1
CP-UM-5306E
Control Motor
Model ECM3000
User’s Manual
Thank you for purchasing an Azbil Corporation product.
This manual contains information for ensuring the correct
use of this product. This manual should be read by those who
design and maintain equipment that uses this product.
Be sure to keep this manual nearby for handy reference.
Please read“Terms and Conditions”from the following URL
before ordering and use.
https://www.azbil.com/products/factory/order.html
NOTICE
Be sure that the user receives this manual before the product is
used.
Copying or duplicating this user’s manual in part or in whole is
forbidden. The information and specifications in this manual are
subject to change without notice.
Considerable effort has been made to ensure that this manual is
free from inaccuracies and omissions. If you should find an error or
omission, please contact the azbil Group.
In no event is Azbil Corporation liable to anyone for any indirect,
special or consequential damages as a result of using this product.
SAFETY PRECAUTIONS
Safety precautions are for ensuring safe and correct use of
this product, and for preventing injury to the operator and
other people or damage to property. You must observe these
safety precautions. Also, be sure to read and understand the
contents of this user’s manual.
If this device is used in a manner not specified by the
manufacturer, its built-in protective functions may be
impaired.
lKey to symbols
WARNING
Warnings are indicated when mishandling this prod-
uct might result in death or serious injury to the user.
CAUTION
Cautions are indicated when mishandling this prod-
uct might result in minor injury to the user, or only
physical damage to this product.
WARNING
Before doing other wiring work, connect the frame
ground terminal to ground. The ground connection
should have a resistance of 100 or less. Afterwards
connect the other circuits.
Before removing, mounting, or wiring this device, be
sure to turn off the power to the device and all connected
devices. Failure to do so may cause electric shock.
Do not touch electrically charged parts such as the
power terminals. There is a risk of electric shock.
CAUTION
In order to use this product correctly, be sure to follow
this manual, the manuals for any associated devices
and equipment.
Installation, wiring, inspection, adjustment, maintenance,
etc., should be carried out only by trained and experi-
enced technicians who have knowledge and technical
skills related to this device and associated equipment.
Be sure to use this device correctly, within the ranges
specified in this user’s manual. Otherwise device fail-
ure or malfunction could result.
Avoid installing the device where it will be subject to
conditions such as the following. Otherwise device fail-
ure could result.
• Certain chemicals, corrosive gases, or salt
• High temperatures
• Prolonged vibration
• Direct sunlight
Do not stand on this device or use it as a step.
Doing so could damage the device, and if you lose your
footing you may be injured.
Wire this device properly according to indoor wiring
standards, technical standards, etc., using the types of
wire and wiring methods specified in the user’s manual.
Otherwise, device failure or malfunction could result.
The motor part of this device can reach a high tempera-
ture during operation. There is a risk of burns if the
cover is opened and the motor is touched immediately
after the power has been turned off.
While power is being supplied and during operation, do
not touch any movable part. Doing so may cause injury.
If equipment safety may be endangered by the failure
of this device, consider having a fail-safe design for the
system as a whole, with circuit breakers, duplexed con-
trollers, and limiter; or use a redundant design.
When discarding this device, dispose of it properly as
industrial waste, following local regulations.
WARNING SYMBOLS USED FOR THE PRODUCT
To reduce the risk of an electric shock. resulting in
personal injury, and to ensure safe operation of de-
vices, follow all safety notices in this document.
This symbol warns the user when there is a danger
of electric shock from accidental contact.
This symbol on the motor warns the user that there
is a danger of burns from accidental contact.
UNPACKING
Check the following items when removing the ECM3000 from its
package:
Name Part No. Q’ty Remarks
• Upset head bolt with captive washer
395-106-25A 4 M6 size
• label [0],[100] 83165267-001 1
0(fully closed) and 100(fully open)
• User’s Manual CP-UM-5306JE 1 This Manual
OVERVIEW
ECM3000 control motors are designed to control various types of
industrial equipment.
There are two types of strokes: a 90° stroke for burner control and
a 160° stroke for valve control using hot and cold water, steam,
etc. There are three types of control signal inputs: relay contact,
4–20mADC, and potentiometer (nominal 135Ω resistance input).
24, 100, and 200VAC models are available. Flexible 85–264VAC
powered models are also available for 4–20mADC signal input
models. The included bracket can be used for replacement of an
older Azbil Corporation motor with this one.

2
MODEL SELECTION TABLE
: Applicable —: Not applicable
Model No. Power Signal name Rotation
angle
Rotation time Output
torque
Power
consumption Notes UL*1*8CE*1*9
50Hz 60Hz
ECM3000D01 _ _ 24 V AC Relay contacts 90° 39 s 33 s
12.5 N･m
9 VA*4ON/OFF operation  
ECM3000D11 _ _ 100 V AC — —
ECM3000D21 _ _ 200 V AC — —
ECM3000E01 _ _ 24 V AC Potentiometer Position proportional
operation
 
ECM3000F01 _ _ 24 V AC Relay contacts  
ECM3000F11 _ _ 100 V AC — —
ECM3000F21 _ _ 200 V AC — —
ECM3000G01 _ _*224 V AC 4～20 mA DC  
ECM3000G91 _ _*285～264 V AC 39 s 14 W*5— —
ECM3000F03 _ _ 24 V AC Relay contacts 20 s 16 s 6 N･m14 VA High-speed motor
model
Position proportional
operation
—
ECM3000D020 _ 24 V AC Relay contacts 160° 69 s 58 s
12.5 N･m
9 VA*4ON/OFF operation  
ECM3000E020 _ Potentiometer Position proportional
operation
 
ECM3000F020 _ Relay contacts  
ECM3000F120 _ 100 V AC — —
ECM3000F220 _ 200 V AC — —
ECM3000G02 _ _*2*724 V AC 4～20 mA DC  
ECM3000G92 _ _*2*785～264 V AC 72 s 14 W*5— —
ECM3000F040 _ 24 V AC Relay contacts 35 s 29 s 6 N･m14 VA High-speed motor
model
Position proportional
operation
—
(Example) ECM3000D01_ _
0 (zero): not GB-compliant, C: GB-compliant
0 (zero): No options*3
3: 4 built-in auxiliary switches (for standard model. Contact current: 100 mA to 5 A [resistive load], 100 mA to 3 A [inductive
load])*7*8
4: 2 built-in auxiliary switches (for standard model. Contact current: 100 mA to 5 A [resistive load], 100 mA to 3 A [in-
ductive load]) with forced open/close function*6*8
5: 4 built-in auxiliary switches (for low-current model. Contact current: 1 to 100 mA [inductive load, including inrush
current])*7*8
6: 2 built-in auxiliary switches (for low-current model. Contact current: 1 to 100 mA [inductive load, including inrush
current]) with forced open/close function*6*8
*1. GB-compliant models are not compliant with UL or CE standards.
*2. Direct/reverse operation can be switched and zero point, span, and deadband can be adjusted. The device is adjusted at the factory with the direct opera-
tion setting. Readjustment is essential if the type of operation is switched.
*3. An extension unit can be mounted.
*4. Power consumption of the following models is 11 VA. ECM3000G014_, ECM3000G016_, ECM3000G024_, ECM3000G026_
*5. Power consumption of the following models is 15 W. ECM3000G914_, ECM3000G916_, ECM3000G924_, ECM3000G926_
*6. Selectable only for ECM3000G01_ _, ECM3000G91_ _, ECM3000G02_ _, ECM3000G92_ _.
*7. 4 built-in auxiliary switches models can not be selected.
*8. Use a class 2 power supplies with double or reinforced isolation from the MAINS power supply for the power supply and auxiliary switches.
*9. Use a limited-energy circuit (EN61010-1) with double or reinforced isolation from the MAINS power supply for the power supply and auxiliary switches.
Handling Precautions
• Use high-speed motor models at a duty ratio (operating ratio) of 40% or less.
• Do not connect the ECM3000F to a mechanical balancing relay such as the R9107A or R927C. Doing so may apply excessive voltage to
the potentiometer, resulting in device failure.
• Be sure to connect non-voltage contacts to terminals S, CONT, CW, and CCW of an ECM3000 model with forced open/close function.
In the case of the M744 and M7284, 24VAC may be applied to the S, CONT, CW, and CCW terminals.
If the ECM3000 is replaced with a forced open/close function model, do not apply 24VAC to any terminal. Doing so will damage the
circuit.
• For the ECM3000F and ECM3000D, leakage current from the snubber circuit protecting the motor drive element (relay or SSR) must
be within the following.
• 100VAC: 0.8mA (RMS) max.
• 200VAC: 0.4mA (RMS) max.

3
NAMES OF PARTS
Control Motor
ECM3000E9110
*123103800150*
Handling Precautions
• The default setting for the output shaft is 0% opening.
• L: counterclockwise (CCW) rotation
R: clockwise (CW) rotation
CW: Clockwise CCW: Counterclockwise
AB
0 100
CD
7 6 54 3 2 1
lTerminal block
For 4 built-in auxiliary switches
7654321For the power supply and signals
D3 D2 D1 C3 C2 C1 For auxiliary switches A to D
B3 B2 B1 A3 A2 A1
2 built-in auxiliary switches with forced open/close function
7654321For the power supply and signals
S CONT CW CCW
Not
used Not used
Forced open/close function
Auxiliary switches A and B
B3 B2 B1 A3 A2 A1
MOUNTING
Installation location
To install the ECM 3000, use the supplied bolt or equivalent (M6
size, with spring washer and flat washer). Use a nut (not supplied)
if necessary.
Bolt tightening torque: 4.1 to 5.2 N·m
Do not install the device in locations prohibited in the SAFETY
PRECAUTIONS section. For outdoor use, use a protective cover
or the like.
Handling Precautions
• Prevent foreign matter or moisture from entering the
device from the output shaft.
• When the motor is used with a control valve in an appli-
cation such as fluid control, if the control valve is located
higher than the motor, water drops may enter the motor
by running along the valve.
Mounting orientation
l90° stroke model
This model can be mounted with any desired orientation.
However, take measures to prevent water and foreign matter
from entering the output shaft.
l160° stroke model
This device can be mounted with the output shaft horizontal or
facing downwards. To prevent water drops from entering the
device, do not mount with the output shaft facing upward.
Incorrect Incorrect Incorrect
To ensure splash-proofing
Close the cover securely so that the packing and cable are not
pinched. Make the knockout hole watertight after wiring.
• Use a waterproof connector for the cables running from the
motor. Recommended waterproof connector: refer to the
sealing item of specifications
• If a conduit is used, use a waterproof precut tube or the like
to ensure waterproofing.
WIRING
Symbols used on the device:
Symbol Meaning
AC power supply
DC signal
Functional ground terminal (not a protevtive ground terminal)
CAUTION
Make sure that the frame ground terminal is properly
grounded (100Ω max.) using at least 2mm2wire and
M4 crimp terminals with insulating sleeves.
During wiring, open a knockout hole (22mm dia.) on either side,
and pull out the cables from the hole. For wiring to the terminals,
follow the terminal label indicated on the terminal block, and be sure
to use M3.5 crimp terminals with insulating sleeves.
Handling Precautions
• To open a knockout hole, using a flat-head screwdriver, set
its tip on the outer edge of the knockout plug, and lightly
tap the screwdriver all the way around this edge until the
knockout is removed.
• Do not allow any fragments to enter the actuator when the
knockout hole is opened.
• Do not use unused terminals on the device as relay
terminals.
• Be sure to attach the cover after wiring is complete.
• Do not run the signal wires in the same conduit as power lines.
• Keep power cables at least 50cm away from signal cables.
• If the power and signal cables must run together in the
same conduit, use JCS4364-compliant instrument cable
for signals.
• Use the appropriate supply voltage according to the
model No.
• Be sure to install a circuit breaker (8A max) for the power
source.
• During motor operation, in order to stop hunting (which
causes the controller’s internal relay to turn ON and OFF
excessively), change the parameters of the controller.
For example, set the derivative time (D) to 0 seconds, set
a wider dead band, etc.
If the internal relay operates excessively, the life of the
motor or the host controller relay will be shortened.
Main unit
Resin cover: protects the inside of the device.
Cover retaining screw:
Secures the cover. 3 screws are used.
The recommended tightening torque
is 0.8 to 1.0N·m.
Label [0],[100] (90° stroke models only):
When viewing the output shaft, “R”
indicates the valve opening direction
and “L” indicates the valve closing
direction.
Output shaft:
Moves the actuator via the linkage.
Pointer (90° stroke models only)
Mounting hole:
Located in the mounting bracket.
Bracket:
Used to mount the
control motor.
Knockout hole:
Used to run the wires out.
There is one hole each on the left
and right sides.
Frame ground terminal (use an M4 round
terminal lug for wiring)
Ground wire (E and G models only)
Terminal block:
Used for wiring. M3.5 screws are used.
Auxiliary switches (A, B, C, and D, or A and B):
Switches may be built into the motor de-
pending on the model.
Adjustment section of 4–20mADC input models:
Direct/reverse action can be switched, and zero/span
and dead band are adjustable.

4
lCables
Except for 24 V AC models, use a power cable rated at 600 V or
more and 70 °C or higher.
For 24 V AC models, use a power cable rated at 60 V or more
and 70 °C or higher.
The auxiliary switch cable should be rated at a voltage sufficient
for the operating voltage and rated at 70 °C or higher.
For other signal lines, use cables rated at 60 V or more and
70 °C or higher.
lRelay contact input (ECM3000D and ECM3000F)
1 2
M
L R G Y T
3 4 5 6 7
Not used
*1
*2 *2 *2
L: counterclockwise (CCW) rotation
R: clockwise (CW) rotation
CW: Clockwise CCW: Counterclockwise
*1. The supply voltage varies depending on the model.
MODEL SELECTION TABLE (page 2 )
*2. Terminals 4–6 of the ECM3000D are not used.
Handling Precautions
• The default setting for the output shaft is 0% opening.
lPotentiometer input (135) (ECM3000E)
1 2
W
24 V AC
F.G .
B R
RL
34567
*
Not used
L: counterclockwise (CCW) rotation
R: clockwise (CW) rotation
* For details on TY9000, etc., contact the azbil Group.
l4–20mA input (ECM3000G)
1 2
*4–20 mA DC
F. G.
+ −
34567
Not used
* The supply voltage varies depending on the model.
MODEL SELECTION TABLE (page 2 )
Note
• The 4–20mA input circuit is isolated from the power circuit
inside the device.
Handling Precautions
• During motor operation, in order to stop hunting (which
causes the controller’s internal relay to turn ON and OFF
excessively), change the parameters of the controller. For
example, set the derivative time (D) to 0 seconds, set a
wider dead band, etc.
If the internal relay operates excessively, the life of the
motor or the host controller relay will be shortened.
If frequent operation cannot be avoided, install an auxiliary
relay between the motor and controller.
• The feedback potentiometer of the ECM3000F is a com-
bination resistor consisting of two different resistors con-
nected in parallel.
Accordingly, the angle of rotation of the ECM3000F is pro-
portional not to the resistance of the feedback potentiom-
eter but to the voltage ratio between the potentiometer
terminals (T–G voltage or Y–G voltage).
The resistance of the feedback potentiometer cannot be
used to measure the angle of the motor rotation.
lAuxiliary switch (up to 4)
A1 A2 A3
R
COM L
L: counterclockwise (CCW) rotation
R: clockwise (CW) rotation
Note: The internal connections of switches B, C,
and D are the same as those of switch A.
Models with forced open/close function
have only auxiliary switches A and B.
lForced open/close input
(a) Forced fully closed (b) Forced fully open (c) Automatic operation
CCW CW CONT S
CCW CW CONT S
CCW CW CONT S
Handling Precautions
• Before shipment, terminals CONT and S are connected.
Disconnect these terminals if operation with the valve
forced fully open (or closed) is desired.
• Only one of terminals CCW, CW, and CONT can be con-
nected to terminal S. Multiple terminals cannot be con-
nected to terminal S.
• Be sure to connect non-voltage contacts to terminal S,
CONT, CW, or CCW of an ECM3000 model with a forced
open/close function. If 24VAC is applied, the circuits will
fail.
• If the same signal is input to multiple control motors that
are connected in parallel, faulty operation may result.
The same contact signal cannot synchronize multiple
ECM3000 motors.
lIf the ECM3000E is used to fully open/close the valve
4
5
6
1
2
W
XO
W
B
R
Azbil Corporation's
L91 pressure regulator
Transformer
Power supply
ECM3000E
(resistance input of nominal 135 Ω)
Switch for
full open
XO XC
100 % when XO is open
0 % when XC is open
Switch for
full close
XC B
R
T1
T2
Note: Recommended contact rating for XO and XC
Material: Gold plating
Rated voltage: 15V DC min.
Rated current: 100mA

5
INSPECTION AND MAINTENANCE
Inspection Method
Item Frequency Inspection method
Visual
inspection
6 months • Check for loose screws.
• Check for damage to the motor.
Operation
state
6 months • Check for unusual noise or vibration.
• Check that the motor operation is normal.
Daily
inspection
As needed • Check for unusual noise or vibration.
• Check that the motor operation is normal.
• Check hunting.
Maintenance method
Cleaning: If the module is dirty, wipe it with a soft, dry cloth. Do
not use a detergent or an organic solvent like thinner or benzene.
Check the motor operation visually every six months. If a prob-
lem is found, take corrective actions.
Problem Check item Corrective action
• The motor does
not work.
• Wiring status and
disconnection.
• Supply power voltage.
• Check the wiring.
• Check the supply
power voltage.
• The motor rotation
stops halfway.
• Check for loose terminal
screws.
• Tighten terminal
screws.
• Auxiliary switches
do not work.*1
• Check the auxiliary
switch cam.
• Wiring status and
disconnection.
• Set it up again.
• Check the wiring.
• The feedback po-
tentiometer does
not work.*2
• Check the resistance.
• Wiring status and
disconnection.
• Check for loose terminal
screws.
• Set it up again.
• Check the wiring.
• Tighten terminal
screws.
• Decreased control
sensitivity.
• Deceased motor
torque.
• Wiring status and
disconnection.
• Check for loose terminal
screws.
• Supply power voltage.
• Check the wiring.
• Tighten terminal
screws.
• Check the supply
power voltage.
*1. For models with auxiliary switch
*2. For models with feedback potentiometer
AUXILIARY SWITCH OPTIONAL
Adjustment
lOperating point
An auxiliary switch can turn on if the arrow on the setting dial
(A, B, C, or D) is aligned with the mark.
The operating point can be set in a range of 5–95% opening.
The repeatability is within ±3%.
The differential is approximately 2%.
After the settings are changed, make sure that the switch oper-
ates before the motor reaches the fully-open and fully-closed
positions.
lOperation type
If the actual opening is greater than the set opening, connec-
tion between terminals 1 and 2 (Common–NO) will be electri-
cally continuous, but connection between terminals 1 and 3
(Common–NC) will not be.
The figure below shows an example in which, at 50% opening,
connection between terminals 1 and 2 is ON while connection
between terminals 1 and 3 is OFF.
Between terminals 1 and 2
OFF ON
ON OFF
90 %
Approx. 2 % differential
50 %
(example)
10 %
Between terminals 1 and 3
Opening
lHow to set the operating point
(1) Operate the motor electrically until the output shaft travels
to the desired angle that turns on the switch. Then, align
the arrow on the setting dial with the mark using a flat-
head screwdriver.
(2) Operate the motor electrically to rotate the output shaft
near the set travel position, and check that the switch
works normally.
The figure below shows an example of setting at 50% opening.
NC
NO
COM
A1
A2
A3
B1
B2
B3
C1
C2
C3
D1
D2
D3
Auxiliary switch: Sw.D
(variable 5–95 %)
Auxiliary switch: Sw.C
(variable 5–95 %)
Auxiliary switch: Sw.B
(variable 5–95 %)
Auxiliary switch: Sw.A
(variable 5–95 %)
Terminal block
NC
NO
COM
NC
NO
COM
NC
NO
COM
Terminal block A
Setting dial
Terminal block B
Note
• Use a 6mm flat-head screwdriver for the slotted-head screws
(JIS B 4609).

6
Installation and removal
lInstallation
(1) Turn OFF the power.
(2) Loosen the 3 screws and remove the cover. Keep the re-
moved parts in a safe place.
Screws
(3) Rotate part B of the chassis upward and remove it. Fold
part A of the terminal block outside and remove it.
Part A of the
terminal block
Part B of the
chassis
(4) Insert the shaft of the auxiliary switch into the actuator
shaft. (The triangular arrow on the 0–100 dial should be
positioned within the scale.)
(5) Turn the auxiliary switch unit counterclockwise until it
clicks.
(6) Align the holes on the terminal block bracket with the
holes on the chassis.
(7) Insert and tighten the 2 screws.
(5)
(4)
(7)
(6)
(6)
(7)
lRemoval
(1) Remove the 2 screws.
(2) Remove the terminal block. The bracket is combined with
the terminal block.
(3) Press and hold the release button.
(4) Turn the auxiliary switch unit clockwise.
(5) Remove the unit by pulling it up.
(3)
(4)
(5)
(1)
(1)
(2)
MOUNTING ON A BUTTERFLY VALVE V51E
If this device is mounted on the V51E, install the base kit
(83165292-001, sold separately) between the V51E and the device.
Device
Base kit
V51E

7
SPECIFICATIONS
Specifications
Item Specifications
Operation mode (fixed
by the model)
ON-OFF or position proportioning
Input signal Relay contact, 4–20mADC, potentiometer
Feedback
potentiometer
Reference resistance for selection: 135 (com-
bination resistor*1)
Max. applied voltage: 5VDC
Input impedance (with
4–20mADC input)
125max. (at 20mA) (45  of signal reception
resistor + resistance of overcurrent protection
circuit)
Angle of rotation
(fixed by the model)
90° or 160°
Rotation
time
90° stroke
model
39/33 s Relay contact, 50/60Hz without load
39 s Supply power: 85–264VAC, 50/60Hz
without load
20/16 s Relay contact, 50/60Hz, without load,
high-speed motor model
160° stroke
model
69/58 s Relay contact, 50/60Hz without load
72 s Supply power: 85–264VAC, no load,
50/60Hz without load
35/29 s Relay contact, 50/60Hz, without load,
high-speed motor
Output torque 12.5N·m (high-speed motor: 6N·m)
Supply power voltage
(fixed by the model)
24VAC ±15%, 50/60Hz
100VAC ±10%, 50/60Hz
200VAC ±10%, 50/60Hz
85–264VAC, 50/60 Hz
Power consumption
(during operation) MODEL SELECTION TABLE (page 2 )
Standard operating
conditions
23±2°C, 50 ±10%RH
Ambient temperature −20 to +60°C
Ambient humidity 5–95%RH (without condensation)
Vibration resistance 4.9m/s2
Insulation resistance 5M min. with a 500VDC megger between
housing and power supply, signal terminals, or
forced open/close input terminals
20M min. with a 500VDC megger between
housing and auxiliary switches
Dielectric strength 500VAC for 60 s (24VAC models), 1200VAC
for 60s (100VAC models), 1500VAC for 60s
(200VAC and 85–264VAC models) between
housing and power & signal terminals
1500VAC for 60s between housing and auxil-
iary switch terminals
500VAC for 60s (24VAC models), 1200VAC
for 60s (100VAC models), 1500VAC for 60s
(200VAC and 85–264VAC models) between
housing and power & forced open/close input
terminals
Default positions of
auxiliary switches*2
A and C: at 9° ±5°
B and D: at 81°±5°
Forced open/close
input
Non-voltage contact
Contact rating: 15VDCmin., 100mAmin,
Contact resistance: 10Ωmax. (at 1mADC)
Sealing Equivalent to IP54 when using the following
waterproof connector.
However, not UL-certified.
Model no. : 83104346-003
Lock nut tightening torque : 1.0 Nm
Tightening cap (cable) tightening torque : 1.5 Nm
Applicable cable diameter : 7 to 9 mm
Material Case: Die-cast aluminum
Cover: Glass-containing polycarbonate resin
Bracket: Steel
Installation location Indoors
Altitude 2000 m max.
Pollution degree 3
Mass Approx. 3kg
Item Specifications
Terminal screw tight-
ening torque and wire
size
For power and signal terminals:
0.8 N·m
14 to 18 AWG (0.75 to 2.0 mm2)
For auxiliary switches and forced open/close
function:
0.8 to 1.2 N·m
14 to 18 AWG (0.75 to 2.0 mm2)
Standards
compliance*3
CE: EN 55011, EN 61000-6-2 *4
UL: UL 61010-1
GB: GB 30439.8
*1. Feedback potentiometer output specifications
The feedback potentiometer of the ECM3000F has the following equiv-
alent circuit. (See the diagram of parallel resistors below.)
In the controller, the resistance of the feedback potentiometer is con-
verted to voltage, which indicates the motor opening.
In other words, the angle of rotation is not calculated directly from
the resistance of the potentiometer. But if a combination resistor
(1k+180) is used, the resistance can be close to 135, which has
been conventionally used in the industry.
The following are Azbil Corporation’s controllers compatible with
this device: SDC35/36, SDC45/46, the SDC40 series, DMC10, Network
Instrumentation Modules, RN748.
For other products, please contact the azbil Group.
G Y T
Clockwise
(open)
Counterclockwise
(close)
4 5 6
P
R
P: 1 kΩ
R: 180 Ω
ECM3000F
Note
• In old models, such as the M904, because the feedback
potentiometer uses a single resistor, if the resistance of the
potentiometer is measured (between terminals G and T)
with a continuity tester, the motor opening can be deduced.
However, the output part of the feedback potentiometer of this
device consists of multiple resistors. Thus, unlike old models,
its resistance is not proportional to the motor opening.
The controller calculates the motor opening from the voltage
between terminals G and T.
The voltage between terminals G and T is linear to the motor
opening, but if the resistance between these terminals is mea-
sured, as was possible for older models, the result will not be
linear to the motor opening. Instead, the relationship can be
graphed as a parabola, as shown below.
0 10 20 30 40 50 60 70 80 90 100
350
300
250
200
150
100
50
0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
Opening (%)
Resistance between terminals G and T (Ω)
Voltage between terminals G and T (V)
Resistance Voltage
*2. For 90° stroke models with auxiliary switches
*3. Varies depending on the model.
MODEL SELECTION TABLE (page 2 )
*4. During EMC testing, the reading may fluctuate by ±5%FS

8
1-12-2 Kawana, Fujisawa
Kanagawa 251-8522 Japan
URL: https://www.azbil.com
(11)
Specifications are subject to change without notice.
© 2003–2019 Azbil Corporation. All Rights Reserved.
1st edition: Dec. 2003 (E)
10th edition: July 2019 (V)
Optional parts (sold separately)
Name Model No.
Crank arm N-3128
Damper arm J-26026G-ARM
Ball joint J-27518-JOINT
Valve linkage*1 Q455C/D
Damper linkage Q605A/D/E
V51 base kit 83165292-001
Waterproof connector 83104346-003
24 V AC power transformer AT72-J1
Extension
unit*2
4 built-in auxiliary
switches
83174065-002
(Contact current: 100 mA to 5 A [resistive
load], 100 mA to 3 A [inductive load])
83174065-102
(Contact current: 1 to 100 mA [inductive
load, including inrush current])
83174065-003*3
(Contact current: 100 mA to 5 A [resistive
load], 100 mA to 3 A [inductive load])
83174065-103*3
(Contact current: 1 to 100 mA [inductive
load, including inrush current])
Auxiliary potentiom-
eter for 90° stroke
83165272-001
Auxiliary potentiom-
eter for 160° stroke
83165272-002
*1. Can be attached to 160° stroke models.
*2. Only one type of extension unit can be mounted on the model without
internal auxiliary switch.
*3. For compliance with GB standards, use this model.
Handling Precautions
• The output of the auxiliary potentiometer cannot be con-
nected to an M904E Modutrol motor and to an ECM3000E
motor. Use the potentiometer for output to an external
valve-opening indicator or the like.
lAuxiliary switch
Item Specifications
Auxiliary switches*4 (or 2)
Contact rating Standard model.: 250 V AC, 100 mA to 5 A
(resistive load), 100 mA to 3
A (inductive load)
Low-current model.: 250 V AC, 1 to 100 mA
(inductive load, including
inrush current)
Note: See Model Selection Table notes *8and *9.
Service life Standard model: 50,000 cycles or more.
Low-current model: 200,000 cycles or more.
Note: Service life figures assume a resistive load.
Default positions A and C: at 9°±5°
B and D: at 81°±5°
Setting range 5–95% opening
Terminals (4 or 2) 1 Common
2 NO (Normally Open)
3 NC (Normally Closed)
* Models with forced open/close function have only auxiliary switches
A and B.
lAuxiliary potentiometer
Total resistance 1k ±10%
Accuracy ±8%FS
Hysteresis ±5%FS
Terminal Y voltage change in
relation to the applied voltage
Continuous change between
14±6% (0% opening) and 86±6%
(100% opening)
Max. applied voltage 5VDC
External dimensions
Unit: mm
Angle of rotation A B C
90° stroke model 32.5 161.6 22
160° stroke model 20.5 149.6 12
2
139
185
154
85 124
111
104.516.5 5
128.5
B
C*
A
104
7
12
7 ϕ
* C is the length of the output shaft (9.5mm square).
l0% opening position of the output shaft (when viewing
the output shaft)
Closed
position
Open
position
45°
9.5 square
90°
2.4±0.1
4.5±0.1
1.2±0.1
11.8 dia.
0
−0.1
−0
−0.05
10°
Output shaft
Key groove
Closed position
Open position
160°
90° stroke model 160° stroke model
Handling Precautions
• The length of the output shaft varies depending on the
model. Only 90° stroke models have a pointer.
基于SJ/T11364-2014 「电子电气产品有害物质限制使用标识要求」的表示式样
部件名称
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
电路板组件 ×○ ○ ○ ○ ○
本体 ×○ ○ ○ ○ ○
产品中有害物质的名称及含量
本表格依据SJ/T 11364 的规定编制。
○ : 表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572规定的限量要求以下。
× : 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。
