Az-Box Elite User manual

1
Azbox Elite
Azbox Premium
User Manual
High Definition
Digital Satellite Receiver
Personal Video Recorder

2
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
(a) Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
(b) The mains plug, which is used as a disconnect device, shall remain
readily operable.
Caution
(a) Always follow these instructions to avoid the risk of injury to
yourself or damage to your equipment.
(b) Unplug the receiver from the AC power outlet before cleaning. Use
only a damp cloth for cleaning the exterior of the receiver.
(c) Do not use accessories or attachments not recommended by the
receiver manufacturer, as they may cause hazards and will void the
warranty.
(d) Do not operate the receiver in high-humidity areas, or expose it to

3
water or moisture.
(e) Do not place the receiver on an unstable cart, stand, tripod, bracket,
or table. The receiver may fall, causing serious personal injury and
damage to the receiver.
(f) Do not block or cover slots and openings in the receiver. These are
provided for ventilation and protection from overheating. Never place
the receiver near or over a radiator or heat register. Do not place the
receiver in an enclosure such as a cabinet without proper ventilation.
(g) Do not stack the receiver on top of or below other electronic
devices.
(h) Operate the receiver using only the type of power source indicated
on the marking label. Unplug the receiver power cord by gripping the
power plug, not the cord.
(i) Route power supply cords so that they are not likely to be walked on
or pinched by items placed upon or against them. Pay particular
attention to cords at plugs, convenience receptacles, and the point
where they exit from the unit.
(j) Use an outlet that contains surge suppression or ground fault
protection. For added protection during a lightning storm, or when
the receiver is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the lines between the
receiver and the antenna. This will provide some protection against
damage caused by lightning or power line surges.
(k) Do not attempt to service the receiver yourself, as opening or
removing covers may expose you to dangerous voltage, and will void

4
the warranty. Refer all servicing to Authorized service personnel.
(l) Unplug the receiver from the wall outlet and refer servicing to
authorized service personnel whenever the following occurs:
- The power supply cord or plug is damaged;
- Liquid has been spilled, or objects have fallen into the receiver;
- The receiver has been exposed to rain or water;
- The receiver has been dropped or the chassis has been damaged;
- The receiver exhibits a distinct change in performance.
Safety Precautions
Please read carefully the following safety precautions.
①The mains power must be 90 to 250 volts. Check it before
connecting the digital receiver to the mains socket. For the power
consumption of the digital receiver, see 6.1.
②The mains socket should be near the equipment. Do not run an
extension lead to the unit.
③Do not expose the digital receiver to any moisture. The digital
receiver is designed for use indoors only. Use dry cloth when
cleaning the digital receiver.
④Place the digital receiver on a firm and level surface.
⑤Do not place the digital receiver close to heat emitting units or in
direct sunlight, as this will impair cooling. Do not lay any objects
such as magazines on the digital receiver. When placed in a
cabinet, make sure there is a minimum space of 10 centimeters

5
around it. For the physical specification of the digital receiver, see
6.1.
⑥Protect the power cord from being walked on or pinched. If the
cord is damaged, do not use the digital receiver and get the cord
replaced.
⑦Never open the digital receiver casing under any circumstances,
or the warranty will be void.
⑧Refer all servicing to a qualified service technician.

6
Table of Contents
1. Introduction................................................................................................................................... 10
1.1 Features ....................................................................................................................................................10
1.2 Package Contents .................................................................................................................................12
1.2.1 Azbox Elite..........................................................................................................................................12
1.2.2 Azbox Premium..................................................................................................................................13
1.3 The front panel .......................................................................................................................................14
1.3.1 Azbox Elite..........................................................................................................................................14
1.3.2 Azbox Premium..................................................................................................................................15
1.4 The Rear panel .......................................................................................................................................17
1.4.1 Azbox Elite..........................................................................................................................................17
1.4.2 Azbox Premium..................................................................................................................................19
1.5 The remote control ...............................................................................................................................21
1.5.1 Azbox Elite..........................................................................................................................................21
1.5.2 Azbox Premium..................................................................................................................................24
1.5.3 Premium Model RCU .........................................................................................................................27
1.5.3.1 STB Code output Format (Varied NEC protocol)...................................................................27
1.5.3.2 TV Universal configuration 1 (4-digit number input) ...........................................................27
1.5.3.3 TV Universal configuration 2 (Auto search)...........................................................................28
1.5.3.4 TV configuration number search (ID Recall).........................................................................28
1.5.3.5 TV List.........................................................................................................................................28
1.6 CI (Common Interface) ......................................................................................................................29
1.6.1 To watch a pay service .....................................................................................................................29
2. Installations................................................................................................................................... 31
2.1 Connections to antenna ......................................................................................................................31
2.2 Connections to TV .................................................................................................................................32
2.2.1 HDMI connector.................................................................................................................................33
2.2.2 SCART connector...............................................................................................................................34
2.2.3 Component video connector............................................................................................................35
2.2.4 Composite video connector..............................................................................................................36
2.2.5 Audio connection...............................................................................................................................37
2.3 Installing batteries ...............................................................................................................................38
2.4 Powering on for the first time ..........................................................................................................39
2.4.1 Powering on and checking picture..................................................................................................40
2.5 Firmware Update ...................................................................................................................................41
2.5.1 Checking the firmware information ................................................................................................41
2.5.1.1 Internet.......................................................................................................................................42
2.5.1.2 USB Storage ...............................................................................................................................43
3. Settings........................................................................................................................................... 45
Cont
ents

7
3.1 System Information .............................................................................................................................45
3.2 Language/Time settings ....................................................................................................................46
3.2.1 Menu Language .................................................................................................................................47
3.2.2 Audio Language / Sub audio language ..........................................................................................47
3.2.3 Subtitle language...............................................................................................................................48
3.3 Local time setting ..................................................................................................................................49
3.4 Timer ..........................................................................................................................................................52
3.4.1 Timer Number....................................................................................................................................52
3.4.2 Timer State.........................................................................................................................................53
3.4.3 Timer Cycle.........................................................................................................................................53
3.4.4 Timer Service .....................................................................................................................................53
3.4.5 Time.....................................................................................................................................................53
3.5 Internet ....................................................................................................................................................54
3.5.1 Network...............................................................................................................................................54
3.5.2 IP Setting............................................................................................................................................54
3.5.3 Speed Check.......................................................................................................................................55
3.6 Storage ......................................................................................................................................................56
3.6.1 Device..................................................................................................................................................56
3.6.2 Partition...............................................................................................................................................57
3.6.3 Partition Format.................................................................................................................................57
3.7 Video and audio settings ....................................................................................................................58
3.7.1 Video Format......................................................................................................................................59
3.7.2 Video resolution.................................................................................................................................59
3.7.3 Screen Format....................................................................................................................................60
3.7.4 Display Format...................................................................................................................................60
3.7.5 Video Output......................................................................................................................................61
3.7.6 Default Audio Format........................................................................................................................61
3.7.7 Audio Output......................................................................................................................................61
3.7.8 Dolby Output......................................................................................................................................61
3.7.9 RF Channel Number..........................................................................................................................62
3.7.10 RF Audio Type....................................................................................................................................62
3.8 TV Channel ...............................................................................................................................................63
3.8.1 Antenna Setup ...................................................................................................................................63
3.8.1.1 Satellite Name............................................................................................................................64
3.8.1.2 LNB Frequency...........................................................................................................................65
3.8.1.3 DiSEqC.........................................................................................................................................66
3.8.1.4 22KHZ Tone................................................................................................................................66
3.8.1.5 0/12V Switch..............................................................................................................................66
3.8.1.6 LNB Power..................................................................................................................................66
3.8.1.7 TP Frequency .............................................................................................................................67
3.8.1.8 Positioner Setup.........................................................................................................................67
3.8.1.9 Network Search..........................................................................................................................70
3.8.2 Satellite Scan......................................................................................................................................71
3.8.3 TP Scan...............................................................................................................................................72
3.8.4 Advanced Scan...................................................................................................................................73
3.8.4.1 PID Edit.......................................................................................................................................73

8
3.8.5 SAT/TP Edit.........................................................................................................................................74
3.8.5.1 Add satellite (TP).......................................................................................................................74
3.8.5.2 Delete Satellite (TP)..................................................................................................................74
3.9 Parental control .....................................................................................................................................75
3.9.1 Change password..............................................................................................................................75
3.9.2 Menu lock feature..............................................................................................................................76
3.9.3 Age rating control / Age limit...........................................................................................................76
3.10 Data Reset ...........................................................................................................................................78
3.10.1 Factory setting ...................................................................................................................................78
3.10.2 Delete all channels............................................................................................................................79
3.10.3 Delete satellite channels...................................................................................................................79
3.11 GOGO-list .............................................................................................................................................80
4. Main Menu...................................................................................................................................... 81
4.1 TV ................................................................................................................................................................82
4.1.1 Watching television ...........................................................................................................................82
4.1.1.1 Changing Channels....................................................................................................................82
4.1.1.2 Adjusting the Volume................................................................................................................82
4.1.2 Channel Selection..............................................................................................................................83
4.1.2.1 How to sort the channels.........................................................................................................84
4.1.2.2 Favorite channel lists.................................................................................................................84
4.1.2.3 Channel Edit...............................................................................................................................86
4.1.2.4 Program Information.................................................................................................................87
4.1.2.5 Selecting subtitle lists................................................................................................................88
4.1.2.6 Viewing Teletext.........................................................................................................................89
4.1.2.7 Selecting audio lists...................................................................................................................89
4.1.3 EPG (Electronic Program Guide)......................................................................................................90
4.1.3.1 EPG (Electronic Program Guide)..............................................................................................91
4.1.3.2 Single EPG ..................................................................................................................................92
4.1.3.3 Search EPG.................................................................................................................................92
4.1.4 PVR (Personal Video Recorder) .......................................................................................................92
4.1.4.1 PVR..............................................................................................................................................93
4.1.4.2 Record Live TV...........................................................................................................................94
4.1.4.3 Reserve Record/Play .................................................................................................................94
4.1.4.4 Reserve recordings using the EPG ..........................................................................................95
4.1.4.5 Recording a pay service program............................................................................................96
4.1.4.6 Recorded Program.....................................................................................................................97
4.1.4.7 Reserved Program.....................................................................................................................97
4.1.4.8 Time-Shift...................................................................................................................................97
4.2 YouTube ..................................................................................................................................................100
4.2.1 How to search in the YouTube.......................................................................................................100
4.2.2 Load Video Lists...............................................................................................................................102
4.3 File Play & Management ...................................................................................................................103
4.3.1 Movie / Music / Photo.....................................................................................................................103
4.3.1.1 Movie.........................................................................................................................................104
4.3.1.2 Music .........................................................................................................................................105
4.3.1.3 Photo.........................................................................................................................................106

9
4.3.2 File Management.............................................................................................................................107
4.3.2.1 Move files to another folder...................................................................................................108
4.4 RSS News ...............................................................................................................................................109
4.4.1 Add new category............................................................................................................................110
4.4.2 Register new channel......................................................................................................................110
4.5 Browser ...................................................................................................................................................111
4.5.1 Favorite List......................................................................................................................................111
5. Network ........................................................................................................................................ 113
5.1 Connect the digital receiver to the computer................................................................................113
5.2 Connect the computer to the digital receiver................................................................................113
5.2.1 Windows XP.....................................................................................................................................114
5.2.2 Windows Vista.................................................................................................................................114
6. Product specifications / Warranty........................................................................................... 116
6.1 Product specifications .......................................................................................................................116
6.1.1 Power specifications........................................................................................................................116
6.1.1.1 Azbox Elite................................................................................................................................116
6.1.1.2 Azbox Premium........................................................................................................................116
6.1.2 Physical specifications.....................................................................................................................116
6.1.2.1 Azbox Elite................................................................................................................................116
6.1.2.2 Azbox Premium........................................................................................................................117
6.2 Warranty ................................................................................................................................................118
6.2.1 Warranty Terms and Conditions ....................................................................................................118
6.2.2 Provisions of Warranty....................................................................................................................118
6.2.3 Notes regarding warranty maintenance.......................................................................................120
6.2.4 Disclaimer of Warranty ...................................................................................................................121
7. Appendix....................................................................................................................................... 122

10
1.Introduction
The Azbox Elite/Premium HD digital receiver is fully compliant with the
international Digital Video Broadcasting(DVB) standard, and thus is able
to receive digital broadcasts of that standard.
For its operation you need an antenna, which must be installed
appropriately.
NOTE
In general we equate a channel with a frequency. However, unlike
analogue broadcasts, digital broadcasts are not all assigned to their own
frequencies; instead, multiple television broadcasts are transmitted
through a single frequency. The frequency in digital broadcasting is
usually called transponder. To reduce confusion in this manual, the word
service is preferably used than channel as a term to indicate one
television or radio broadcast.
1.1 Features
The Azbox Elite/Premium HD digital receiver has the following
features:
①Supports DiSEqC 1.0, DiSEqC 1.2 and USALS.
②Can store up to 15,000 television and radio services.
③You can edit the services list.
④You can create favorite lists of your favorite services.
⑤You can view information about the current television or radio
program.
⑥Has an electronic program guide that provides an overview of
6
Introduction
6
Introduction

11
scheduled programs.
⑦You can record one service while you are currently watching
another.
⑧The large storage capacity of the hard disk drive allows you to
record up to about 60 hours of television —in case of 250
gigabytes— in excellent picture and sound quality.
⑨Time shift is a special technical feature available on the Azbox
Elite (PVR Ready) /Premium (PVR). You can pause the program
you are watching and resume it again at a later time. Then you
can quickly go to any part of the current program by fast
forward or backward search.

12
1.2 Package Contents
Before going any further, check that you have received the following
items with your digital receiver.
1.2.1 Azbox Elite
• Azbox Elite
• Remote control unit
• Two batteries for the remote control (AAA 1.5V)
• One power cable
• User Guide CD
6
Introduction

13
1.2.2 Azbox Premium
• Azbox Premium
• Remote control unit
• Two batteries for the remote control (AAA 1.5V)
• One power adaptor
• One power cable
• One SATA cable
• User Guide CD
• Four Screw bolts
NOTE
Accessories may vary according to your local area.
6
Introduction

14
1.3 The front panel
The front panel of the Azbox Elite/Premium has buttons to perform
basic functions such as changing channels, adjusting volume, and
powering on and off. And specific LEDs and a display to indicate its
status. The following indicates what they mean.
1.3.1 Azbox Elite
①One SMART CARD Slot: Supports electronic commerce using a
smart card.
②Two CI CARD Slots: Connect to support devices.
③Main Display: Display the current channel name. While the
receiver is in stand-by mode, it will show the current time.
④Power button: Switch the digital receiver between stand-by mode
and operation mode. To reboot the receiver, press this button for 3
seconds.
⑤VOLUME +/- buttons: Increase or decrease the volume.
6
Introduction

15
⑥CHANNEL ∨/∨buttons: Switch to previous or next service. They
are also used to navigate around menu screens.
⑦OK button: Determine your selection or to display channel selection.
1.3.2 Azbox Premium
①One SMART CARD Slot: Support electronic commerce using a
smart card.
②Two CI CARD Slots: Connect to support devices.
③USB Slot: Connect to support devices. (Premium model has two
USB slots. One is on the front, the other is on the rear panel)
④Main Display: Display the current channel name. While the
receiver is in stand-by mode, it will show the current time.
LED Indicator
Power LED: Blue LED while the digital receiver is on.
6
Introduction

16
REC LED: Red LED when you are recording a program.
HD Channel LED: Green LED when receiving a HD(High
Definition) program.
⑤Power button: Switch the digital receiver between stand-by
mode and operation mode. To reboot the receiver, press this
button for 3 seconds.
⑥MENU button: Enter the detail menu.
⑦EXIT button: Exit menus, EPG(Electronic Program Guide), and
program information.
⑧Home button: Enter the main menu.
⑨VOLUME +/- buttons: Increase or decrease the volume.
⑩CHANNEL ∨/∨buttons: Switch to previous or next service.
They are also used to navigate around menu screens.
⑪OK button: Determine your selection or to display channel
selection.
6
Introduction

17
1.4 The Rear panel
The Azbox Elite/Premium has a wide range of connections on the back.
Check what connections your television set has in comparison with the
digital receiver. The following indicates what they mean.
1.4.1 Azbox Elite
①POWER SWITCH: Turn the digital receiver On and OFF.
②AC POWER INPUT: Connect AC power cord to deliver power to the
digital receiver.
③0/12V: 0V or 12V output
④S/PDIF: Dolby digital output socket for the audio system.
⑤HDMI: Audio and video output socket for the high definition
television set.
⑥LAN: Local area network port.
⑦Two USB Slots: Connect to support devices.
6
Introduction

18
⑧Y/Cb/Cr: Component video output socket for the television set.
(green/blue/red)
⑨VIDEO: Composite video output socket for the television set.
(yellow)
⑩AUDIO L/R: Stereo audio output socket for the television set or the
audio system. (white/red)
⑪ANT IN: Connect with TV RF antenna.
⑫TV OUT: Connect with RF feed.
⑬SCART TV: Audio and video output socket for the television set.
⑭LNB OUT: Satellite broadcasting signal output socket.
⑮LNB IN: Satellite broadcasting signal input socket.
6
Introduction

19
1.4.2 Azbox Premium
①POWER SWITCH: Turn the digital receiver On and OFF.
②AC POWER INPUT: Connect AC power cord to deliver power to the
digital receiver.
③HDMI: Audio and video output socket for the high definition
television set.
④LAN: Local area network port.
⑤USB Slot: Connect to support devices.
⑥0/12V: 0V or 12V output
⑦S/PDIF: Dolby digital output socket for the audio system.
⑧Y/Cb/Cr: Component video output socket for the television set.
(green/blue/red)
⑨VIDEO: Composite video output socket for the television set.
(yellow)
⑩AUDIO L/R: Stereo audio output socket for the television set or the
audio system. (white/red)
6
Introduction

20
⑪ANT IN: Connect with TV RF antenna.
⑫TV OUT: Connect with RF feed.
⑬SCART TV: Audio and video output socket for the television set.
⑭LNB OUT: Satellite broadcasting signal output socket.
⑮LNB IN: Satellite broadcasting signal input socket.
Table 1.4: Connectors specifications
HDMI High definition video output
Left & right audio output
Dolby digital audio output
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
YCbCr Component video (YUV) output
S/PDIF Dolby digital audio output
USB 2.0 Host (5V, 500 mA)
6
Introduction
