER to play the file. Press the PLAY/PAUSE key to
pause the playback, press the stop key to stop the play. To return to the upper
menu, press navigation key to choose the icon and press ENTER to confirm.
Open the option menu using the navigation keys
Filter: Allows selectingthe categories of filesdisplayed in the browserlist.
Repeat: To switch differentrepeat playing mode
Select single option to enable one file repeat, select folder option to
enable all the files in the folder repeat.
Mode: Select differentplaying mode
Normal: Normal playback
Shuffle: Shuffle mode enabled. When playback reaches the end of the
current chapter/track, playback jumps to a random chapter/track.
Music Intro: In this mode, the unit will play the first 10 seconds of the file and then skip
to the next file.
Edit Mode: Use this option to enable programmed playback mode. Select the mode,
press LEFT Navigation key to directory and press ENTER to choose the
desired track and press Add to program to program the playback list.
Program view: Display directory/folder.
Brower view: Display playback list directory.
Add to program: Use this in combination with Edit Mode to create a play list.
Clear program: When entered the Browser View and in complete stop state (press
STOP button twice), use this option in combination with Edit Mode to
delete tracks from the playback list.
5

PICTURE CD PLAYBACK
SYSTEM SETUP
MENU OPERATION
Press theSETUP button on the remote control and the
SETUP MENU will be displayed. Use the directionbuttons
for up and down movementto select the desired item,
then press the ENTER button to confirm.
Press LEFT direction button return tothe main menu. To exit
the setup, press theSETUP button. Press right navigation key to
enter the submenu.
LANGUAGE SETUP
Select Language in the setup menu.
Press Navigation key to choose theroot directory and
press ENTER button to enter the subdirectory. Press
Language
Video
Rating
Misc
OSD Language
Language
Subtitle
MPEG4 Subtitle
Audio
DVD Menu
Navigation key to choose the desired picture and press
ENTER to view the picture. If you want to return to the
upper menu, press Navigation key to choose and
press ENTER.
Image rotation
In picture play state, press Navigation key to rotation
the picture, press ANGLE button to change the picture
scan mode.
6
Use this item to selectthe language of the setupmenu and screen
display.
Subtitle
Set the default subtitle.
Note: not every disc supports this function.
MPEG4 Subtitle
Set default MPEG4 subtitleencoding option.
Note: not every disc supports this function.
Audio
Set the default audio language.
Note: not every disc supports this function.

SYSTEM SETUP
DVD Menu
Set the default DVD menu language.
Note: not every disc supports this function.
RATING SETUP
Select Rating in the setup menu, and display the Rating submenu:
Note: Not all DVD support ratings.
VIDEO SETUP
Select Video in the setup menu,and display theVideo submenu:
Language
Video
Parental Control
Set Password
Language
Video
Aspect Ratio
TV System
Smart Picture
Rating
Misc
Rating
Misc
TV System
This product supports output ofvarious systems (NTSC, PAL).
When connecting to a TV set make sure that both units have the
same PAL / NTSC settings.
Smart picture
Adjust display effect:
Standard: default effect.
Bright: internal setting for brightview effect.
Soft: internal setting for softview effect.
Parental Control
Set the desired level.
Note: not every disc supports this function.
Set Password
Use the 0-9 keys toinput four digits(password), then pressENTER
to confirm.
Note: If you forget yourpassword, please use theuniversal
password 6666 to unlock.
MISC SETUP
Select MISC in the setup menu,and display the submenu:
* Use Default Settings
Reset data tofactory default.
Dynamic: user adjusts brightness, contrast,color etc.
Language
Video
Rating
Misc
7
Use Default Settings

Play mode
NTSC/PAL
Disc mode
DVD,VCD, CD, MP3, CD-R, CD-RW, JPEG,
DVD+ -R/W, MPEG4,
Video characteristic
Video S/N ratio
65dB.
Resolution
500 lines.
Audio characteristic
Frequency response
fs 96KHz: 20Hz-20KHz:+/-1dBI
Audio S/N ratio
90dB
Dynamic range
80dB
Distortion
< 0.01%
D/A Converter
96KHz/24bit
Specifications Other
Output characteristic
Display Device
Color TFT-LCD
Screen Size
7 inches
Video output
1Vp-p(75 )
Audio output
2CH
Power Voltage
DC IN 12V
Power consumption
15W
Size
206x160x40mm
Weight
1.0kg
Accessories
Specifications are subject to change without notice.
8

If at any timein the future youshould need to disposeof this product please
note that: Wasteelectrical products should notbe disposed of withhousehold
waste. Please recycle wherefacilities exist. Check withyour Local Authority
or retailer for recyclingadvice. (Waste Electricaland Electronic Equipment
Directive)
